ComAp InteliCompact NT Reference Manual page 216

Setpoint: AI2Calibration
Group Sensors Spec
Range [units] Limits and units depend on analog input configuration
Related All
applications
This setpoint can be used to "calibrate" the controller analog input 2, i.e. shift
Description
the measured value on the analog input with a constant. The setpoint
(constant) is always added to the measured analog value.
N :
OTE
It is recommended to perform the calibration under operating conditions, i.e.
perform a coolant temperature sensor calibration when the engine is warm,
not cold.
Setpoint: AI3Calibration
Group Sensors Spec
Range [units] Limits and units depend on analog input configuration
Related All
applications
This setpoint can be used to "calibrate" the controller analog input 3, i.e. shift
Description
the measured value on the analog input with a constant. The setpoint
(constant) is always added to the measured analog value.
N :
OTE
It is recommended to perform the calibration under operating conditions, i.e.
perform a coolant temperature sensor calibration when the engine is warm,
not cold.
Setpoint: IOM AI1 Calibr
Group Sensors Spec
Range [units] Limits and units depend on analog input configuration
Related All
applications
This setpoint can be used to "calibrate" the analog input 1 of the extension
Description
module IG-IOM or IGS-PTM, i.e. shift the measured value on the analog
input with a constant. The setpoint (constant) is always added to the
measured analog value.
N :
OTE
It is recommended to perform the calibration under operating conditions, i.e.
perform a coolant temperature sensor calibration when the engine is warm,
not cold.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
216
