InteliDrive Lite
®
Modular Engine Controller
SW version 1.9, August 2015
Reference Guide
Copyright ©2015 ComAp a.s.
ComAp a.s.
Kundratka 17, 180 00 Praha 8, Czech Republic
Tel: +420 246 012 111, Fax: +420 266 316 647
E-mail:info@comap.cz, www.comap.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InteliDrive Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ComAp InteliDrive Lite

Summary of Contents for ComAp InteliDrive Lite

  • Page 1 InteliDrive Lite ® Modular Engine Controller SW version 1.9, August 2015 Reference Guide Copyright ©2015 ComAp a.s. ComAp a.s. Kundratka 17, 180 00 Praha 8, Czech Republic Tel: +420 246 012 111, Fax: +420 266 316 647 E-mail:info@comap.cz, www.comap.cz...

  • Page 2: Table Of Contents

    Table of controller analog inputs..................37 4.2.2 Table of analog inputs options ..................38 4.2.3 Connection of InteliDrive Lite analog inputs ..............40 4.2.4 Current output transducers ....................41 4.2.5 Analog input extension measurement (0 - 70V, 4 - 20mA) ..........41 Binary inputs and outputs ......................
  • Page 3 How to list History records? ...................... 51 MEASUREMENT screens description ..................51 5.9.1 Main measure screen ...................... 51 5.9.2 InteliDrive Lite Analog inputs screens ................51 5.9.3 IL-NT-AIO Analog inputs screen ..................52 5.9.4 InteliDrive Lite Binary inputs .................... 52 5.9.5...
  • Page 4 D+ function [ENABLED, CHRGFAIL, DISABLED] ............82 7.4.17 ECU Control [ENABLED, DISABLED] ................82 7.4.18 ECU SpeedAdj [RPM] ....................82 7.4.19 RetToSpeedAdj [DISABLED, ENABLED] ..............82 7.4.20 MinSpeedLim [RPM] ...................... 82 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 5 AIN3 Level 1 [ ] ....................... 95 7.7.16 AIN3 Level 2 [ ] ....................... 95 7.7.17 AIN3 Del [s] ........................95 7.7.18 Batt overvolt [V]....................... 96 7.7.19 Batt undervolt [V] ......................96 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 6 Date/Time ..........................106 7.8.1 Time stamp per [min] ....................106 7.8.2 SummerTimeMod [DISABLED, WINTER, SUMMER, WINTER-S, SUMMER-S] ....106 7.8.3 Time [HH:MM:SS] ...................... 107 7.8.4 Date [DD:MM:YYYY] ....................107 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 7 TelNo/Addr Ch1, 2 […] ....................111 7.11.3 Values ............................113 Binary input functions ....................... 115 Binary inputs InteliDrive Lite - default configuration ............... 115 Configuration of binary inputs ....................115 Binary inputs list ........................116 9.3.1 Not used ......................... 116 9.3.2...
  • Page 8 9.3.30 Prot Test ........................120 Binary output functions ....................... 121 10.1 Binary outputs InteliDrive Lite - default ................... 121 10.2 Binary outputs – list ........................ 121 10.2.1 Not used ......................... 121 10.2.2 Starter ..........................121 10.2.3 Fuel solenoid........................121 10.2.4 Stop solenoid .........................
  • Page 9 14.19.3 Dimensions and weight ....................148 14.19.4 Horn output ........................148 Language support ........................ 149 Appendix ..................Error! Bookmark not defined. 16.1 Table of setpoints ............... Error! Bookmark not defined. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 10 16.2 Table of values ................Error! Bookmark not defined. 16.3 Table of binary input functions ........... Error! Bookmark not defined. 16.4 Table of binary output functions ..........Error! Bookmark not defined. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 11: Document Information

    1.9.0 13.8.2015 Note: ComAp believes that all information provided herein is correct and reliable and reserves the right to update at any time. ComAp does not assume any responsibility for its use unless otherwise expressly undertaken. InteliDrive Lite, SW version 1.9...

  • Page 12: Clarification Of Notation

    EC Low Voltage Directive No: 73/23 / EEC and EC Electromagnetic Compatibility Directive 89/336 / EEC based on its design and type, as brought into circulation by us. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 13: System Overview

    This manual is intended for operators of engines, for engine control panel builders or for everybody who is concerned with installation, operation and maintenance of the engine applications. Warnings InteliDrive Lite controller can be remotely controlled. In case of the work on the engine check, that nobody can remotely start the engine. To be sure:...

  • Page 14: Configurability And Monitoring

    InteliDrive Lite controllers are equipped with a powerful graphic display showing icons, symbols and bar-graphs for intuitive operation, which sets, together with high functionality, new standards in engine controls. InteliDrive Lite provides gas engine support without ventilation. Controller supports WebSupervisor system. This system enables engine fleet and assets management as well as pure monitoring.
  • Page 15 FITTED IN THE CONTROLLER YOU WANT TO REACH ACCESS CODE 3. You will see the Control window and you can continue with configuration of Setpoint, inputs, outputs etc. DIT CONTROL WINDOW InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 16: Open Connection From Web Browser

    InteliMonitor Reference Guide and InteliDrive Communication Guide. 2.4.2 Open connection from web browser It is possible to connect from a web browser to InteliDrive Lite controllers, mounted with IB-Lite module (or IB-NT with specific conditions) and connected to internet. 1. Open web browser 2.

  • Page 17: Open Connection From Winscope

    You can try the WebServer from ComAp webpage. The access code is 0. WebSupervisor is possible to use as a control and monitor tool. For access is necessary to be registered. Connection setting and other information you can find in the WebSupervisor Reference Guide.

  • Page 18: Applications Overview

    Basic wiring scheme for single engine, all engine data are transferred from ECU via CAN J1939 interface in example below. The extension IGL-RA15 modules can be connected to CAN bus together with ECU. PPLICATION ESCRIPTION InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 19: Installation

    ID-FLX-Lite is distributed as ID-FLX-Lite-x.y.iwe package and it is compatible with the PC tool LiteEdit x.y.z and ECU list-x.y, where x, y, z are numbers of software version. Find installation files on ComAp web. Version of published files on the webpage are compatible each other.

  • Page 20: Components

    8x BIN or BOUT Optional plug-in External modules IL-NT RD Remote display Optional external IGL-RA15 Remote annunciator Optional external IB-NT Communication module (3G, Ethernet) Optional external Terminal diagram and dimension InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 21 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 22: Extension Plug-In Modules

    Sensor/gauge curve and value are configured in LiteEdit PC tool. Any analog value from the controller may be configured to the outputs. All outputs operate as PWM signal at 1200Hz. Examples of default analog output curves: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 23 Example of wiring for Dacon gauges and IL-NT-AOUT8: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 24: Il-Nt Aio

    0 – 20 mA (max 22mA) max 100 Ohm load Iout 0 – 4,5V (max 10mA) Uout PWM 5V / 15mA / 500 Hz Not used Do not connect! InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 25: Il-Nt Io1

    IL-NT IO1 is optional plug-in card. Through this card controller can drive up to 4 propotional valves and to use 4 additional binary inputs. The 0V (GND) terminal is internally wired with battery minus internally, the 12-24V (+Ubat) terminal is wired to battery plus power supply of InteliDrive Lite controller.

  • Page 26: Communication Modules

    Communication modules 3.5.1 IL-NT RS232 IL-NT RS232 is optional plug-in card, which enables InteliDrive Lite controller for RS232 serial communication. This is required for computer or ModBus connection. The card has to be inserted into the expansion “Communication module” slot back on the controller, similarly to extension modules.

  • Page 27: Il-Nt Rs232-485

    3.5.2 IL-NT RS232-485 IL-NT RS232-485 is optional plug-in card, which enables InteliDrive Lite controller RS232 and RS485 serial communication. This is required for computer or Modbus connection. The IL-NT RS232-485 is a dual port module with RS232 and RS485 interfaces at independent COM channels. The RS232 is connected to COM1 and RS485 to COM2.

  • Page 28: Ib-Lite

    USB hubs, it can be recognized as new hardware and the drivers are installed again with different number of the virtual serial port. AUTION Use shielded USB cable only! (ComAp order code: USB-LINK CABLE 1.8m) 3.5.4 IB-Lite IB-Lite is a optional plug-in card with Ethernet 10/100 Mbps interface in RJ45 connector. The card is...

  • Page 29: Il-Nt Gprs

    • Settings MODEM = module works as standard GSM modem enabling CSD (Circuit Switch Data) connection to controller with LiteEdit or other ComAp PC SW and sending alarm SMSes. Module is usually used for connection to remote monitoring and controlling system WebSupervisor http://websupervisor.comap.cz...

  • Page 30: Remote Modules

    IL-NT RD is remote display software for a controller. Remote display provides the same control and monitoring functions as controller itself. Remote display for InteliDrive controllers uses standard InteliDrive Lite controller with Remote display software. No further programing of the display is required – unit is self configurable from the main controller.
  • Page 31 LiteEdit software (password is required). IL-NT-RD Wiring IL-NT-RD can be connected to InteliDrive Lite controller via RS232 or RS485 communication line. It is possible to connect only up to two remote displays to one master controller, if they are using different communication COMs.

  • Page 32: Igl-Ra15

    LiteEdit. If IGL-RA15 remote announciator is not communicating with a controller via CAN bus, it activates a warning. See the documentation of IGL-RA15 for the technical description. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 33: Ib-Nt

    3.6.3 IB-NT Internet bridge allows different type of communication and multiple controllers communication. Single InteliDrive Lite controller is possible to connect via serial line RS232. For multiple controllers connection is necessary to use RS485 communication port. IB-NT offers direct, internet, AirGate and cellular network type of communication.

  • Page 34: Putting It Into Operation

    Analog and binary inputs should use shielded cables, especially when length >3m. During the configuration of controller or setpoints changes is required a password to the controller. The default password from ComAp is “0”. 4.1.1 Grounding To ensure proper function: Use cable min.

  • Page 35: Power Supply Fusing

    When there is a potential risk the controller being subjected to conditions outside its capabilities, an outside protection devise should be used. The InteliDrive Lite controller should be grounded properly in order to protect against lighting strikes!! The maximum allowable current through the controller’s negative terminal is 4A (this is dependent on binary output load).

  • Page 36: Binary Output Protections

     Check ground connection from pick-up to controllers, eventually disconnect ground connection to one of them  Galvanic separate InteliDrive Lite RPM input using ComAp separation transformer RPM-ISO (1:1)  Use separate pick-up for Speed governor and InteliDrive Lite InteliDrive Lite, SW version 1.9...

  • Page 37: Analog Inputs

    If RPM > 2 then the controller is in the state Not ready and the engine will not be allowed to start. Analog inputs On the InteliDrive Lite controller nine analog inputs are available. See the two tables here bellow with specific characteristics.

  • Page 38: Table Of Analog Inputs Options

    Table and graph: customize curves Contact Valid only for binary and three-state inputs type Valid only for binary and three-state inputs User curves “Points” are adjustable in LiteEdit PC tool. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 39 AIN7 HighDel = 2s Class C protection is working and LowWrn, LowSd, LowDel, HiWrn, HiSd, HiDel setpoints are visible only when corresponding AIN is configured in Modify->Alarm properties-> Direction-> Window prot. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 40: Connection Of Intelidrive Lite Analog Inputs

    4.2.3 Connection of InteliDrive Lite analog inputs Standard connection of three resistive sensors to analog inputs. Mixed connection of InteliDrive Lite analog inputs: AI1 – binary input AI2 – three state input AI3 – analog resistive input InteliDrive Lite, SW version 1.9...

  • Page 41: Current Output Transducers

    4-20mA/100 or 4-20mA/60 sensors. This method reduces the input resolution by less than 50%. Some types of transducers are not suitable for connection to InteliDrive Lite analog inputs because of influencing by InteliDriveLite analog input. Default current sensor characteristic...
  • Page 42 ‘V’ in column “Dim:” to ‘Bar’ and by sensor specification adjust all corresponding values in this column. In this case you can change the value at row 6. from 5 to 3. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 43: Binary Inputs And Outputs

    When you finish with adjusting the values click OK and Write to controller. Binary inputs and outputs InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 44: Analog Outputs

    Any value from controller may be configured to the outputs. Use LiteEdit PC tool to configure corresponding sensor/gauge curve and value selection. 4.4.1 Default analog output curves InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 45: Remote Modules - Can Bus Connection

    For CAN data cables details see chapter Technical data - Communication interface. CAN cable shielding is conneced to InteliDrive Lite COM terminal. InteliDrive Lite contains internal fix 120Ohm resistor and must be located on the CAN bus end. It is possible to connect only one IGL-RA15 to InteliDrive Lite controller.

  • Page 46: Operator Guide

    This button will not work if the controller mode is forced by one of binary inputs Remote OFF, Remote MAN, Remote AUT, Remote TEST. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 47 DOWN button. Use this button to select the set point, select the screen or decrease set point value ENTER button. Use this button to finish editing a setpoint or moving right in the history page. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 48: Init Screens

    Configuration of this screen is only done by LiteEdit PC tool. Init (welcome) screeen appears immediately after power on with ComAp default text. It is possible to modify it using LiteEdit – Configuration – Init button. There is space for 8 text lines per 21 ASCII characters each.

  • Page 49: Display Menus

    5.6.2 How to check software revision? Hold ENTER and then press PAGE. This activates the panel LED test and controller’s display is switched to Firmware screen. On the display you can see (for 10 seconds) InteliDrive Lite Firmware screen containing:...

  • Page 50: How To Check The Serial Number And Choose Interface

    Only in MEASUREMENT screen. 5.6.3 How to check the serial number and choose interface? Hold ENTER and then three times press PAGE. On the display you can see InteliDrive Lite User Interface screen containing: 1) User interface: can choose User(block adjustment function of controller) or Engineer interface...

  • Page 51: How To List History Records

    4. Run hrs - events counting Running hours of the engine 5. Timer - events counting time (e.g. prestart, cooling, etc.) 6. Engine RPM 5.9.2 InteliDrive Lite Analog inputs screens First screen: Oil pressure (AI1 bargraph with protection limits indication)

  • Page 52: Il-Nt-Aio Analog Inputs Screen

    This screen is shown/hidden depending on whether the IL-NT-IO1 is configured or not. Analog outputs are not displayed on any screen! 5.9.8 ECU State ECU State ECU YellowLamp ECU RedLamp InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 53: Ecu Values

    (SPN, OC and FMI codes). If the verbal description of alarm is not available, the SPN (decimal and hexadecimal) is displayed. EngOilPress BoostPress EngOilTemp 629(275h) Controller#1 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 54: Alarm List

    For FMI = 0 and 1, WRN is displayed. For other FMI codes, FLS is displayed. 5.9.12 Alarm list Alarm list displays active or inactive alarms occured on InteliDrive Lite unit. InteliDrive Lite controller automatically switches to the Alarm list screen when any new Alarm appears, but from Main measure screen only.

  • Page 55: Display Screens And Pages Structure

    5.10 Display screens and pages structure InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 56: Function Description

    Condition of the transition Action Next state Ready Start request PRESTART on Prestart Prestart time counter started Stop (Stop fail) RPM > 2 or Oil pressure detected or D+ is active InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 57 STOP SOLENOID on 60 sec. Elapsed FUEL SOLENOID off Shutdown (Start fail) STOP SOLENOID on Cooling Running Stop request READY TO LOAD off Cooling time timer started InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 58: Aut Mode

    Starting Poil signal can be analog or binary. Even the binary signal is to be connected to AIN1 input. In LiteEdit, window Modify, input Oil Pressure, check off the option Binary. The setpoint Starting Poil set to 1. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 59: Engine Timer

    The information about these analog values is brought into the controller through analog inputs (AIN) or, in the case of an electronic engine (engine equipped by ECU), by CAN bus. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 60: Engine Rpm Control In Man Mode

    Switch the RPM in three steps by Binary inputs BI Speed Sel1, 2, 3.  Ramp engine RPM Up/Down by Binary inputs BI Speed Up and Speed Down.  Control engine RPM by Analog input - e.g. by potentiometer. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 61: Engine Rpm Idle - Nominal Switching

    Adjust Regulator: LAI SpeedReq = AI1-9 … to corresponding controller or extension module analog input. Configure this Analog input - sensor characteristic in RPM or Percentage (expected potentiometer resistance 2,5kOhm in example below). Engine params: Speed ramp setpoint is active. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 62: Speed Request Chart

    This group has one PI loop and one CMPH. Both functions can use different inputs from ECU (Engine Load or RPM) or from pickup (RPM) or value from Analog input. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 63: Functions 1 And 2

    Set PI Regulator output to constant P Bias Regulator is working when this LBI is not configured. Function: LoadSwitch Load Comparator output (Up/Down Limit) Function: LoadLimitAOut Analog output of Load Limitation PI control loop. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 64: Functions 1 And 2 Setpoints

    Description: PI detects the difference between actual and requested value and changes the output to keep the controlled value on the limit. Can be used PI in function 1 or 3 Function requires plug-in module with Analog output. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 65 Binary input: Reg Disable (optional) Output Analog output: Load LimitAnOut (plug-in module) Note: LoadLimitAnOut range = 0 - 10000 Setpoints Load limit: Load Input = Load Load Bias InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 66 RPM from pickup (or ECU) Binary Load Switch output Setpoints Load limit: Load CMP Input = RPM Load CMP On = e.g. 2000 Load CMP Off = e.g. 2200 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 67: Aut Mode: Engine Regulation By Rpm Control - Overview

    The PI function output is Speed request transmitted via J1939 or Analog output. Both functions can use controller or plug-in IL-NT-AIO module Analog inputs. In Regulator is input only from analog inputs or from RPM-BI3. In table below see different operation conditions. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 68: Functions 3 And 4

    R Reg Disable Set PI Regulator output to R Bias Function: Speed Switch Regulator Comparator output 6.10.2 Functions 3 and 4 setpoints Regulator Values CU: AI1-AI9 LAI SpeedRequest AIO: AI1-AI4 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 69: Functions 3 And 4 Examples

    Binary input: Request 2 (optional) Binary input: R Reg Disable (optional) Output Analog output: Speed Request Setpoints Regulator: Reg Input Reg Bias Request Request 2 Reg Gain Reg Integral InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 70 Load Request 2 = 100 Load ReqRamp = 80 Load UpLimit = 9000 Load DnLimit = 1000 Load Gain = 50 Load Integral = 80 Load Ramp = 5000 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 71: Setpoints

    7 Setpoints Configuration of Setpoints is possible through panel buttons as is described above or via ComAp PC tool LiteEdit, where the setting can be open by click on the icon Password 7.1.1 EnterPassword Password is a four-digit number. Password enables change of relevant protected set points Use  or ...

  • Page 72: Rpmbywterminal

    [Pickup, AIO-AIN1, AIO-AIN2, AIO-AIN3, AIO-AIN4] Switch from where the RPM is measured. When source is Analog input the converted value is going to be in RPM range – see example below. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 73: Controllermode [Off, Man, Aut]

    Idle Speed is reached and this status is maintained until the I/0 button is pressed. The function is allowed in MAN mode only and is blocked during Cooling time. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 74: Runhourssource [Ecu, Internal, Auto]

    Comms Settings 7.3.1 ControllerAddr It is controller’s identification number. It is possible to set controller address different from the default value 1 so that more InteliDrive Lite controllers can be interconnected (via RS485) and accessed e.g. from Modbus terminal. Adresses: 1 - 32 InteliDrive Lite, SW version 1.9...

  • Page 75: Com1 Mode [Direct/Modem/Modbus/Ecu Link]

    COM1 Mode=DIRECT, COM2=MODBUS and ModbusComSpeed=57600. There isn’t required any other additional setting (of course except IB-Lite setpoints, see below) 7.3.6 IBLite IP Addr IP address of IB-Lite module 7.3.7 IBLite NetMask IB-Lite network mask InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 76: Iblite Gateip

    Dynamically change IP address of the controller after each switch on of the controller. IP address collision protection. Default state. 7.3.10 ComAp Port This sepoint is for adjustment of port for ComAp communication over IB-Lite or IL-NT-GPRS module. Standard ComAp port is 23, what is default value of this setpoint. 7.3.11 APN Name Name of APN access point for GPRS network This information shall provide your telecommunication operator.

  • Page 77: Smtp Username

    Engine params 7.4.1 Starting RPM [RPM] “Firing” speed when InteliDrive Lite controller stops cranking (starter goes OFF). Sd Underspeed protection is activated when RPM drops back below the Starting RPM for more than 5 second the engine starting procedure. Limit is ignored when Gear teeth = 0 i.e. in engine operation without speed pickup (running state is indicated from D+ or Starting POil.

  • Page 78: Starting Poil [Bar]

    – when Starting RPM speed is reached. Step: Range: 0 - 600s Default value: 0s 7.4.5 MaxCrank time This setpoint is giving maximum time limit of engine cranking. Step: Range: 1 - 60s InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 79: Crnkfail Pause [S]

    Speed request in engine Idle state i.e. after engine start or when switched to Idle in MAN mode by Binary input Nominal/Idle and after Engine ShutDown. Step: 1RPM Starting RPM – MinSpeedLimit Range: Default value: 800RPM InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 80: Cooling Speed [Idle, Nominal]

    The delay of Fuel solenoid output activation in relation to Starter output is defined by FuelSol offset. The output closes only if RPM > 30 (i.e. the starter motor is engaged). InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 81: Fuelsol Offset [S]

    Generally, the output closes after reaching value of CrankRPM = 30RPM (fixed value). The output opens after stopping of the engine or during crank fail pauses among crank attempts. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 82: D+ Function [Enabled, Chrgfail, Disabled]

    Start request, Stop request, Speed request are enabled if available. Default state. DISABLED: Control of an electronic engine is fully blocked and the InteliDrive Lite can only monitor the values of an electronic engine. 7.4.18 ECU SpeedAdj [RPM] Enables to adjust engine speed in ECU via CAN bus.

  • Page 83: Maxspeedlim [Rpm]

    7.4.25 Speed Ramp [RPM/s] Any Speed request change is done via this Ramp function. The Ramp via Binary SpeedUp and SpeedDown inputs is dual rate, see below. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 84: 0%Ofspeedreq [Rpm]

    2400RPM = 100% Different setting: 800RPM = 0% 1200RPM = 33.3% 2400RPM = 100% It is possible easily configure own output curve and use it for analog output Speed Request. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 85: 100%Ofspeedreq [Rpm]

    Active alarm "Wrn FuelTheft" can be sent via SMS and displayed by WebSupervisor (if used). Step: Range: 0 - 50% Default: Set 0 to disable Fuel Theft Protection function into MaxFuelDrop setpoint. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 86: Regulator

    (regulator output) is assigned to Reg Bias value in the case of selected analog input sensor fail. Default state: CU:AI1 7.5.3 Reg Bias Constant PI regulator output when the LBI R Reg Disable = closed. Step: Range: 0 - 10000 Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 87: Request 1 [-]

    0.0% - +100.0% Default: InteliDrive Lite controllers include PI loop for speed or analog output regulation. The requested value is given by setpoints Request 1, 2. This loop is working like Proportional-Integral regulation with setpoints Reg Gain and Reg Integral for each part and these parts affect each other.

  • Page 88: Reg Cmp Input

    It is also possible to use Binary input 3 in function of RPM detection. Default state: CU:AI1 7.5.9 Reg CMP On Limit to close LBO SpeedSwitch. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 89: Reg Cmp Off

    Constant Load limit PI regulator output. Load Bias is activated when  Engine Sd protection is activated  LBI LoadRegDisable = closed  Load input value is invalid (Sensor Fail) InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 90: Loadrequest 1 [-]

    Load limit regulator PI output low limit. Step: Range: 0 - 10000 Default: 7.6.8 Load Gain This is setpoint is giving Load limit gain factor. Step: Range: -200.0% - +200.0% InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 91: Load Integral [%]

    During the start of the engine, some engine protections have to be blocked (e.g. Oil pressure). The protections are unblocked after the Protection del time. The time starts after reaching Start RPM. Step: Range: 0 - 300s Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 92: Bin6 Delay [S]

    The “Ready to load” output is deactivated when Wrn underspeed protection is active and needs the Fault reset for activation after RPM is over Underspeed limit. Step: 1% of nominal RPM Range: Starting RPM - 100% Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 93: Flow Switchdel [S]

    Shut-down level RPM = 10 Engine params: Idle time Engine protect: Eng prot del Tables below describe Underspeed protection behavior depends on Underspeed Sd setpoint setting and RPM value. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 94: Ain1 Level 1 [Bar]

    Delay for ANALOG INPUT 1 Step: Range: 0 - 180s Default: Analog input 1 is usually determined to Oil Pressure measurement and it is resistive type of input with range 0-2500Ohm. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 95: Ain2 Level 1 [ ]

    7.7.16 AIN3 Level 2 Shutdown limit level for ANALOG INPUT 3 Step: Range: -100 - +10000% Default: 7.7.17 AIN3 Del Delay for ANALOG INPUT 3 Step: Range: 0 - 180s Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 96: Batt Overvolt [V]

    7.7.22 AIN4 Level 2 Shutdown limit level for AIN4 Step: Range: 0 - 10000 Default: 7.7.23 AIN4 Del Delay for Wrn/Sd AIN4 alarm. Step: Range: 0 - 3600s Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 97: Ain4 Eval [Normal, Class C]

    7.7.28 AIN4 HighWrn High Warning limit level for AIN4 Step: Range: 0 - 10000 Default: 7.7.29 AIN4 HighSd High ShutDown limit level for AIN4 Step: Range: 0 - 10000 Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 98: Ain4 Highdel [S]

    - after engine start. Warning/ShutdDown protection is activated with fix delay 0,5s. Class C protection is working and corresponding setpoints are visible only when corresponding AIN is configured in Modify->Alarm properties-> Direction-> Window prot. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 99: Ain5 Lowwrn [ ]

    High level protection delay for Wrn and Sd of AIN5 Step: Range: 0 - 3600s Default: Analog input 5 is fully configurable and it is voltage type of input with range 0-40V InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 100: Ain6 Level 1 [ ]

    7.7.45 AIN6 LowWrn Low Warning limit level for AIN6 Step: Range: 0 - 10000 Default: 7.7.46 AIN6 LowSd Low ShutDown limit level for AIN6 Step: Range: 0 - 10000 Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 101: Ain6 Lowdel [S]

    7.7.51 AIN7 Level 1 Warning limit level for AIN7 Step: Range: 0 - 10000 Default: 7.7.52 AIN7 Level 2 Shutdown limit level for AIN7 Step: Range: 0 - 10000 Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 102: Ain7 Del [S]

    Low level protection delay for Wrn and Sd of AIN7 Step: Range: 0 - 3600s Default: 7.7.58 AIN7 HighWrn High Warning limit level for AIN7 Step: Range: 0 - 10000 Default: InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 103: Ain7 Highsd [ ]

    Delay for Wrn/Sd AIN8 alarm. Step: Range: 0 - 3600s Default: Analog input 8 is configurable with basic two levels protection and it is voltage type of input with range 0-10V. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 104: Ain9 Level 1 [ ]

    Difference check between RPM and RPM3 with calculation of gear-box ratio, when Engine protect: GearBoxRatio > 0.0. Protection is active when engine is Ready to load. Step: 0.1RPM Range: 0.0 - 5.0RPM InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 105: Rpmdiff Sd [Rpm]

    7.7.72 BIN1 Prot Del…BIN7 Prot Del Seven setpoints are dedicated for separately adjustment of the delay for each of binary inputs according to the Class B protection standard. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 106: Def Level Min

    Automatic switching between summer and wintertime is disabled. WINTER (SUMMER): Automatic switching between summer and winter time is enabled and it is set to winter (summer) season. WINTER-S (SUMMER-S) : Modification for southern hemisphere. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 107: [Hh:mm:ss]

    Timer is activated on selected day interval. 7.8.7 Timer1 ON time [HH:MM:SS] Display day time when Timer 1 output is activated. 7.8.8 Timer1Duration [min] Adjusts duration of Timer 1 output. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 108: Timer2Function [Nofunc, Autorun, Autoregcmp, Autobatt, Autostop]

    7.8.11 Timer2 ON time [HH:MM:SS] Display day time when Timer 2 output is activated. 7.8.12 Timer2Duration [min] Adjusts duration of Timer 2 output. Step: 1min Range: 1 - 1440min InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 109: Sensor Spec

    Note: The number of controller screen characters is limited – i.e. displays ????? when steps over range. Both counters starts from again zero when reach maximum. Statistics value Screen From Over Total 1 or Total 2 Controller 9999999,9 ????????? InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 110: Counter Mode 1, Counter Mode 2

    Delay for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm. Step: Range: 0 - 180s Default: Plug-in analog inputs protection alarms can be configured following way Configuration Protection InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 111: Sms/E-Mail

    „@“ it is supposed to be e-mail address and active e-mail is sent. If the value is number, without „@“, it is supposed to be the telephone number and active SMS is sent. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 112 For cellular network numbers use either national format (i.e. like number you will dial if you want to make a local call) or full international format with "+" character followed by international prefix at the beginning. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 113: Values

    RemoteControl button for more details Date/Time Time Date ID info Engine state Timer text Timer val SW version Application SW branch PasswordDecode InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 114 Modem Status: Iveco Values DEF TankLevel Values read from specific type DEF TankTemp of ECU DEF Quantity Catal UpTemp Catal DownTemp DEF Pressure Catalyst Level AIO module AnInAIO1-AnInAIO4 InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 115: Binary Input Functions

    9 Binary input functions Any Binary input can be configured to any InteliDrive Lite controller terminal or changed to different function by LiteEdit PC tool. There is adjustable delay when any binary input is configured as protection. Binary inputs InteliDrive Lite - default configuration...

  • Page 116: Binary Inputs List

    9.3.6 Remote OFF If closed, InteliDrive Lite is switched to OFF mode (there are three modes OFF-MAN-AUT). When opens controller is switched back to previous mode. This binary input should be connected to schedule timer switch, to avoid start of engine.

  • Page 117: Remote Aut

    Function is active in any controller mode. 9.3.11 StartButton Binary input has the same function as Start button on the InteliDrive Lite front panel. It is active in MAN mode only. 9.3.12 StopButton Binary input has the same function as Stop button on the InteliDrive Lite front panel. It is active in MAN mode only.

  • Page 118: Speed Up

    When more binary inputs are active at the same time, e.g. all binary inputs: ‘Speed Sel1’, ‘Speed Sel2’, ‘Speed Sel3’ then requested speed is given by Engine params: BI Speed Sel 1 (lowest index) setpoint. 9.3.21 Lang selection Switch display texts between two languages. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 119: Conveyor

    The function works when the controller is connected to an ECU or in other case is consumption counted from the changes of analog input value Fuel rate and setpoint Engine params: FuelTankVolume. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 120: Flow Switch

    When the new LBI Protection Test is activated (by rising edge), all Sd alarms are for 90s blocked. The exception is LBI Emergency stop and Overspeed protection. Behavior of LBI Prot Test 90 sec 90 sec 90 sec Time (sec) LBI Prot Test Blocked status InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 121: Binary Output Functions

    10 Binary output functions Any Binary input can be configured to any InteliDrive Lite controller terminal or changed to different function by LiteEdit PC tool. There is adjustable delay when any binary input is configured as protection. 10.1 Binary outputs InteliDrive Lite - default...

  • Page 122: Stop Solenoid

    When LBI Nominal/Idle is configured (to a physical binary input), it has priority and the switching between the nominal and the idle speed by I/0 button is blocked. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 123: Air Valves

    Output closes if the engine is in Running state. 10.2.17 Cooling The output closes when engine is in Cooling state. 10.2.18 Fault Reset One second pulse as echo for panel Fault reset button. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 124: Chrgalternfail

     alarm is not active and  FAULT RESET is pressed 10.2.24 Battery flat Output closes when InteliDrive Lite performs reset during start procedure (probably due to weak battery). The output opens, if  alarm is not active and ...

  • Page 125: V Batt Failed

     alarm is not active and  FAULT RESET is pressed 10.2.31 Wrn Oil Press Output closes if the oil pressure warning alarm activates. The output opens, if InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 126: Sd Engine Temp

    10.2.38 AUT mode The output is closed, if AUT mode is selected. 10.2.39 ServiceTime Output closes if the ServiceTime alarm activates. Service time is adjusted by setpoint Engine protect: NextServTime. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 127: Def Tank Level

    Output closes if the shutdown alarms for AIN4, AIN5, AIN6, AIN7, AIN8, AIN9 activates. The output opens, if  alarm is not active and  FAULT RESET is pressed InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 128: Ecu Commok

    Binary output function of Conveyor. See Binary input Conveyor. 10.2.55 SpeedSwitch Binary output from Speed switch comparator – see Regulator setpoint group. 10.2.56 LoadSwitch Binary output from Load switch comparator – see Load limit setpoint group. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 129: Close Load

    Allows configure Remote control switches to physical binary outputs. These switches are accessible from PC tools LiteEdit (see picture below) or InteliMonitor by button and it can be controlled via ModBus communication. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 130: Communication

    InteliDrive Lite can be connected directly with PC via optional communication plug-in modules IL-NT RS232, IL-NT RS232-485, IL-NT S-USB. Use the standard serial/USB cable to connect PC with InteliDrive Lite. In the area with electromagnetic interefernece should be used shielded cables.

  • Page 131: Remote Connection

    11.2 Remote connection 11.2.1 Internet connection InteliDrive Lite controllers can be monitored from PC tools as LiteEdit or InteliMonitor over the Internet using Internet Bridge IB-NT connected to the controller via IL-NT RS232-485 port, via optional IB-Lite plug-in module or via IL-NT GPRS for cellular internet network. See Comms Settings.

  • Page 132: Ecu Engine Support

    64 35 = CRC 11.4 ECU engine support InteliDrive Lite firmware branch covers both standard and electronic controlled (monitored) engines. The appropriate engine/ECU type is selected in PC tool LiteEdit like other peripheries. Press the button in LiteEdit configuration window Modify.

  • Page 133: Choosing The Ecu To Configure

    Comap Electronic Engines Support manual. The InteliDrive Lite controller always sends either speed request = 0 % or the IDLE command via J1939 in controller Idle state. In the MAN mode the Idle operation can be controlled by Nominal/Idle binary input.

  • Page 134: Ecu Analog Inputs

    If the engine without ECU is controlled by InteliDrive Lite, the first analog input is permanently configured to Oil Pressure, other analog inputs remain freely configurable.
  • Page 135 1 0 0 % A s h L o a d 1 0 0 % Tier4 values Soot Load and Ash Load are visible on ECU screen as well. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 136: Maintenance

    12 Maintenance InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 137: Troubleshooting

    When cooldown comes up, engine is stoped slowly over cooling state. 13.1.4 Shut down (Sd) When the shutdown alarm comes up, InteliDrive Lite opens all outputs e.g. FUEL SOLENOID, STARTER and PRESTART to stop the engine immediately. Alarm outputs and common shutdown output are closed.

  • Page 138: List Of Possible Alarms

    Binary input Configurable YES Configurable Warning/Shutdown alarms on the inputs of InteliDrive Lite. Battery flat If the controller switches off during starting sequence due to bad battery condition it doesn’t try to start again and activates this protection.

  • Page 139: History File

    RTC backup battery is flat 13.2 History file InteliDrive Lite stores a record of each important event into the history file. The history file seats 255 records. When the history file is full, the oldest records are removed. To force history download in LiteEdit (direct, modem or internet) open History window and select History | Read history command.

  • Page 140: Diagnostic Messages Read From Ecu

    CalibrMemFail 1110 Engine Sd InteliDrive Lite controller doesn’t support J1587 diagnostic line on Volvo engines. This can cause in some cases a J1939 alarm message FC:000608 due to missing J1587 bus. Contact your Volvo distributor to update ECU firmware. For Scania Fault codes (FC) are displayed. Following messages are available for particular groups of...

  • Page 141: Tier 4 Diagnostic Codes

    Active when 3697 = 1 and SPN 3701 = 4 + Warning DPF Lamp Active when 3697 = 1 and SPN 3701 = 5 + STOP Yellow Lamp Active when DM1 Yellow lamp is active. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...
  • Page 142 Red Lamp Active when DM1 Red lamp is active. InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 143: Technical Data

    LCD display limits range for controller operating temperature: from -20°C to +70°C, even if the other electronic components work in wider temperature range. Internal preheating foil is mounted in InteliDrive Lite LT to extend display operational temperature range. Preheating starts at temperature below 5°C and preheating power depends on temperature and power supply voltage.

  • Page 144: Dimensions And Weight

    Minimum input voltage (from 4Hz to 4kHz) Maximum input voltage Minimum measured frequency Maximum measured frequency 10 kHz (min. input voltage 6V pk-pk Frequency measurement tolerance 0,2% InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 145: D+ Function

     Unitronic BUS CAN  Unitronic-FD BUS P CAN UL/CSA 14.10 IL-NT RS232 (optional card) Plug-in into InteliDrive Lite controller COMMUNICATION MODULE port. Maximal distance Speed 19.2kBd (STD) 9.6kBd (MODBUS) Recommend external converter: ADVANTECH – ADAM 4520: RS232 to RS422/485 converter, DIN rail, automatic RS485 bus supervision, no external data flow control signals, galvanic isolated.

  • Page 146: Il-Nt Rs232-485 (Optional Card)

    14.11 IL-NT RS232-485 (optional card) Plug-in into InteliDrive Lite controller COMMUNICATION MODULE port. Maximal distance 10m (RS232), 1200m (RS485) Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog modem, 9.6 kBd digital modem, 57.6 kBd (MODBUS) 14.12 IL-NT S-USB (optional card) Plug-in into InteliDrive Lite controller COMMUNICATION MODULE port.

  • Page 147: Il-Nt Aio (Optional Card)

    14.16 IL-NT AIO (optional card) Plug-in into InteliDrive Lite controller EXTENSION MODULE port. Resolution 10bits Inputs Number of Analog inputs 4 (2400Ohm, 20mA, 4V) Maximal resistance range 2400Ohm Maximal voltage range Current range 0-20 mA Input impedance (current) 180Ohm for mA measuring Input impedance (voltage) >68 kOhm for V measuring...

  • Page 148: Dimensions And Weight

    Protection front panel IP65 14.19.3 Dimensions and weight Dimensions 180x120x55mm Weight 950g 14.19.4 Horn output Maximum current Maximum switching voltage 36VDC InteliDrive Lite, SW version 1.9 ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015...

  • Page 149: Language Support

    15 Language support InteliDrive Lite controllers support different languages. In default setting of controller are accessible two languages English, which isn’t possible remove and Chinese. In the controller is possible to substitute Chinese language by next language via LiteEdit (see the table below). These languages are possible modify via Translator tool in LiteEdit.

Table of Contents

Save PDF
