ComAp InteliCompact NT Reference Manual page 256

Binary output: Speed Up
Related All
applications
Description This output together with the complementary output
designed for speed and power control at gen-sets, where the governor does
not support analog control. The outputs are also used for direct control of a
gas throttle at asynchronous gen-sets.
N :
OTE
Droop function is required when these outputs are used for power control
through a governor.
Binary output: Speed Down
Related All
applications
Description This output together with the complementary output
for speed and power control at gen-sets, where the governor does not
support analog control. The outputs are also used for direct control of a gas
throttle at asynchronous gen-sets.
N :
OTE
Droop function is required when these outputs are used for power control
through a governor.
Binary output: AVR Up
Related All
applications
Description This output together with the complementary output
for voltage and power factor control at gen-sets, where the AVR does not
support analog control.
N :
OTE
Droop function is required when these outputs are used for power factor
control.
Binary output: AVR Down
Related All
applications
Description This output together with the complementary output
voltage and power factor control at gen-sets, where the AVR does not
support analog control.
N :
OTE
Droop function is required when these outputs are used for power factor
control.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Speed Down is
Speed Up is designed
AVR Down is designed
AVR Up is designed for
256
