ComAp InteliCompact NT Reference Manual page 257

Binary output: Ready To Load
Related All
applications
Description The output is closed whenever the GCB is closed or can be closed. Details
about conditions when the GCB can be closed are available in the chapter
Connecting to the
Binary output: Synchronizing
Related All
applications
Description The output is closed during forward or reverse synchronizing.
Binary output: Running
Related All
applications
Description The output is designed to be used as an indication that the gen-set is
running. It is activated at the moment the gen-set has been started and the
idle period has elapsed. It remains active until stop command is issued.
Binary output: Loaded
Related All
applications
Description The output is closed whenever the GCB is closed except the unloading
phase prior to opening the GCB.
Binary output: Unloading
Related All
applications
Description The output is closed during the unloading phase (ramping the power down)
prior to opening the GCB. More detailed description is available in the
chapter
Binary output: AnalogSwitch 1
Related All
applications
Description This is an output from the
Binary output: AnalogSwitch 2
Related All
applications
Description This is an output from the
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
load.
Parallel to mains operation.
Analog switch
Analog switch
1.
2.
