Page 1 4 Installation and wiring 5 Controller setup 6 Communication 7 Technical data 8 Appendix Copyright © 2019 ComAp a.s. Written by Ladislav Kadanik, Pavel Doubek, Vladimír Zubák, Jan Kovačka Prague, Czech Republic ComAp a.s., U Uranie 1612/14a, 170 00 Prague 7, Czech Republic...
Page 2: Table Of Contents
2.2.5 Modbus protocol 2.2.6 Password protection 2.2.7 WebSupervisor 2.3 List of supported modules 3 Application overview 3.1 ID-DCU MARINE functions 3.1.1 Default archives 3.1.2 Function description details 3.1.3 Operational modes 3.1.4 Universal states 3.2 ID-RPU InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 3: Table Of Contents
4.3.7 Binary output separation 4.3.8 Connection of ID-DCU MARINE analog inputs 4.3.9 ID-DCU MARINE Analog inputs hardware configuration 4.3.10 ID-DCU MARINE Analog inputs software configuration 4.4 Extension modules 4.4.1 Inteli AIN8 4.4.2 Inteli AIN8TC InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 4: Table Of Contents
7 Technical data 7.1 ID-DCU MARINE 7.2 CAN bus interface 8 Appendix 8.1 Controller objects 8.1.1 List of controller objects types 8.1.2 Setpoints 8.1.3 Binary Inputs 8.1.4 Binary outputs 8.1.5 Analog Inputs 8.1.6 Values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 5: Document Information
1.2 About this guide InteliDrive DCU Marine is a specialized engine controller for Marine applications. It controls, monitors and protects the engine in single (Auxiliary) or variable (propulsion) speed operational modes. The controller can communicate with Engine Management System via the CAN serial line using standard J1939 or another (KWP2000) communication protocol.
Page 6: Legal Notice
Official version of the ComAp’s End User's Guide/Manual is the version published in English. ComAp reserves the right to update this End User's Guide/Manual at any time. ComAp does not assume any responsibility for its use outside of the scope of the Terms or the Conditions and the License Agreement.
Page 7: System Overview
Cycle backward through engine operation modes: OFF <- AUX / EME / HRB / PRP. Deactivates the HORN. Acknowledges faults and alarms. Starts the engine in AUX, EME, HRB, PRP mode. Stops the engine in AUX, EME, HRB, PRP mode (hold time =1 sec). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 8: Controller Screens
Info screen: Fw and App. version, s.n., .. Language list and switch. Language screen Fast edit screen Available using ↑ or ↓ front panel keys ECU diagnostics code list Alarm list ID Mode, RPM1, Engine state, Oil Pressure and Coolant 1 = Main screen InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 9 Broken wire Sensor fail Three state Alarm list indication * Wrn Water temp Active not accepted alarm Wrn Water temp Active accepted alarm * Wrn Water temp Inactive not accepted alarm Inactive accepted alarm InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 10 Service Time It is decreased each finished 60 minutes when engine is running. DayCons Daily fuel consumption, every liter of fuel is calculated. TripCons Trip fuel consumption, every liter of fuel is calculated. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 11 Wrn RPU Fail Sd RPU Fail Bw RPU FuelSol Bw RPU StopSol Wrn RPU Fail Sd RPU Fail ID-RPU A Battery voltage <, > ID-RPU B Battery voltage <, > Wrn DETCON Sd DETCON InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 12 ID-DCU MARINE binary input RemRepStart ID-DCU MARINE binary input Blackout start ID-DCU MARINE binary input Button start ID-DCU MARINE panel button Extern Start External engine start Stops Engine stop Stop from ID-DCU MARINE panel or BI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 13 Depends on setpoint setting period Password set Any level from any terminal Password changed Any level from any terminal Access set Access code was set Access changed Access code was changed Watchdog Controller internal watchdog protection InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 14: Display Menu
2.1.2 Display menu There are 4 display menus available: MEASUREMENT, External measurement, ADJUSTMENT and HISTORY. Each menu consists of several screens. Pressing the Page button repeatedly will scroll the user through the menu screens. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 15: Functions Available From Id-Dcu Marine Front Panel Keys
2.1.4 How to change controller language? Go to Info screen by pressing Page + Enter. Press Page to go to Language screen. Select language ↑ or ↓ a press Page to confirm selection and exit window. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 16: How To Change The Display Backlight Intensity
2.1.10 How to view and edit setpoints? 1. Pressing the Page button repeatedly will scroll the user through the menu screens. Select the ADJUSTMENT screen. 2. Use ↑ or ↓ to select requested set points group. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 17: How To View Measured Data
3. Use Enter to select requested screen (record items) within displayed records 2.1.13 Main screen indication Active controller mode (inverse) Available mode Controller LOC (Local) mode indication R = Remote connection indication (connection to InteliMonitor is active) L = Access lock indication InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 18: Controller Configuration And Monitoring
On the other side the clients (only ComAp PC applications - DriveConfig, DriveMonitor InteliMonitor and WebSupervisor) connect to the AirGate server instead of connecting directly to the controller. The server then creates a "tunnel" between the client and the controller.
Page 19: Configuration Steps
PTC protection activates and interrupts RS232 communication. In such case disconnect RS232 line wait a minute for PTC recovery and try again. The simple solution is to assure, that the PC supply 240/20V is ground free (GND terminal is not connected). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 20: Driveconfig
Configuration file can be opened (Open file or Load from ID) modified and stored to the PC (Save, Save as) or downloaded to Controller (Store to ID). DriveConfig functions Tool for ID-DCU MARINE controller and extension modules configuration Extension modules addressing All I/O function or protection configuration Setpoints adjusting InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 21: Modbus Protocol
Just one communication object can be read or written by one communication function. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 22: Password Protection
Setting of statistic is possible protect separately - from Monitor only 2.2.7 WebSupervisor WebSupervisor is web based system designed for monitoring and controlling ComAp controllers via the Internet. This system offers a number of beneficial features that help optimize revenue for machinery fleets, as each piece of equipment can be individually monitored for all important operation values.
Page 23: List Of Supported Modules
Note: The WebSupervisor ComAp tool is supported from ID-DCU Marine version 2.2, specifically fromID- DCU-MARINE-W-2.2.mhx firmware. 2.3 List of supported modules Product Description Order code Inteli AIN8 8 Analog inputs (R, I, V) and 1 pulse/frequency input I-AIN8 Inteli AIN8TC...
Page 24: Application Overview
3.1.2 Function description details Protection Fls can be used with electronic modules and ID-RPU module only. Protection is activate only if there is failure of receiving data and value is in logical 0. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 25 Fls will not be triggered if binary is in logical 1 and for physical inputs Protections Note: There are visible only the first two bar graph marks for protection limits indication on ID-DCU MARINE screen !!! InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 26 How to configure analog input window protection 1. Switch DriveConfig to EXPERT mode. 2. Configure standard two level analog protection 3. Add another protections in EXPERT window. There can be set the same delay for all four limits. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 27 100% TP respectively 0% TP Overload protection (PRP only) Overload protection and corresponding Alarm message is activated when following conditions are valid in period longer than Overload del: InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 28 Under speed protection Under speed protection is activated 5 sec after RPM > Engine params: Starting RPM. Engine underspeed is detected when RPM drops below setpoint Engine Protect: UnderSpeed. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 29 Protection delay and blocking InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 30: Operational Modes
The controller still measures all engine parameters. But it only records to the history file and can notify remote operator via Active call when detects any parameter out of range. The only active shut down protection is engine overspeed and Emergency stop. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 31: Universal States
State is resetted (output is opened) when corresponding Alarm is not active and confirmed (Fault reset was pressed). There are seven universal (free) states available in ID-DCU MARINE-3.0.0 that are not joined to any value or input. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 32: Id-Rpu
Example of Universal state1 configuration to Engine speed (Warning for Engine speed > 1600RPM, 1s): This configuration is available in DriveConfig – Expert mode. 3.2 ID-RPU Image 3.1 Redundancy protection unit Note: Maximal torque to tight main screw is 0.25 Nm. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 33: Id-Rpu Functions
ID-DCU MARINE was in EME mode (or Sd override function was active) before fail. The only Emergency stop and Overspeed protection is active in this mode. Shut down Sd1 to Sd5 inputs are inactive. ID-RPU starts to Emergency backup mode after power on without active ID-DCU MARINE. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 34 ID-DCU MARINE. In case the stop solenoid is not used, the output must be configured as not used, otherwise broken wire protection will be detected. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 35: Id-Rpu Overspeed Setting
Engine overspeed protection or some Shutdown input (not in EME mode or Sd override), is activated. 3.2.2 ID-RPU overspeed setting ID-RPU Overspeed limit is set via two DIP switches: Prefix and Speed preset. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 36 Gear teeth Prefix Speed preset DIP8 1800 1000 10001101 1800 1000 01110001 1800 0100 11100010 1000 0010 11111011 Speed preset binary conversion examples Speed preset DIP8 00000000 00000001 00000010 00000100 00001000 00010000 00100000 InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 37 01000000 10000000 11111111 6 back to Application overview InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 38: Installation And Wiring
Active alarm indication alarm is still active. Disappears after "Fault reset" c onfirmation.- when alarm is inactive. Right GREEN Engine running indication Light when engine is running. Note: Please check the last software version. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 39: Communication Lines Wiring
(e.g. Start, Stop commands) and analog outputs (e.g. Speed request). ECU size (count of input and output resources) are configurable and depends on controller possibilities. 4.1.4 ID DCU MARINE dimensions ID-COM and ID-SCM are mounted directly to ID-DCU MARINE case. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 40: Id-Com Terminals
The new standard ID-COM will only be with the RS485 interface. Note: Maximal torque to tight main screw is 0.25 Nm. CAN1 Extension modules: EMS, IS-AIN8(TC), IS-BIN16/8, IGS-PTM, IGL-RA15 CAN2 Intercontroller: I-LB+, IG-IB, IB-NT, others ID-DCU MARINE InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 41: Id-Dcu Marine Terminals
BO1 to BO14 Binary outputs; Low side switch; 0,5 Amps each; D plus terminal AIN1 to AIN4 Analog inputs - group 1 AIN5+, AIN5- AIN6+, AIN6- Analog inputs - group 2 AIN7+, AIN7- AIN8+, AIN8- InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 42: Id-Dcu Xx -Lt Version With Display Preheating
ID-DCU -LT version contains a preheating foil on the display activated below +5°C (measured on the PCB). Heating is switched off when controller power supply is below 10VDC (together with display backlight). 4.1.8 ID-RPU terminals Redundant Protection Unit. ID-RPU is mounted directly to ID-DCU MARINE box. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 43: Id-Scm Speed Control Module
(active) impulse sensor with maximal frequency range up to 60 Hz. Minimal pulse duration is 1ms. The output values SCM Imp1, SCM Imp2 calculation use setpoints SCM unit: TransferRate1 and TransferRate2 - see below. ID-SCM inputs wiring example InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 44: Id-Scm1
Note: Maximal torque to tight main screw is 0.25 Nm. Outputs 4.1.10 ID-SCM1 Technical data Power supply: internal supply from ID-DCU MARINE (8 to 36 VDC) Operating temperature range: -40°C to +70°C Number of analog outputs: 1, no galvanic separation InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 45: Intelivision 5 Can, Intelivision 5 Can Backlit
10 corresponding terminal female pins ECU Simulator set containing supported USB/CAN converter and various cabling, for new firmware / font / logo download into the InteliVision 5 CAN InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 46 Power supply 8 – 36VDC 6 - 8 CAN bus (with galvanic separation) Binary output configured for Horn function. It is Solid State Relay with galvanic separation. Max 3 - 4 36VDC/0,5A (like free contact). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 47: Intelivision 8, Intelivision 8 Marine
Note: It is possible to connect up to five InteliVision 5 CAN or four InteliVision 8 displays to common CAN2 bus. The display addresses must be different in this case. 4.1.12 InteliVision 8, InteliVision 8 Marine InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 48: Intelivision 12Touch Oem
4.1.13 InteliVision 12Touch OEM InteliVision 12Touch, industrial operator panel equipped with a 12,1” colour, multi-touch screen, is dedicated together with the main ComAp controller to visualize and control single gen-set and drive controllers in various applications. It is designed as an intuitive, easy to use Plug and Play solution and delivers high visibility of all engine data, monitoring information and trend history in a bright, colorful and impressive industrial capacitive touch based design.
Page 49 Image 4.2 InteliVision 12Touch - dimensions Image 4.3 Wiring example: ID-DCU Marine to InteliVision 12Touch Note: For more information see InteliVision 12Touch Globa guide InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 50: Recommended Wiring
CAN H = 5, CAN L = 9, COMMON = 3 and 8. IGS-PTM unit contains internal jumper-removable 120 Ω resistor. To be sure check resistor presence by ohmmeter. Unit with internal resistor should be connected to the end of CAN2 line. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 51: Electronic Engine Without Redundancy Line
4.2.2 Electronic engine without redundancy line InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 52: Engine Without Ecu (Mechanical Engine)
2. Configure corresponding CONTROLLER CAN addresses in PC configuration tool. 3. Configure separate inputs and outputs in corresponding Analog, Binary inputs, outputs in PC configuration tool. Note: In case of CAT engines, there is RS232 connection between I-CB and CCM. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 53: Id-Rpu Wiring
53). 4.2.6 Recommended wiring acording to DNV rules There is recommended wiring diagram of InteliDrive DCU Marine controller + ID-RPU module following latest DNV requirements for mutual independency of control, alarm and safety systems. InteliDrive DCU Marine provides features of control and alarm system, ID-RPU provides features of safety system.
Page 54 ID RPU / EM. STOP input. It is also acceptable to use relay NC contacts in the circuit connected to ID RPU / EM. STOP input (relay coil is controlled by emergency stop circuit) in case of NO (Normally Opened) emergency stop circuit type, if it is required by application. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 55: Wiring Example - Complete System Without Rpu
Do not connect binary outputs directly to DC relays without protection diodes. Use protection diodes even if the relays are not connected directly to controller outputs. Use a fast recovery 3A / 50V diodes. Image 4.4 Example of controller protection InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 56 General To ensure proper function: Use grounding terminals. The InteliDrive DCU Marine power feeding input is galvanically isolated from controller body, use the grounding terminal for proper grounding. Wiring for binary inputs and analog inputs must not be lead parallel with high voltage/current cables.
Page 57: Analog As Binary Input
Note: For redundancy power supply use ID-RPU module – see chapter Recommended wiring. Note: The InteliDrive DCU Marine controller should be grounded properly in order to protect against atmospheric discharges! Install separate conductors for signal and power inputs. Allow for conductor voltage drop when determining conductor size.
Page 58: Analog Sensors Availability With Extension Modules
Table of supported sensors on various modules. Do not configure sensors that are not supported on the input. IS-AIN8 I-AIN8 IS-AIN8TC I-AIN8TC I-AIO 9/1 IGS-PTM not used analog input user curves PT100 [°C] PT1000 [°C] NI100 [°C] NI1000 [°C] Thermocpl J [°C] Thermocpl K [°C] Thermocpl L [°C] 4-20 mA passive InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 59: Binary Inputs/Outputs On Id-Dcu Marine
User define input curve only sensor 0-2400Ω. Note: Fahrenheit sensors are supported from IS-AIN8 of sw version 2.2 only. 4.3.6 Binary inputs/outputs on ID-DCU MARINE Use wiring cables min. of 1.0 mm2 to ensure proper function. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 60: Binary Output Separation
Binary output LED indication. In the Example below when EMERGENCY STOP contact is opened, the BO3 LED should light (without separating diode SD3) even if the BO3 output is opened. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 61: Connection Of Id-Dcu Marine Analog Inputs
ID minus Power supply terminal. To ensure a proper function use shielded cables, especially for length over >3 m. 4.3.9 ID-DCU MARINE Analog inputs hardware configuration Configure Analog inputs AI1-AI8 connection by jumpers on PCB (remove cover). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 62 - Jumper on pins 2-3. Resistance measurement - Jumper on pins 3-4. Note: Maximal voltage on controller Differential analog inputs AI5 to AI8 is in the range –2 to +5 VDC against minus power supply terminal! InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 63: Id-Dcu Marine Analog Inputs Software Configuration
Analog Input. Configure protection activity: All the time or Engine running with three different adjustable Block type delays when protectioln is active after engine start (RPM > Starting RPM). Bargraph Bargraph starting value. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 64 For 1V or 100mV Voltage: 2-3 Tristate Resistance: 3-4 0 to 5 VDC Adjustable Voltage: 2-3 Configuration examples Conversion from 4-20 mA to 6.0 Bar Oil pressure sensor (Wrn+Sd protection and Oil press function) InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 65 HW configuration: CU 0-1 V can be used for characteristics ±1 V, but this ± characteristics can be configured to AI5 to AI8 inputs only! Sensor range (gray background) automatically follows the User sensor characteristics (zero value at the above picture is not important). Conversion from ±20 mA to ±100 % request InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 66 1. Create User sensor as below. 2. Configure user sensor instead default ± 20mA sensor. 3. Configure Bargraph 100% to correspond User sensor. Bargraph indicates full 0 to 100% range in this case. 1. Create sensor like below. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 67 User sensor examples Availability Configuration 0 - 20mA / 600 AI1 to AI4 AI5 to AI8 Analog input jumper = 1-2 (current) 4 - 20mA / 100,0 AI1 to AI4 AI5 to AI8 InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 68 AI1 to AI4 AI5 to AI8 Analog input jumper = 3-4 (resistance) Note: It is possible to set up to 30 points non-linear sensor characteristics. Connect external resistors (voltage divider) to extend input voltage range. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 69: Extension Modules
4.4.9 InternetBridge-NT 4.4.10 I-CB Communication bridge 4.4.11 I-AOUT8 4.4.1 Inteli AIN8 Image 4.5 Dimensions of Inteli AIN8 Inteli AIN8 unit can be mounted on DIN rail (35 mm). All dimensions are in mm. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 70: Inteli Ain8Tc
All dimensions are in mm. 4.4.3 Inteli IO8/8 (can be switched to IO16/0) Image 4.7 Dimensions of Inteli IO8/8 Inteli IO8/8 unti can be mounted on DIN rail (35 mm). All dimensions are in mm. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 71: Is-Bin 16/8
Address 1: AIN8(TC) module Thermo(nc) Address 2: AIO9/1 module Thermo(nc) – another position 3 is ocuppied by 9th input Address 4: AIO9/1 module Thermo(nc) – another position 5 is ocuppied by 9th input InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 72: Is-Ain8
Inteli AIO9/1unit can be mounted on DIN rail (35 mm). All dimensions are in mm. 4.4.6 IS-AIN8 Image 4.10 Dimensions of IS-AIN8 IS-AIN8 unit can be mounted on DIN rail (35 mm). All dimensions are in mm. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 73: Is-Ain8Tc
4.4.7 IS-AIN8TC Image 4.11 Dimensions of Inteli AIN8 Inteli AIN8 unit can be mounted on DIN rail (35 mm). All dimensions are in mm. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 74: Igs-Ptm
4.4.8 IGS-PTM Image 4.12 Dimensions of IGS-PTM All dimensions are in mm. IGS-PTM unit can be mounted on DIN rail (35 mm). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 75: Internetbridge-Nt
But: only one couple of balancing resistors has to be added on the whole RS485 line, and setpoint in ID-DCU CommSet called RS485 TermCSpd (page 122) has to be set to 57600 bps. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 76: I-Cb Communication Bridge
Note: In case of CAT engines, there is RS232 connection between I-CB and CCM. 4.4.11 I-AOUT8 General Description I-AOUT8 is an extension unit with 8 Analog outputs. Each analog output can be switched by jumper for. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 77 I-AOUT8 unit can be mounted on DIN rail (35 mm). Connection of Multiple Units Up to four modules can be connected to one controller. Set module CAN address corresponding to configuration according table below. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 78 Current output 0 to 20 mA Current output 0 to 20 mA Current output 0 to 20 mA Current output 0 to 20 mA Pwm output Voltage output 0 to 10 VDC 6 back to Installation and wiring InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 79: Controller Setup
Any used PLC Aout x can be configured as physical analog output.Used values are visible at controller screen. Unsigned value that is automatically used for Counter and Timer functions, 16 PLC resources are available. PLC resource Values are visible in InteliMonitor only. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 80: List Of Available Plc Functions
PLC Function Selection Available Number of available blocks in ID-DCU Marine 3.0.0 OR/AND 128x XOR/RS 128x Comp Hyst Comp Time Comp Win. Math Fc Ext Math Fc InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 81 PLC Function Selection Available Number of available blocks in ID-DCU Marine 3.0.0 Interpol Fc 'B' Nonlin I Fc Math AxB/C PID Bin PID Ana C Ramp Up/Down InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 82 PLC Function Selection Available Number of available blocks in ID-DCU Marine 3.0.0 Inc/Dec Mov Avg Timer Delay Delay B Ana Switch Force Hist Force Prot Jump InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 83: Plc Configuration Example
Based on adjustable pressure limits ID controller switch the engine between RPM1 to RPM2. When Pressure drops below Pressure ON limit engine increases from RPM1 to RPM2 and after Pressure increases above Press OFF limit goes back to RPM1. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 84 1. Start DriveConfig and open default archive ID-DCU-X.aid. 2. Pressure measuring: configure pressure sensor characteristic – suppose range 0 to 10,0 Bars on ID-DCU MARINE Analog input 4. Wrn and Sd protection limits should be adjusted over Pressure OFF limit. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 85 3. Go to PLC window and drag & drop PLC functional block Comp Hyst, double click the block. 4. Configure Comparator Input: click on button and select input value from the list. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 86 7. Drag & drop PLC functional block Ana Switch, configure Input 1 and Input 2 as PLC setpoints and edit the setpoint names to RPM 1 and RPM 2. 8. Configure binary Input SW: PLC values: PLC Bout 1.1. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 87 Speed governor output characteristics for Lo limit and Hi limit setting above. Speed governor output voltage in this case (when RPM1= 500 and RPM2=1800) is 9V when pressure is low and 2,5V when pressure is high 11. Final PLC layout in DriveConfig InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 88 Login by entering correct password and clicking red button Logout by clicking green button Create/change password by slicking on "Change" button To change password, current and new password must be entered. New password must be entered twice (match check) InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 89 If password is not used for any PLC sheet, password is removed immediately without warning. No need to enter correct password. To assign password to the PLC sheet, click on assign icon in title of PLC sheet: InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 90: Shared Io And Virtual Io
It is possible to share Binary and Analog values between all the controllers via CAN bus, thus saving physical Inputs and Outputs and excess wiring. How to add a virtual module is shown in the following picture. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 91 Note: Controller sends Shared Binary Outputs each 100ms if there are any changes in any bit position. If there are no changes, controller sends the information with period 1s. A protection upon module failure can be configured in GenConfig. See the schematic below. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 92: Distributed Binary Inputs And Outputs
Note: Controller sends Distributed Binary Outputs each 100ms if there are any changes in any bit position. If there are no changes, controller sends the information with period 1s. IMPORTANT: DISTBIN and DISTBOUT function is conditioned by IGS-NT-LSM+PMS dongle. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 93: Multiple Ecu Modules Support
Use Modules card in DriveConfig to configure support of ECU modules with the Insert/Remove buttons: IMPORTANT: Be aware that it is necessary to use ECU list, which enables use of multiple ECU modules. Check and select used ECU list using this option: InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 94 It is recommended to use this option and use different setting only if the default one does not work. Example: Set Module address to 5, if engine CAN1 address is 5. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 95 Note: Total number of available 4B analog input values is limited to 20 with all configured modules (e.g. 5 modules with 4 inputs would use all available inputs). 6 back to Controller setup InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 96: Communication
Tier 4 Final support generally provides monitoring and control of after-treatment system installed on generators engine. The requirements are defined as: Providing After-Treatment status information by displaying universal lamps (icons) displaying analog and binary values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 97 Image 6.2 Example of inactive Tier 4 Final screen Universal lamps (icons) Universal lamp icons are shown on the After-Treatment screen. Based on specific value read in specific frame with specific SPN is every lamp icon either: InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 98 Note: DPF = Diesel Particulate Filter; SCR = Selective Catalytic DPF/SCR lamp command Reduction. This lamp also activates alarm After- treatment Note: This lamp also Exhaust system high temperature activates alarm After- lamp command treatment InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 99 Fluid tank low level indicator activates alarm After- treatment Note: Indicates the state of diesel particulate filter active regeneration DPF regeneration inhibited inhibition. This lamp also activates alarm After- treatment 6 back to Communication InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 100: Technical Data
5 – 25 Hz, ±1.6mm Vibration 25 – 100 Hz, a = 4 g Shocks a = 200 m/s2 Heat radiation Dimensions and weight (183×123×47 mm) Dimensions See chapter terminals and dimensions Weight 800 g InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 101 ± 2 % ± 2 Ω out of measured value Voltage measurement tolerance ± 1 % ± 1 mV out of measured value Current measurement tolerance ± 1 % ± 0.5 mA out of measured value Group 2 AI5 – AI8 InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 102: Can Bus Interface
Recommended Industrial Automation & Process Control Cables: BELDEN (see http://www.belden.com): 3082A DeviceBus for Allen-Bradley DeviceNet 3083A DeviceBus for Allen-Bradley DeviceNet 3086A DeviceBus for Honeywell SDS 3087A DeviceBus for Honeywell SDS 3084A DeviceBus for Allen-Bradley DeviceNet InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 103 3105A Paired EIA Industrial RS485 cable LAPP CABLE (see http://www.lappcable.com) Unitronic BUS DeviceNet Trunk Cable Unitronic BUS DeviceNet Drop Cable Unitronic BUS CAN Unitronic-FD BUS P CAN UL/CSA 6 back to Technical data InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 104: Appendix
8 Appendix 8.1 Controller objects 6 back to Table of contents InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 105: Controller Objects
List of setpoint groups Password Engine commands and Statistics protection Basic settings Comms settings Engine params Engine protect RPMdep protect (PRP only) Load sharing Analog inputs Act. Calls/SMS Date and Time ID-SCM unit DetCon20 Protections InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 106 For full list of setpoints go to the chapter List of setpoints (page 107) 6 back to Controller objects InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 107 AIN2 Offset MinLoadSpeed Group of setpoints: AIN3 Offset Batt > V Engine parameters AIN4 Offset Batt < V Starting RPM AIN5 Offset Batt Volt Del Starting POil AIN6 Offset OverloadSpLim AIN7 Offset Overload Del InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 108 Group of setpoints: Date/Time Time Date Time Stamp Per SummerTimeMod EnTimeSync Group of setpoints: ID- SCM unit FreqRate1 FreqRate2 TransferRate1 TransferRate2 Group of setpoints: DetCon20 DelayLoadRed DecreaseRamp IgnRedLimit ImmStopLimit TimingRedGain 6 back to Controller objects InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 109 Has to be set before remote modem or SMS connection is opened. Can be up to 16 ASCII characters At first Password 3 has to be entered before the new Access code can be changed. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 110 ID-DCU MARINE version 2.1 and higher support independent password protection of Stop command according to description above. Note: All setpoints below can be modified from Remote panel or InteliMonitor as well. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 111 Mode ID [ OFF, AUX ] Mode ID [ OFF, EME ] Mode ID [ OFF, EME, HRB ] Mode ID [ OFF, PRP ] Equivalent to Controller mode changes by Mode→ or ←Mode buttons. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 112 Nominal engine speed, base for Overspeed protection limit and Engine Values: Speed Request percentage calculation. Note: Nominal RPM must correspond to 100% Throttle position in ECU for correct Load sharing function in PRP application. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 113 Activates/deactivates the logical binary output Nominal Sw, that can be configured as J1939 output to switch ECU. BIN.INPUT: IDLE/NOMINAL mode is switched via Binary input BI Nominal (NOMINAL when closed). 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 114 In case no ECU support is configured, internal running hours value is used despite RunHoursSource setting. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 115 Related FW 3.0.0 Range [units] [hh:mm:ss] Default value 0:00:00 Step Comm object 10042 Related applications Config level Standard Setpoint visibility Always Description Timer Repeat (page 116) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 116 Timer OFF. The function depends on Timer Repeat settings. The output is closed when controller is switched On and Timer settings corresponds to closed state. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 117 Other units IG-IB, IB-NT detect CAN bus speed automatically. Note: If the controller is connected to IB-NT, set the mode to 8C - verified stable communication speed. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 118 Message ECU Diag disabled is displayed in the alarm list while ECU diagnostics is disabled. The ECU Diagnostic is disabled/enabled using LBI:ECU DiagBlck binary input in case of setting to EXTERNAL. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 119 Related applications Config level Standard Setpoint visibility Always Description The setpoint adjusts communication speed of the RS232 interface when RS232 Mode (page 120) is set to MODBUS. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 120 RS232 Mode (page 120) is set to STANDARD. Note: If the controller is connected to IB-NT via the RS232 interface, set the speed to 57600 - the supported communication speed. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 121 ECU LINK: Connection to an electronic-controlled engine which uses non-J1939 ECU. The proper ECU type must be also configured with GenConfig. Note: Detailed description of Modbus protocol include some examples, see in InteliGen Communication guide. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 122 Normally a collision would be indicated if there were more sources on the bus and this setpoint can be used to disable the evaluation of collisions in this special case. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 123 Config level Standard Setpoint visibility Always Description “Firing” speed when controller stops cranking = one of the engine running indications. Note: Under speed limit is fix 30 RPM. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 124 Coolant pressure limit = one of the engine running indications. To activate this function any Analog input must be configured to Analog logical input Coolant press. Note: PRP only Note: Step, Range and dimension depend on corresponding Analog input sensor characteristic. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 125 CMB, EME: 3 ..200 [s], AUX, PRP: 0 .. 200 [-] Default value Step Comm object 8257 Related applications Config level Standard Setpoint visibility Always Description Pause between cranking attempts. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 126 Step Comm object 9946 Related applications Config level Standard Setpoint visibility Always Description Default Idle speed (should be the same as Idle speed set with engine ECU). 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 127 Idle time delay starts when RPM exceeds Starting RPM. During the Idle time the Binary output Idle/Nominal is opened and after then it is closed. Binary output Idle/Nominal opens during Cooling period (Cooling Time) again. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 128 Prelubrication starts PrelubrPause after engine stops. Prelubrication starts immediately when: - controller power supply turns on - mode changes from OFF to another - Emergency Stop is released 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 129 8662 Related applications Config level Standard Setpoint visibility Always Description Binary output Cooling Pump is closed when engine starts and opens with AfterCoolTime delay after engine stopping. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 130 CHRGFAIL: The D+ terminal is used for charge fail detection only DISABLED: The D+ terminal is not used. Note: Alternator magnetization current is provided independently from the parameter setting. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 131 If the gas engine is unsuccessful in starting the starter output will stay energized 25% longer in order to vent the remaining gas. Example of FUEL SOLENOID output behavior during unsuccessful start. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 132 DISABLED: Engine Values: Speed Request is changed via Binary inputs Speed Up, Speed Down or via Logical Analog input Requested RPM.see Speed Request (page 266) t charts for (page 267) (page 267) modes. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 133 ENABLED. Setpoint can be changed as standard setpoint or by Fast edit function: press Enter for 4 sec, / ¯ set value, press Enter to confirm. see Speed Request (page 266) charts for PRP and AUX / EME / HRB modes. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 134 #1) are started to be evaluated. The "running only" alarms are not beeing evaluated while the engine is not running or then, after start, while the adjusted delay is running. For details see drawing, which is part of RunOnlyBlkDel3 (page 136) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 135 #2) are started to be evaluated. The "running only" alarms are not beeing evaluated while the engine is not running or then, after start, while the adjusted delay is running. For details see drawing, which is part of RunOnlyBlkDel3 (page 136) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 136 Analog input Oil Press > Engine params: Starting Poil or Analog input Coolant Press > Engine params: StartPCoolant (PRP only) or Active Binary input RunIndication1 or Active Binary input RunIndication2 or Active Binary input RunIndication3. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 137 Binary input protection is activated when input is closed for longer time than BinInp delay 2. To use this filter, binary input protection Delay must be configured in DriveConfig to BinInp delay 2. For details see BinInp Delay 3 (page 138) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 138 BinInp delay x is active only for Binary inputs configured as protection and it is related to protection only. BinInp delay x does not affect optional logical function of an input. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 139 Delay for Force block protection activation after binary input Force Block 2 is opened. Protection deactivation is without delay. Protection is activated/deactivated independent on engine running or not running state. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 140 0 .. 200 [%] Default value Step 1% of Nominal RPM Comm object 8263 Related applications Config level Standard Setpoint visibility Always Description Threshold for engine overspeed protection. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 141 Range [units] Batt <V.. 40,0 [V] Default value 30,0 Step Comm object 9587 Related applications Config level Standard Setpoint visibility Always Description Warning level for battery over voltage. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 142 20,0 Step Comm object 9950 Related applications Config level Standard Setpoint visibility Always Description Engine overload protection limit. See Requested RPM, Overload protection (PRP only) (page 27) 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 143 DEFAULT: LBO: Common Wrn is activated , if ECU alarm is received by controller. ALARM ONLY: LBO: Common Wrn is not activated, if ECU alarm is received by controller. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 144 Standard Setpoint visibility Always Description Linear Warning characteristic is defined by two points for Idle RPM and Nominal RPM.OPIdleRPMWrn defines oil pressure warning level at idle speed. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 145 Linear Shutdown characteristic is defined by two points for Idle RPM and Nominal RPM.OPNomRPMSd defines oil pressure shutdown level at nominal speed. For details see OilPrRPMdel (page 146) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 146 Linear Warning characteristic is defined by two points for Idle RPM and Nominal RPM.CPIdleRPMWrn defines coolant pressure warning level at idle speed. For details see CoolPrRPMdel (page 148) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 147 Linear Shutdown characteristic is defined by two points for Idle RPM and Nominal RPM.CPNomRPMSd defines coolant pressure shutdown level at nominal speed. For details see CoolPrRPMdel (page 148) description. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 148 To activate RPM dependent coolant pressure protection any analog value has to be linked with LAI: Coolant Press. Note: RPM dependent coolant pressure protection is fix configured Protection block type = Engine running only with RunOnlyBlkDel1 delay. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 149 Average value calculated from all Speed Request values of controllers running in Loadsharing mode together (on the same CAN2 bus). See Load sharing block diagram (page 151). 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 150 RQSP Ramp Setpoint group Load sharing Related FW 3.0.0 Range [units] 0 .. 100 [%/s] Default value Step Comm object 10148 Related applications Config level Standard InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 151 ThrottlePos output (request to EMS) is switched to be equal to the Engine Values: Speed request after other engines clutches are disconnected (no load sharing, only one engine powers the shaft). 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 152 ThrottlePos Setpoint group Load sharing Related FW 3.0.0 Range [units] 0 .. 1000 [%] Default value Step Comm object 10000 Related applications Config level Standard InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 153 Note: Loadsharing state - the Loadsharing: Back Up Speed value is taken into account instead of Engine Values: Speed Request if the Logical Analog input Requested RPM indicates Sensor Fail (#####) and Logical Binary input Back Up Speed is active. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 154 Step Comm object 9949 Related applications Config level Standard Setpoint visibility Always Description Time between the clutch is switched on/off and the load sharing function is activated. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 155 Clutch can be switched on if ClutchMinSpeed < RPM < ClutchMaxSpeed. Limits are in % of Requested speed. See Requested RPM, Overload protection (PRP only) (page 27) Note: 0,0% corresponds to (Idle speed + Idle offset) value, 100,0% corresponds to Nominal speed. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 156 Engine clutch start protection. Start fail alarm is activated, if engine running condition is not detected during MaxClStrPer delay time after Binary output Clutch Connect is closed. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 157 Setpoint visibility Always Description Enables Wrn OthrCommEr warning message when no other unit is recognized on the CAN bus. Binary output OthrCommEr is closed in this case. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 158 Range [units] -32767 .. 32767 [-] Default value Step Comm object 8467 Related applications Config level Standard Setpoint visibility Always Description Adjustable offset for AIN3 for calibrating purposes. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 159 Range [units] -32767 .. 32767 [-] Default value Step Comm object 8795 Related applications Config level Standard Setpoint visibility Always Description Adjustable offset for AIN6 for calibrating purposes. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 160 Range [units] -32767 .. 32767 [-] Default value Step Comm object 11599 Related applications Config level Standard Setpoint visibility Always Description Adjustable offset for AIN8 for calibrating purposes. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 161 8485 Related applications Config level Standard Setpoint visibility Always Description Enables or disables active calls/SMS to selected phone or mobile numbers when a Cool down alarm occurs. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 162 Note: To receive DATA active call run InteliMonitor – Type of connection = Active call. InteliMonitor Active call window contains list of received AID files. Each list item contains Engine name, Date, Time, ID serial number. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 163 Note: To receive DATA active call run InteliMonitor – Type of connection = Active call. InteliMonitor Active call window contains list of received AID files. Each list item contains Engine name, Date, Time, ID serial number. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 164 Config level Standard Setpoint visibility Always Description Address for channel 1 active call. Each above message type has either phone number or e-mail address associated with it. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 165 Note: To receive DATA active call run InteliMonitor – Type of connection = Active call. InteliMonitor Active call window contains list of received AID files. Each list item contains Engine name, Date, Time, ID serial number. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 166 Number of rings prior to open modem connection from PC to controller. Note: Num Rings AA change is not accepted immediately, but only after controller is switched on or when modem is connected to controller. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 167 Note: Timeout for connection is 90 sec and after 120 sec controller starts the next attempt. Incoming calls are blocked when controller is trying to send active call message. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 168 The setpoint adjusts time interval of Time stamp history records. Note: No history Time stamp is recorded when TimeStamp Per = 0. RTC and Date is in each History record. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 169 The setpoint is used to enable Time synchronization function with InteliGen-NT and InteliSys-NT controllers over CAN2 bus. The synchronization is just unidirectional from InteliGen-NT or InteliSys-NT controller into InteliDrive- DCU Marine, not vice versa. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 170 Setpoint visibility Always Description Conversion ratio (number of pulses for increase by 1) for ID-SCM IMP 1 impulse input / SCM Imp1 value. Frequency range max. 60 Hz. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 171 Config level Standard Setpoint visibility DetCon20 support configured Description Delay after load reduction defines delay of timing signal reduction process after knocking level drops below the IgnRedLimit. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 172 Setpoint visibility DetCon20 support configured Description Immediate stop limit is knocking value above which DetCon20 binary output TRIP is activated. This causes engine to shut down if properly wired. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 173 Config level Standard Setpoint visibility DetCon20 support configured Description Timing reduction gain influences rate at which timing reduction signal (analog output) is amplified when knocking is detected. 6 back to List of setpoints InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 174: Binary Inputs
BinInp delay 1, 2, 3 that can be adjusted by corresponding Setpoint BinInp Delay 1, 2, 3. Input BI delay configuration Setpoint Standard (0,5s) BinInp delay 1 BinInp Delay 1 BinInp delay 2 BinInp Delay 2 BinInp delay 3 BinInp Delay 3 See setpoints BinInp delay 1 [s] etc… InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 175 User Mask 4 Fire Speed Watchdog test Rem Clutch StartBlocking1 6 back to Controller objects StartBlocking2 StartBlocking3 StartBlocking4 StartBlocking5 Load Blocking RunIndication1 RunIndication2 RunIndication3 Nominal Speed Loaded Emerg. Manual EnClutchStart Sd Override Speed Down InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 176 Note: Access Lock does not protect Setpoints change, Mode change and START, STOP commands from InteliMonitor (direct or modem). To avoid unqualified changes of the selected setpoints or commands use password protection. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 177 External modules Bin Inputs ...start/stop Remote OFF Remote HBR (RS232 or CAN2) STOP FLT RES HORN RES Setpoint change Mode change InteliMonitor START (serial line) STOP FLT RES HORN RES Setpoint change Mode change InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 178 Force Block 3 Related FW 3.0.0 Related applications Comm object Description Active input blocks protections that are configured as “Force Block 3” Prot. block type. Corresponding setpoint is ForceBlockDel3. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 179 Binary output Close load is closed/opened depends on the state of Remote On/Off binary input when engine RPM is over Engine protection: MinLoadSpeed. Remote On/Off is not active in LOC mode. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 180 IMPORTANT: This is a software function only. It can be extended by a "hard wired" emergency stop function, which means disconnecting power supply from the controller outputs. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 181 Active signal inhibits automatic DPF filter regeneration. 6 back to List of LBI RegenForce Related FW 3.0.0 Related applications Comm object Description Active signal inhibits automatic DPF filter regeneration. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 182 Inactive in MODE Note: The setpoint Crank Attempts is not followed if Sd Override is active, crank attempts number is then unlimited in case of Blackout Start. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 183 Description OR logical function of all StartBlocking Logical Binary inputs forces controller NotReady state ( i.e. disables engine start). It is active in LOC (Local) mode as well. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 184 6 back to List of LBI Load Blocking Related FW 3.0.0 Related applications Comm object Description Active input disables the Close load function. No influence when Binary output Close load is closed. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 185 Engine running state = RPM > Engine params: Starting RPM or Analog input Oil pressure > Engine params: Starting Poil or Active Binary input RunIndication1 or Active Binary input RunIndication2 or Active Binary input RunIndication3. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 186 Binary input activates Engine start via clutch. Engine is started by the other running engine via closed clutch - binary output Clutch Connect. See MaxClStrtPer (page 156) protection setpoint. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 187 Engine speed to specific like 1500 RPM value. Note: Minimal Speed Up and Speed Down pulse duration is 110ms to be accepted by controller. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 188 Fault reset button (screen sensitive - active only in ECU Alarm list screen). Note: Activation of ECU Fault reset will affect InteliDrive DCU Marine controller only, no reset request is sent to ECU. There is separated acknowledge input for Alarms – see Binary input...
Page 189 Start/Stop is still closed. To prevent unlimited number of starts – configure on LBO Start fail Sd protection. Note: Engine stays running when Rem Start/Stop is opened in controller LOC (Local) mode. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 190 Input simulates the panel Mode → button. 6 back to List of LBI Page Button Related FW 3.0.0 Related applications Comm object Description Input simulates the panel Page button. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 191 Input controls ECU Diagnostic functionality in case of setting ECU Diag = EXTERNAL. 6 back to List of LBI Clear DayCons Related FW 3.0.0 Related applications Comm object Description Rising edge clears Day consumption counter. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 192 Related FW 3.0.0 Related applications Comm object Description Rising edge forces to fill register Statistics: Memo2 by Logical Analog Input: Memory2 actual value. Memo2 Statistics value can be set or resetted by InteliMonitor command. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 193 Note: This function can be used to "swap" between two different screen instruments when certain conditions are fulfilled. Logical binary inputs Mask 1..4 can be used to define any custom condition for this "swapping" function. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 194 Note: This function can be used to "swap" between two different screen instruments when certain conditions are fulfilled. Logical binary inputs Mask 1..4 can be used to define any custom condition for this "swapping" function. 6 back to List of LBI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 195 Rising edge of this input will provide reset of controller processor. 6 back to List of LBI Binary inputs from J193 configuration Binary inputs protection Property: Function line is free, no logical function is (usually) selected. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 196: Binary Outputs
8.1.4 Binary outputs Depending on Modules configuration there are exist more groups of binary items that can be configured to any physical binary output. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 197 ECU6 Comm Fail Fuel Solenoid User Button 4 ECU7 Comm Fail Cooling Pump User Button 5 ECU8 Comm Fail Watchdog User Button 6 ECU10 Comm Fail Close Load User Button 7 CommError 10 InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 198 PLC Message 9 PLC Message 10 PLC Message 11 PLC Message 12 PLC Message 13 PLC Message 14 PLC Message 15 PLC Message 16 Emergency Stop Engine RPM Overload OthrCommEr ChrgAlternFail Stop Fail Overspeed InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 199 Binary output for Horn, Buzzer alarm acoustic indication. Output is automatically switched off after Engine protection: Horn timeout. Horn is active unlimited time (until Fault reset) when Horn timeout = 0. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 200 The output closes when any Cool-down alarm is active. Output opens when all Cd alarms disappear and Fault reset is pressed (no Cd alarm in Alarm list). 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 201 PRP Mode (PRP only) The output is closed in controller PRP mode. AUX Mode (AUX only) The output is closed in controller AUX mode. HRB Mode (CMB only) The output is closed in controller HRB mode. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 202 Output stays closed even if the RPM goes out of limits above. Can’t be opened by button when Binary input Rem Clutch is closed. BI Rem clutch is not active in LOC (Local) mode. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 203 Closed output energizes the engine starter. 6 back to List of LBO Stop Solenoid Related FW 3.0.0 Related applications Comm object Description Output is closed during engine stopping procedure. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 204 Comm object 1829 Description Active when continued operation could result in damage to exhaust system, but actual reason of the alarm may not be exhasut system related. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 205 Related FW 3.0.0 Related applications Comm object Description Closed output opens the fuel solenoid. Adjustable to DIESEL or GAS. See also the Fuel Solenoid (page 131) setpoint description. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 206 The output is closed/opened with rising edge of Binary input Rem On/Off (or I/0 front panel button) when engine is in Running state and engine RPM is over MinLoadSpeed. Output opens when RPM is below InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 207 "Nominal speed offset" = 0 × 3A = 58 % => speed offset = +8 rpm Referens speed to govenor at full load = 1500 + 8 = 1508 rpm 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 208 Active signal indicates low level of Diesel Exhaust Fluid (DEF). It starts flashing when the DEF tank is nearly empty (e.g. when the level is 10%), engine power may be reduced. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 209 6 back to List of LBO Logical 1 Related FW 3.0.0 Related applications Comm object Description Constant value that can be configured to any output (e.g. CurrentGear in Volvo-PRP). 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 210 Indicates any active protection configured as Shut down Override. 6 back to List of LBO Derating Alarm Related FW 3.0.0 Related applications Comm object Description Power derating indication, information received from communication bus. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 211 PLC input for example. 6 back to List of LBO StartButtEcho Related FW 3.0.0 Related applications Comm object Description 1 sec pulse is generated after panel Start button is pressed. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 212 1 sec pulse is generated after panel Horn reset button is pressed. 6 back to List of LBO ClutchButtEcho Related FW 3.0.0 Related applications Comm object Description 1 sec pulse is generated after panel I/0 button is pressed. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 213 Related FW 3.0.0 Related applications Comm object Description AirFlaps output is activated with engine starting (when controller enters state Cranking) and it is deactivated 5s after engine stopping. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 214 InteliVision function buttons can be assigned to these LBOs User Button 1 .. 16. The configuration of button’s functionality is done via Screen Editor feature in DriveConfig PC application. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 215 InteliVision function buttons can be assigned to these LBOs User Button 1 .. 16. The configuration of button’s functionality is done via Screen Editor feature in DriveConfig PC application. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 216 InteliVision function buttons can be assigned to these LBOs User Button 1 .. 16. The configuration of button’s functionality is done via Screen Editor feature in DriveConfig PC application. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 217 6 back to List of LBO RegenForce Related FW 3.0.0 Related applications Comm object Description Indicates that automatic DPF filter regeneration is forced using 181). EGEN ORCE PAGE 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 218 Comm object Description Those eight LBOs can be handled from InteliMonitor Remote switch window. This way can operator directly handle controller binary outputs or other e.g. PLC functions. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 219 Comm object Description Those eight LBOs can be handled from InteliMonitor Remote switch window. This way can operator directly handle controller binary outputs or other e.g. PLC functions. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 220 6 back to List of LBO SS-Status Related FW 3.0.0 Related applications Comm object 10213 Description Binary output Stop solenoid (SS) status when output is closed – see FS-Status (page 220) 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 221 RPU control Related FW 3.0.0 Related applications Comm object 10213 Description When closed ID-RPU module is active (after ID-DCU MARINE fail) for engine Sd and Overspeed protection. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 222 Description ID-RPU watchdog timer is over = ID-DCU MARINE fail when closed. Note: Fuel and Stop solenoid Broken wire indications are available in the list of Prg.states 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 223 Description J1939 communication fail indication. 6 back to List of LBO ECU4 Comm Fail Related FW 3.0.0 Related applications Comm object 2001 Description J1939 communication fail indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 224 2006 Description J1939 communication fail indication. 6 back to List of LBO CommError 10 Related FW 3.0.0 Related applications Comm object 2007 Description J1939 communication fail indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 225 Description J1939 communication fail indication. 6 back to List of LBO ECU16 Comm Fail Related FW 3.0.0 Related applications Comm object 2013 Description J1939 communication fail indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 226 6 back to List of LBO UnivState 3 Related FW 3.0.0 Related applications Comm object Description Universal states 1 to Universal states 7 indication. See Universal states (page 31) description. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 227 Related FW 3.0.0 Related applications Comm object Description The output is closed while the alarm generated by the PLC block Force Prot is present in the alarm list. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 228 Related FW 3.0.0 Related applications Comm object Description The output is closed while the alarm generated by the PLC block Force Prot is present in the alarm list. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 229 Related FW 3.0.0 Related applications Comm object Description The output is closed while the alarm generated by the PLC block Force Prot is present in the alarm list. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 230 Engine speed state indication. Output is closed when no RPM is received from J1939 (sensor fail) or Overspeed or Under speed is detected. 6 back to List of LBO Overload Related FW 3.0.0 Related applications Comm object Description Active overload protection activation. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 231 3.0.0 Related applications Comm object Description Engine overspeed indication. 6 back to List of LBO Underspeed Related FW 3.0.0 Related applications Comm object Description Under speed indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 232 6 back to List of LBO Not Lubricated Related FW 3.0.0 Related applications Comm object Description The lubrication cycle (PrelubrTime) is not finished after controller Switch on or return from OFF mode. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 233 Related applications Comm object Description It is closed when the battery B voltage of RPU is out of limits: Engine protection: Batt >V, Batt <V, Batt V del. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 234 3.0.0 Related applications Comm object Description Start blocking indication. 6 back to List of LBO ClutchBlocking Related FW 3.0.0 Related applications Comm object Description Clutch blocking indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 235 Source: Ana protections List of Analog inputs protection indication is dynamic. Any protection configured e.g. on Analog input appears in Source: Ana protection Binary output list. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 236 Source: Bin protections List of Binary inputs protection - indication is dynamic. Any protection configured on Binary input appears in Source: Bin protection. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 237 Source: Binary Inputs CU Binary CU list contains all ID-DCU MARINE binary inputs that can be configured to Binary outputs. This source contains binary inputs physical states (no protection activity). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 238 Indication of ID-RPU Shut down 3 input state. RPU-SD 4 Indication of ID-RPU Shut down 4 input state. RPU-SD 5 Indication of ID-RPU Shut down 5 input state. EmStop RPU Indication of ID-RPU Emergency stop input state. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 239 Source: Binary Inputs List (depend on modules configuration) contains all Extension modules binary inputs that can be configured to any Binary outputs. This source contains binary inputs physical states (no protection activity). InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 240 Comm object Description Engine overspeed indication. 6 back to List of LBO OilPress Related FW 3.0.0 Related applications Comm object Description Oil pressure out of limit indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 241 Oil temperature out of limit indication. 6 back to List of LBO CoolantLevel Related FW 3.0.0 Related applications Comm object Description Coolant level out of limit indication. 6 back to List of LBO InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 242: Analog Inputs
Binary output to J1939 configuration: Source-Value 8.1.5 Analog Inputs InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 243 Cyl Temp 7 Cyl Temp 8 Cyl Temp 9 Cyl Temp 10 Cyl Temp 11 Cyl Temp 12 Cyl Temp 13 Cyl Temp 14 Cyl Temp 15 Cyl Temp 16 6 back to Controller objects InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 244 6 back to List of LAI Coolant Press (PRP only) Related FW 3.0.0 Related applications Comm object Description Running indication and speed dependable protection in PRP. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 245 Fuel Rate [ l/h ] or separate Actual Fuel consumption sensor connected to physical Analog input. Both statistics values is possible to modify in InteliMonitor – Set Statistics command or clear by Logical Binary Inputs ClearDayCons or ClearTripCons. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 246 6 back to List of LAI BoatSpeed Related FW 3.0.0 Related applications Comm object Description Analog input for boat speed value [kts], which is used for MomAvgFlCon L (page 282) calculation 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 247 Page, Page, select the new language by up/down arrows, Enter) Note: Translate text “OilPress” and “CoolTemp” - no space between words because of similar texts (e.g. Coolant Temp, etc. are located on other screens). 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 248 Page, Page, select the new language by up/down arrows, Enter) Note: Translate text “OilPress” and “CoolTemp” - no space between words because of similar texts (e.g. Coolant Temp, etc. are located on other screens). 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 249 Input Memory1 or Memory2 value in the time of Logical Binary input Memo1 Trigger or Memo2 Trigger rising edge. Both statistics values is possible to modify in InteliMonitor – Set Statistics command. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 250 IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module with index #2 etc. Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 251 IS-AIN8 (TC) module with index #1, Cold Temp 2 corresponds to IS-AIN8 (TC) module with index #2 etc. Note: Thermocouples without internal compensation "Thermo(nc)..." must be used for this case. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 252 Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI Cyl Temp 6 Related FW 3.0.0 Related applications Comm object Description Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 253 Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI Cyl Temp 12 Related FW 3.0.0 Related applications Comm object Description Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 254 Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI Cyl Temp 16 Related FW 3.0.0 Related applications Comm object Description Analog inputs for engine Cylinder temperature measuring. 6 back to List of LAI InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 255 Analog inputs from J1939 configuration InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 256 1. Switch to I-O , analog inputs, e.g. ID-AIN8 2. Switch to Expert mode 3. Configure standard two level protection Expert field is now empty. This field is visible in Expert mode only. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 257 5. Add the third protection: “+” button, and edit Property (e.g. Wrn, Under, ….) Any protection limit/delay can be set to Constant (then value is fixed, specified in line below) and can not be changed by customer (not included in setpoint list) … or … InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 258 In example above there is Wrn limit type set to Const = 60. There is visible setpoint corresponding to Wrn, Over protection. It is possible to change limit name, value and limits. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 259 Use “+” button to add new limit for the third (Wrn, Under) protection. Name “Limit3” can be changed. Limit and Delay type must be in this case set to “Setpoint” Use “+” button to add Delay setpoint and set/change name value and limits. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 260 1. Select free universal state for selected protection Note: Configure this UnivState to some Binary output and modify Bin output Name. Oil pressure and Water temperature on the first ID controller screen indication 1. Reading from ID-DCU MARINE analog inputs InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 261 2. Reading from J1939 logical function Please note that Protections can be configured as well. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 262: Values
Shut down is activated in the case of sensor fail as well Sd override This protection stays active in the case of Sd override is activated. Alarm only Only Alarm list indication, disappear without confirmation HistRecOnly History record only 8.1.6 Values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 263 Longitude Oil Press GPS Speed AIN CU 2 AIN CU 3 Group of values: AIN CU 4 Statistics AIN CU 5 RunHours AIN CU 6 NumSuccStarts AIN CU 7 NumUnscStarts AIN CU 8 InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 264 3.0.0 Resolution [units] 1 [-] Comm object 10135 Related applications Description Text string value containing "LOC" or empty text string depending on Activated or Deactivated LOC mode. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 265 Engine Values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 266 Speed Request Value group Engine values Related FW 3.0.0 Resolution [units] 1 [%] Comm object 10137 Related applications InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 267 Description Internal Speed Request value which can be used to control engine speed. See following flow charts how the Speed Request value is generated in case of PRP or AUX/EME/HRB mode. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 268 AUX/CMB/EME conversion 0,0% = 0.9 * NominalRPM, 100,0% = 1.1 * NominalRPM In the case of sensor fail (out of range) is Sped request = 0 for PRP and 50% (=Nominal RPM) for AUX configuration. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 269 Cool Temp Value group Engine values Related FW 3.0.0 Resolution [units] 1 [°C] Comm object 10267 Related applications Description Internal value corresponding to Logical Analog input Coolant Temp 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 270 Analog input value corresponding to analog input located directly on ID-DCU controller. Note: The name "Ain CU 2" is just default value which can be changed in analog input Property: Name. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 271 Analog input value corresponding to analog input located directly on ID-DCU controller. Note: The name "Ain CU 6" is just default value which can be changed in analog input Property: Name. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 272 Analog input value corresponding to analog input located directly on ID-DCU controller. Note: The name "Ain CU 8" is just default value which can be changed in analog input Property: Name. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 273 6 back to List of values ID BOUT Value group Binary CU Related FW 3.0.0 Resolution [units] Comm object 8239 Related applications Description Controller binary outputs state indication. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 274 6 back to List of values LogBout 5 Value group LogBout Related FW 3.0.0 Resolution [units] Comm object 9147 Related applications Description List of logical binary outpus. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 275 Related applications Description List of logical binary outpus, which can be closed and opened remotely, e.g. from InteliMonitor using the "Remote switches" tool or using MODBUS communication. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 276 3.0.0 Resolution [units] Comm object 24339 Related applications Description Major and minor firmware version number. E.g. value "2,2" means version 2.2. Release version number is not included. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 277 Value group Info Related FW 3.0.0 Resolution [units] 1 [s] Comm object 8955 Related applications Description The value contains remaining time of the currently running system process timer. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 278 States of predefined ECU alarms, which are available with Modbus reading. Note: Alarm linked with a specific bit is defined in ESC (Engine Specific Code) and is not user configurable. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 279 Value group Info Related FW 3.0.0 Resolution [units] 0,1 [kts] Comm object 12165 Related applications Description Speed in knots received from IB-NT (1 knot = 1,852 km/h). 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 280 Statistics values. Adjust the timer to the requested maintenance interval. It will be decremented while the engine is running. The alarm WrnServiceTime is issued as soon as the timer counts down to zero. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 281 Input Memory1 or Memory2 value in the time of Logical Binary input Memo1 Trigger or Memo2 Trigger rising edge. Both statistics values is possible to modify in InteliMonitor – Set Statistics command. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 282 0,1 [/nm] Comm object 11321 Related applications Description Momentary average fuel consumption per nautical mile. It is available, if both LAI: FuelConsump and LAI: BoatSpeed are configured. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 283 DEF Level Value group Aftertreatment Related FW 3.0.0 Resolution [units] 1 [%] Comm object 14522 Related applications Description Indicates aftertreatment Diesel Exhaust Fluid tank level in percent. 6 back to List of values InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 284 Following are examples of transfer characteristics 0 - 100% to 4 – 20mA. The first case is transfer characteristics -25 - 100% to 0 – 20mA, it contains the needed conversion to 4 – 20mA. InteliDrive DCU Marine - 3.0.0 Global Guide...
Page 285 6 back to Appendix 6 back to Table of contents InteliDrive DCU Marine - 3.0.0 Global Guide...
