Setpoint: Dwell Time
Group Sync/Load Ctrl
0 ... 25.0 [s]
Range [units]
Related All
applications
Description The period of time that the phase angle difference must be within +/-
Window
closed.
Setpoint: Freq Gain
Group Sync/Load Ctrl
Range [units] 0 ... 200.0 [%]
Related All
applications
Description Gain of the frequency control PI loop.
Setpoint: Freq Int
Group Sync/Load Ctrl
Range [units] 0 ... 100 [%]
Related All
applications
Description Relative integration factor of the frequency control loop.
Setpoint: Angle Gain
Group Sync/Load Ctrl
Range [units] 0 ... 200.0 [%]
Related All
applications
Description Gain of the phase angle control loop.
During synchronization, first the frequency loop is started to match the
generator frequency with the mains or bus and after that the phase angle
loop is started to match the phase angle.
