Binary output: Breaker Trip
Related All
applications
Description The output is designed for auxiliary breaker tripping.
The output closes if:
-
-
It opens if:
-
-
Binary output: kWh pulse
Related All
applications
Description This output generates a 100 ms pulse whenever the internal kWh counter is
incremented.

16.4.2 ECU info

Binary output: ECU Comm OK
Related All
applications
Description This output is active when an ECU is configured, connected and the
communication with the ECU is established.
Binary output: ECU Comm Error
Related All
applications
Description This output is active when an ECU is configured, but the communication with
the ECU is not established or has dropped out.
Binary output: ECU YellowLamp
Related All
applications
This output is active when the ECU sends an active "yellow lamp" flag, i.e. it
Description
has detected a non-critical malfunction. This flag is taken from the DM1
frame on standard J1939 ECUs. Some ECUs provide this flag in their own
proprietary frames and some do not provide the flag at all.
NT
InteliCompact , SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
a fast opening of the GCB occurs due to any error (overcurrent, short
current etc.)
any BOC or SD alarm appears or Emergency Stop is active
No BOC and SD alarms are active and
FAULT RESET is pressed
