FIGURE B–5.
C o n n e c t o r :
M 5 x 4 P i n A C o d e d ( M )
Table B–6 describes the signals for the HETLC-050 Lighting control cable.
TABLE B–6.
M5 Pin
1
2
3
4
Rev. 1H, Mar 2009
HETLC-050 Lighting Control Cable
H E T L C - 1 0 0 - L i g h t i n g
HETLC-050 Lighting Control Cable Signals
Signal Name
Light_Out
Light_Rtn
Strobe_Out
Strobe_Rtn
Visionscape® Smart Camera HE1600T Guide
HETLC-050 - Lighting Control Cable
C o n t r o l C a b l e
Wire Color Description
Brown Light Output
White Light Output Return
Blue Strobe Output
Black Strobe Output Return
B
B r o w n L i g h t O u t
W h i t e L i g h t R t n
B l u e S t r o b e O u t
B l a c k S t r o b e R t n
B-5
