Displaying the Output of a Datum

Copying a Symbolic Name to the Clipboard

Use the following procedure to copy a symbolic name to the Clipboard:
In FrontRunner, stop your Job if it's still running.
1.
Click Editor.
2.
In the left pane, click on the tool that contains the datum(s) you want to copy
3.
to the Clipboard (Figure 4–14).
In the right pane, click Show Output Datums (Figure 4–14).
4.
In the right pane, put the mouse pointer on the datum whose symbolic name
5.
you want to copy to the Clipboard (Figure 4–14).
Right click and select "Copy Symbolic Name to Clipboard":
6.
FIGURE 4–14.
FrontRunner will display a message to the effect that "<symbol> was saved
to the clipboard".
Click OK.
7.
Close the Editor.
8.
Restart your Job in FrontRunner.
9.
Rev. 1H, Mar 2009
Copy Symbolic Name to Clipboard
Visionscape® Smart Camera HE1600T Guide
Displaying the Output of a Datum
Show Output Datums
4
4-19
