Chapter 2
System Components
"HawkEyeXXXXXX," where XXXXXX is the last six alphanumeric
characters in its MAC address. So, for the Visionscape
HE1600T with MAC address 00:60:33:E1:FF:FA, the default network name
is "HawkEyeE1FFFA".
• Optional IntelliFind License Key (applies to HE1610TIS & HE1610TIH
only)

Power-on Sequence

Each stage of the power-on sequence drives the LEDs in a binary up-count
fashion according to Table 2–5. The LEDs illuminate before the test is executed
and remain in that pattern until the next test is run or an error condition is
detected and displayed.

Error Codes

In the event of an error being detected, the beeper beeps five times and an error
code (in binary form) representing the test that failed flashes on the LEDs. The
LEDs continue to flash until the <Escape> character is sent on the serial port, at
which point an error message is logged to the serial port and the Diagnostic
Monitor is launched. The serial port terminal server must be set to the following
parameters: 115200, 8, N, 1.
Table 2–5 describes the Mode/Status LED power-on sequence and error codes.
TABLE 2–5.
Mode
2-8
Mode/Status LED Power-On Sequence & Error Codes
Fail Pass Trig
•
•
•
•
• •
• •
Visionscape® Smart Camera HE1600T Guide
Test Performed
• Data Line Test
Address Line Test
• Bootloader CRC Check
Kernel CRC Check
• RS-232 Internal Loopback
FPGA Load Test
• FPGA PCI Config Test
®
Smart Camera
Rev. 1H, Mar 2009
