APPENDIX F
This appendix describes how to connect an Allen-Bradley ControlLogix PLC to
the Visionscape
knowledge of TCP/IP, the CIP protocol (Ethernet/IP), and Rockwell RSLogix
5000 software. For more information on the CIP protocol, visit www.odva.org.
For more information on installing, configuring, and using RSLogix as well as
identifying Rockwell-specific hardware, visit www.rockwell.com.
This information was written against the hardware and software setup listed in
Table F–1. The screen shots and examples assume this hardware; therefore,
adjust the Rockwell-specific settings in the examples to comply with your
specific hardware set.
TABLE F–1.
Software/Hardware
1756-A4 4-slot Chassis
ControlLogix 5555 PLC Using
1756-ENBT Ethernet Bridge
Rockwell RSLogix 5000
Visionscape
HE1600T
Rev. 1H, Mar 2009
Ethernet/IP Communication
with ControlLogix PLCs
®
Smart Camera HE1600T. You should have a working
Hardware & Software Configuration
®
Smart Camera
Visionscape® Smart Camera HE1600T Guide
Notes
slot 0
Static class C IP address is 10.2.1.172,
using slot 1
v16.21
v3.7.3 software must be downloaded to
camera, static class C IP address is
10.2.1.20
F
F-1
