Chapter 3
Ethernet/IP Communications
results in the Input Assembly to the Output Assembly that was latched at the start
of the same inspection cycle.
DINT 2: Camera Control Register
TABLE 3–2.
BIT
0
1
2
3
4...31
DINT 2: Camera Status Register
TABLE 3–3.
BIT
0
1
2
3
4...31
Commands sent to the Control Register are ignored when the camera is offline;
the camera must be online before sending a Start trigger.
3-6
Control Register Bit Definitions
Meaning
Stop, transition 0->1 to stop inspections
Start, transition 0->1 to start inspections
Clear error, transition 0->1 to clear Last Error
Clear command status, transition 0->1 to clear command stat
Reserved
Status Register Bit Definitions
Meaning
System Online
1 = System is online and a job is loaded on the camera
0 = Camera is not ready for inspection to go online; it is either
loading a job or no job is loaded on the system.
Inspection Online
1 = Inspection is online, the job is running on the camera
0 = Inspection is offline
Command Complete. Cleared by issuing 'Clear Command Status'
1 = Last issued command has completed
0 = Last issued command is being processed
Command Succeeded. Updated when command is completed.
Cleared by issuing 'Clear Command Status'
1 = Success
0 = Failure, check Last Error for more information
Reserved
