Chapter 2
System Components
TABLE 2–2.
(Continued)
Port Name Protocol
Reports & TCP
Statistics Control
Port
Serial TCP Ports TCP
Camera UDP
Login/Command
Port
Camera Announce UDP
Port

Serial Port Connectivity

FrontRunner always communicates over Ethernet with the Visionscape
Camera HE1600T; however, the Serial port is fully supported by the Job in the
form of allowing Serial triggers and Serial ASCII reporting output via the
Acquire, Digital Input and Formatted Output Tools.
The serial string(s) are formatted using the *printf C syntax*. Special characters
can be used and are summarized in Table 2–3.
TABLE 2–3.
Sequence
\a
\b
\f
\n
\r
\t
\v
\'
2-4
®
Visionscape Smart Camera HE1600T TCP/IP Connectivity
Number Note
49202 Allow control over a Report Connection, in particular
update rate and allows records to be added/removed
from the connection.
49211 Send Formatted Output Strings serially over TCP as
49212 programmed in the by the Formatted Output Step
49213
49214
49493 Gains control to the camera in order to edit and modify
its network parameters. A network login to the camera
is required to gain control with the HE1600.
49495 Broadcasts HE1600T Smart Camera identity on the
current subnet used by Network View in FrontRunner,
provides general counters, camera name, IP, IP in
control, camera status, and camera software version.
Special Characters
Output Character
Bell (alert)
Backspace
Formfeed
New line
Carriage return
Horizontal tab
Vertical tab
Single quotation mark
Visionscape® Smart Camera HE1600T Guide
®
