Appendix D
Setting Up Network Communications
To check a camera IP address, simply select the camera in FrontRunner Network
Overview.
To check a host PC IP address1:
At the DOS prompt, type:
1.
ipconfig
®
Visionscape Smart Camera HE1600T Boot Parameters
The Visionscape
in Non-Volatile memory. You can edit these by connecting a Serial cable to the
camera and HyperTerminal. The communication parameters must be set to
115200-No Parity-8-1-No Flow Control.
Note: The Visionscape
be set to 'No Parity'.

Changing Network Parameters

To change network parameters:
Start a HyperTerminal session with the communication parameters set to
1.
115200-No Parity-8-1-No Flow Control.
While you hold down the Escape key, cycle power on the Visionscape
2.
Smart Camera HE1600T. Information similar to the following is displayed:
HawkEye Smart Camera
400MHz 16MB Flash 64MB RAM
-----------------------------
Name: HawkEyeE1000E
Static IP: 161.218.121.183
Network Mask: 255.255.255.0
Gateway: 0.0.0.0
DHCP: 1
MAC Address: 00:60:33:e1:12:34
1. Modify User Parameters
2. Reset User Account
3. Exit to Application
>>
Type 1 to begin stepping through network parameters.
3.
D-4
®
Smart Camera HE1600T stores network and other parameters
®
Smart Camera HE1600T parity parameter must always
