Mounting Using Accessory Mounting Block

You can mount the Visionscape
mounting block (see Figure 2–6). The backward compatible mounting block
positions a Visionscape
Visionscape
FIGURE 2–6.

Location for Backward Compatible Mounting Block

Figure 2–7 shows the screw hole locations for the backward compatible
mounting block.
FIGURE 2–7.
M4 x .7 x 10 Screws
Rev. 1H, Mar 2009
®
®
Smart Camera HE1600T in the same position as a
®
Smart Camera HE1600 for optical alignment.
Accessory Mounting Blocks
Part Number - 98-HT00-0CM2
Location for Backward Compatible Mounting Block
Visionscape® Smart Camera HE1600T Guide
Visionscape® Smart Camera HE1600T
Smart Camera HE1600T using the accessory
M3 x .5 x 6 Screw
