Visionscape Smart Camera HE1600T Models
Table 1–1 lists and describes the Visionscape
including acquisition modes and resolutions.
TABLE 1–1.
Number
GMV-0HT16-0CM0G
GMV-1HT16-0CM0G
GMV-0HF16-0CM0G
GMV-1HF16-0CM0G
The Visionscape
inspections.
Rev. 1H, Mar 2009
Visionscape® Smart Camera HE1600T Models
®
Visionscape Smart Camera HE1600T Models & Resolutions
Model
HE 1610TS
(Standard Resolution)
HE 1610TH
(High Resolution)
HE 1610TIS
(Standard Resolution w/IntelliFind)
HE 1610TIH
(High Resolution w/IntelliFind)
®
Smart Camera HE1600T supports up to a maximum of four
Visionscape® Smart Camera HE1600T Guide
®
Smart Camera HE1600T models,
Resolution
FullScan: 648x494
PartialScan:Half: 648x227
Quarter: 648x81
Binning:324x242
FullScan: 1024x768
PartialScan:Half: 1024x344
Quarter: 1024x137
Binning:512x370
FullScan: 648x494
PartialScan: Half: 648x227
Quarter: 648x81
Binning:324x242
FullScan: 1024x768
PartialScan: Half: 1024x344
Quarter: 1024x137
Binning:512x370
1
1-5
