Chapter
4
Visualization HMIs
The default behavior is:
Images and counters are for the first inspection in the job
All images (pass & fail) are shown
The display is refreshed automatically at regular intervals (auto=on)
Graphics are overlaid on the image
Note: For performance reasons, not all graphics are available when viewing
images on the web page. Only vector graphics are displayed.
The border around the image signifies the status of the inspection
(green=pass, red=fail)
The Runtime Image Page is accessed through a URL that contains the IP address
of the camera, and optional parameters. The default page is accessed by
specifying the IP address of the camera in a web browser. For example:
http:// 161.218.121.58
(example only; use actual IP address of the HE1600T)
If no previous settings have been set by the user, the display will be similar to the
screen in Figure 4–1
4-2
Visionscape® Smart Camera HE1600T Guide
Rev. 1H, Mar 2009
