8.3. Parameter Options

All parameters in the VLT ® AQUA Drive FC 200 are listed in the following tabels.

8.3.1. How to Read the Parameter Tabels

Changes during operation
"TRUE" means that the parameter can be changed while the frequency converter is in operation and "FALSE" means that the frequency converter must
be stopped before a change can be made.
4-Set-up
'All set-up': the parameter can be set individually in each of the four set-ups, i. e. one single parameter can have four different data values.
'1 set-up': data value will be the same in all set-ups.
Conversion index
This number refers to a conversion figure used when writing or reading by means of a frequency converter.
Conv. index 100 67
Conv. factor 1 1/60 1000000 100000
Data type Description
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible String
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
SR = Size related
6 5 4 3
10000 1000 100
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
2 1 0 -1 -2
10 1 0.1 0.01
-3 -4 -5 -6
0.001 0.0001 0.0000 0.000001
1
