Danfoss VLT AQUA Drive Operating Instructions Manual page 144

10. Specifications
Protection and Features:
• Electronic thermal motor protection against overload.
• Temperature monitoring of the heatsink ensures that the frequency converter trips if the temperature reaches 95 °C ± 5°C. An overload tem-
perature cannot be reset until the temperature of the heatsink is below 70 °C ± 5°C (Guideline - these temperatures may vary for different
power sizes, enclosures etc.). The frequency converter has an auto derating function to avoid it's heatsink reaching 95 deg C.
• The frequency converter is protected against short-circuits on motor terminals U, V, W.
• If a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
• Monitoring of the intermediate circuit voltage ensures that the frequency converter trips if the intermediate circuit voltage is too low or too high.
• The frequency converter is protected against earth faults on motor terminals U, V, W.
Mains supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cosφ) near unity
Switching on input supply L1, L2, L3 (power-ups) ≤ enclosure type A
Switching on input supply L1, L2, L3 (power-ups) ≥ enclosure type B, C
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS symmetrical Amperes, 500/600/690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency
Switching on output
10
Ramp times
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
*Percentage relates to VLT AQUA Drive's nominal torque.
Cable lengths and cross sections:
Max. motor cable length, screened/armoured
Max. motor cable length, unscreened/unarmoured
Max. cross section to motor, mains, load sharing and brake *
Maximum cross section to control terminals, rigid wire
Maximum cross section to control terminals, flexible cable
Maximum cross section to control terminals, cable with enclosed core
Minimum cross section to control terminals
* See Mains Supply tables for more information!
Control card, RS-485 serial communication:
Terminal number
Terminal number 61
The RS-485 serial communication circuit is functionally separated from other central circuits and galvanically isolated from the supply voltage (PELV).
144
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
®
VLT AQUA Drive
Operating Instructions
380-480 V ±10%
525-690 V ±10%
50/60 Hz
3.0 % of rated supply voltage
≥ 0.9 nominal at rated load
(> 0.98)
maximum 2 times/min.
maximum 1 time/min.
overvoltage category III/pollution degree 2
0 - 100% of supply voltage
0 - 1000 Hz
Unlimited
1 - 3600 sec.
maximum 110% for 1 min.
maximum 135% up to 0.5 sec.
maximum 110% for 1 min.
VLT AQUA Drive: 150 m
VLT AQUA Drive: 300 m
1.5 mm 2 /16 AWG (2 x 0.75 mm
1 mm 2 /18 AWG
0.5 mm 2 /20 AWG
0.25 mm
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
*
*
*
2 )
2
