5. Electrical installation
All types of three-phase asynchronous standard motors can be connected
to the frequency converter. Normally, small motors are star-connected
(230/400 V, D/Y). Large motors are delta-connected (400/690 V, D/Y).
Refer to the motor name plate for correct connection mode and voltage.
NB!
In motors without phase insulation paper or other insulation reinforcement suitable for operation with voltage supply (such as a fre-
quency converter), fit a sine-wave filter on the output of the frequency converter. (Motors that comply with IEC 60034-17 do not require
5
an Sine-wave filter).
No. 96
U1
W2
U1
No. 99
PE
Table 5.6: 3 and 6 cable motor connection.

5.1.10. Motor wiring overview

Enclosure:
Motor size:
200-240 V
380-480 V
Goto:
Table 5.7: Motor wiring table.
32
97 98 Motor voltage 0-100% of mains voltage.
U V W 3 cables out of motor
V1 W1
6 cables out of motor, Delta-connected
U2 V2
V1 W1 6 cables out of motor, Star-connected
U2, V2, W2 to be interconnected separately
(optional terminal block)
Earth connection
A2 A3
(IP 20/ (IP 20/
IP 21) IP 21)
0.25-3.0 3.7
kW kW
0.37-4.0 5.5-7.5
kW kW
5.1.11
MG.20.M4.02 - VLT
Illustration 5.12: Terminals for motor connection
A5 B1
(IP 55/ (IP 21/
IP 66) IP 55/IP 66) IP 55/IP 66)
0.25-3.7 5.5-7.5
kW kW
0.37-7.5 11-18.5
kW kW
5.1.12 5.1.13
®
is a registered Danfoss trademark
VLT
Operating Instructions
B2 C1
(IP 21/ (IP 21/
IP 55/IP 66) IP 55/IP 66)
11-15 18.5-22
kW kW
22-30 37-55
kW kW
5.1.14
®
AQUA Drive
C2
(IP 21/
30-45
kW
75-90
kW
