8. How to programme the frequency converter
8.2.7. 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals.
The digital inputs are used for selecting various functions in the frequency converter. All digital inputs can be set to the following functions:
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
DC-brake inverse
Stop inverse
External interlock
Start
Latched start
Reversing
Start reversing
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Pulse input
Ramp bit 0
8
Mains failure inverse
Run Permissive
Hand start
Auto start
DigiPot Increase
DigiPot Decrease
DigiPot Clear
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
Sleep Mode
Reset Maintenance Word
Lead Pump Start
Lead Pump Alternation
Pump 1 Interlock
Pump 2 Interlock
Pump 3 Interlock
All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/ are the terminals on MCB 101.
Functions dedicated to only one digital input are stated in the associated parameter.
All digital inputs can be programmed to these functions:
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse Reset and coasting stop Inverted input (NC).
[5] DC-brake inverse
[6] Stop inverse
76
Select
[0]
[1]
[2]
[3]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[32]
[34]
[36]
[52]
[53]
[54]
[55]
[56]
[57]
[60]
[61]
[62]
[63]
[64]
[65]
[66]
[78]
[120]
[121]
[130]
[131]
[132]
No reaction to signals transmitted to terminal.
Resets frequency converter after a TRIP/ALARM. Not all alarms can be reset.
Leaves motor in free mode. Logic '0' => coasting stop.
(Default Digital input 27): Coasting stop, inverted input (NC).
Leaves motor in free mode and resets the frequency converter. Logic '0' => coasting stop and reset.
Inverted input for DC braking (NC).
Stops motor by energizing it with a DC current for a certain time period. See par. 2-01 to par. 2-03. The function
is only active when the value in par. 2-02 is different from 0. Logic '0' => DC braking.
Stop Inverted function. Generates a stop function when the selected terminal goes from logical level '1' to '0'.
The stop is performed according to the selected ramp time (par. 3-42, par. 3-52, par. 3-62, par. 3-72).
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
Operating Instructions
Terminal
All *term 32, 33
All
All
All
All
All
All
All *term 18
All
All *term 19
All
All *term 29
All
All
All
All
All
All
All
All
All
All
term 29, 33
All
All
All
All
All
29, 33
29, 33
All
29, 33
29, 33
All
®
