VLT AQUA Drive
Operating Instructions
5-13 Terminal 29 Digital Input
Option:
*
No Operation
[0]
5-14 Terminal 32 Digital Input
Option:
* No Operation
[0]
5-15 Terminal 33 Digital Input
Option:
* No Operation
[0]
5-40 Function Relay
Array [8]
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
[0] No Operation
[1] Control Ready
[2] Drive Ready
[3] Drive Ready/Remote
[4] Stand-by/No Warning
* Running
[5]
[6] Running/No Warning
[8] Run on Ref./No Warn-
ing
[9] Alarm
[10] Alarm or Warning
[11] At Torque Limit
[12] Out of Current Range
[13] Below Current, low
[14] Above Current, high
[15] Out of Speed Range
Setting in Par. 5-1*
[130] Pump1 Interlock
[131] Pump2 Interlock
[132] Pump3 Interlock
[133] Pump4 Interlock
[134] Pump5 Interlock
[135] Pump6 Interlock
[136] Pump7 Interlock
[137] Pump8 Interlock
[138] Pump9 Interlock
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
Function:
Same options and functions as par. 5-1*
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
Setting in Par. 25-06
[0] No [1] Yes
Controlled by RELAY1 Frequency Converter controlled
(only if not lead pump) (cannot be interlocked)
Controlled by RELAY2 Controlled by RELAY1
Controlled by RELAY3 Controlled by RELAY2
Controlled by RELAY4 Controlled by RELAY3
Controlled by RELAY5 Controlled by RELAY4
Controlled by RELAY6 Controlled by RELAY5
Controlled by RELAY7 Controlled by RELAY6
Controlled by RELAY8 Controlled by RELAY7
Controlled by RELAY9 Controlled by RELAY8
Digital Inputs
.
Digital Inputs Pulse input
, except for
Digital Inputs
.
(Relay 1 [0], Relay 2 [1], Relay 7 [6], Relay 8 [7], Relay 9 [8])
.
