8. How to programme the frequency converter

8.1. How to programme

8.1.1. Parameter Set-Up
Overview of parameter groups
Group Title
0- Operation / Display
1- Load / Motor
2- Brakes
3- Reference / Ramps
4- Limits / Warnings
5- Digital In/Out
6- Analog In/Out
8- Communication and Options
9- Profibus
10- DeviceNet Fieldbus
11- LonWorks
13- Smart Logic
14- Special Functions
15- Drive Information
16- Data Readouts
18- Info and Readouts
20- Drive Closed Loop
21- Extended Closed Loop
22- Application Functions
23- Time-based Functions
25- Basic Cascade Controller Functions
26- Analog I/0 Option MCB 109
27- Extended Cascade Control
29- Water Application Functions
31- Bypass Option
Table 8.1: Parameter Groups
Parameter descriptions and selections are displayed on the graphic (GLCP) or numeric (NLCP) in the display area. (See Section 5 for details.) Access the
parameters by pressing the [Quick Menu] or [Main Menu] key on the control panel. The quick menu is used primarily for commissioning the unit at start-
up by providing those parameters necessary to start operation. The main menu provides access to all parameters for detailed application programming.
All digital input/output and analog input/output terminals are multifunctional. All terminals have factory default functions suitable for the majority of water
applications but if other special functions are required, they must be programmed in parameter group 5 or 6.
8.1.2. Quick Menu Mode
The GLCP provides access to all parameters listed under the Quick Menus. To set parameters using the [Quick Menu] button:
Pressing [Quick Menu] the list indicates the different areas contained in the Quick menu.
Efficient Parameter Set-up for Water Applications
The parameters can easily be set up for the vast majority of the water and wastewater applications only by using the [Quick Menu].
The optimum way to set parameters through the [Quick Menu] is by following the below steps:
1. Press [Quick Setup] for selecting basic motor settings, ramp times, etc.
2. Press [Function Setups] for setting up the required functionality of the frequency converter - if not already covered by the settings in [Quick
Setup].
General Settings
3. Choose between
Function
Parameters related to the fundamental functions of the frequency converter, function of
the LCP buttons and configuration of the LCP display.
Parameter group for motor settings.
Parameter group for setting brake features in the frequency converter.
Parameters for reference handling, definitions of limitations, and configuration of the re-
action of the frequency converter to changes.
Parameter group for configuring limits and warnings.
Parameter group for configuring the digital inputs and outputs.
Parameter group for configuration of the analog inputs and outputs.
Parameter group for configuring communications and options.
Parameter group for Profibus-specific parameters.
Parameter group for DeviceNet-specific parameters.
Parameter group for LonWorks parameters
Parameter group for Smart Logic Control
Parameter group for configuring special frequency converter functions.
Parameter group containing frequency converter information such as operating data,
hardware configuration and software versions.
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm,
warning and status words.
This parameter group contains the last 10 Preventive Maintenance logs.
This parameter group is used for configuring the closed loop PID Controller that controls
the output frequency of the unit.
Parameters for configuring the three Extended Closed Loop PID Controllers.
These parameters monitor water applications.
These parameters are for actions needed to be performed on a daily or weekly basis, e.g.
different references for working hours/non-working hours.
Parameters for configuring the Basic Cascade Controller for sequence control of multiple
pumps.
Parameters for configuring the Analog I/0 Option MCB 109.
Parameters for configuring the Extended Cascade Control.
Parameters for setting water specific functions.
Parameters for configuring the Bypass Option
Open Loop Settings Closed Loop Settings.
, and
®
