8. How to programme the frequency converter
[32] Pulse input
[34] Ramp bit 0
[36] Mains failure inverse
[52] Run Permissive
[53] Hand start
[54] Auto start
8
[55] DigiPot Increase
[56] DigiPot Decrease
[57] DigiPot Clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Preventive Main-
tenance Word
The below setting options are all related to the Cascade Controller. Wiring diagrams and settings for parameter, see group 25-** for more details.
[120] Lead Pump Start
[121] Lead Pump Alternation Forces alternation of the lead pump in a Cascade Controller.
[130 - 138] Pump1
Pump9 Interlock
78
(Default Digital input 32)
Select Pulse input when using a pulse sequence as either reference or feedback. Scaling is done in par. group
5-5*.
Select which ramp to use. Logic "0" will select ramp 1 while logic "1" will select ramp 2.
Mains Failure
Activates par. 14-10
The input terminal, for which the Run permissive has been programmed must be logic "1" before a start com-
mand can be accepted. Run permissive has a logic 'AND' function related to the terminal which is programmed
START Jog
for [8], [14] or
conditions must be fulfilled. If Run Permissive is programmed on multiple terminals, Run permissive needs only
be logic '1' on one of the terminals for the function to be carried out. The digital output signal for Run Request
Start Jog
( [8], [14] or
not be affected by Run Permissive.
A signal applied will put the frequency converter into Hand mode as if button
pressed and a normal stop command will be overridden. If disconnecting the signal, the motor will stop. To
make any other start commands valid, another digital input must be assign to
Hand On
to this. The
Hand Start Auto Start
and
again. If no signal on neither
command applied. If signal applied to both
the Off button on the LCP the motor will stop regardless of signals on
A signal applied will put the frequency converter into Auto mode as if the LCP button
See also Hand Start [53]
Uses the input as an INCREASE signal to the Digital Potentiometer function described in parameter group 3-9*
Uses the input as a DECREASE signal to the Digital Potentiometer function described in parameter group 3-9*
Uses the input to CLEAR the Digital Potentiometer reference described in parameter group 3-9*
(Terminal 29 or 33 only) Input for increment counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter A.
(Terminal 29 and 33 only) Input for increment counting in the SLC counter.
(Terminal 29 and 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter B.
Forces frequency converter into Sleep Mode (see par. 22-4*, Sleep Mode). Reacts on the rising edge of signal
applied!
Resets all data in par. 16-96, Preventive Maintenance Word, to 0.
Starts/Stops the Lead Pump (controlled by the frequency converter). A start requires that also a System Start
signal has been applied e.g. to one of the digital inputs set for
either At Command [2] or
the four options.
Interlock - For the above 9 setting options, par. 25-10, Pump Interlock, must be set to
on the setting in par. 25-06, Fixed Lead Pump. If set to
relay RELAY1 etc. If set to
any of the build in relays involved) and Pump2 to the pump controlled by the relay RELAY1. Variable speed pump
(lead) cannot be interlocked in the basic Cascade Controller.
See below table:
MG.20.M4.02 - VLT
. Mains failure inverse is active in the Logic "0" situation.
Freeze Output
[20], which means that in order to start running the motor, both
Freeze output
[20]) programmed in par. 5-3* Digital outputs, or par. 5-4* Relays, will
Auto On
and buttons on the LCP has no impact. The
Hand On Auto On
. Press either the or
Hand Start Auto Start
nor , the motor will stop regardless of any normal Start
Hand Start and Auto Start
At Staging or At Command [3].
No
Yes
[1], Pump1 refers to the pump controlled by the frequency converter only (without
®
