VLT AQUA Drive
Operating Instructions
6-25 Terminal 54 high ref./feedb. value
Range:
*
100.000 Unit [Par. 6-24 to
1000000.000]
6-50 Terminal 42 Output
Option:
[0] No operation
*
Output frequency
[100]
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to lim
[105] Torque rel to rated
[106] Power
[107] Speed
[113] Ext. closed loop 1
[114] Ext. closed loop 2
[115] Ext. closed loop 3
[130] Output freq. 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20 mA
[134] Torque % lim. 4-20 mA :0 - Torque limit (par. 4-16)
[135] Torque % nom 4-20
mA
[136] Power 4-20 mA
[137] Speed 4-20 mA
[139] Bus ctrl. 0-20 mA
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl. 0-20 mA, time-
out
[142] Bus ctrl. 4-20 mA, time-
out
[143] Ext. Closed Loop 1,
4-20 mA
[144] Ext. Closed Loop 2,
4-20 mA
[145] Ext. Closed Loop 3,
4-20 mA
NB!
Values for setting the Minimum Reference is found in par. 3-02
Open Loop
par. 3-03 and par. 20-14
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in par. 6-21 and
par. 6-23.
Function:
Select the function of Terminal 42 as an analog current output.
: 0 - 100 Hz
: Minimum reference - Maximum reference
: -200% to +200% of par. 2-14
: 0 - Inverter Max. Current (par. 16-37)
: 0 - Torque limit (par. 4-16)
: 0 - Motor rated torque
: 0 - Motor rated power
: 0 - Speed High Limit (par. 4-13 and par. 4-14)
: 0 - 100%
: 0 - 100%
: 0 - 100%
:0 - 100 Hz
:Minimum Reference - Maximum Reference
:-200% to +200% of par. 2-14
:0 - Inverter Max. Current (par. 16-37)
:0 - Motor rated torque
:0 - Motor rated power
:0 - Speed High Limit (par. 4-13 and par. 4-14)
:0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
Open Loop
Closed Loop
.
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
Closed Loop
and par. 20-13 - values for Maximum Reference is found in
