Danfoss VLT AQUA Drive Operating Instructions Manual page 70

8. How to programme the frequency converter
NB!
Please consult the
0-21 Display Line 1.2 Small
Option:
*
Analog input 53
[1662]
0-22 Display Line 1.3 Small
Option:
*
Motor Current
[1614]
0-23 Display Line 2 Large
Option:
8
* Frequency
[1615]
0-24 Display Line 3 Large
Option:
* Feedback [Unit]
[1652]
0-37 Display Text 1
Option:
0-38 Display Text 2
Option:
0-39 Display Text 3
Option:
70
®
VLT AQUA Drive Programming Guide, MG.20.OX.YY
Function:
Select a variable for display in line 1, middle position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 1, right position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Small
.
Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Small .
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read via serial
communication. If to be displayed permanently select Display Text 1 in par. 0-20, par. 0-21, par. 0-22, par. 0-23
Display Line XXX
or par. 0-24, . Use the
buttons to move the cursor. When a character is highlighted by the cursor, it can be changed. Use the
▼
buttons on the LCP to change a character. A character can be inserted by placing the cursor between two
▲ ▼
characters and pressing or
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read via serial
communication. If to be displayed permanently select Display Text 2 in par. 0-20, par. 0-21, par. 0-22, par. 0-23
or par. 0-24, Display Line XXX . Use the
buttons to move the cursor. When a character is highlighted by the cursor, this character can be changed. A
character can be inserted by placing the cursor between two characters and pressing
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read via serial
communication. If to be displayed permanently select Display Text 3 in par. 0-20, par. 0-21, par. 0-22, par. 0-23
MG.20.M4.02 - VLT
for detailed information.
Display Line 1.1 Small
Display Line 1.1 Small
▲ ▼
or buttons on the LCP to change a character. Use the
.
▲ ▼
or buttons on the LCP to change a character. Use the
®
is a registered Danfoss trademark
®
VLT AQUA Drive
Operating Instructions
.
.
Display Line 1.1
Display Line 1.1
◀ ▶
and
▲
or
◀ ▶
and
▲ ▼
or .
