VLT AQUA Drive
Operating Instructions
22-26 Dry Pump Function
Option:
* Off
[0]
[1] Warning
[2] Alarm
22-27 Dry Pump Delay
Range:
*
60 sec. [0-600 sec.]
22-30 No-Flow Power
Range:
[Depends on the power size detec-
tion of No-Flow]
22-31 Power Correction Factor
Range:
100% [1-400%]
22-32 Low Speed [RPM]
Range:
0 RPM [0.0 - par. 4.13 (Motor High
Speed Limit)]
22-33 Low Speed [Hz]
Range:
*
0 Hz [0.0 - par. 4-14 (Motor High
Speed Limit)]
22-34 Low Speed Power [kW]
Range:
*
0 [0.0 - par. 22-38]
22-35 Low Speed Power [Hp]
Range:
*
0 [0.0 - Par. 22-39]
22-36 High Speed [RPM]
Range:
*
0 RPM [0.0 - par. 4-13 (Motor High
Speed Limit)]
Function:
Low Power Detection
must be Enabled (par. 22-21) and commissioned (using either par. 22-3*,
Tuning Auto Set-Up
, or par. 22-20 ) in order to use Dry Pump Detection.
Messages in the Local Control Panel display (if mounted) and/or signal via a relay or a digital output.
The frequency converter trips and motor stays stopped until reset.
Function:
Defines for how long the Dry Pump condition must be active before activating Warning or Alarm
Function:
Read out of calculated No Flow power at actual speed. If power drops to the display value the frequency converter
will consider the condition as a No Flow situation.
Function:
Make corrections to the calculated power at No Flow Detection (see par. 22-30).
If No Flow is detected the setting should be increased to above 100%. If however No Flow is not detected the
setting should be decreased.
Function:
Motor Speed Unit
To be used if par. 0-02,
Set used speed for the 50% level.
This function is used for storing values needed to tune No Flow Detection.
Function:
To be used if par. 0-02, Motor Speed Unit
Set used speed for the 50% level.
The function is used for storing values needed to tune No Flow Detection.
Function:
Regional Settings
To be used if par. 0-03,
selected).
Set power consumption at 50% speed level.
This function is used for storing values needed to tune No Flow Detection.
Function:
To be used if par. 0-03, Regional Settings
selected).
Set power consumption at 50% speed level.
This function is used for storing values needed to tune No Flow Detection.
Function:
Motor Speed Unit
To be used if par. 0-02,
Set used speed for the 85% level.
The function is used for storing values needed to tune No Flow Detection.
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
, has been set for RPM (parameter not visible if Hz selected).
, has been set for Hz (parameter not visible if RPM selected).
, has been set for International (parameter not visible if North America
, has been set for North America (parameter not visible if International
, has been set for RPM (parameter not visible if Hz selected).
No Flow Power
