7. How to operate the frequency converter
7.1.14. PC Software tools
PC Software - MCT 10
All Frequency converters are equipped with a serial communication port. Danfoss provides a PC tool for communication between PC and frequency
converter, VLT Motion Control Tool MCT 10 Set-up Software.
MCT 10 Set-up Software
MCT 10 has been designed as an easy to use interactive tool for setting parameters in our frequency converters. The software can be downloaded from
the Danfoss internet site http://www.vlt-software.com.
The MCT 10 Set-up Software will be useful for:
• Planning a communication network off-line. MCT 10 contains a
complete frequency converter database
• Commissioning frequency converters on line
• Saving settings for all frequency converters
MCT 10 Set-up Software supports Profibus DP-V1 via a Master class 2 connection. It makes it possible to on line read/write parameters on-line in a
frequency converter via the Profibus network. This will eliminate the need for an extra communication network.
Save Frequency Converter Settings:
1. Connect a PC to the unit via USB com port. (Note: Use a PC, which is isolated from the mains, in conjunction with the USB port. Failure to do
7
so may damage equipment.)
2. Open MCT 10 Set-up Software
3. Choose "Read from drive"
4. Choose "Save as"
All parameters are now stored in the PC.
Load Frequency Converter Settings:
1. Connect a PC to the frequency converter via USB com port
2. Open MCT 10 Set-up software
3. Choose "Open"– stored files will be shown
4. Open the appropriate file
5. Choose "Write to drive"
All parameter settings are now transferred to the frequency converter.
A separate manual for MCT 10 Set-up Software is available: MG.10.R2.02.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
Ordering number:
Please order the CD containing MCT 10 Set-up Software using code number 130B1000.
MCT 10 can also be downloaded from the Danfoss Internet: WWW.DANFOSS.COM, Business Area: Motion Controls.
60
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Casade Control Config. Tool
®
MG.20.M4.02 - VLT
• Replacing a frequency converter in a network
• Simple and accurate documentation of frequency converter set-
tings after commissioning.
• Expanding an existing network
• Future developed frequency converters will be supported
