4. Mechanical installation
4
Mechanical dimensions
Voltage:
200-240 V
380-480 V
Encapsula-
tion
Height 1)
Height A
Distance be-
tween
a
mounting
holes
Width 1)
Width B
Distance be-
tween
b
mounting
holes
Depth
Depth C
Screw
holes
c
d
e
f
Max.
weight
Table 4.4: A5, B1, B2, B3, B4, C3 and C4 mechanical dimensions.
1) The dimensions state the maximum height, width and depth needed for mounting the frequency converter, when the top cover is mounted.
22
Frame size Frame size Frame size
A5 B1 B2
0.25-3.7 5.5-11 kW 15 kW
kW 11-18.5 kW 22-30 kW
0.37-7.5
kW
IP55/66 IP21/55/66 IP21/55/66
420 mm 480 mm 650 mm
402 mm 454 mm 624 mm
242 mm 242 mm 242 mm
215 mm 210 mm 210 mm
195 mm 260 mm 260 mm
8.25 mm 12 mm 12 mm
ø12 mm ø19 mm ø19 mm
ø6.5 mm ø6.5 mm ø6.5 mm
9 mm 9 mm 9 mm
13.5 / 14.2 23 kg 27 kg
MG.20.M4.02 - VLT
Frame size Frame size Frame size
B3 B4 C1
5.5-11 kW 15-18.5 18.5-30 kW
11-18.5 kW 37-55 kW
kW 22-37 kW
IP20 IP20 IP21/55/66
399 mm 520 mm 680 mm
380 mm 495 mm 648 mm
165 mm 230 mm 308 mm
140 mm 200 mm 272 mm
232 mm 239 mm 310 mm
8 mm - 12.5 mm
ø19 mm
12 mm -
ø6.8 mm ø8.5 mm ø9
7.9 mm 15 mm 9.8
12 kg 23.5 kg 45 kg
®
is a registered Danfoss trademark
®
VLT AQUA Drive
Operating Instructions
Frame size Frame Frame
C2 size C3 size C4
30-45 kW 22-30 37-45
75-90 kW kW kW
45-55 75-90
kW kW
IP21/55/66 IP20 IP20
770 mm 550 mm 660 mm
739 mm 521 mm 631 mm
370 mm 380 mm 370 mm
334 mm 270 mm 330 mm
335 mm 330 mm 330 mm
12.5 mm - -
ø19 mm
- -
ø9 ø8.5 ø8.5
9.8 17 17
65 kg 35 kg 50 kg
