VLT AQUA Drive
Operating Instructions
[5] Select setup 4
[10] Select preset ref. 0
[11] Select preset ref. 1
[12] Select preset ref. 2
[13] Select preset ref. 3
[14] Select preset ref. 4
[15] Select preset ref. 5
[16] Select preset ref. 6
[17] Select preset ref. 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set dig. out. A low
[33] Set dig. out. B low
[34] Set dig. out. C low
[35] Set dig. out. D low
[36] Set dig. out. E low
[37] Set dig. out. F low
[38] Set dig. out. A high
[39] Set dig. out. B high
[40] Set dig. out. C high
[41] Set dig. out. D high
[42] Set dig. out. E high
[43] Set dig. out. F high
[60] Reset counter A
[61] Reset counter B
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7
23-02 OFF Time
Array [10]
*
00:00:00 [00:00:00 –23:59:59]
Sets the OFF time for the Timed Action.
®
MG.20.M4.02 - VLT is a registered Danfoss trademark
8. How to programme the frequency converter
8
95
