4. Mechanical installation
4
Mechanical dimensions
Voltage
200-240 V
Voltage
380-480 V
Encapsulation
Height
Height of back plate
Distance between
holes
Width
Width of back plate
Distance between
holes
Depth
Depth without option A/B
With option A/B
Without option A/B
With option A/B
Screw holes
Maximum weight
Table 4.3: A2 and A3 mechanical dimensions
NB!
Option A/B are serial communication and I/O options, which when fitted increase the depth on some enclosure sizes.
20
Frame size A2
0.25-3.0 kW
0.37-4.0 kW
IP20
A 268 mm
mounting
a 257 mm
B 90 mm
mounting
b 70 mm
C 205 mm
C 220 mm
D
D
c 8.0 mm
d ø11 mm
ø5.5 mm
e
f 9 mm
4.9 kg
MG.20.M4.02 - VLT
IP21/Type 1 IP20
375 mm 268 mm
350 mm 257 mm
90 mm 130 mm
70 mm 110 mm
205 mm 205 mm
220 mm 220 mm
207 mm
222 mm
8.0 mm 8.0 mm
ø11 mm ø11 mm
ø5.5 mm ø5.5 mm
9 mm 9 mm
5.3 kg 6.6 kg
®
is a registered Danfoss trademark
®
VLT AQUA Drive
Operating Instructions
Frame size A3
3.7 kW
5.5-7.5 kW
IP21/Type 1
375 mm
350 mm
130 mm
110 mm
205 mm
220 mm
207 mm
222 mm
8.0 mm
ø11 mm
ø5.5 mm
9 mm
7.0 kg
