Page 1: Service Manual
X65x Series Machine Type 7462-xxxx Service Manual • Start diagnostics • Maintenance • Safety and notices • Trademarks • Index June 28, 2016 www.lexmark.com P/N 12G9823...
Page 2: Product Information
Trademarks Lexmark and the Lexmark logo are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard Company’s designation of a set of printer commands (language) and functions included in its printer products.
Page 3: Table Of Contents
7462 Table of contents Product information..................2 Edition notice....................2 Notices and safety information..............19 Laser notices............................... 19 Safety information............................. 22 Preface......................27 Service manual conventions...........................27 Change history..............................27 General information..................31 Media guidelines..............................31 Paper Guidelines ................................31 Using recycled paper and other office papers....................33 Supported paper sizes, types, and weights ......................
Page 4 7462 No fuse check ................................58 Paper jams................................59 Avoiding jams ................................60 Understanding jam messages and locations......................61 200-201 paper jams..............................62 202-203 paper jams..............................85 230 paper jams................................98 231-239 paper jams ..............................107 241-245 paper jams ..............................117 250 paper jams................................133 260 paper jams................................134 27y paper jams................................139 28y paper jams ................................148...
Page 5 7462 Memory full, cannot print faxes..........................188 Network/Network <x>..............................189 No analog phone line connected to modem, fax is disabled.................189 No answer ..................................189 No dial tone..................................189 Queued for sending..............................189 Ready.....................................189 Reattach bin <x>................................189 Reattach bin <x> – <y> ..............................190 Reattach envelope feeder............................190 Receive complete................................191 Receiving page <n>...
Page 6 7462 38 Memory full ................................195 39 Complex page, some data may not have printed ..................195 42.xy Cartridge region mismatch ...........................195 50 PPDS font error..............................195 51 Defective ﬂash detected .............................196 52 Not enough free space in ﬂash memory for resources ................196 53 Unformatted ﬂash detected..........................196 54 Network <x>...
Page 7 7462 Defective print cartridge service check.......................204 Paper is too short service check .......................... 205 Resource Save off deﬁcient memory service check..................205 Insufficient Collation Area service check......................206 Insufficient Memory service check ........................206 Memory Full service check ............................ 206 Complex page service check..........................207 Cartridge Region Mismatch service check ......................207 PPDS Font Error service check..........................207...
Page 8 7462 DUPLEX TESTS ................................267 INPUT TRAY TESTS ..............................270 OUTPUT BIN TESTS ..............................270 BASE SENSOR TEST ..............................271 DEVICE TESTS ................................272 PRINTER SETUP.................................272 EP SETUP ..................................274 REPORTS ..................................276 EVENT LOG................................. 277 SCANNER TESTS............................... 277 Conﬁguration menu............................279 Maintenance page count ............................279 Maintenance page counter reset..........................279 USB Scan to Local..............................279 Print quality pages..............................279...
Page 9 7462 Repair information................... 289 Removal precautions............................. 290 Handling ESD‑sensitive parts..........................290 Adjustments..............................291 Adjusting skew................................291 Flatbed scanner skew adjustment........................293 ADF skew adjustment (via ADF document tray)....................293 ADF skew adjustment (via duplex LED assembly)....................295 Media squareness check ............................297 Print skew correction procedure...........................299 Copy skew correction procedure ..........................301 Printer skew speciﬁcations .............................302 Handling ESD-sensitive parts..........................304...
Page 10 7462 Sensor (input) removal ............................334 Front side removals............................335 Charge roll assembly removal ..........................335 Inner deﬂector removal............................337 Media turn guide removal ............................338 MPF lift plate assembly removal..........................338 MPF media out actuator removal ..........................339 MPF pick roll assembly removal..........................339 MPF tray door assembly removal (models X651, X652, X654, X656) ............340 MPF tray door assembly removal (model X658)....................
Page 11 7462 Media support removal............................376 Output cover assembly removal (models X651, X652, X654, X656)............376 Output cover assembly removal (model X658)....................377 Printhead assembly removal ..........................377 MPF cam gear removal..........................379 Redrive motor assembly removal....................... 379 Sensor (duplex input) removal........................382 Sensor (standard bin exit) removal ......................
Page 12 7462 550-sheet tray controller card assembly removal.....................413 550-sheet tray option drive shaft with spring removal ..................414 Anti-tip latch assembly removal..........................415 High capacity input tray (HCIT) removals....................417 High capacity input tray (HCIT) media tray assembly removal............... 417 High capacity input tray (HCIT) tray cover, front removal ................418 High capacity input tray (HCIT) cover, rear removal..................420 High capacity input tray (HCIT) cover, right removal..................421 High capacity input tray (HCIT) cover, left removal ..................423...
Page 13 7462 Offset stacker paddle drive motor assembly removal..................457 Sensor (offset stacker media stack) removal .....................458 Sensor (offset stacker paddle HP) removal ......................459 Sensor (offset stacker tamper HP left and right) removal................460 Sensor (offset stacker bin full send) removal......................461 Sensor (offset stacker bin full receive) removal ....................462 Sensor (offset stacker deﬂector HP) removal ....................462 Stapler/stacker controller card assembly removal ...................463 Other removals..............................
Page 14 7462 MFP stapler assembly LED sensor cover removal ...................489 Sensor (MFP stapler assembly ﬁnisher media bin present) removal............490 MFP stapler assembly standard output bin LED and LED clear lens removal ...........491 MFP stapler assembly tamper drive belt removal ....................492 MFP stapler assembly tamper drive motor assembly removal ..............492 MFP stapler assembly media stack ﬂap and media stack ﬂap actuator removal........493 MFP stapler assembly stapler unit assembly removal..................494 MFP stapler assembly paddle drive motor assembly removal ..............495...
Page 15 7462 Scanner unit assembly removal (models X651, X652, X654, and X656)............531 Scanner unit assembly removal (model X658)....................533 ADF removals..............................534 ADF feed/pick roll assembly removal ........................534 ADF separator roll removal.............................535 ADF separator torque limiter assembly removal ....................536 ADF front cover removal ............................537 ADF rear cover removal............................538 ADF document tray assembly removal .......................539 ADF top door assembly removal...........................539...
Page 16 7462 Lubrication guide............................567 Individual maintenance part expected life....................567 Scheduled maintenance..........................568 Maintenance kits................................568 Cleaning the printer parts..........................569 Cleaning the exterior of the printer ........................569 Cleaning the scanner glass ............................569 Parts catalog..................... 572 Legend................................572 Assembly 1: Covers (X651, X652, X654, and X656)................573 Assembly 2: Covers 1 (X658)........................577 Assembly 3: Covers 2 (X658)........................
Page 17 7462 Assembly 28: MFP 4-bin mailbox assembly #3..................635 Assembly 29: Envelope feeder........................637 Assembly 30: Miscellaneous........................639 Assembly 31: Power cords..........................641 Assembly 32: Universal trays and accessories..................643 Appendix A: Printer speciﬁcations............645 Power consumption............................645 Product power consumption ..........................645 Power Saver................................645 Off mode..................................646 Total energy usage ..............................646...
Page 18 7462 High capacity input tray (HCIT) tray assembly....................673 250-sheet/550-sheet tray assembly........................674 Paper path, rolls, and sensors..........................677 Media tray assembly..............................680 Duplex ..................................682 Appendix D: Acronyms................685 Acronyms................................685 Index......................687 Part number index..................699 Part name index..................713 Table of contents...
Page 19: Notices And Safety Information
7462 Notices and safety information Laser notices Laser notice The printer is certiﬁed in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certiﬁed as a Class I laser product conforming to the requirements of IEC 60825-1.
Page 20 7462 Aviso de láser Esta impresora se ha certiﬁcado en EE. UU. de conformidad con los requisitos de DHHS 21 CFR, capítulo I, subcapítulo J, para los productos láser de Clase I (1), y en otros países está certiﬁcada como un producto láser de Clase I de acuerdo con los requisitos de IEC 60825-1.
Page 21 7462 Luokan I lasertuotteita ei pidetä haitallisina. Tulostimen sisällä on luokan IIIb (3b) laser, joka on nimellisteholtaan 5 mW:n galliumarsenidilaser ja toimii 770–795 nanometrin aallonpituuksilla. Laserjärjestelmä ja tulostin ovat rakenteeltaan sellaisia, että käyttäjä ei joudu alttiiksi luokkaa 1 suuremmalle säteilylle normaalin käytön, ylläpidon tai huollon aikana.
Page 22: Safety Information
7462 Class I 레이저 제품은 위험한 제품으로 간주되지 않습니다. 프린터에는 770-795 나노미터의 파장 영역에서 작 동하는 공칭 5밀리와트 갈륨 비소 레이저인 클래스 IIIb(3b) 레이저가 내부에 포함되어 있습니다. 레이저 시스 템과 프린터는 정상적인 작동, 사용자 유지 관리 또는 사전 설명된 서비스 조건에는 사람에게 클래스 I 수준 이 상의...
Page 23 7462 AVERTISSEMENT—RISQUE DE BLESSURE La batterie lithium de ce produit n'est pas destinée à être remplacée. Il existe un risque d'explosion si une batterie lithium est placée de façon incorrecte. Ne rechargez pas, ne démontez pas et n’incinérez pas une batterie lithium. Mettez les batteries lithium usagées au rebut selon les instructions du fabricant et les réglementations locales.
Page 24 7462 PRECAUCIÓN: POSIBLES DAÑOS PERSONALES La batería de litio de este producto no debe reemplazarse. Existe riesgo de explosión si se sustituye incorrectamente una batería de litio. No recargue, desmonte ni incinere una batería de litio. Deseche las baterías de litio según las instrucciones del fabricante y las normativas locales. Informações de Segurança •...
Page 25 7462 安全信息本产品的安全性以原来设计和特定产品的测试结果和认证为基础。万一使用来经许可的替换部件，制造商 • 不对安全性负责。本产品的维护信息仅供专业服务人员使用，并不打算证其他人使用。 • 本产品在拆卸、维修时，遭受电击或人员受伤的危险性会增高，专业服务人员对这点必须有所了触，并采 • 取必要的预防措施。当心一可能的伤害：本产品中的锂电池不可更换。如果不正确更换锂电池，可能会有爆炸危险。不要再充电、拆解或焚烧锂电池。丢弃旧的锂电池时应按照制造商的指导及当地法规进行处理。 Notices and safety information...
Page 26 7462...
Page 27: Preface
7462 Preface This manual contains maintenance procedures for service personnel. It is divided into the following chapters: • General information contains a general description of the printer. Special tools and test equipment are discussed. • Diagnostic information contains diagnostic aids you can use to isolate failing FRUs. These diagnostic aids include error code tables, symptom tables, and service checks.
Page 28: June
7462 May 19, 2016 • Updated the 250‑ and 550‑sheet tray assemblies (Assemblies 15 and 17) to remove the following parts that are not anymore FRUs: – Tray front cover – Tray right cover – Tray left cover January 8, 2016 •...
Page 29 7462 April 30, 2013 • Added ADF paper feed service check and ADF maintenance kit. • Updated the warning statement in the System card assembly removal topic. Added the same warning to the Operator panel assembly removal and the Operator panel door assembly removal. February 28, 2012 •...
Page 30 7462...
Page 31: General Information
7462 General information The Lexmark laser printers are letter-quality page printers designed to attach to personal computers and to most computer networks.. The printers are available in the following models: Description Machine type / model Model name Simplex Duplex ADF Duplex...
Page 32 7462 Weight The printer can automatically feed paper weights from 60–176 g/m (16–47 lb bond) grain long. Paper lighter than 60 g/m (16 lb) might not be stiff enough to feed properly, and may cause paper jams. For best performance, use 75 g/m (20 lb bond) grain long paper.
Page 33: Using Recycled Paper And Other Office Papers
Lexmark consistently tests its printers with recycled paper (20–100% post-consumer waste) and a variety of test paper from around the world, using chamber tests for different temperature and humidity conditions. Lexmark has found no reason to discourage the use of today's recycled office papers, but generally the following property guidelines apply to recycled paper.
Page 34: Supported Paper Sizes, Types, And Weights
The following tables provide information on standard and optional paper sources and the types of paper they support. Note: For an unlisted paper size, conﬁgure a Universal Paper Size. For information on card stock and labels, see the Card Stock & Label Guide on the Lexmark Web site at http://support.lexmark.com. Paper sizes supported by the printer...
Page 35: Paper Types And Weights Supported By The Printer
7462 Paper size Dimensions 250‑ or Optional Multipurpose Duplex unit 550‑sheet 2000‑sheet feeder trays (standard tray or optional) 216 x 330 mm Folio (8.5 x 13 in.) 140 x 216 mm Statement (5.5 x 8.5 in.) 138 x 210 mm Universal (5.5 x 8.3 in.) up to 216 x 356 mm...
Page 36 7462 Paper type 250‑ or 550‑sheet Optional Multipurpose feeder Duplex unit trays (standard or 2000‑sheet tray optional) Paper • Plain • Bond • Colored • Custom • Letterhead • Light • Heavy • Preprinted • Rough/Cotton • Recycled Card stock Envelopes Labels •...
Page 37: Tools Required For Service
7462 Paper type Finisher standard Output Expander 5‑Bin Mailbox StapleSmart bin (250 or 550 (550 sheets) or High Finisher (500 sheets) sheets) Capacity Output (500 sheets Stacker (1850 sheets) Paper • Plain • Bond • Colored • Custom • Letterhead •...
Page 38 7462 • Analog or digital multimeter • Flashlight (optional) General information...
Page 39: Diagnostic Information
7462 Diagnostic information • “Troubleshooting overview” on page 39 • “Fixing print quality issues” on page 41 • “Paper jams” on page 59 • “List of status and error messages” on page 184 • “User attendance messages” on page 202 •...
Page 40: Power-On Reset (Por) Sequence
7462 • Make sure the printer is properly grounded. Check the power cord ground terminal. • Make sure the power supply line voltage is within 10% of the rated line voltage. • Make sure the machine is securely installed on a level surface in a well‑ventilated area. •...
Page 41: Fixing Print Quality Issues
7462 You can enter Safe Mode in one of the following ways: • Enable Safe Mode from the Conﬁguration menu, and then POR the printer. • Press the Stop and Back keys, and then POR the printer. Return the printer to standard operating mode to service the printer and return to full‑function printing. Safe mode print behavior The following table outlines the behavior for this printer model while in Safe Mode: Safe Mode engine features...
Page 42: Initial Print Quality Check
7462 The symptoms described in this chapter might require replacement of one or more CRUs (Customer Replaceable Units) designated as supplies or maintenance items, which are the responsibility of the customer. With the customer's permission, you might need to install a toner cartridge. Initial print quality check Before troubleshooting speciﬁc print problems, complete the following initial print quality check: •...
Page 43 7462 Action Step 1 Go to step 2. The problem is solved. Check the media condition. Load new, dry, recommended media, and perform a print test. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the toner level, and if necessary, replace the print cartridge.
Page 44: Repeating Defects Check
7462 Action Step 9 Contact the next The problem is level of support. solved. Replace the printhead assembly. Go to “Printhead assembly removal” on page 377. Does the problem remain? Repeating defects check Actions Step 1 Contact next level of Problem is solved.
Page 45 7462 Action Step 1 Go to step 2. The problem is solved. Check the media condition. Load new, dry, recommended media, and perform a print test. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the toner level, and if necessary, replace the print cartridge.
Page 46: Solid Black Pages Check
7462 Action Step 9 Go to step 10. The problem is solved. Check the printhead assembly for proper connection, and if necessary, replace the connection. Does the problem remain? Step 10 Go to step 11. The problem is solved. Check the system card assembly for proper connection, and if necessary, replace the connection.
Page 47 7462 Action Step 4 Go to step 5. Problem is solved. Check the HVPS for proper installation, and if necessary, reinstall the HVPS properly. Does the problem remain? Step 5 Go to step 6. Problem is solved. Check the high voltage metal contacts between the imaging unit and the HVPS for damage.
Page 48: Vertical Lines And Bands (Process Direction) Check
7462 Vertical lines and bands (process direction) check Leading edge Trailing edge Action Step 1 Go to step 2. The problem is solved. Check the media condition. Load new, dry, recommended media. Reprint the defective image. Does the problem remain? Step 2 Go to step 3.
Page 49: Horizontal White Stripes And Bands (Side To Side Direction) Check
7462 Action Step 7 Contact the next The problem is level of support. solved. Replace the printhead assembly. Go to “Printhead assembly removal” on page 377. Does the problem remain? Horizontal white stripes and bands (side to side direction) check Leading edge Trailing edge Action...
Page 50: Vertical Stripes (Process Direction) Check
7462 Action Step 6 Contact the next The problem is level of tech support. solved. Replace the printhead assembly. Go to “Printhead assembly removal” on page 377. Does the problem remain? Vertical stripes (process direction) check Leading edge ABCDE ABCDE ABCDE Trailing edge Action...
Page 51: Horizontal Stripes (Side To Side Direction) Check
7462 Action Step 6 Go to step 7. Problem is solved. Check the heat roll and pressure roll. If necessary, remove and then reinstall the fuser unit assembly. Go to “Fuser unit assembly removal” on page 373. CAUTION—HOT SURFACE: Allow the fuser unit assembly to cool down.
Page 52: Partial Lack Check
7462 Action Step 4 Go to step 5. Problem is solved. Check the charge roll assembly for contamination and wear, and if necessary replace the charge roll assembly. Go to “Access door removal” on page 308. Does the problem remain? Step 5 Go to step 6.
Page 53: Spots Check
7462 Action Step 1 Go to step 2. The problem is solved. Check the media condition. Load new, dry, recommended media. Reprint the defective image. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the toner level, and if necessary, replace the print cartridge. Does the problem remain? Step 3 Go to step 4.
Page 54 7462 Action Step 1 Go to step 2. The problem is solved. Check the media condition. Load new, dry, recommended media. Reprint the defective image. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check if the media transfer route is free of debris and contamination.
Page 55: Background (Fog) Check
7462 Action Step 8 Contact the next The problem is level of support. solved. Check the printhead assembly for proper installation and damage, and if necessary, replace the printhead assembly. Does the problem remain? Background (fog) check Leading edge A B C D A B C D A B C D A B C D...
Page 56: Skew Check
7462 Action Step 6 Contact the next The problem is level of support. solved. Check the printhead assembly for proper installation. Go to “Printhead assembly removal” on page 377. Does the problem remain? Skew check Action Step 1 Go to step 2. The problem is solved.
Page 57: Media Damage Check
7462 Action Step 5 Go to step 6. The problem is solved. Check the alignment assembly for proper adjustment. Go to “Alignment assembly adjustment” on page 305. If necessary, replace the alignment assembly. Go to “Output cover assembly removal (models X651, X652, X654, X656)” on page 376 “Output cover assembly removal (model X658)”...
Page 58: No Fuse Check
7462 Action Step 4 Go to step 5. Problem is solved. Check the transfer roll assembly for contamination and wear, and replace the transfer roll assembly if necessary. Go to “Transfer roll assembly removal” on page 351. Does the problem remain? Step 5 Go to step 6.
Page 59: Paper Jams
7462 Action Step 3 Go to step 4. The problem is solved. Check the media condition. Load new, dry, recommended media. Does the problem remain? Step 4 Go to step 5. The problem is solved. Check the heat roll and pressure roll. Remove, and then reinstall the fuser unit assembly.
Page 60: Avoiding Jams
7462 Avoiding jams Load paper properly • Make sure that the paper lies ﬂat in the tray. • Do not remove a tray while the printer is printing. • Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it. •...
Page 61: Understanding Jam Messages And Locations
7462 Understanding jam messages and locations When a jam occurs, a message indicating the jam location and information to clear the jam appears on the printer display. Open the doors, covers, and trays indicated on the display to remove the jam. Notes: •...
Page 62: 200-201 Paper Jams
7462 Jam access area Printer control panel message What to do Finisher output bin [x]-page jam, remove all pages • Move the left tamper arm to the left and the right from the output bin. Leave paper tamper arm to the right, and then remove the in bin [45y.xx] jammed paper from the ﬁnisher bin.
Page 63 7462 Place the print cartridge aside. Warning—Potential Damage: Do not leave the cartridge exposed to light for extended periods. Warning—Potential Damage: The jammed paper may be covered with unfused toner which can stain garments and skin. Remove the jammed paper. CAUTION—HOT SURFACE: The inside of the printer might be hot.
Page 64 7462 200 error messages Error code Description Action 200.00 Sensor (input) area jam Go to “Sensor (input) service check” on page The media is jammed in the sensor (input) area. 200.01 Sensor (input) lingering jam (MPF, duplex, or Go to “Sensor (input) lingering jam service envelope feeder) check”...
Page 65 7462 Error code Description Action 200.15 Laser power did not settle. Go to “Printhead laser start failure service check” on page Laser circuit failure on printhead or system card assembly. 200.16 Main drive motor assembly load error Go to “Main drive motor assembly load error service check”...
Page 66 7462 Error code Description Action 200.37 Sensor (input) lingering jam (tray 3 and tray level Go to “Sensor (input) lingering jam service not low) check” on page The media reached the sensor (input) but did not clear it within the speciﬁed time. 200.38 Sensor (input) lingering jam (tray 3 and tray level low)
Page 67 7462 201 error messages Error code Description Action 201.00 Sensor (fuser output) area jam (type 1 fuser) Go to “Sensor (fuser output) service check” on page The media is jammed in the sensor (fuser output) area. 201.01 Main drive motor assembly load error (type 1 fuser) Go to “Main drive motor assembly load error service check”...
Page 68 7462 Error code Description Action 201.30 Operator panel door assembly interlock switch Go to “Operator panel door assembly switch failure (type 2 fuser) failure service check” on page The printer detected that the switch (operator panel door interlock) did not cycle prior to printer restart.
Page 69 7462 Error code Description Action 201.57 Sensor (fuser output) late jam (type 1 fuser and Go to “Sensor (fuser output) late jam service fuser page count exceeds life) check” on page The media is late reaching the sensor (fuser output) within the speciﬁed time. 201.75 Sensor (fuser output) late jam (type 1 fuser and fuser page count exceeds life)
Page 70 7462 Sensor (input) service check Action Step 1 Go to step 2. Problem is solved. Fan the media, ensure the media is properly installed and check the paperpath for obstructions. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 71 7462 Action Step 4 Go to step 5. The problem is solved. Check the fuser unit assembly for excess wear and damage. If necessary, replace the fuser unit assembly. Go to“Fuser unit assembly removal” on page 373. Does the problem remain? Step 5 Go to step 7.
Page 72 7462 Action Step 10 Go to step 11. The problem is solved. Remove obstructions in the aligner assembly. Does the problem remain? Step 11 Contact the next The problem is level of support. solved. Perform a print test. Does the problem remain? Sensor (input) early jam service check Action Step 1...
Page 73 7462 Action Step 7 Go to step 8. Problem is solved. Remove any prestaged or jammed media in all the trays. Does the problem remain? Step 8 Go to step 10. Go to step 9. Check the sensor (input) for proper operation. Enter the diagnostic mode.
Page 74 7462 Action Step 5 Go to step 6. Problem is solved. Remove obstructions in the pass‑thru areas of the tray. Does the problem remain? Step 6 Go to step 7. Problem is solved. Make sure that the media originate from the MPF. Does the problem remain? Step 7 Go to step 8.
Page 75 7462 Action Step 13 Go to step 18. Problem is solved. Perform a print test and check the duplex drive motor assembly for proper operation. If necessary, replace the duplex drive motor assembly. Go to “Duplex drive motor assembly removal” on page 370.
Page 76 7462 Action Step 19 Go to step 20. Problem is solved. Check the sensor (input) for proper operation. Enter the Diagnostic mode. Select Base sensor test. Observe the line item, “input.” Does the problem remain? Step 20 Go to step 21. Problem is solved.
Page 77 7462 Sensor (input) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media. Does the problem remain? Step 2 Go to step 4. Go to step 3. Check the sensor (input) for proper operation. Enter the diagnostic mode.
Page 78 7462 Action Step 4 Go to step 5. The problem is solved. Replace the printhead. Go to “Printhead assembly removal” on page 377. Does the problem remain? Step 5 Contact the next The problem is level of support. solved. Replace the system card. Go to “System card assembly removal”...
Page 79 7462 Action Step 7 Go to step 8. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the sensor (narrow media) is interrupted or blocked? Enter the Diagnostic mode. Select Base sensor tests. Observe the line item, “input.”...
Page 80 7462 Main drive motor assembly load error service check Action Step 1 Go to step 2. Problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly.
Page 81 7462 Operator panel door assembly switch failure service check Action Step 1 Go to step 2. The problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly.
Page 82 7462 Sensor (toner empty) service check Action Step 1 Go to step 2. Problem is solved. Inspect the print cartridge pulse wheel for damage, and if necessary, replace the print cartridge pulse wheel. Does the problem remain? Step 2 Go to step 3. Problem is solved.
Page 83 7462 Action Step 3 Problem is solved. Go to step 4. Enter the diagnostic mode. Select Base sensor test. Observe the line item “exit.” Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked? Step 4 Contact next level of Problem is solved.
Page 84 7462 Action Step 6 Go to step 7. Check the sensor (fuser output) for proper operation. Enter the Diagnostic mode Select Base sensor test. Observe the line item, “output.” Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked? Step 7 Go to step 8.
Page 85: 202-203 Paper Jams
7462 Printhead write failure service check Action Step 1 Go to step 2. The problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly. See “Fuser wiper cover assembly removal”...
Page 86 7462 If the paper is not exiting the printer: Pull down the top rear door. Remove the jammed paper. Close the top rear door. Touch Continue. 202 error messages Error code Description Action 202.00 Paper jam around fuser exit or redrive area (type Go to “Paper jam around fuser exit or redrive 1 fuser)
Page 87 7462 Error code Description Action 202.07 Sensor (fuser output) lingering jam (type 1 fuser) Go to “Sensor (fuser output) lingering jam service check” on page 94 Media reached the sensor (fuser output), but did not clear it in the speciﬁed time 202.09 Sensor (fuser output) lingering jam (type 1 fuser) Media reached the sensor (fuser output), but did...
Page 88 7462 Error code Description Action 202.31 Sensor (fuser output) static jam (type 2 fuser) Go to “Sensor (fuser output) static jam service check” on page 95 Media remains on the sensor (fuser output) during the warm-up sequence. 202.32 Sensor (fuser output) lingering jam (type 2 fuser) Go to “Sensor (fuser output) lingering jam service check”...
Page 89 7462 Error code Description Action 202.53 Sensor (narrow media) static jam (type 1 fuser and Go to “Sensor (narrow media) static jam fuser page count exceeded life) service check” on page 96 Media remains on the sensor (narrow media) during the warm‑up sequence. 202.54 Sensor (fuser output) bounce (type 1 fuser and Go to...
Page 90 7462 Error code Description Action 202.63 Sensor (fuser output) static jam and sensor Go to “Paper jam around fuser exit or redrive (narrow media) static jam (type 1 fuser and fuser area service check” on page 92 page count exceeded life) Media remains on the sensor (fuser output) and the sensor (narrow media) during the warm‑up sequence.
Page 91 7462 Error code Description Action 202.82 Sensor (fuser output) lingering jam (type 2 fuser Go to “Sensor (fuser output) lingering jam and fuser page count exceeded life) service check” on page 94 Media reached the sensor (fuser output), but did not clear it in the speciﬁed time.
Page 92 7462 203 error messages Error code Description Action 203.00 Paper jam around redrive area Go to “Paper jam around fuser exit or redrive area service check” on page Page may be jammed in redrive area. 203.01 Internal duplex drive motor control failure (internal Go to “Internal duplex drive motor control duplex)
Page 93 7462 Action Step 4 Go to step 5. Problem is solved. Check the sensor (fuser output) for damage. If necessary, replace the fuser unit assembly. See “Fuser unit assembly removal” on page 373. Does the problem remain? Step 5 Go to step 6 Go to step 6.
Page 94 7462 Sensor (fuser output) lingering jam service check Action Step 1 Go to step 2. The problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks. If necessary, replace the fuser wiper cover assembly.
Page 95 7462 Action Step 8 Go to step 9. The problem is solved. Check the redrive assembly for damage. If necessary, replace the redrive assembly. Go to “Redrive assembly removal” on page 374. Does the problem remain? Step 9 Go to step 10. The problem is solved.
Page 96 7462 Action Step 5 Contact next level of Problem is solved. support. Perform a print test. Does the problem remain? Sensor (narrow media) static jam service check Action Step 1 Go to step 2. Problem is solved. Check the fuser wiper cover assembly for missing parts or damage, such as cracks.
Page 97 7462 Internal duplex drive motor control failure service check Action Step 1 Go to step 2. The problem is solved. Remove all media present in media path. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 98: 230-239 Paper Jams
7462 Action Step 4 Go to step 4. Problem is solved. Check all connections on the system card assembly, and if necessary, replace the connections. Does the problem remain? Step 5 Contact next level of Problem is solved. support. Replace the redrive motor assembly if problem remains. See “Redrive assembly removal”...
Page 99 7462 Remove the jammed paper. Close the bottom rear door. Insert the standard tray. Touch Continue. 230 error messages Error code Description Action 230.00 Paper jam around internal duplex (internal duplex) Go to “Paper jam around internal duplex service check” on page 100.
Page 100 7462 Error code Description Action 230.10 Internal duplex drive motor control failure (internal Go to “Internal duplex drive motor control duplex) failure service check” on page The internal duplex drive motor does not reach the proper operating speed at the speciﬁed time. 230.13 Sensor (duplex input) static jam (internal duplex) Go to...
Page 101 7462 Action Step 4 Go to step 5. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the above sensor is interrupted or blocked. Enter the Diagnostic mode. Select Base sensor test. Observe the line item, “exit.”...
Page 102 7462 Action Step 3 Go to step 4. The problem is solved. Replace the damaged media with new media. Does the problem remain? Step 4 Go to step 5. The problem is solved. Remove obstructions in the media tray pass-thru areas. Does the problem remain? Step 5 Go to step 6.
Page 103 7462 Action Step 9 Contact the next The problem is level of support. solved. Perform a print test using the appropriate input tray, and if necessary, replace the input option. Does the problem remain? Sensor (duplex input) late jam service check Action Step 1 Go to step 2.
Page 104 7462 Action Step 7 Go to step 8. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (duplex input) is interrupted. Enter the Diagnostic mode. Select Duplex tests. Select Sensor test.
Page 105 7462 Sensor (duplex input) service check Action Step 1 Go to step 2. The problem is solved. Check the sensor (duplex input) for damage, and if necessary, replace the sensor (duplex input). Go to “Sensor (duplex input) removal” on page 382.
Page 106 7462 Sensor (duplex input) lingering jam service check Action Step 1 Go to step 2. The problem is solved. Remove obstructions in the internal duplex media path. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 107: 231-239 Paper Jams
7462 Action Step 7 Go to step 8. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (duplex input) is interrupted or blocked. Enter the Diagnostic mode. Select Duplex tests.
Page 108 7462 Error code Description Action 236.00 Sensor (duplex input) lingering jam (internal Go to “Sensor (duplex exit) lingering jam duplex) service check” on page 112. Media reached the sensor (duplex exit) within the speciﬁed time but did not clear it within the speciﬁed time.
Page 109 7462 Error code Description Action 238.06 Sensor (duplex exit) static jam and sensor (double- Go to “Sensor (duplex exit) static jam service feed) static jam (external duplex) check (external duplex)” on page 114. Media remains on the sensor (duplex exit) and the sensor (double-feed) during the warm-up sequence.
Page 110 7462 Sensor (duplex double-feed) late jam service check Action Step 1 Go to step 2. Problem is solved. Remove all media present in media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove obstructions in the media path. Does the problem remain? Step 3 Go to step 4.
Page 111 7462 Action Step 5 Go to step 6. Problem is solved. Open and then properly close the rear door of the external duplex. Does the problem remain? Step 6 Go to step 7. Problem is solved. Check sensor (duplex exit) for proper operation, and if necessary replace the sensor.
Page 112 7462 Sensor (duplex double-feed) lingering jam service check Action Step 1 Go to step 2. Problem is solved. Remove all media present in media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Reinstall all media properly. Does the problem remain? Step 3 Go to step 4.
Page 113 7462 Action Step 5 Go to step 6. Problem is solved. Check sensor (duplex exit) for proper operation, and if necessary replace the sensor. See “Sensor (duplex exit) service check (external duplex only)” on page 111. Does the problem remain? Step 6 Contact next level of Problem is solved.
Page 114 7462 Action Step 8 Go to step 9. Problem is solved. Check the lower option drive (PTO) assembly for damage, and if necessary the lower option drive assembly. Does the problem remain? Step 9 Contact next level of Problem is solved. support.
Page 115 7462 Mechanical feed error or timing error (external duplex) service check Action Step 1 Go to step 2. The problem is solved. Remove all media present in the media path. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 116 7462 External duplex assembly error (external duplex) service check Action Step 1 Go to step 2. Problem is solved. Remove all media present in the media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Reinstall all media properly.
Page 117: 241-245 Paper Jams
7462 241-245 paper jams 240–249 paper jams Touch Status/Supplies to identify the location of the jam. Pull the standard tray out. Remove any jammed paper, and then close the tray. Touch Continue. If the jam message persists, then pull out any optional trays. Remove the jammed paper, and then insert the trays.
Page 118 7462 Error code Description Action 241.06 Sensor (input) late jam (tray 1 or MPF) Go to “Sensor (input) late jam service check” on page The media is late reaching the sensor (input) within the speciﬁed time. 241.07 Pick motor load error (media tray 1) Go to “Tray pick motor load error service check”...
Page 119 7462 242 error messages Error code Description Action 242.00 Media tray 2 area jam Go to “Tray area jam service check” on page 127. The media is jammed in the media tray 2 area. 242.02 Sensor (pass through) late jam (tray 2) Go to “Sensor (pass through) late jam service check”...
Page 120 7462 Error code Description Action 242.32 Tray 2 pick motor overrun failure (tray 2) Go to “Tray pick motor lost encoder failure service check” on page 131. The pick motor encoder continues to detect pulses after the motor was turned off. 242.33 Tray 2 not ready (tray 2) Go to...
Page 121 7462 Error code Description Action 242.66 Pick motor underspeed error (tray 2) Go to “Tray pick motor control failure service check” on page 130. The pick motor does not rotate at the speciﬁed speed. 242.67 Pick motor overspeed error (tray 2) The pick motor does not rotate at the speciﬁed speed.
Page 122 7462 Error code Description Action 243.18 Pick retry timeout (tray 3) The engine timed out waiting for the tray 3 to 243.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 243.33 Tray 3 not ready (tray 3) Go to “Tray not ready service check”...
Page 123 7462 Error code Description Action 243.66 Pick motor underspeed error (tray 3) Go to “Tray pick motor control failure service check” on page 130. The pick motor does not rotate at the speciﬁed speed. 243.67 Pick motor overspeed error (tray 3) The pick motor does not rotate at the speciﬁed speed.
Page 124 7462 Error code Description Action 244.18 Pick retry timeout (tray 4) The engine timed out waiting for the tray 4 to 244.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 244.33 Tray 4 not ready (tray 4) Go to “Tray not ready service check”...
Page 125 7462 Error code Description Action 244.66 Pick motor underspeed error (tray 4) Go to “Tray pick motor control failure service check” on page 130. The pick motor does not rotate at the speciﬁed speed. 244.67 Pick motor overspeed error (tray 4) The pick motor does not rotate at the speciﬁed speed.
Page 126 7462 Error code Description Action 245.18 Pick retry timeout (tray 5) The engine timed out waiting for the tray 5 to 245.19 report ready before the ﬁrst pick attempt. Thus, turn the machine off, and then turn it on. 245.33 Tray 5 not ready (tray 5) Go to “Tray not ready service check”...
Page 127 7462 Error code Description Action 245.66 Pick motor underspeed error (tray 5) Go to “Tray pick motor control failure service check” on page 130. The pick motor does not rotate at the speciﬁed speed. 245.67 Pick motor overspeed error (tray 5) The pick motor does not rotate at the speciﬁed speed.
Page 128 7462 Action Step 3 Go to step 4. The problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (pass through) is interrupted or blocked. Enter the Diagnostic mode. Select Input tray tests.
Page 129 7462 Sensor (pass through) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove any prestaged or jammed media in the media path. Does the problem remain? Step 2 Go to step 3. Problem is solved. Check if the display on the operator panel changes every time the sensing area of the media tray sensor (pass through) is interrupted or blocked.
Page 130 7462 Action Step 4 Go to step 5. Problem is solved. Check all connections on the pick arm assembly, and if necessary, replace the connections. Does the problem remain? Step 5 Go to step 6. Problem is solved. Check all connections on the system card assembly, and if necessary, replace the connections.
Page 131 7462 Action Step 5 Go to step 6. Problem is solved. Replace the pick arm assembly. See “Pick arm assembly removal” on page 359. Does the problem remain? Step 6 Contact next level of Problem is solved. support. Replace the system card assembly. See “System card assembly removal”...
Page 132 7462 Tray not ready service check Action Step 1 Go to step 2. Problem is solved. Check the size sensing ﬁngers on the media tray for damage, and if necessary, replace the media tray assembly. Does the problem remain? Step 2 Contact next level of Problem is solved.
Page 133: 250 Paper Jams
7462 250 paper jams 250 paper jam Touch Status/Supplies to identify the location of the jam. Remove the paper from the multipurpose feeder. Flex the sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface.
Page 134: 260 Paper Jams
7462 250 error messages Error code Description Action 250.00 MPF area jam Go to “Sensor (input) service check” on page The media is jammed in the media tray 5 area. 250.03 Sensor (input) late jam (MPF) Go to “Sensor (input) late jam service check” on page The media is late reaching the sensor (input) 250.06...
Page 135 7462 260 error messages Error code Description Action 260.00 Envelope feeder area jam Go to “Envelope feeder area jam service check” on page 135. The media is jammed in the envelope feeder area. 260.01 Envelope feeder assembly error Go to “Envelope feeder assembly error service check”...
Page 136 7462 Action Step 4 Go to step 5. Problem is solved. Remove obstructions in the media path. Does the problem remain? Step 5 Go to step 6. Problem is solved. Check the sensor (input) for damage, and if necessary, replace the sensor (input).
Page 137 7462 Action Step 5 Go to step 6. Problem is solved. Properly install the envelope feeder assembly. Does the problem remain? Step 6 Go to step 7. Problem is solved. Check all connections on the envelope feeder assembly, and if necessary, replace the connections.
Page 138 7462 Sensor (envelope feeder pass through) late jam (envelope feeder) service check Action Step 1 Go to step 2. Problem is solved. Remove the envelope feeder. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove all media present in media path. Does the problem remain? Step 3 Go to step 4.
Page 139: 27Y Paper Jams
7462 Sensor (envelope feeder pass through) static jam service check Action Step 1 Go to step 2. Problem is solved. Remove the envelope feeder. Does the problem remain? Step 2 Go to step 3. Problem is solved. Remove all media present in media path. Does the problem remain? Step 3 Contact next level of...
Page 140 7462 Error code Description Action 271.04 The media is late reaching the sensor (output pass Go to “Sensor (output pass through) late jam through) within the speciﬁed time. service check” on page 142. This applies to: • High capacity output •...
Page 141 7462 Error code Description Action 271.53 The media is late reaching the sensor (mailbox Go to “Sensor (mailbox empty) late jam service empty) within the speciﬁed time. check” on page 144. 27y.54 The media reached the sensor (output pass Go to “Sensor (output pass through) lingering through) but did not clear it in the speciﬁed time.
Page 142 7462 Action Step 5 Go to step 6. The problem is solved. Replace the sensor (output pass through). Go to “4-bin mailbox assembly sensor (pass through) removal” on page 397. Does the problem remain? Step 6 Go to step 7. The problem is solved.
Page 143 7462 Action Step 5 Go to step 6. The problem is solved. Replace the sensor (output pass through). Go to “4-bin mailbox assembly sensor (pass through) removal” on page 397. Does the problem remain? Step 6 Go to step 7. The problem is solved.
Page 144 7462 Action Step 5 Go to step 6. The problem is solved. Perform a print test using the option. Does the problem remain? Step 6 Contact the next The problem is level of support. solved. Replace the output option. Does the problem remain? Sensor (mailbox empty) late jam service check Action Step 1...
Page 145 7462 Action Step 7 Contact the next The problem is level of support. solved. Replace the output option. Does the problem remain? Sensor (mailbox empty) lingering jam service check Action Step 1 Go to step 2. The problem is solved. Make sure that the output option is properly installed.
Page 146 7462 Sensor (mailbox empty) static jam service check Action Step 1 Go to step 2. The problem is solved. Check and clear the media path for partially fed or jammed media. Does the problem remain? Step 2 Go to step 5. Go to step 3.
Page 147 7462 Left tamper does not leave home position failure (offset stacker) service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the output option controller card, and if necessary, replace the connections. Does the problem remain? Step 2 Go to step 3.
Page 148: 28Y Paper Jams
7462 Action Step 3 Go to step 4. The problem is solved. Replace the right tamper motor assembly. Go to “MFP stapler assembly tamper drive motor assembly removal” on page 492. Does the problem remain? Step 4 Go to step 5. The problem is solved.
Page 149 7462 283 staple jams Touch Status/Supplies to identify the location of the jam. Press the latch to open the stapler door. Pull the latch of the staple cartridge holder down, and then pull the holder out of the printer. Diagnostic information...
Page 150 7462 Use the metal tab to lift the staple guard, and then remove any loose staples. Close the staple guard. Press down on the staple guard until it snaps into place. Diagnostic information...
Page 151 7462 Push the cartridge holder ﬁrmly back into the stapler unit until the cartridge holder clicks into place. Close the stapler door. 28y.xx error messages Note: These errors are applicable only to the StapleSmart ﬁnisher. [y] represents the bin number. Error code Description Action 28y.25...
Page 152 7462 Error code Description Action 28y.40 The sensor (left tamper HP) does not detect that the Go to “Left tamper does not leave home tamper has moved from home position. position failure (StapleSmart ﬁnisher) service check” on page 159. 28y.41 The sensor (left tamper HP) does not detect that the tamper has reached home position.
Page 153 7462 Error code Description Action 28y.59 The sensor (self priming) within the stapler Go to “Staple ready home position jam service assembly does not detect a ready staple in the check” on page 158. speciﬁed time after the staple job was sent. 28y.60 A software error has occurred with the output Go to...
Page 154 7462 StapleSmart ﬁnisher software error service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Contact the next The problem is level of support.
Page 155 7462 Sensor (StapleSmart ﬁnisher eject HP) service check Action Step 1 Go to step 2. The problem is solved. Check all connections on the output option controller card, and if necessary, replace the connections. Does the problem remain? Step 2 Contact the next The problem is level of support.
Page 156 7462 Sensor (stapler pass through) late jam service check Action Step 1 Go to step 2. The problem is solved. Make sure that the output option is properly installed. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 157 7462 Action Step 3 Go to step 6. Go to step 4. Check the sensor (stapler pass through) for proper operation. Enter the Diagnostics menu, and then navigate to: Finisher sensor test > Sensor test > pass & media Observe the line item, “passthru.” Does the display on the operator panel change every time the sensing area of the sensor is interrupted or blocked? Step 4...
Page 158 7462 Sensor (self priming) late failure service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the StapleSmart ﬁnisher controller card and the stapler assembly. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 159 7462 Action Step 3 Go to step 4. The problem is solved. Remove the stapler assembly. Go to “MFP stapler assembly stapler unit assembly removal” on page 494. Manually rotate the drive gears, and then reset the stapler. Remove all jammed staples, and then reinstall the stapler assembly.
Page 160 7462 Right tamper does not leave home position failure (StapleSmart ﬁnisher) service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the output option controller card. Does the problem remain? Step 2 Go to step 3.
Page 161 7462 Left tamper home position (StapleSmart ﬁnisher) jam service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the output option controller card. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 162 7462 Action Step 4 Go to step 5. The problem is solved. Replace the sensor (tamper HP). Go to “Sensor (MFP stapler assembly tamper HP left and right) removal” on page 498. Does the problem remain? Step 5 Contact the next The problem is level of support.
Page 163 7462 Deﬂector gate transition to output option not detected service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the StapleSmart ﬁnisher controller card. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 164: 29Y Paper Jams
7462 29y paper jams 290–294 paper jams Remove all original documents from the ADF. Open the ADF cover, and then remove any jammed paper. Close the ADF cover. Open the scanner cover, and then remove any jammed pages. Diagnostic information...
Page 165 7462 Open the bottom ADF door, and then remove any jammed pages. Close the bottom ADF door and scanner cover. Touch Restart Job. 29y.xx error messages Error code Description Action 290.00 Media remains on the sensor (ADF sheet through) Go to “Sensor (ADF sheet through) static jam during the warm up sequence.
Page 166 7462 Error code Description Action 294.00 Media remains on the sensor (ADF media exit) Go to “Sensor (ADF media exit) static jam during the warm up sequence. service check” on page 180. 294.01 The media reached the sensor (ADF media exit) Go to “Sensor (ADF media exit) lingering jam within the speciﬁed time but did not clear it within...
Page 167 7462 Action Step 2 Go to step 3. The problem is solved. Check the sensor (ADF closed interlock) for proper connection. Replace the connection, if necessary. Does the problem remain? Step 3 Contact the next The problem is level of support. solved.
Page 168 7462 Action Step 6 Go to step 7. The problem is solved. Replace the ADF controller card assembly. Go to “ADF controller card removal” on page 541. Does the problem remain? Step 7 Contact the next The problem is level of support. solved.
Page 169 7462 Action Step 5 Go to step 6. The problem is solved. Replace the ADF feed drive motor assembly. Go to “ADF feed drive motor assembly removal” on page 551. Does the problem remain? Step 6 Go to step 9. Go to step 7.
Page 170 7462 Sensor (ADF sheet through) lingering jam service check Action Step 1 Go to step 2. The problem is solved. Check the media size setup and tray guides for the ADF. • Make sure that the media size matches the size set for the ADF. •...
Page 171 7462 Action Step 7 Go to step 8. The problem is solved. Check the ADF feed drive motor assembly for proper connection. Replace the connection, if necessary. Does the problem remain? Step 8 Go to step 9. The problem is solved.
Page 172 7462 Sensor (ADF 1st scan) late jam service check Action Step 1 Go to step 2. The problem is solved. Check if the original document is free of paper clips and staples as well as creases, tears, holes, or excessive wear. If the original document is damaged, replace it, and then perform an ADF test.
Page 173 7462 Action Step 7 Go to step 8. The problem is solved. Check the ADF feed drive motor assembly for proper connection. Replace the connection, if necessary. Does the problem remain? Step 8 Go to step 9. The problem is solved.
Page 174 7462 Action Step 3 Go to step 4. The problem is solved. Check the sensor (ADF 1st scan) for proper connection. Replace the connection, if necessary. Does the problem remain? Step 4 Go to step 5. The problem is solved. Replace the sensor (ADF 1st scan).
Page 175 7462 Action Step 3 Go to step 4. The problem is solved. Check the sensor (ADF 2nd scan) for proper connection. Replace the connection, if necessary. Does the problem remain? Step 4 Go to step 5. The problem is solved. Replace the sensor (ADF 2nd scan).
Page 176 7462 Action Step 3 Go to step 4. The problem is solved. Check the media path for contaminates. Make sure that the media path is free of excess media dust and foreign objects such as paper clips and staples. Does the problem remain? Step 4 Go to step 7.
Page 177 7462 Action Step 10 Go to step 11. The problem is solved. Replace the ADF controller card assembly. Go to “ADF controller card removal” on page 541. Does the problem remain? Step 11 Contact the next The problem is level of support. solved.
Page 178 7462 ADF top door open jam service check Action Step 1 Go to step 2. The problem is solved. Remove all documents from the ADF. Place an undamaged document in the ADF, and then perform an ADF test. Does the problem remain? Step 2 Go to step 5.
Page 179 7462 Media missing jam service check Action Step 1 Go to step 2. The problem is solved. Remove all documents from the ADF. Place an undamaged document in the ADF, and then perform an ADF test. Does the problem remain? Step 2 Go to step 5.
Page 180 7462 Sensor (ADF media exit) static jam service check Action Step 1 Go to step 2. The problem is solved. Check and remove any media or media fragments from the media path. Does the problem remain? Step 2 Go to step 5. Go to step 3.
Page 181 7462 Sensor (ADF media exit) late jam service check Action Step 1 Go to step 2. The problem is solved. Check if the original document is free of paper clips and staples as well as creases, tears, holes, or excessive wear. If the original document is damaged, replace it, and then perform an ADF test.
Page 182 7462 Action Step 7 Go to step 8. The problem is solved. Check the ADF transport drive motor assembly for proper connection. Replace the connection, if necessary. Does the problem remain? Step 8 Go to step 9. The problem is solved.
Page 183 7462 Action Step 3 Go to step 4. The problem is solved. Check the media path for contaminates. Make sure that the media path is free of excess media dust and foreign objects such as paper clips and staples. Does the problem remain? Step 4 Go to step 7.
Page 184: List Of Status And Error Messages
7462 Action Step 10 Go to step 11. The problem is solved. Replace the ADF controller card assembly. Go to “ADF controller card removal” on page 541. Does the problem remain? Step 11 Contact the next The problem is level of support. solved.
Page 185: Close Door Or Insert Cartridge
7462 If the error occurs a second time: Turn the printer off. Unplug the power cord from the wall outlet. Remove the tray. Reattach the tray. Connect the power cord to a properly grounded outlet. Restart the printer. If the error occurs again: Turn the printer off.
Page 186: Fax Failed
7462 Touch Continue to clear the message. Fax failed The fax failed to be sent. Wait for the message to clear. Fax memory full There is not enough memory to send the fax job. Touch Continue to clear the message. Fax partition inoperative.
Page 187: Insert Staple Cartridge
7462 Insert staple cartridge Try one or more of the following: • Insert a staple cartridge to clear the message. • Touch Continue to clear the message and print without using the staple feature. Insert Tray <x> Insert the speciﬁed tray into the printer. Install bin <x>...
Page 188: Invalid Pin
7462 Invalid PIN Enter a valid PIN. Job stored for delayed transmission The scanning completed for a delayed send fax job. Wait for the message to clear. Line busy A fax number is dialed, but the fax line is busy. Wait for the message to clear. Load <src>...
Page 189: Network/Network
7462 Network/Network <x> The printer is connected to the network. Network indicates that the printer is using the standard network port built into the printer system board. Network <x> indicates that an internal print server is installed inside the printer or that the printer is connected to an external print server.

Page 190: Reattach Bin –
7462 Remove the speciﬁed bin. Contact Customer Support. • Touch Continue to clear the message and print without using the speciﬁed bin. Reattach bin <x> – <y> Try one or more of the following: • Turn the printer off and then back on. If the error occurs a second time: Turn the printer off.

Page 191: Receive Complete
7462 Receive complete The printer has received an entire fax job. Wait for the message to clear. Receiving page <n> The printer receives page <n> of the fax job, where <n> is the number of the page received. Wait for the message to clear.
Page 192: Replace Wiper
7462 • Touch Finish job without further scanning if page jam recovery is active. The job ends at the last successfully scanned page, but the job is not canceled. Successfully scanned pages go to their destination: copy, fax, e-mail, or FTP. •...
Page 193: Set Clock
7462 Set clock The clock is not set. This message appears if no other fax status message appears. It remains until the clock is set. SMTP server not set up. Contact system administrator. An error occurred on the SMTP server, or the SMTP server is not conﬁgured properly. Touch Continue to clear the message.
Page 194: Invalid Reﬁll, Change Cartridge
7462 30 Invalid reﬁll, change cartridge Remove the print cartridge, and then install a supported one. 31 Replace defective cartridge Remove the defective print cartridge, and then install a new one. 32 Cartridge part number unsupported by device Remove the print cartridge, and then install a supported one. 34 Short paper Try one or more of the following: •...
Page 195: Insufficient Memory, Some Held Jobs Were Deleted
7462 37 Insufficient memory, some Held Jobs were deleted The printer deleted some held jobs in order to process current jobs. Touch Continue to clear the message. 37 Insufficient memory, some held jobs will not be restored The printer was unable to restore some or all of the conﬁdential or held jobs on the printer hard disk. Touch Continue to clear the message.
Page 196: Defective Flash Detected
7462 51 Defective ﬂash detected Try one or more of the following: • Touch Continue to clear the message and continue printing. • Cancel the current print job. 52 Not enough free space in ﬂash memory for resources Try one or more of the following: •...
Page 197: Unsupported Option In Slot
7462 • Upgrade (ﬂash) the network ﬁrmware in the printer or print server. 55 Unsupported option in slot <x> <x> is a slot on the printer system board. Try one or more of the following: Turn the printer power off. Unplug the power cord from the wall outlet.

Page 198: Usb Port Disabled
7462 56 USB port <x> disabled <x> is the number of the USB port. Try one or more of the following: • Touch Continue to clear the message. The printer discards any data received through the USB port. • Make sure the USB Buffer menu item is not set to Disabled. 57 Conﬁguration change, held jobs were not restored Since the time the jobs were stored on the printer hard disk something has changed in the printer to invalidate the held jobs.
Page 199: Too Many Trays Attached
7462 Connect the power cord to a properly grounded outlet. Turn the printer back on. 58 Too many trays attached Turn the printer off. Unplug the power cord from the wall outlet. Remove the additional trays. Connect the power cord to a properly grounded outlet. Turn the printer back on.
Page 200: Unformatted Disk
7462 63 Unformatted disk Try one or more of the following: • Touch Continue to clear the message and continue printing. • Format the printer hard disk. If the error message remains, the hard disk may be defective and require replacing. 80 Routine maintenance needed The printer needs to have routine maintenance done.
Page 201: Yy Scanner Jam
7462 290‑294.yy scanner jam Clear all original documents from the scanner. 293 Replace all originals if restarting job. The scanner was instructed to scan using the ADF but there is no paper in the ADF. Load paper in the ADF. Try one or more of the following: •...
Page 202: Emulation Error, Load Emulation Option
1565 Emulation error, load emulation option The printer automatically clears the message in 30 seconds and then disables the download emulator on the ﬁrmware card. To ﬁx this, download the correct download emulator version from the Lexmark Web site at www.lexmark.com. User attendance messages User attendance messages (0‑99)
Page 203 7462 Error code Description Action The printer detects a defective ﬂash. Go to “Defective or full Flash service check” on page 208. The printer detects an unformatted ﬂash at Go to “Defective or full Flash service check” on power on. page 208.
Page 204: System Timeout Service Check
7462 Error code Description Action The fuser that had been previously installed in a Go to “Replace fuser service check” on different printer has reached its maximum page page 214. count. The toner cartridge supply is low. Go to “Replace cartridge service check” on page 214.
Page 205: Paper Is Too Short Service Check
7462 Paper is too short service check Action Step 1 Go to step 2. The problem is solved. Adjust the media tray guides to match the size of the media being used. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 206: Insufficient Collation Area Service Check
7462 Insufficient Collation Area service check Action Step 1 Go to step 2. Problem is solved. Delete fonts, macros, and other data in RAM. Does the problem remain? Step 2 Contact next level of Problem is solved. support. Install additional memory. Does the problem remain? Insufficient Memory service check Action...
Page 207: Complex Page Service Check
7462 Action Step 6 Contact next level of Problem is solved. support. Reset the active media bin. Does the problem remain? Complex page service check Action Step 1 Go to step 2. The problem is solved. Simplify, and then resend the print job. Does the problem remain? Step 2 Contact the next...
Page 208: Defective Or Full Flash Service Check
Have the network administrator verify that the device is using the correct SSID, and wireless security protocols. For more network troubleshooting information, consult the Lexmark Network Setup Guide. Actions Step 1 Go to step 2.
Page 209 7462 Actions Step 3 Go to step 4. The problem is solved. Make sure that the IP address displayed on the network settings page match the IP address in the port of the drivers using the printer. Does the problem remain? Step 4 Go to step 5.
Page 210 7462 Actions Step 11 Contact the next The problem is level of support. solved. Replace the system card. Go to “System card assembly removal” on page 321. Does the problem remain? Step 12 Go to step 13. The problem is solved.
Page 211: Unsupported Option In Slot [X] Service Check
7462 Unsupported Option in Slot [x] service check Action Remove unsupported internal option. Contact next level of Problem is solved. support. Does the problem remain? Standard USB port dsabled Action Step 1 Go to step 2. The problem is solved. From the operator panel, press the Submit button to clear the message.
Page 212: Too Many Flash Options Service Check
7462 Too Many Flash Options service check Action Contact next level of Problem is solved. Turn off the printer, and unplug it. support. Remove the excess ﬂash options. Plug in the printer, and turn it on. Does the problem remain? Too Many Trays Attached service check Action Contact next level of...
Page 213: Incompatible Output Bin [X] Service Check
7462 Incompatible Output Bin [x] service check Action Contact next level of Problem is solved. Turn off the printer, and unplug it. support. Remove the incompatible output option. Plug in the printer, and turn it on. Does the problem remain? Incompatible Output Tray [x] service check Action Contact next level of...
Page 214: Routine Maintenance Needed Service Check
7462 Routine Maintenance Needed service check Action Contact next level of Problem is solved. Replace the maintenance kit. support. Reset the maintenance counter. Go to “Maintenance page counter reset” on page 279. Does the problem remain? Replace fuser service check Action Step 1 Go to step 2.
Page 215 7462 Error code Description Action 841.xx The scanner image ASIC has failed. Go to “Scanner image ASIC failure service check” on page 215. 842.xx The ADF controller card has lost communication Go to “ADF communication failure service with the system. check”...
Page 216 7462 ADF communication failure service check Action Step 1 Go to step 2. The problem is solved. Check if all connections on the ADF controller card assembly are properly connected. Does the problem remain? Step 2 Contact the next The problem is level of support.
Page 217: Yy Errors
7462 Hard drive installation service check Action Remove, and then reinstall the hard drive. Contact the next The problem is level of support. solved. Does the problem remain? Sensor (scanner HP) service check Action Step 1 Go to step 2. The problem is solved.
Page 218 7462 Note: Not all of the items are retrievable from the printer you are working on. A. Collecting the history information from the SE menu Note: Make sure that your printer is connected to a network or to a print server. Open a Web browser, type http://printer_IP_address/se, and then press Enter.
Page 219 7462 Printing the menu settings page From the home screen, navigate to: Reports > Menu Settings Page Print the menu settings page, and then use Scan to E-mail to send it to your next level of support. D. Collecting information from the user Ask the user for information about the following: •...
Page 220 7462 910.xx–917.xx error messages Error code Description Action 910.00 The pick arm motor has stalled or become Go to “Pick arm motor service check” on obstructed. page 240. 911.00 The pick arm motor encoder continues to detect pulse after motor stops. 912.00 The pick arm motor does not rotate at the speciﬁed speed.
Page 221 7462 Error code Description Action 920.07 The fuser hot roll temperature is not maintained Go to “Fuser (920.07, 920.31, 920.32) failure properly while the media in the fuser nip. service check” on page 243. 920.25 Fuser does not maintain proper operating Go to “Fuser (920.25–920.29) failure service temperature within steady state control.
Page 222 7462 Error code Description Action 920.56 The fuser hot roll temperature does not increase Go to “Fuser unit assembly removal” on while the lamp is turned on. page 373. Fuser page count has exceeded life. Replace the fuser unit assembly. 920.57 The fuser hot roll temperature is not maintained properly while the media in the fuser nip.
Page 223 7462 922.xx error messages Error code Description Action 922.00 Fuser hot roll failed to reach target departure. Go to “Fuser (922.00, 922.25) failure service check” on page 245. 922.02 The fuser hot roll does not reach the “beginning Go to “Fuser (922.02–922.04 and 922.06–...
Page 224 7462 Error code Description Action 922.50 Fuser hot roll failed to reach target departure. Go to “Fuser unit assembly removal” on page 373. Fuser page count has exceeded life. Replace the fuser unit assembly. 922.52 The fuser hot roll does not reach the “beginning lamp detection”...
Page 225 7462 Error code Description Action 922.75 Fuser hot roll failed to reach target departure. Go to “Fuser unit assembly removal” on page 373. Fuser page count has exceeded life. Replace the fuser unit assembly. 922.77 The fuser hot roll does not reach the “beginning lamp detection”...
Page 226 7462 Error code Description Action 923.50 Fuser hot roll has exceeded the proper operating Go to “Fuser unit assembly removal” on temperature. page 373. Replace the fuser unit assembly. 923.51 Fuser hot roll has exceeded the proper operating temperature. Replace the fuser unit assembly. 923.75 Fuser hot roll has exceeded the proper operating temperature.
Page 227 7462 925.xx error messages Error code Description Action 925.00 The machine detected a 115 V lamp in a 220 V Go to “Fuser (923.00–923.01, 923.25–923.26) machine. The fuser lamp has an excessive wattage failure service check” on page 247. 925.01 rating.
Page 228 7462 Error code Description Action 929.01 The sensor (toner empty) does not provide toner Go to “Sensor (toner empty) service check” on level feedback or the print cartridge is damaged. page 249. 929.02 929.03 930.00 Possible causes: Go to “Printhead assembly removal” on page 377.
Page 229 7462 Error code Description Action 937.71 • Go to “Main drive motor assembly service The main drive motor assembly may be faulty check” on page 251. or has failed. • The internal duplex assembly is not properly grounded to the LVPS. This only applies to machines with an installed internal duplex assembly.
Page 230 7462 Error code Description Action 952.xx A recoverable NVRAM Cyclic Redundancy Check Go to “NVRAM Cyclic Redundancy Check error (CRC) error occurred. service check” on page 252. 953.xx The NVRAM chip has failed on the scanner Go to “Scanner interface card assembly interface card assembly.
Page 231 7462 Error code Description Action 978.xx The system detected a bad checksum while programming a network port. 979.xx The ﬂash parts failed while programming a network port. 982.04 An output option was not fully seated onto the Go to “Output option is missing service check” printer or has been removed while the main power on page 253.
Page 232 Note: Before troubleshooting, determine the operating system used when the error occurred. If possible, determine whether a PostScript or PCL ﬁle was sent to the device when the error occurred. Ask the customer which Lexmark Solutions applications are installed on the device. Action Step 1 Go to step 2.
Page 233 7462 Action Step 4 Contact the next The problem is solved. level of support Replace the RIP board, and then restart the device. Note: If an error displayed is different from the original 900.xx, then consult the service check for that error. Does the problem remain? Step 5 Contact the next...
Page 234 Step 13 Contact the next The problem is solved. level of support Install a Lexmark‑recommended memory option, and then send a print job to the device. Does the problem remain? Step 14 Go to step 15. Go to step 19.
Page 235 7462 Action Step 16 Go to step 17. The problem is solved. Upgrade the ﬁrmware. Contact your next level of support for the correct ﬁrmware level to use. Restart the printer to operating mode. Send the printer a print job. Does the problem remain? Step 17 Contact the next...
Page 236 7462 Action Step 22 Contact the next Go to step 23. level of support Replace the faulty ISP option, and then restart the device. Run a job to test the new option. Does the problem remain? Step 23 Go to step 24. The problem is solved.
Page 237 7462 System software (901.xx) error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is ﬁrmware related, or if the customer is sending a corrupted print job.
Page 238 7462 Paperport link driver error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is system software related, or if the customer is sending a corrupted print job.
Page 239 7462 Paperport device interface error service check Action Step 1 Go to step 2. The problem is solved. POR the machine, and then print a simple test page to determine if the problem is system software related, or if the customer is sending a corrupted print job.
Page 240 7462 Pick arm motor service check Action Step 1 Go to step 2. The problem is solved. Check all the connections on the pick arm assembly, and if necessary, replace the connections. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 241 7462 Transfer problem service check Action Step 1 Go to step 2. The problem is solved. Check the HVPS. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the system board. Does the problem remain? Step 3 Go to step 4.
Page 242 7462 Action Step 3 Contact the next The problem is level of support. solved. Replace the duplex drive motor assembly. Go to “Duplex drive motor assembly removal” on page 370. Does the problem remain? Fuser hot roll control code service check Action Turn off the machine, and then turn it back on.
Page 243 7462 Fuser (920.06) failure service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 244 7462 Action Step 3 Go to step 4. The problem is solved. Check all connections on the fuser and LVPS card assembly. Does the problem remain? Step 4 Go to step 5. The problem is solved. Replace the fuser unit assembly. Go to “Fuser unit assembly removal”...
Page 245 7462 Fuser (922.00, 922.25) failure service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 246 7462 Action Step 5 Go to step 6. The problem is solved. Replace the fuser unit assembly. Go to “Fuser unit assembly removal” on page 373. Does the problem remain? Step 6 Contact the next The problem is level of support. solved.
Page 247 7462 Fuser (923.00–923.01, 923.25–923.26) failure service check Action Step 1 Go to step 2. The problem is solved. Turn off the machine, and then turn it back on. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 248 7462 Main cooling fan service check Action Step 1 Go to step 2. The problem is solved. Check for cooling fan obstructions. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the connections on the main cooling fan, and replace the connections if necessary.
Page 249 7462 LVPS cooling fan service check Action Step 1 Go to step 2. The problem is solved. Check for cooling fan obstructions. Does the problem remain? Step 2 Go to step 3. The problem is solved. Check the connections on the main cooling fan, and replace the connections if necessary.
Page 250 7462 Action Step 5 Contact the next The problem is level of support. solved. Check the toner pulse wheel on the print cartridge for damage, and if necessary, replace the cartridge. Does the problem remain? Printhead failure service check Action Step 1 Go to step 2.
Page 251 7462 Motor (printhead polygon mirror) service check Action Step 1 Go to step 2. The problem is solved. Check all connections on the printhead assembly for proper connectivity. Does the problem remain? Step 2 Go to step 3. The problem is solved.
Page 252 7462 NVRAM Cyclic Redundancy Check error service check Action Turn off the machine, and then turn it back on. This resets the error Contact the next The problem is condition. level of support. solved. Does the problem remain? NVRAM mismatch (950.00 through 950.29) service check Warning—Potential Damage: When replacing the scanner interface card assembly and the system card assembly, make sure to: •...
Page 253 7462 Action Step 6 Contact the next The problem is level of support. solved. Replace the original operator panel assembly with a new and not previously installed operator panel door assembly or the operator panel assembly. Go to “Operator panel door assembly removal (models X651, X652, X654,X656)”...
Page 254 7462 Action Step 2 Contact the next The problem is level of support. solved. Check all the output option interface connections, and if necessary, replace the connections. Does the problem remain? Too many options installed service check Action Remove the appropriate input or output options. Contact the next The problem is level of support.
Page 255: Service Menus
7462 Service menus Understanding the ADF and scanner glass Automatic Document Feeder (ADF) Scanner glass Use the ADF for multiple‑page documents. Use the scanner glass for single pages, small items (such as postcards or photos), transparencies, photo paper, or thin media (such as magazine clippings or lightweight carbonless forms).
Page 256: Understanding The Printer Control Panel
7462 Understanding the printer control panel PQRS WXYZ Item Description Display View scanning, copying, faxing, and printing options as well as status and error messages. Keypad Enter numbers or symbols on the display. PQRS WXYZ Dial Pause • Press to cause a two- or three-second dial pause in a fax number. In the Fax To ﬁeld, a Dial Pause is represented by a comma (,).
Page 257: Understanding The Home Screen
7462 Item Description Start • Press to initiate the current job indicated on the display. • From the home screen, press to start a copy job with the default settings. • If pressed while a job is scanning, the button has no effect. Indicator light Indicates the printer status: •...
Page 258 7462 Display item Description Shows the current printer status such as Ready or Busy. Status message bar • Shows printer conditions such as Toner Low. • • Shows intervention messages to give instructions on what you should do so the printer can continue processing, such as Close door or Insert print cartridge.
Page 259: Using The Touch-Screen Buttons
7462 Display item Function Cancel Jobs Opens the Cancel Jobs screen. The Cancel Jobs screen shows three headings: Print, Fax, and Network. The following items are available under the Print, Fax, and Network headings: • Print job • Copy job •...
Page 260 7462 Button Function Left scroll decrease Scrolls to another value in decreasing order Right scroll increase Scrolls to another value in increasing order Left arrow Scrolls left Right arrow Scrolls right Submit Saves a value as the new user default setting Back Navigates back to the previous screen Other touch-screen buttons...
Page 261 7462 Button Function Unselected radio button This is an unselected radio button. The radio button is gray to show it is unselected. Selected radio button This is a selected radio button. The radio button is blue to show it is selected. Cancel Jobs Opens the Cancel Jobs screen.
Page 262: Understanding The Colors Of The Sleep Button And Indicator Lights
7462 Features Feature Description Menu trail line: A Menu trail line is located at the top of each menu screen. This feature acts as a trail, showing the path taken to arrive at the current menu. It gives the Menus > Settings > Copy Settings > exact location within the menus.
Page 263: Accessing The Service Menus
7462 Accessing the service menus There are different test menus that can be accessed during POR to identify the problems with the printer. • Diagnostics menu—This group consists of menus, settings, and operations that are used to diagnose various printer problems. Note: While the Diagnostics menu group is active, all host interfaces are offline.
Page 264: Print Tests
7462 Conﬁgure any of the following margin settings. Top Margin (value: ‑25 to +25)—A positive change moves the image down the page and increases the • top margin. A negative change moves the image up and decreases the top margin. Bottom Margin (value: ‑20 to +20)—A positive change compresses the image so it appears to move •...
Page 265 7462 Input Source Test From the Diagnostics menu, select PRINT TESTS. Select a media source to test: • Tray 1 (standard tray) • Tray 2 • Tray 3 • Tray 4 • Tray 5 • MP Feeder • Envelope Feeder Note: Trays 2–5 and the feeders are optional and are only available if installed.
Page 266: Hardware Tests
7462 HARDWARE TESTS Panel Test This test automatically toggles each pixel of the display or home screen, depending on your printer model, through every contrast level beginning with the darkest to the brightest. This continues until you press the Stop button.
Page 267: Duplex Tests
7462 Where: P:###### represents the number of times the cache has passed and ﬁnished successfully. • The maximum pass count is 999,999. F:##### represents the number of times the cache has failed and ﬁnished with errors. • The maximum pass count is 999,999. Note: After the maximum pass or fail count is reached, the test stops and the ﬁnal results appear.
Page 268 7462 Check the page for the correct offset between the placement of the ﬁrst scan line on the front and back side of a duplexed sheet. If duplex top margin needs adjustment, then adjust ﬁrst the top margin setting in the Registration menu. Note: A positive offset moves the text down the page and widens the top margin, while a negative offset moves the text up the page and narrows the top margin.
Page 269 7462 Motor Test This test determines whether the power and velocity values of the duplex option paper feed drive system are acceptable. The duplex runs the DC motor at high and low speed, taking an average of the power (PWM) required for each speed and calculating the KE value.
Page 270: Input Tray Tests
7462 INPUT TRAY TESTS Feed Tests (input tray) This test feeds blank pages through the paper path. This runs using any supported paper or envelope sizes. From the Diagnostics menu, navigate to INPUT TRAY TESTS > Feed Tests. Select a paper source, and then select one of the following: •...
Page 271: Base Sensor Test
7462 Note: Make sure that Conﬁgure Bins is not set to Link. From the Diagnostics menu, select OUTPUT BIN TESTS > Feed Tests. Select an output bin to test. Note: Only the installed bins are listed in the menu. Select one of the following: •...
Page 272: Device Tests
7462 DEVICE TESTS Quick Disk Test This test performs a nondestructive read/write test on one block per track on the disk. If the block is good, then the saved data is written back to the disk. From the Diagnostics menu, navigate to DEVICE TESTS > Quick Disk Test. After the testing is completed, a message indicating whether the test passed or failed appears on the display.
Page 273 7462 To view the page count, from the Diagnostics menu, select PRINTER SETUP > Printed Page Count. Permanent Page Count Note: The Permanent Page Count value cannot be reset. The value of this setting indicates the total amount of pages that have been printed. After all print tests have been completed, the value will reset to zero.
Page 274: Ep Setup
7462 Notes: – When the last digit or character is changed, press the select button to validate Conﬁguration ID 1. If the process is successful, then Submitting Selection and the value for conﬁguration ID 2 – appear on the display. Enter conﬁguration ID 2.
Page 275 7462 Warm Up Time This setting determines the amount of time the printer warms up before allowing the pages to print. The factory default setting is 0. This time period lets the backup roll heat up and helps reduce curl in some environments. Transfer This setting can be set to Low, Medium, or High.
Page 276: Reports
7462 • Cleans the transfer roll • Calculates reﬂectivity ratios and operating points to attain the darkness target of each operating point • Modiﬁes the EP mechanism as necessary to adjust toner darkness The cartridge smart chip controls how often this process executes. From the Diagnostics menu, navigate to EP SETUP >...
Page 277: Event Log
From the Diagnostics menu, navigate to EVENT LOG > Print Log. Note: You can fax this event log to Lexmark or to your next level of support for veriﬁcation or diagnosis. Depending on your printer model, touch Back or press the Back button to return to EVENT LOG.
Page 278 7462 ASIC Test A pattern appears and ASIC Test Passed displays. If xxxxxx displays, then the test was unsuccessful. Press Stop to return to the SCANNER TESTS menu. Feed Test To run the scanner feed test: Touch the right arrow button to select Feed Test from the SCANNER TESTS menu. The panel displays the setting’s current value.
Page 279: Conﬁguration Menu
7462 Conﬁguration menu Maintenance page count When selected, the printer displays the current value for the maintenance kit counter. This counter tracks printer usage. A print job containing a single page increments the counter by one, while a duplex print job increments the counter by two.
Page 280: Reports
7462 Note: These pages are printed in English and must always be on letter, legal, or A4 paper. Reports Menu Settings Page From the Conﬁgurations menu, navigate to Reports > Menu Settings Page. This generates reports on several Conﬁguration menu settings, including the following: •...
Page 281: Panel Menus
Restore Network or Restore STD Net—To restore all network NVRAM settings. Note: This is available only to network printers or printers connected to print servers. • Restore LES—To restore the factory default settings of the Lexmark Embedded Solutions applications. This is applicable only to some printer models. Service menus...
Page 282: Energy Conserve
7462 Energy Conserve This setting controls what values appear on the Power Saver menu. From the Conﬁguration menu, select Energy Conserve. Select one of the following: • On—The Power Saver feature cannot be turned off. On is the factory default setting. •...
Page 283: Adf Edge Erase
7462 ADF Edge Erase This setting sets the size of the no-print area around an ADF scan job. Enter the Conﬁguration menu, and then select ADF Edge Erase. Select a setting. Apply the changes. FB Edge Erase This setting sets the size of the no‑print area around a ﬂatbed scan job. Enter the Conﬁguration menu, and then select FB Edge Erase.
Page 284: Disable Scanner
7462 Select from the following options: • ADF Front—Place the quick test page faceup, short edge ﬁrst into the ADF. • ADF Back—Place the quick test page facedown, short edge ﬁrst into the ADF. The current values of the horizontal adjust and top margin registration settings appear. Adjust the value of the horizontal adjust and top margin settings.
Page 285: Action For Prompts
7462 • Envelope Feeder Note: This is available only in models T650, T652, and T654. • Manual Env or Manual Envelope (depending on your printer model) Depending on your printer model, touch Submit or press the Select button to apply the changes. Action for Prompts This setting determines what action is required from the printer to resolve any paper- or envelope-related change prompts.
Page 286: Wipe Disk
Apply the changes. LES Applications Note: This setting is for touch-screen models only. This setting allows you to enable or disable Lexmark Embedded Solutions (LES) applications. This setting does not affect built‑in applications. From the Conﬁguration menu, select LES Applications.
Page 287: Key Repeat Initial Delay
7462 Key Repeat Initial Delay This setting determines the length of delay before a repeating key starts repeating. The range is 0.25–5 seconds, with increments of 0.25. One second is the factory default setting. From the Conﬁguration menu, navigate to Key Repeat Initial Delay. Adjust the setting.
Page 288 7462...
Page 289: Repair Information
7462 Repair information • “Removal precautions” on page 290 • “Adjustments” on page 291 • “Removal procedures” on page 307 • “Left side removals” on page 308 • “Right side removals” on page 323 • “Front side removals” on page 335 •...
Page 290: Removal Precautions
7462 Removal precautions CAUTION—SHOCK HAZARD: For personal safety and to prevent damage to the printer, remove the power cord from the electrical outlet before you connect or disconnect any cable, electronic board, or assembly. Disconnect any connections between the printer and the PCs/peripherals. Handling ESD‑sensitive parts Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD).
Page 291: Adjustments
7462 Adjustments Adjusting skew For ﬂatbed scanner and ADF skew adjustment, refer to the examples below to identify if “negative” or “positive” skew is present; this will help with determining the correct adjustment to be made. Repair information...
Page 292 7462 Acceptable ADF and ﬂatbed scanner speciﬁcations Scan Flatbed (LE, TE, left and right edges) = +/‑ 0.5% (or +/‑ 0.005 mm/mm) ADF simplex and duplex (LE, TE, left and right edges) = +/‑ 0.75% Copy Flatbed, ADF simplex and duplex (LE, TE, left and right edges) = +/‑ 0.75% Repair information...
Page 293: Flatbed Scanner Skew Adjustment
7462 Flatbed scanner skew adjustment Remove the scanner left cover. Go to “Scanner left cover removal (models X651, X652, X654, and X656)” on page 522 “Scanner left cover removal (model X658)” on page 523. To adjust the ﬂatbed scanner skew, loosen the screws (A), and then slide the scanner rod mounting plate left or right accordingly, and then retighten the screws (A).
Page 294 7462 For the positive skew, rotate the document tray clockwise as shown above. Center For negative skew, rotate the document tray counterclockwise as shown above. After skew correction has been made, tighten the document tray screws, and then reinstall the ADF front and rear covers.
Page 295: Adf Skew Adjustment (Via Duplex Led Assembly)
7462 ADF skew adjustment (via duplex LED assembly) Remove the ADF front cover. Go to “ADF front cover removal” on page 537. Loosen the M4 screw (A) on the right below. Turn the skew adjustment screw (B) (to the left, below) appropriately ‑ clockwise for negative skew and counterclockwise for positive skew.
Page 296 7462 After skew correction has been made, tighten the M4 screw. Assembly is reverse of the removal procedures. Note: If the bracket above is aligned with the alignment hole in the ADF frame, the duplex LED assembly is parallel with its roller. Repair information...
Page 297: Media Squareness Check
7462 Media squareness check This test is critical when cut paper is being used to align the ADF skew during reworks. Pallets of quality paper may be found with more than 2 mm of skew. Remove the consecutive pieces of paper from the ream. Flip one of the pages over in the direction shown below.
Page 298 7462 This shows the ﬁnal position of the two pages. Ttap the two pages on a ﬂat surface until the bottom edge is aligned. Repair information...
Page 299: Print Skew Correction Procedure
7462 Look closely at the top edge of the media to see if the sheets are aligned. Square Media: Top and sides are perfectly aligned The two pages do not align perfectly at the top or sides. Media Not square: DO NOT use for ADF skew rework.
Page 300 7462 Measure L1, L2, T1, T2, R1, R2, B1, and B2 data points as shown below. Determine the following calculations: • L2‑L1 = ____ • R2‑R1 = ____ • T2‑T1 = ____ • B2‑B1 = ____ Determine if the printer passes or fails the skew speciﬁcations based on the values listed on the table. Speciﬁcations ‑‑...
Page 301: Copy Skew Correction Procedure
7462 Copy skew correction procedure Note: This speciﬁcation is used for copies from the ﬂatbed, front ADF, and back ADF. Check the paper squareness. Make sure that the guides in the paper tray are properly aligned. Check the base printer skew and registration. Make sure that the page is pushed to the top left corner of the ﬂatbed.
Page 302: Printer Skew Speciﬁcations
If the horizontal line does not fall within the deﬁned limit or spec, then it is considered skewed and the printhead must be adjusted. Go to “Polygon printhead mechanical registration adjustment” on page 304. Lexmark C544 Quick Test Printer Information Margin Settings Page Count...
Page 303 7462 Printhead Skew + Paper Feed Skew Duplex Skew Speciﬁcation Side Print Sequence Thru Printer 16 lb. to 24 lb. +/-0.007 mm/mm +/-0.005 mm/mm All Other Papers +/-0.010 mm/mm +/-0.005 mm/mm Card Stock +/-0.007 mm/mm +/-0.007 mm/mm Labels +/-0.010 mm/mm +/-0.010 mm/mm •...
Page 304: Handling Esd-Sensitive Parts
7462 Handling ESD-sensitive parts Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power before removing logic boards: •...
Page 305: Alignment Assembly Adjustment
Select Quick Test Page. The test page should only be printed on letter or A4 paper from Tray 1. The Quick Test Page consists of alignment diamonds, horizontal lines that can be used for mechanical registration adjustment. An example of the printhead alignment printout is shown below: Lexmark Hd Quick Test Device Information...
Page 306 7462 Back the reference adjustment screw out far enough to allow the alignment assembly to be removed from the printer. It is not necessary to completely remove the screw. Allen wrench Install the new alignment assembly. Turn the reference screw clockwise with a 7 mm M3 Allen wrench until it touches the back of the reference plate, and tighten the nut with a 5.5 mm wrench.
Page 307: Fuser Solenoid Adjustment
7462 Fuser solenoid adjustment Perform the fuser solenoid adjustment whenever you replace the fuser solenoid. Adjust the fuser solenoid while installed in the printer. Adjust the screw on the eccentric mounted on the solenoid housing to provide an air gap between the rear of the solenoid stator and the solenoid armature. The solenoid air gap for all models is 4.5 mm ±...
Page 308: Left Side Removals
7462 Left side removals Access door removal Open the access door. Gently detach the two hinges (A) of the access door from the machine. Remove the access door. Repair information...
Page 309: Alignment Assembly Removal
7462 Alignment assembly removal Warning—Potential Damage: When replacing the alignment assembly, ensure that the media skew is properly adjusted using the adjuster screw (C), or jamming will occur. Go to “Alignment assembly adjustment” on page 305. Remove the left side cover. Go to “Left side cover removal (models X651, X652, X654, and X656)”...
Page 310 7462 Remove the inner deﬂector. Go to “Inner deﬂector removal” on page 337. Remove the MPF pick solenoid assembly. Go to “MPF pick solenoid assembly removal” on page 313. Remove the two screws (B) securing the alignment assembly to the machine. Notes: •...
Page 311: Main Cooling Fan Removal
7462 Remove the alignment assembly. Installation warning: When replacing the alignment assembly, ensure that the media skew is properly adjusted using the adjuster screw (C), or jamming will occur. Go to “Alignment assembly adjustment” on page 305. Main cooling fan removal Remove the left side cover.
Page 312: Main Drive Motor Assembly Removal
7462 Remove the metal shield. Remove the two screws (B) securing the fuser cooling fan to the machine. Remove the fuser cooling fan. Remove the fuser cooling fan connection (C). Main drive motor assembly removal Remove the system card assembly. Go to “System card assembly removal”...
Page 313: Mpf Pick Solenoid Assembly Removal
7462 Close the operator panel door assembly. Remove the four screws (A) securing the main drive motor assembly to the machine. Gently remove the main drive motor assembly. Disconnect the connection (B) from the main drive motor assembly. Installation warning: Ensure that all electrical connections are properly replaced. Installation warning: When replacing the main drive motor assembly, ensure that the operator panel door assembly is in the closed position or the main drive motor assembly will not align properly and damage will occur.
Page 314 7462 Remove the six screws (A) securing the metal cover to the machine. Remove the metal cover. Repair information...
Page 315 7462 Remove the screw (B) securing the MPF pick solenoid assembly to the machine. Remove the MPF pick solenoid assembly. Disconnect the connection (C) from the MPF pick solenoid assembly. Repair information...
Page 316: Print Cartridge Clamp Assembly Removal
7462 Print cartridge clamp assembly removal Note: This procedure can be applied to the left or right printer cartridge hold down assembly. Remove the laser cover. Go to “Laser cover removal (models X651, X652, X654, and X656)” on page 325 “Laser cover removal (model X658)”...
Page 317: Left Side Cover Removal (Models X651, X652, X654, And X656)
7462 Release the two hooks (A) securing the print cartridge ID connector assembly to the machine. Remove the print cartridge ID connector assembly. Disconnect the connection (B) from the print cartridge ID connector assembly. Left side cover removal (models X651, X652, X654, and X656) Remove the rear door assembly.
Page 318: Left Side Cover Removal (Model X658)
7462 Remove the three screws (A) securing the left side cover to the machine. Remove the left side cover by pulling out the tabs on the top and bottom and by pulling the cover out of its rear hinges. Left side cover removal (model X658) Remove the left rear corner cover.
Page 319 7462 Release the two tabs (A) in the front. Remove the left side cover. Repair information...
Page 320: Switch (Media Size) Assembly Removal
7462 Switch (media size) assembly removal Remove the left side cover. Go to “Left side cover removal (models X651, X652, X654, and X656)” on page 317 “Left side cover removal (model X658)” on page 318. Remove the six screws (A) securing the metal cover to the machine. Remove the metal cover.
Page 321: System Card Assembly Removal
7462 System card assembly removal Warning—Potential Damage: When replacing the system card assembly and the operator panel assembly, make sure to: • Replace only one component at a time. • Perform a POR every after each component is replaced. If this procedure is not followed, then the printer will be rendered inoperable. These components can be used as a method of troubleshooting as long as the machine is booted into diagnostic mode or is operating in diagnostic mode.
Page 322 7462 Remove the metal shield. Warning—Potential Damage: When disconnecting all the electrical connections, ensure that the connectors and harnesses are not damaged. Repair information...
Page 323: Right Side Removals
7462 Disconnect all connections from the system card assembly. Note: There are two ﬁne thread screws and four course thread screws securing the system card assembly to the machine. Ensure that these screws are properly reinstalled. Remove the six screws (B) securing the system card assembly to the machine. Warning—Potential Damage: When removing the system card assembly from the machine, ensure that the LVPS assembly connection (C) is not damaged.
Page 324: Fuser Drive Release Linkage Removal
7462 Fuser drive release linkage removal Remove the system card assembly. Go to “System card assembly removal” on page 321 Gently unsnap the upper end of the fuser drive release linkage from the machine. Rotate the fuser drive release linkage 90° to release the lower end of the fuser drive release linkage from the machine.
Page 325: Laser Cover Removal (Models X651, X652, X654, And X656)
7462 Remove connection (B) and the two high voltage connections (C) from the HVPS card assembly. Installation warning: When replacing the HVPS card assembly, ensure that the two high voltage connections (C) are properly replaced. Laser cover removal (models X651, X652, X654, and X656) Remove the ADF unit assembly.
Page 326 7462 Remove the three screws (B) on either side of the laser cover. Remove the redrive assembly. Go to “Redrive assembly removal” on page 374. Remove the sensor (ADF media exit) bracket assembly. Go to “Sensor (ADF media exit) bracket assembly removal (model X651)”...
Page 327: Laser Cover Removal (Model X658)
7462 Laser cover removal (model X658) Remove the ADF unit assembly. Go to “ADF unit assembly removal (model X658)” on page 561. Remove the scanner unit assembly. Go to “Scanner unit assembly removal (model X658)” on page 533. Remove the scanner control card. Go to “Scanner controller card assembly removal (model X658)”...
Page 328: Lvps Card Assembly Removal
7462 Remove the four screws (B) on the right securing the laser cover. Remove the sensor (ADF media exit) bracket assembly. Remove the print cartridge cover. Go to “Print cartridge cover assembly removal (model X658)” on page 355. Remove the laser cover. LVPS card assembly removal Warning—Potential Damage: When replacing the LVPS card assembly, ensure that the voltage selection switch is set to the proper setting, or damage will occur.
Page 329 7462 Disconnect the connector (A) from the LVPS card assembly. Remove the two screws (B) from the LVPS card assembly. Gently pull the LVPS card assembly from the machine. Disconnect the connector (C) from the LVPS card assembly. Remove the LVPS card assembly. Installation warning: When replacing the LVPS card assembly, ensure that all connections are replaced.
Page 330: Lvps Cooling Fan Removal
7462 Installation warning: When replacing the LVPS card assembly, ensure that the connector pins (D) properly engage the system card. Installation warning: When replacing the LVPS card assembly, ensure that the voltage selection switch (E) is set to the proper setting, or damage will occur. LVPS cooling fan removal Remove the LVPS card assembly.
Page 331: Print Cartridge Cooling Fan Removal
7462 Print cartridge cooling fan removal Remove the right side cover. Go to “Right side cover removal (models X651, X652, X654, and X656)” on page 332 “Right side cover removal (model X658)” on page 331. Remove the screw (A) securing the print cartridge cooling fan to the machine. Remove the print cartridge cooling fan.
Page 332: Right Side Cover Removal (Models X651, X652, X654, And X656)
7462 Remove the screw (A), and pull the side cover, right up and out to remove. Right side cover removal (models X651, X652, X654, and X656) Remove the rear door assembly. Go to “Rear door assembly removal” on page 368. Remove the rear lower cover.
Page 333: Sensor (Toner Empty) Removal
7462 Remove the screw (B) from the rear. Firmly grasp the cover from the top, and then pull it out to remove. Sensor (toner empty) removal Remove the HVPS card assembly. Go to “HVPS card assembly removal” on page 324. Remove the screw (A) securing the sensor (toner empty) to the machine.
Page 334: Sensor (Input) Removal
7462 Disconnect the connection (B) from the sensor (toner empty). Sensor (input) removal Remove the inner deﬂector. Go to “Inner deﬂector removal” on page 337. Release the hooks (A) securing the sensor (input) to the machine. Remove the sensor (input). Disconnect the connection (B) from the sensor (input).
Page 335: Front Side Removals
7462 Front side removals Charge roll assembly removal Warning—Potential Damage: When removing the charge roll assembly, avoid touching the charge roll surface. Open the MPF door assembly. Open the operator panel front cover assembly. Detach the left side of the charge roll assembly from the machine. Repair information...
Page 336 7462 Detach the right side of the charge roll assembly from the machine. Remove the charge roll assembly. Installation warning: When replacing the charge roll assembly, avoid touching the charge roll surf Repair information...
Page 337: Inner Deﬂector Removal
7462 Inner deﬂector removal Note: The MPF lift plate assembly can be detached and allowed to hang by the harness. The connection to the MPF lower deﬂector assembly does not need to be disconnected. Remove the MPF lift plate assembly. Go to “MPF lift plate assembly removal”...
Page 338: Media Turn Guide Removal
7462 Media turn guide removal Remove the MPF tray door assembly. Go to “MPF tray door assembly removal (models X651, X652, X654, X656)” on page 340 “MPF tray door assembly removal (model X658)” on page 343. Gently bend the left side of the media turn guide to release the hook (A) as shown in the picture. While gently bending the media turn guide, move the media turn guide in the direction of the arrow.
Page 339: Mpf Media Out Actuator Removal
7462 Disconnect the connector (B) from the MPF lower deﬂector assembly. Remove the MPF lift plate assembly. Installation warning: When replacing the MPF lift plate assembly, ensure that the lever (C) is held down when reinstalling the MPF lift plate assembly, or damage will occur. Installation warning: When replacing the MPF lift plate assembly, ensure that the MPF pick solenoid assembly does not become damaged.
Page 340: Mpf Tray Door Assembly Removal (Models X651, X652, X654, X656)
7462 Remove the plastic washer (B). Remove the MPF pick roll assembly. Installation warning: When replacing the MPF pick roll assembly, do not touch the rubber surface. MPF tray door assembly removal (models X651, X652, X654, X656) Open the MPF tray door. Carefully pry the left and right manual feeder tabs out of the slots in the manual feed tray.
Page 341 7462 Slide the MPF input tray towards the front, and remove the two clips (A) securing the MPF door hinges. Bow the door slightly to remove the right side hinge pin. Repair information...
Page 342 7462 Slide the door assembly to the left until the door clears all the pins (B). Continue to slide the MPF tray door assembly to the left, and remove. Repair information...
Page 343: Mpf Tray Door Assembly Removal (Model X658)
7462 MPF tray door assembly removal (model X658) Open the MPF tray door assembly. Remove the MPF media guide assembly. Go to “MPF media guide assembly removal (model X658)” on page 344. Remove the two retaining clips (A) from the hinges on the MPF tray door. Remove the left clip (B) securing the front door tension link.
Page 344: Mpf Media Guide Assembly Removal (Model X658)
7462 MPF media guide assembly removal (model X658) Open the MPF feeder door. Remove the two tabs (A) from the slots to disconnect the MPF media guide assembly. Push the spring on the right side down, and then remove the MPF media guide assembly by rotating the assembly vertical and lift up.
Page 345: Operator Panel Cover Latch Assembly Removal (Models X651, X652, X654, X656)
7462 Operator panel cover latch assembly removal (models X651, X652, X654, X656) Lift the operator panel cover assembly. Remove the ten screws (A) securing the operator panel cover latch assembly to the operator panel cover assembly. Remove the operator panel cover latch assembly. Operator panel door assembly removal (models X651, X652, X654,X656) Warning—Potential Damage: When replacing the operator panel assembly or the system card assembly, only replace one component at a time.
Page 346 7462 Remove the pins (D) on both sides securing the links. Repair information...
Page 347 7462 Remove the eight screws (E) securing the scanner controller cage cover to the cage. An X658 model is represented in the graphic below, however, the card cage cover removal procedure is similar for all models. Remove the printer controller cage cover. Disconnect the USB cable and the cover closed interlock switch harness.
Page 348 7462 Lift the operator panel door assembly out of the machine. Repair information...
Page 349: Operator Panel Assembly Removal (Model X658)
7462 Operator panel assembly removal (model X658) Warning—Potential Damage: When replacing the operator panel assembly or the system card assembly, only replace one component at a time. Replace the required component and perform a POR before replacing another component. If this procedure is not followed, the printer will be rendered inoperable. Never replace two or more components without a POR after installing each one or the printer will be rendered inoperable.
Page 350 7462 Remove the three screws (B) securing the operator panel assembly bottom to the scanner frame. Remove the cover strip (C) from the operator panel assembly. Remove the three screws (D) securing the operator panel assembly. Slide the operator panel assembly to the left. Rotate the operator panel assembly upside down, and remove the three screws (E).
Page 351: Sensor Shield Assembly Removal
7462 Sensor shield assembly removal Remove the inner deﬂector. Go to “Inner deﬂector removal” on page 337. Gently unsnap the sensor shield assembly from the machine. Remove the sensor shield assembly. Installation warning: When replacing the sensor shield assembly, ensure that the spring (A) is properly aligned and the sensor shield assembly opens and closes properly.
Page 352: Left Transfer Roll Bracket Assembly Removal
7462 Remove the transfer roll assembly. Installation warning: When replacing the transfer roll assembly, do not touch the foam surface. Left transfer roll bracket assembly removal Remove the transfer roll assembly. Go to “Transfer roll assembly removal” on page 351. Remove the inner deﬂector.
Page 353: Right Transfer Roll Bracket Assembly Removal
7462 Installation warning: When reinstalling the transfer roll bracket assembly, left, ensure that the bushing (C), spring (D), and ground wire (F) are properly replaced. Right transfer roll bracket assembly removal Remove the transfer roll assembly. Go to “Transfer roll assembly removal” on page 351.
Page 354 7462 Remove the screw (A) securing the ground wire to the transfer deﬂector. Remove the ground wire. Installation warning: When replacing the transfer deﬂector, ensure that the ground wire is properly replaced. Repair information...
Page 355: Print Cartridge Cover Assembly Removal (Model X658)
7462 Print cartridge cover assembly removal (model X658) Open the print cartridge cover assembly. Remove the two screws (A) securing the print cartridge cover assembly. Remove the cartridge access door. Bottom side removals Duplex assembly removal Note: When removing the duplex drive motor assembly, it does not need to be completely removed from the machine.
Page 356: Duplex Input Sensor Assembly Removal
7462 Remove the four screws (A) securing the duplex assembly to the machine. Remove the harnesses (B) from the clamp. Disconnect the connection (C) from the duplex assembly. Note: When removing the duplex assembly, the lower duplex drive belt (D) will become detached. Remove the duplex assembly.
Page 357: Front Duplex Guide Assembly Removal
7462 Front duplex guide assembly removal Remove the media tray. Gently place the printer on its left or right side. Detach the front left duplex guide spring (A) from the front duplex guide assembly. Detach the front right duplex guide spring (B) from the front duplex guide assembly. Fully open the front duplex guide assembly 90°, and detach it from the machine.
Page 358: Media Out Actuator Removal
7462 Remove the front duplex guide assembly. Media out actuator removal Remove the pick arm assembly. Go to “Pick arm assembly removal” on page 359. Release the hook (A) securing the media out actuator to the unit. Remove the media out actuator. Option drive shaft removal Gently place the printer on its left or right side.
Page 359: Pick Arm Assembly Removal
7462 Remove the spring. Installation warning: When replacing the option drive shaft, ensure that the plastic hook (A) is not damaged, or the option drive shaft will not remain secured. Pick arm assembly removal Remove the media tray from the machine. Place the machine on the left or right side.
Page 360 7462 Remove the two E-clips (B) securing the pick arm assembly to the machine. Repair information...
Page 361 7462 Remove the screw (C) securing the pick arm assembly to the machine. Remove the band (D) from the pick arm assembly. Remove the cover from the pick arm assembly. Remove the three connections (E) from the pick arm assembly. Repair information...
Page 362: Pick Roll Assembly Removal
7462 Remove the wiring harness (F) from the pick arm assembly. Remove the pick arm assembly. Installation warning: When replacing the pick arm assembly, ensure that the harnesses are properly rerouted. Installation warning: When replacing the pick arm assembly, ensure that the connections are properly replaced.
Page 363: Sensor (Media Level) Removal
7462 Sensor (media level) removal Remove the pick arm assembly. Go to “Pick arm assembly removal” on page 359. Release the hooks (A) securing the sensor (media level) to the assembly. Remove the sensor (media level). Sensor (media out) removal Remove the pick arm assembly.
Page 364: Rear Side Removals
7462 Rear side removals Rear connection access cover removal Gently detach the two hinges (A) of the connection access cover, rear from the machine. Remove the connection access cover, rear. Rear lower cover removal Remove the rear door assembly. Go to “Rear door assembly removal”...
Page 365 7462 Remove the remaining two screws (B). Lift and remove the rear lower cover. Repair information...
Page 366: Left Rear Corner Cover Removal (Model X658)
7462 Left rear corner cover removal (model X658) Remove the scanner support left rear cover. Go to “Scanner support left rear cover removal (model X658)” on page 513. Remove the two screws (A) securing the left rear corner cover to the machine. Slide the left rear corner cover up and out.
Page 367 7462 Remove the two screws (A) securing the left rear corner cover. Lift and remove the right rear corner cover. Repair information...
Page 368: Rear Lower Cover Assembly Removal (Models X654, X656, X658)
7462 Rear lower cover assembly removal (models X654, X656, X658) Open the rear lower door. Remove the four screws (A) securing the rear lower cover assembly to the machine. Remove the rear lower cover assembly. Rear door assembly removal Pull the door assembly, rear away from the machine. Twist the door strap left or right until vertical, and pull the strap out of the slot.
Page 369: Rear Duplex Guide Assembly Removal
7462 Remove the door assembly, rear. Rear duplex guide assembly removal Remove the rear lower cover assembly. Go to “Rear lower cover assembly removal (models X654, X656, X658)” on page 368. Remove the media tray. Gently place the printer on its left or right side. Remove the two screws (A) securing the two retainers (B) to the machine.
Page 370: Duplex Drive Motor Assembly Removal
7462 Detach the rear duplex guide spring (C). Remove the rear duplex guide assembly. Remove the screw (D) securing the rear duplex guide handle to the assembly. Remove the rear duplex guide assembly. Duplex drive motor assembly removal Remove the fuser access door. Go to “Fuser access door assembly removal”...
Page 371 7462 Remove the three screws (A) securing the duplex drive motor assembly to the machine. Note: When removing the duplex drive motor assembly, the upper duplex drive belt (B) will become detached. Remove the band (C) from the duplex drive motor assembly. Remove the cover from the duplex drive motor assembly.
Page 372: Fuser Access Door Assembly Removal
7462 Installation warning: When replacing the duplex drive motor assembly, ensure that all harnesses are properly re-routed. Installation note: Ensure that the belt is replaced properly. Fuser access door assembly removal Remove the door assembly, rear. Go to “Rear door assembly removal” on page 368.
Page 373: Fuser Unit Assembly Removal
7462 Swing the fuser access door assembly away from the machine. Unsnap the fuser access door assembly from the machine. Remove the fuser access door assembly. Fuser unit assembly removal Remove the fuser wiper cover assembly. Go to “Fuser wiper cover assembly removal” on page 375.
Page 374: Redrive Assembly Removal
7462 While pressing the two buttons (A), pull the fuser unit assembly from the machine. Installation warning: When replacing the fuser unit assembly, ensure that the electrical connection (B) and the two buttons (A) are properly secured. Redrive assembly removal Remove the rear door assembly.
Page 375: Top Side Removals
7462 Rear Right Front Left Top side removals Fuser wiper cover assembly removal Press the button (A) securing the fuser wiper cover assembly to the machine. Remove the fuser wiper cover assembly. Repair information...
Page 376: Media Support Removal
7462 Media support removal Gently detach the two bosses (A) of the media support from the machine. Remove the media support. Output cover assembly removal (models X651, X652, X654, X656) Open the rear door assembly. Note: If you do not have a short screwdriver, remove the scanner unit assembly. Go to “Scanner unit assembly removal (models X651, X652, X654, and X656)”...
Page 377: Output Cover Assembly Removal (Model X658)
7462 Output cover assembly removal (model X658) Open the rear door assembly. Lift the right side of the fuser exit access panel and remove. Printhead assembly removal Warning—Potential Damage: When replacing the printhead assembly, ensure that the printhead skew is properly adjusted, or print quality issues will occur.
Page 378 7462 Disconnect the connections (B) from the printhead assembly. Remove the four screws (C) securing the printhead assembly to the machine. Remove the printhead assembly. Installation warning: When replacing the printhead assembly, ensure that the printhead skew is properly adjusted, or print quality issues will occur. Go to “Alignment assembly adjustment”...
Page 379: Mpf Cam Gear Removal
7462 MPF cam gear removal Remove the alignment assembly. Go to “Alignment assembly removal” on page 309. Release the hook (A) securing the gear to the unit. Remove the MPF cam gear. Redrive motor assembly removal Remove the laser cover. Go to “Laser cover removal (models X651, X652, X654, and X656)”...
Page 380 7462 Remove the metal cover. Disconnect the connection (B) from the redrive motor assembly. Disconnect the connection (C) from the sensor (standard media bin full). Repair information...
Page 381 7462 Release the hooks (D) securing the output option interface cable assembly to the machine. Detach the output option cable assembly. Remove the two screws (E) securing the redrive motor assembly to the machine. Remove the redrive motor assembly. Repair information...
Page 382: Sensor (Duplex Input) Removal
7462 Sensor (duplex input) removal Remove the duplex input sensor assembly. Go to “Duplex input sensor assembly removal” on page 356. Release the hooks (A) securing the senor (duplex media path) to the bracket. Remove the sensor (duplex input). Sensor (standard bin exit) removal Remove standard bin actuator assembly.
Page 383: Standard Bin Actuator Assembly Removal
7462 Disconnect the connection (B) to the sensor (toner density). Standard bin actuator assembly removal Remove the laser cover. Go to “Laser cover removal (models X651, X652, X654, and X656)” on page 325 “Laser cover removal (model X658)” on page 327.
Page 384: Sensor (Standard Exit Bin) Actuator Assembly Removal
7462 Sensor (standard exit bin) actuator assembly removal Open the upper rear door. Remove the fuser access panel. Remove the redrive assembly. Go to “Redrive assembly removal” on page 374. Using a ﬂat‑blade screwdriver, press on the tab (A) securing the sensor (standard exit bin) actuator assembly. Position the sensor (standard exit bin) actuator assembly where the laser can be removed.
Page 385: Tray Roller Catch Assembly Removal
7462 Tray roller catch assembly removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. Remove the media tray catch spring. Go to “Media tray catch spring removal” on page 466. Remove the tray roller catch assembly from the drawer. 550‑sheet option tray assembly Repair information...
Page 386: Bin Mailbox Removals
7462 4-bin mailbox removals 4-bin mailbox assembly left cover removal Place the 4‑bin mailbox assembly on its side. Remove the two screws (A) on the underside of the 4-bin mailbox assembly securing the left cover. Using your ﬁnger, pull up on the top surface of the left cover while simultaneously pulling out, and remove. 4-bin mailbox assembly controller card assembly removal Remove the 4‑bin mailbox assembly left cover.
Page 387: Bin Mailbox Assembly Sensor (Media Bin Full) Removal
7462 Remove the two screws (A) securing the controller card to the 4-bin mailbox assembly and remove. 4-bin mailbox assembly sensor (media bin full) removal Remove the 4‑bin mailbox assembly left cover. Go to “4-bin mailbox assembly left cover removal” on page 386.
Page 388: Bin Mailbox Assembly Sensor (Deﬂector Gate Hp) Removal
7462 Pinch the tabs securing the sensor (media bin full) to the media tray and remove. 4-bin mailbox assembly sensor (deﬂector gate HP) removal Remove the 4‑bin mailbox assembly left cover. Go to “4-bin mailbox assembly left cover removal” on page 386.
Page 389: Bin Mailbox Assembly Rear Door Assembly Removal
7462 Disconnect the harness from the sensor (deﬂector gate HP). 4-bin mailbox assembly rear door assembly removal Open the rear door. Gently spread each side of the 4‑bin mailbox assembly until the rear door hinge is free to be removed. Repair information...
Page 390: Bin Mailbox Assembly Right Cover Removal
7462 Remove the rear door assembly. 4-bin mailbox assembly right cover removal Place the 4-bin mailbox assembly on its side. Remove the two screws (A) from the bottom side of the right cover securing cover in place. Using your ﬁngers, pull up on the top of the right cover and pull out simultaneously to remove. Repair information...
Page 391: Bin Mailbox Assembly Led Card Assembly Removal
7462 4-bin mailbox assembly LED card assembly removal Remove the 4-bin mailbox assembly right cover. Go to “4-bin mailbox assembly right cover removal” on page 390. Disconnect the three wire harnesses attached to the LED card assembly. Remove the three screws (A) securing the LED card assembly to the 4-bin mailbox assembly. Remove the 4-bin mailbox assembly LED card assembly.
Page 392 7462 Remove the four screws (A) on each side of the top cover securing it to the 4-bin mailbox assembly. Slide the top cover towards the rear and remove. Repair information...
Page 393: Bin Mailbox Assembly Deﬂector Gate Solenoid Removal
7462 4-bin mailbox assembly deﬂector gate solenoid removal Remove the 4‑bin mailbox assembly top cover. Go to “4-bin mailbox assembly top cover removal” on page 391. Remove the screw (A) securing the deﬂector gate solenoid to the 4-bin mailbox assembly. Carefully unroute the deﬂector gate solenoid cables from the cable clips under the top cover.
Page 394: Bin Mailbox Assembly Spring Removal
7462 Remove the screw (A) securing the transport solenoid to the 4‑bin mailbox assembly. Remove the transport solenoid and pull the cable through the left side frame. 4-bin mailbox assembly spring removal Remove the 4-bin mailbox assembly rear door assembly. Go to “4-bin mailbox assembly rear door assembly removal”...
Page 395: Bin Mailbox Assembly Deﬂector Gate (Bin 1 Through 3) Removal
7462 4-bin mailbox assembly deﬂector gate (bin 1 through 3) removal Remove the 4-bin mailbox assembly rear door assembly. Go to “4-bin mailbox assembly rear door assembly removal” on page 389. Remove the 4-bin mailbox assembly right rear inner cover. Remove the 4-bin mailbox assembly spring.
Page 396: Bin Mailbox Assembly Deﬂector Gate (Bin 4) Removal
7462 4-bin mailbox assembly deﬂector gate (bin 4) removal Remove the 4-bin mailbox assembly rear door assembly. Go to “4-bin mailbox assembly rear door assembly removal” on page 389. Grasp the 4th bin deﬂector gate and pull out on either side. Repair information...
Page 397: Bin Mailbox Assembly Sensor (Pass Through) Removal
7462 4-bin mailbox assembly sensor (pass through) removal Note: The sensor (pass through) is the lower rear sensor. The rear upper sensor is the sensor (mailbox empty). Open the rear door. Life the deﬂector gate above the sensor (pass through) and using a ﬂat‑blade screwdriver, release the tabs securing the sensor (pass through) to the 4‑bin mailbox assembly.
Page 398: Bin Mailbox Assembly Sensor (Mailbox Empty) Removal
7462 Disconnect the sensor (pass through) harness from the controller board. 4-bin mailbox assembly sensor (mailbox empty) removal Note: The sensor (pass through) is the lower rear sensor. The rear upper sensor is the sensor (mailbox empty). Open the rear door. Life the deﬂector gate above the sensor (mailbox empty) and using a ﬂat‑blade screwdriver, release the tabs securing the sensor (mailbox empty) to the 4‑bin mailbox assembly.
Page 399 7462 Remove the 4‑bin mailbox assembly left cover. Go to “4-bin mailbox assembly left cover removal” on page 386. Disconnect the sensor (mailbox empty) harness from the controller board. Repair information...
Page 400: Bin Mailbox Assembly Standard Output Bin Led Removal
7462 4-bin mailbox assembly standard output bin LED removal Remove the three screws (A) on the underside of bin 1 securing the output bin LED bracket. Pull the output bin LED bracket out from the underside of bin 1 and disconnect the LED harness. Repair information...
Page 401 7462 Remove the two screws (B) securing the output bin LED to the bracket and remove the output bin LED. Repair information...
Page 402: Bin Mailbox Assembly Led Clear Lens Removal
7462 4-bin mailbox assembly LED clear lens removal Remove the 4-bin mailbox assembly standard output bin LED. Go to “4-bin mailbox assembly standard output bin LED removal” on page 400. Remove the output bin LED clear lens from the output bin LED bracket. Repair information...
Page 403: Bin Mailbox Assembly Media Bin Full Actuator Removal
7462 4-bin mailbox assembly media bin full actuator removal Remove the 4-bin mailbox assembly left cover. Go to “4-bin mailbox assembly left cover removal” on page 386. Pry the front hinge of the media bin full actuator towards the rear until the front boss is released from its socket.
Page 404: Sheet Option Tray Removals
7462 250-sheet option tray removals 250-sheet media tray assembly removal Note: This removal procedure can be applied to 250-sheet option drawer assembly. Find the 250-sheet media tray assembly in the 250-sheet option drawer assembly. Remove the 250-sheet media tray assembly from the 250-sheet option drawer assembly. 250-sheet tray pick arm bracket assembly removal Note: Carefully remove the base machine from the input option tray assembly before proceeding.
Page 405: Sheet Tray Media Out Actuator Removal
7462 Remove the three screws (A) securing the 250-sheet tray pick arm bracket assembly to the drawer. Remove the 250-sheet tray pick arm bracket assembly. 250-sheet tray media out actuator removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. Remove the 250-sheet tray pick arm bracket assembly.
Page 406: Sheet Tray Frame Assembly Removal
7462 Remove the 250-sheet tray media out actuator from the drawer. 250-sheet tray frame assembly removal Note: The 250-sheet tray frame assembly is not a FRU. Remove the 250-sheet tray pick arm bracket assembly. Go to “250-sheet tray pick arm bracket assembly removal”...
Page 407: Sheet Tray Controller Card Assembly Removal
7462 Remove the 250-sheet tray frame assembly. 250-sheet tray controller card assembly removal Remove the 250-sheet tray frame assembly. Go to “250-sheet tray frame assembly removal” on page 406. Disconnect the three connectors from the 250-sheet tray controller card assembly. Repair information...
Page 408 7462 Remove the three screws (B) securing the 250-sheet tray controller card assembly to the 250-sheet tray frame. Remove the 250-sheet tray controller card assembly. Repair information...
Page 409: Sheet Option Tray Removals
7462 550-sheet option tray removals 550-sheet media tray assembly removal Note: This removal procedure can be applied to 550-sheet option drawer assembly. Find the 550-sheet media tray assembly in the 550-sheet option drawer assembly. Remove the 550-sheet media tray assembly from the 550-sheet option drawer assembly. 550-sheet tray pick arm bracket assembly removal Remove the 550-sheet media tray assembly.
Page 410 7462 Remove the four screws (C) securing the 550-sheet tray pick arm bracket assembly to the drawer. Remove the 550-sheet tray pick arm bracket assembly. Repair information...
Page 411: Sheet Tray Bellcrank Recoil Spring Removal
7462 550-sheet tray bellcrank recoil spring removal Remove the 550-sheet tray pick arm bracket assembly. Go to “550-sheet tray pick arm bracket assembly removal” on page 409. Remove the 550-sheet tray bellcrank recoil spring from the 550-sheet tray pick arm bracket assembly. 550-sheet tray frame assembly removal Note: The 550-sheet tray frame assembly is not a FRU.
Page 412 7462 Remove the four screws (A) securing the 550-sheet tray frame assembly to the drawer. Repair information...
Page 413: Sheet Tray Controller Card Assembly Removal
7462 Remove the 550-sheet tray frame assembly. 550-sheet tray controller card assembly removal Remove the 550-sheet tray frame assembly. Go to “Media size actuator removal” on page 466. Disconnect the three connectors from the 550-sheet tray controller card assembly. Repair information...
Page 414: Sheet Tray Option Drive Shaft With Spring Removal
7462 Remove the three screws (A) securing the 550-sheet tray controller card assembly to the 550-sheet tray frame. Remove the 550-sheet tray controller card assembly. 550-sheet tray option drive shaft with spring removal Remove the 550-sheet tray frame assembly. Go to “Media size actuator removal”...
Page 415: Anti-Tip Latch Assembly Removal
7462 Pull the drive roll gear (B), the shaft with spring (C), and the bevel out through the opening. Remove the 550-sheet tray option drive shaft with spring. Anti-tip latch assembly removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. The left and right anti-tip latch assemblies are the same, and only one is in a package.
Page 416 7462 Remove the anti-tip latch assembly. Repair information...
Page 417: High Capacity Input Tray (Hcit) Removals
7462 High capacity input tray (HCIT) removals High capacity input tray (HCIT) media tray assembly removal Open the HCIT media tray assembly until it reaches a stop. Press the latches (A) on the left and right sides of the HCIT tray slides. Slide the HCIT media tray assembly out of the drawer.
Page 418: High Capacity Input Tray (Hcit) Tray Cover, Front Removal
7462 High capacity input tray (HCIT) tray cover, front removal Open the HCIT media tray assembly until it reaches a stop. Remove the six screws (A) securing the HCIT tray cover, front to the HCIT media tray assembly. Repair information...
Page 419 7462 Remove the HCIT tray cover, front. Repair information...
Page 420: High Capacity Input Tray (Hcit) Cover, Rear Removal
7462 High capacity input tray (HCIT) cover, rear removal Remove the HCIT media tray assembly. Go to “High capacity input tray (HCIT) media tray assembly removal” on page 417. Remove the four screws (A) securing the HCIT cover, rear to the drawer. Repair information...
Page 421: High Capacity Input Tray (Hcit) Cover, Right Removal
7462 Remove the HCIT cover, rear. High capacity input tray (HCIT) cover, right removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Repair information...
Page 422 7462 Note: Before removing the HCIT right cover, ﬁrst remove the right side anti-tip latch assembly. Go to “High capacity input tray (HCIT) anti-tip latch assembly removal” on page 425. Remove the high capacity input tray (HCIT) cover, rear. Go to “High capacity input tray (HCIT) cover, rear removal”...
Page 423: High Capacity Input Tray (Hcit) Cover, Left Removal
7462 Remove the HCIT cover, right. High capacity input tray (HCIT) cover, left removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Repair information...
Page 424 7462 Note: Before removing the HCIT left cover, ﬁrst remove the left side anti-tip latch assembly. Go to “High capacity input tray (HCIT) anti-tip latch assembly removal” on page 425. Remove the high capacity input tray (HCIT) cover, rear. Go to “High capacity input tray (HCIT) cover, rear removal”...
Page 425: High Capacity Input Tray (Hcit) Anti-Tip Latch Assembly Removal
7462 Remove the HCIT cover, left. High capacity input tray (HCIT) anti-tip latch assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. The left and right anti-tip latch assemblies are the same, and only one is in a package. The instructions below are for removing the left latch;...
Page 426: High Capacity Input Tray (Hcit) Drawer Slide Assembly Removal
7462 High capacity input tray (HCIT) drawer slide assembly removal Note: The left and right drawer slide assemblies are the same, and only one is in a package. The instructions below are for removing the left slide; removing the right slide has similar instructions. Remove the HCIT media tray assembly.
Page 427: High Capacity Input Tray (Hcit) Tray Lift Drive Motor Assembly Removal
7462 High capacity input tray (HCIT) tray lift drive motor assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, right. Go to “High capacity input tray (HCIT) cover, right removal” on page 421.
Page 428: High Capacity Input Tray (Hcit) Controller Card Assembly Removal
7462 High capacity input tray (HCIT) controller card assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 423.
Page 429: High Capacity Input Tray (Hcit) Media Size Actuator Assembly Removal
7462 Remove the three screws (A) securing the HCIT controller card assembly. Remove the HCIT controller card assembly and the shield. High capacity input tray (HCIT) media size actuator assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT controller card assembly.
Page 430 7462 Slide the cam size sensing plate (B) through the access hole in the rear side frame. Snap loose the actuator switch (C) and remove. Repair information...
Page 431 7462 Remove the four screws (D) securing the card mount option with the media size actuator to the frame. Remove the card mount option with the media size actuator. Installation notes: Re-install the card mount option with the media size actuator to the frame by inserting the leftmost part of it through the hole, and then securing it with the four screws.
Page 432: High Capacity Input Tray (Hcit) Pick Arm Bracket Assembly Removal
7462 High capacity input tray (HCIT) pick arm bracket assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 423.
Page 433 7462 Remove the ﬁve screws (A) securing the HCIT pick arm bracket assembly. Remove the HCIT pick arm bracket assembly from the drawer by slightly lifting and removing it. Repair information...
Page 434: High Capacity Input Tray (Hcit) Tray Closed Latch With Spring Removal
7462 High capacity input tray (HCIT) tray closed latch with spring removal The left and right tray closed latches with springs are the same, and only one is in a package. The instructions below are for removing the left latch; removing the right latch has similar instructions. Remove the HCIT media tray assembly.
Page 435: High Capacity Stacker Right Cover Removal
7462 Remove the rear door assembly from the hinges by gently prying the hinges off the bosses. High capacity stacker right cover removal Remove the high capacity stacker rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 434.
Page 436: High Capacity Stacker Left Cover Removal
7462 Remove the right cover. High capacity stacker left cover removal Remove the high capacity stacker rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 434. Using a #1 phillips screwdriver, remove the three screws (A) securing the left cover to the high capacity stacker assembly.
Page 437: High Capacity Stacker Controller Card Cover Panel Removal
7462 High capacity stacker controller card cover panel removal Remove the media output bin assembly. Go to “High capacity stacker rear door assembly removal” on page 434. Remove the two screws (A) securing the controller card cover panel on the rear of the assembly. Remove the screw (B) securing the ground strap to the right frame.
Page 438: High Capacity Stacker Switch (Media Bin Hp) Removal
7462 High capacity stacker switch (media bin HP) removal Remove the high capacity stacker controller card cover panel. Go to “High capacity stacker controller card cover panel removal” on page 437. Remove the two screws (A) securing the high capacity stacker switch (media bin HP) to the left frame. Disconnect the high capacity stacker switch (media bin HP) harness from the upper controller card.
Page 439: High Capacity Stacker Sensor (Media Bin Full) Bracket Assembly Removal
7462 Remove the high capacity stacker sensor (media bin full) assembly. High capacity stacker sensor (media bin full) bracket assembly removal Remove the high capacity stacker left cover. Go to “High capacity stacker left cover removal” on page 436. Release the tab securing the bracket to the left frame. Remove the bracket from the frame and disconnect the sensor (media bin full) and media bin full actuator.
Page 440: High Capacity Stacker Controller Card Assembly (Upper And Lower) Removal
7462 High capacity stacker controller card assembly (upper and lower) removal Remove the high capacity stacker controller card cover panel. Go to “High capacity stacker controller card cover panel removal” on page 437. Disconnect the harnesses from the controller card. Note: Pay careful attention to where the power input and output harnesses are attached.
Page 441: High Capacity Stacker Left Frame Removal
7462 Carefully remove the right frame. Note: When installing the right frame, make sure the media output bin assembly is aligned properly. High capacity stacker left frame removal Remove the left media output bin recoil spring. Remove the two screws (A) securing the switch (media bin HP) to the left frame. Remove the high capacity stacker standard output bin LED.
Page 442 7462 Remove the four screws (B) securing the left frame to the high capacity stacker assembly. Carefully remove the left frame. Note: When installing the left frame, make sure the media output bin assembly is aligned properly. Repair information...
Page 443: High Capacity Stacker Upper Deﬂector Gate Removal
7462 High capacity stacker upper deﬂector gate removal Remove the rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 434. With a spring hook, carefully remove the upper deﬂector gate spring and for ease of reassembly, temporarily hook the spring to the upper frame tab.
Page 444: Sensor (High Capacity Stacker Pass Through) Removal
7462 Unsnap each side of the deﬂector gate and remove. Sensor (high capacity stacker pass through) removal Remove the rear door assembly. Go to “High capacity stacker rear door assembly removal” on page 434. Using needle-nose pliers or your ﬁnger, pull out and downward on the sensor (pass through) until the sensor unsnaps.
Page 445 7462 Disconnect the sensor (pass through) harness from the controller card and remove the sensor. Repair information...
Page 446: High Capacity Stacker Left Mounting Bracket Removal
7462 High capacity stacker left mounting bracket removal Remove the high capacity stacker left cover. Go to “High capacity stacker left cover removal” on page 436. Remove the eight screws (A) securing the high capacity stacker left mounting bracket. Pull the bracket up and let it rest on the assembly with the cables intact. Sensor (high capacity stacker deﬂector gate HP) removal Remove the high capacity stacker left mounting bracket.
Page 447: Offset Stacker Removals
7462 Unclip the sensor tabs and remove. Offset stacker removals Offset stacker rear door assembly removal Open the rear door assembly. Force the left hinge out of the slot by pushing the door to the right. Once the left hinge has been disengaged, pull the right hinge out. Repair information...
Page 448: Offset Stacker Right Cover Removal
7462 Remove the offset stacker rear door assembly. Offset stacker right cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the right cover. Pull out on the front side of the right cover to disengage the tabs. Remove the offset stacker right cover.
Page 449: Offset Stacker Left Cover Removal
7462 Offset stacker left cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the left cover. Pull out on the front side of the left cover to disengage the tabs. Remove the offset stacker left cover. Repair information...
Page 450: Mfp Stapler Assembly Top Cover Removal
7462 MFP stapler assembly top cover removal Remove the left and right covers. Go to “Offset stacker left cover removal” on page 449 “Offset stacker right cover removal” on page 448. Remove the screw (A) on each side of the top cover. Pull up and toward the front to remove the offset stacker top cover.
Page 451: Offset Stacker Handle Cover Removal
7462 Offset stacker handle cover removal Remove the left and right covers. Go to “Offset stacker left cover removal” on page 449 “Offset stacker right cover removal” on page 448. Remove the screw (A) on each side of the handle cover. Lift up and to the rear to remove the cover.
Page 452: Offset Stacker Led Sensor Cover Removal
7462 Offset stacker LED sensor cover removal Remove the screw (A) securing the LED sensor cover to the underside of the output bin. Remove the standard output bin LED. Go to “Offset stacker standard output bin LED and LED clear lens removal”...
Page 453: Sensor (Offset Stacker Finisher Media Bin Present) Removal
7462 Remove the LED sensor cover. Sensor (offset stacker ﬁnisher media bin present) removal Remove the offset stacker LED sensor cover. Go to “Offset stacker LED sensor cover removal” on page 452. Using a ﬂat-blade screwdriver, release the tabs (A) on the sensor and remove it from the sensor cover. Remove the harness connected to the sensor (offset stacker ﬁnisher media bin present).
Page 454: Offset Stacker Standard Output Bin Led And Led Clear Lens Removal
7462 Offset stacker standard output bin LED and LED clear lens removal Remove the offset stacker LED sensor cover. Go to “Offset stacker LED sensor cover removal” on page 452. Remove the two screws (A) securing the LED to the cover. Remove the LED and disconnect the harness.
Page 455: Offset Stacker Tamper Drive Belt Removal
7462 Offset stacker tamper drive belt removal Remove the offset stacker tamper recoil spring. Pull the belt out the tamper belt holder and remove the belt from the pulley. Offset stacker tamper drive motor assembly removal Remove the offset stacker top cover. Go to “MFP stapler assembly top cover removal”...
Page 456: Offset Stacker Media Stack Flap And Media Stack Flap Actuator Removal
7462 Remove the two screws (A) securing the tamper drive motor assembly to the tamper frame. Remove the tamper drive motor assembly. Offset stacker media stack ﬂap and media stack ﬂap actuator removal Remove the offset stacker handle cover. Go to “Offset stacker handle cover removal”...
Page 457: Offset Stacker Paddle Drive Motor Assembly Removal
7462 Offset stacker paddle drive motor assembly removal Remove the left cover. Go to “Offset stacker left cover removal” on page 449. Disconnect the paddle motor harness from the controller card. Remove the cable from the harness clip. Repair information...
Page 458: Sensor (Offset Stacker Media Stack) Removal
7462 Remove the two screws (A) securing the two paddle drive motor assemblies. Remove the paddle drive motor assembly. Sensor (offset stacker media stack) removal Remove the offset stacker top cover. Go to “MFP stapler assembly top cover removal” on page 450.
Page 459: Sensor (Offset Stacker Paddle Hp) Removal
7462 Using your ﬁngers, pinch tab (A) securing the offset stacker sensor (media stack) and remove. Sensor (offset stacker paddle HP) removal Remove the offset stacker left cover. Go to “Offset stacker left cover removal” on page 449. Disconnect the harness to the sensor (offset stacker paddle home position). Using your ﬁngers, pinch tab (A) securing the sensor (offset stacker paddle home position) and remove.
Page 460: Sensor (Offset Stacker Tamper Hp Left And Right) Removal
7462 Sensor (offset stacker tamper HP left and right) removal Remove the offset stacker top cover. Go to “MFP stapler assembly top cover removal” on page 450. Disconnect the harness to the sensor (offset stacker tamper HP left and right). Using your ﬁngers, pinch the tabs (A) securing the staple ﬁnisher sensor (tamper HP left and right) and remove.
Page 461: Sensor (Offset Stacker Bin Full Send) Removal
7462 Sensor (offset stacker bin full send) removal Remove the stapler/stacker controller card assembly. Go to “Stapler/stacker controller card assembly removal” on page 463. Remove the two screws (A) securing the staple ﬁnisher sensor (bin full send). Disconnect the harness and remove. Repair information...
Page 462: Sensor (Offset Stacker Bin Full Receive) Removal
7462 Sensor (offset stacker bin full receive) removal Remove the offset stacker right cover. Go to “Offset stacker right cover removal” on page 448. Remove the two screws (A) securing the sensor (bin full receive). Disconnect the harness and remove. Sensor (offset stacker deﬂector HP) removal Remove the offset stacker left cover.
Page 463: Stapler/Stacker Controller Card Assembly Removal
7462 Release the tabs (A) securing the sensor to the offset stacker. Note: The tabs may be difficult to access. The use of a spring hook or ﬂat-blade screwdriver may be necessary to release the tabs. Stapler/stacker controller card assembly removal Remove the left cover.
Page 464: Other Removals
7462 Remove the three screws (A) securing the stapler/stacker controller card assembly. Remove the stapler/stacker controller card assembly. Other removals Lower interface cable assembly removal Remove the 550-sheet frame assembly. Go to “Media size actuator removal” on page 466. Disconnect the lower interface cable connector (A) from the 550-sheet controller card. Repair information...
Page 465: Media Size Actuator Removal
7462 Pinch the options auto connect (B) to separate the lower interface cable assembly from the 550-sheet frame. Remove the lower interface cable assembly. Media size actuator removal Note: Carefully remove the base machine from the input option tray assembly before proceeding. Remove the 250-sheet controller card assembly.
Page 466: Media Tray Catch Spring Removal
7462 Media tray catch spring removal Remove the 250-sheet frame assembly. Go to “250-sheet tray frame assembly removal” on page 406. Turn the drawer upside down to access the media tray catch spring. Release the media tray catch spring. Media size actuator removal Remove the 550-sheet controller card assembly.
Page 467: Media Tray Catch Spring Removal
7462 Media tray catch spring removal Remove the 550-sheet frame assembly. Go to “Media size actuator removal” on page 466. Turn the drawer over so that you can access the media tray catch spring. Release the media tray catch spring. Media tray roller catch assembly removal Remove the media tray catch spring.
Page 468: Sensor (Hcit Tray Raised Hp) With Cable Assembly Removal
7462 Sensor (HCIT tray raised HP) with cable assembly removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 423.
Page 469 7462 Release the hooks (B) securing the sensor to the rear frame. Remove the sensor (HCIT tray raised HP). Repair information...
Page 470: Sensor (Hcit Pass Through) With Cable Removal
7462 Sensor (HCIT pass through) with cable removal Note: Carefully remove the base machine from the HCIT tray assembly before proceeding. Remove the HCIT cover, left. Go to “High capacity input tray (HCIT) cover, left removal” on page 423. Disconnect the sensor (HCIT pass through) cable connector from the HCIT controller card assembly. Note: Remove the cable restraint, and observe the routing for reinstallation.
Page 471: Sensor (Pass Through) With Cable Removal
7462 Sensor (pass through) with cable removal Remove the 250-sheet frame assembly. Go to “250-sheet tray frame assembly removal” on page 406. Disconnect the sensor (pass through) cable connector from the 250-sheet controller card. Remove the sensor (pass through) with cable. Sensor (pass through) with cable removal Remove the 550-sheet frame assembly.
Page 472: Tray Roller Catch Assembly Removal
7462 Tray roller catch assembly removal Remove the media tray catch spring. Go to “Media tray catch spring removal” on page 466. Remove the tray roller catch assembly from the drawer. Tray roller catch assembly removal Remove the media tray catch spring. Go to “Media tray catch spring removal”...
Page 473: Output Expander Removals
7462 Release the two hooks (B) securing the options auto connect to the 550-sheet frame. Remove the upper interface cable assembly. Output expander removals Output expander rear door assembly removal Open the rear door assembly. Hold the door to approximately 45° angle, and force out the left hinge and slide the right hinge out to remove the door.
Page 474: Output Expander Left Outer Cover Removal
7462 Output expander left outer cover removal Remove the output expander rear door assembly. Go to “Output expander rear door assembly removal” on page 473. Grasp the lower rear corner of the left outer cover and pull out to remove. Output expander left inner cover removal Remove the output expander left outer cover.
Page 475: Output Expander Right Outer Cover Removal
7462 Output expander right outer cover removal Remove the output expander rear door assembly. Go to “Output expander rear door assembly removal” on page 473. Grasp the lower rear corner of the right outer cover and pull out to remove. Output expander right inner cover removal Remove the output expander right outer cover.
Page 476: Output Expander Media Bin Latch (Left And Right) Removal
7462 Output expander media bin latch (left and right) removal Remove the output expander left or right inner cover. Go to “Output expander left inner cover removal” on page 474 “Output expander right inner cover removal” on page 475. If removing the right side media bin latch, use a springhook to pull the media bin latch spring off the spring post on the output expander frame.
Page 477: Output Expander Media Bin Full Actuator Removal
7462 Rotate the output bin assembly downward and out of the slots to remove. Output expander media bin full actuator removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 474. Unsnap the actuator from its hinges and pull out to remove. Output expander sensors (media bin full) assembly removal Remove the output bin left inner cover.
Page 478 7462 Release the tabs securing the sensors (media bin full) and remove. Installation note: Be sure to replace the sensors in the correct order. Make sure their positions are not switched. Remove the output expander controller card cover panel. Go to “Output expander controller card cover panel removal”...
Page 479: Output Expander Sensor (Media Bin Full) Bracket Assembly Removal
7462 Output expander sensor (media bin full) bracket assembly removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 474. Grasp the sensor bracket and pull away from the option while releasing the tab. If replacing the bracket, remove the sensors (media bin full) from the bracket.
Page 480: Output Expander Controller Card Cover Panel Removal
7462 Output expander controller card cover panel removal Remove the output expander media output bin assembly. Go to “Output expander media output bin assembly removal” on page 476. Remove the screw (A) on the back side of the option. Remove the grounding screw (B) on the right output option frame guide the grounding cable through the hole in the frame.
Page 481: Sensor (Output Expander Pass Through) Removal
7462 Remove the two screws (A) securing the controller card to the frame. Remove the controller card. Replacement Note: Be sure to replace the interface connectors in their proper orientation as the two have common connection pins. Sensor (output expander pass through) removal Remove the output expander controller card cover panel.
Page 482: Output Expander Deﬂector Gate Removal
7462 Pull the connector harness through the frame and remove. Output expander deﬂector gate removal Use a spring hook to disconnect the upper end of the deﬂector gate spring. Temporarily hook the upper end of the deﬂector gate spring to the left frame. Repair information...
Page 483: Sensor (Output Expander Deﬂector Gate Hp) Removal
7462 Pull the deﬂector gate out of its hinges and remove. Sensor (output expander deﬂector gate HP) removal Remove the output expander left inner cover. Go to “Output expander left inner cover removal” on page 474. Remove the four screws securing the left frame assembly to the option. Pull the left frame assembly out far enough to gain access to the sensor (deﬂector gate HP).
Page 484: Mfp Stapler Assembly Removals
7462 Disconnect the harness to the sensor and remove. MFP stapler assembly removals MFP stapler assembly rear door assembly removal Open the rear door assembly. Force the left hinge out of the slot by pushing the door to the right. Once the left hinge has been disengaged, pull the right hinge out.
Page 485: Mfp Stapler Assembly Right Cover Removal
7462 MFP stapler assembly right cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the right cover. Pull out on the front side of the right cover to disengage the tabs. Remove the right cover. Repair information...
Page 486: Mfp Stapler Assembly Left Cover Removal
7462 MFP stapler assembly left cover removal Remove the two screws (A) on the inside of the exit bin compartment securing the left cover. Pull out on the front side of the left cover to disengage the tabs. Remove the left cover. Repair information...
Page 487: Mfp Stapler Assembly Top Cover Removal
7462 MFP stapler assembly top cover removal Remove the left and right covers. Go to “MFP stapler assembly left cover removal” on page 486 “MFP stapler assembly right cover removal” on page 485. Remove the two screws (A) from the left and right side of the top cover. Pull up and toward the front to remove the top cover.
Page 488: Mfp Stapler Assembly Handle Cover Removal
7462 MFP stapler assembly handle cover removal Remove the left and right covers. Go to “MFP stapler assembly left cover removal” on page 486 “MFP stapler assembly right cover removal” on page 485. Remove two screws (A) from each side of the handle cover. Lift up and to the rear to remove the cover.
Page 489: Mfp Stapler Assembly Led Sensor Cover Removal
7462 MFP stapler assembly LED sensor cover removal Remove the screw (A) securing the LED sensor cover to the underside of the output bin. Remove the standard output bin LED. Go to “MFP stapler assembly standard output bin LED and LED clear lens removal”...
Page 490: Sensor (Mfp Stapler Assembly Finisher Media Bin Present) Removal
7462 Remove the LED sensor cover. Sensor (MFP stapler assembly ﬁnisher media bin present) removal Remove the LED sensor cover. Go to “MFP stapler assembly LED sensor cover removal” on page 489. Using a ﬂat-blade screwdriver, release the tabs (A) on the sensor and remove it from the sensor cover. Remove the harness connected to the sensor (ﬁnisher media bin present).
Page 491: Mfp Stapler Assembly Standard Output Bin Led And Led Clear Lens Removal
7462 MFP stapler assembly standard output bin LED and LED clear lens removal Remove the LED sensor cover. Go to “MFP stapler assembly LED sensor cover removal” on page 489. Remove the two screws (A) securing the LED to the cover. Remove the LED and disconnect the harness.
Page 492: Mfp Stapler Assembly Tamper Drive Belt Removal
7462 MFP stapler assembly tamper drive belt removal Remove the tamper recoil spring. Pull the belt out the tamper belt holder and remove the belt from the pulley. MFP stapler assembly tamper drive motor assembly removal Remove the top cover. Go to “MFP stapler assembly top cover removal”...
Page 493: Mfp Stapler Assembly Media Stack Flap And Media Stack Flap Actuator Removal
7462 Remove the two screws (A) securing the tamper drive motor assembly to the tamper frame. Remove the tamper drive motor assembly. MFP stapler assembly media stack ﬂap and media stack ﬂap actuator removal Remove the handle cover. Go to “MFP stapler assembly handle cover removal”...
Page 494: Mfp Stapler Assembly Stapler Unit Assembly Removal
7462 MFP stapler assembly stapler unit assembly removal Remove the right cover. Go to “MFP stapler assembly right cover removal” on page 485. Remove the four cable harnesses attached to the stapler unit assembly. Repair information...
Page 495: Mfp Stapler Assembly Paddle Drive Motor Assembly Removal
7462 Remove the three screws (A) securing the stapler unit assembly. Remove the stapler unit assembly. MFP stapler assembly paddle drive motor assembly removal Remove the left cover. Go to “MFP stapler assembly left cover removal” on page 486. Disconnect the paddle motor harness from the controller card. Remove the cable from the harness clip.
Page 496: Sensor (Mfp Stapler Assembly Media Stack) Removal
7462 Remove the two screws (A) securing the two paddle drive motor assemblies. Remove the paddle drive motor assembly. Sensor (MFP stapler assembly media stack) removal Remove the top cover. Go to “MFP stapler assembly top cover removal” on page 487.
Page 497: Sensor (Mfp Stapler Assembly Paddle Hp) Removal
7462 Using your ﬁngers, pinch tab (A) securing the sensor (media stack) and remove. Sensor (MFP stapler assembly paddle HP) removal Remove the left cover. Go to “MFP stapler assembly left cover removal” on page 486. Disconnect the harness to the sensor (paddle home position). Using your ﬁngers, pinch tab (A) securing the sensor (paddle home position) and remove.
Page 498: Sensor (Mfp Stapler Assembly Stapler Access Door Interlock) Removal
7462 Sensor (MFP stapler assembly stapler access door interlock) removal Remove the right cover. Go to “MFP stapler assembly right cover removal” on page 485. Disconnect the harness to the sensor (stapler access door interlock). Using your ﬁngers, pinch tab (A) securing the sensor (stapler access door interlock) and remove. Sensor (MFP stapler assembly tamper HP left and right) removal Remove the top cover.
Page 499 7462 Using your ﬁngers, pinch the tabs (A) securing the staple ﬁnisher sensor (tamper HP left and right) and remove. Repair information...
Page 500: Sensor (Mfp Stapler Assembly Bin Full Send) Removal
7462 Sensor (MFP stapler assembly bin full send) removal Remove the stapler/stacker controller card assembly. Go to “Stapler/stacker controller card assembly removal” on page 504. Remove the two screws (A) securing the staple ﬁnisher sensor (bin full send). Disconnect the harness and remove. Repair information...
Page 501: Sensor (Mfp Stapler Assembly Bin Full Receive) Removal
7462 Sensor (MFP stapler assembly bin full receive) removal Remove the right cover. Go to “MFP stapler assembly right cover removal” on page 485. Remove the two screws (A) securing the sensor (bin full receive). Disconnect the harness and remove. Repair information...
Page 502: Sensor (Mfp Stapler Assembly Media In Stapler) Removal
7462 Sensor (MFP stapler assembly media in stapler) removal Remove the stapler unit assembly. Go to “MFP stapler assembly stapler unit assembly removal” on page 494. Using a ﬂat-blade screwdriver, release the tabs (A) securing the sensor. Using needlenose pliers, carefully grip the sensor and pull it out and disconnect the harness. Installation note: Using needlenose pliers, place the rear most tab in the sensor bracket ﬁrst.
Page 503: Sensor (Mfp Stapler Assembly Deﬂector Hp) Removal
7462 Sensor (MFP stapler assembly deﬂector HP) removal Remove the left cover. Go to “MFP stapler assembly left cover removal” on page 486. Disconnect the harness to the sensor (deﬂector HP). Release the tabs (A) securing the sensor to the unit. Note: The tabs may be difficult to access.
Page 504: Stapler/Stacker Controller Card Assembly Removal
7462 Stapler/stacker controller card assembly removal Remove the left cover. Go to “MFP stapler assembly left cover removal” on page 486. Disconnect all harnesses to the controller card. Remove the three screws (A) securing the stapler/stacker controller card assembly. Remove the stapler/stacker controller card assembly. Scanner removals Scanner CCD assembly removal CAUTION—POTENTIAL INJURY: When you see this symbol, there is a danger from hazardous voltage...
Page 505: Scanner/Adf Duplex Ccd Exposure Lamp Removal
7462 Pull slack in the carriage belt, and retighten screw (A). Slide the carriage belt out of the rear of the scanner CCD assembly. Remove the rear CCD scanner shaft (B) from the ﬂatbed frame by lifting the left end of the shaft up and remove through the left side.
Page 506 7462 Remove the lamp reﬂector (B) from the CCD assembly. Remove the two screws (C) securing the exposure lamp card from the underside of the CCD assembly, and lift the card from the CCD assembly. Disconnect the scanner lamp wiring harness from the exposure lamp card. Repair information...
Page 507: Scanner Reference Led Cable Assembly Removal
7462 Remove the scanner exposure lamp wiring harness from the clips (D) on the CCD assembly. Remove the scanner exposure lamp by lifting up on the rear end and pulling the lamp out of the grommet. Scanner reference LED cable assembly removal Remove the scanner platen glass cover assembly.
Page 508: Scanner Interface Card Assembly Removal
7462 Scanner interface card assembly removal Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the wire harness from the scanner interface card. Remove the four screws (A) securing the scanner interface card to the ﬂatbed frame. Remove the scanner interface card.
Page 509: Scanner Cooling Fan Removal
7462 Scanner cooling fan removal Remove the scanner platen glass cover assembly. Go to “Scanner platen glass cover assembly removal (models X651, X652, X654, and X656)” on page 527 “Scanner platen glass cover assembly removal (model X658)” on page 527. Disconnect the cooling fan wiring harness from the scanner interface card connector (CN5) assembly.
Page 510: Scanner Support Right Rear Cover Removal (Model X658)
7462 Scanner support right rear cover removal (model X658) Remove the four screws (A) securing the scanner support right rear cover to the machine. Remove the scanner support right rear cover. Repair information...
Page 511: Scanner Support Right Inner Cover Removal (Model X658)
7462 Scanner support right inner cover removal (model X658) Remove the scanner support right rear cover. Go to “Scanner support right rear cover removal (model X658)” on page 510. Remove the four screws (A) securing the scanner support right inner cover to the machine. Pull the bottom out, and then remove the scanner support right inner cover.
Page 512: Scanner Support Right Cover Removal (Model X658)
7462 Scanner support right cover removal (model X658) Remove the scanner support right inner cover. Go to “Scanner support right inner cover removal (model X658)” on page 511. Remove the four screws (A) securing the scanner support right cover to the machine. (x2) (x2) Remove the scanner support right cover.
Page 513: Scanner Support Left Rear Cover Removal (Model X658)
7462 Scanner support left rear cover removal (model X658) Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the two inner screws (A) and two screws (B) on the rear face securing the scanner support left rear cover to the machine.
Page 514: Scanner Support Left Front Cover Removal (Model X658)
7462 Scanner support left front cover removal (model X658) Open the front door assembly. Remove the two screws (A) on the scanner support left front cover to the machine. Remove the scanner support left front cover . Scanner support left cover removal (model X658) Remove the scanner support left rear cover.
Page 515: Scanner Support Left Inner Cover Removal (Model X658)
7462 Remove the four screws (A) from the inside panel. Remove the scanner support left cover. Scanner support left inner cover removal (model X658) Remove the scanner support left rear cover. Go to “Scanner support left rear cover removal (model X658)” on page 513.
Page 516: Sensor (Platen Glass Length) Assembly Removal
7462 Sensor (platen glass length) assembly removal Remove the scanner platen glass cover assembly. Go to “Scanner platen glass cover assembly removal (models X651, X652, X654, and X656)” on page 527 “Scanner platen glass cover assembly removal (model X658)” on page 527.
Page 517: Sensor (Scanner Hp) Assembly With Bracket Removal
7462 Sensor (scanner HP) assembly with bracket removal Remove the scanner platen glass cover assembly. Go to “Scanner platen glass cover assembly removal (models X651, X652, X654, and X656)” on page 527 “Scanner platen glass cover assembly removal (model X658)” on page 527.
Page 518 7462 Remove the eight screws (A) securing the scanner controller card cage cover to the cage. Remove the scanner controller card cage cover. Disconnect all the harnesses and ribbon cables. Repair information...
Page 519 7462 Remove the seven screws (B) securing the card to the cage. Remove the scanner controller card. Repair information...
Page 520: Scanner Controller Card Assembly Removal (Models X651, X652, X654, And X656)
7462 Scanner controller card assembly removal (models X651, X652, X654, and X656) Remove the left side cover. Go to “Left side cover removal (models X651, X652, X654, and X656)” on page 317. Remove the eight screws (A) securing the scanner controller card cage cover to the cage. Repair information...
Page 521 7462 Remove the scanner controller card cage cover. Disconnect all the harnesses and ribbon cables. Remove the seven screws (B) securing the card to the cage. Remove the scanner controller card. Repair information...
Page 522: Scanner Rear Cover Removal
7462 Scanner rear cover removal Remove the four screws (A) securing the scanner rear cover to the scanner. Pull out from the bottom, and then remove the scanner rear cover. Scanner left cover removal (models X651, X652, X654, and X656) Remove the scanner rear cover.
Page 523: Scanner Left Cover Removal (Model X658)
7462 Scanner left cover removal (model X658) Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the metal screw (A) securing the scanner left cover to the scanner assembly. Slide the scanner left cover to rear, and then remove. Repair information...
Page 524: Scanner Right Cover Removal (Models X651, X652, X654, And X656)
7462 Scanner right cover removal (models X651, X652, X654, and X656) Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the plastic screw (A) and metal screw (B) securing the scanner right cover to the scanner. Slide the scanner right cover to rear, and then remove.
Page 525: Scanner Right Cover Removal (Model X658)
7462 Scanner right cover removal (model X658) Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the plastic screw (A) securing the scanner right cover to the machine. Slide the scanner right cover to rear, and then remove. Scanner front cover removal (models X651, X652, X654, and X656) Open the ADF cover.
Page 526: Scanner Front Cover Removal (Model X658)
7462 Pull and remove the scanner front cover. Scanner front cover removal (model X658) Remove the scanner right cover. Go to “Scanner right cover removal (model X658)” on page 525. Remove the screw (A). Slide the scanner front cover to the right, and then remove. Repair information...
Page 527: Scanner Platen Glass Cover Assembly Removal (Model X658)
7462 Scanner platen glass cover assembly removal (model X658) Remove the ADF unit assembly. Go to “ADF unit assembly removal (model X658)” on page 561. Remove the scanner left cover. Go to “Scanner left cover removal (model X658)” on page 523.
Page 528 7462 Remove the scanner right cover. Go to “Scanner right cover removal (models X651, X652, X654, and X656)” on page 524. Remove the six screws (A) securing the scanner platen glass cover to the assembly. Lift and remove the scanner platen glass cover assembly. Repair information...
Page 529: Scanner Support Platform Removal (Models X651, X652, X654, And X656)
7462 Scanner support platform removal (models X651, X652, X654, and X656) Remove the scanner platen glass cover assembly. Go to “Scanner platen glass cover assembly removal (models X651, X652, X654, and X656)” on page 527. Remove the six screws (A) securing the scanner support platform to the scanner ﬂatbed frame. Remove the two screws (B) securing the plastic cover to the scanner ﬂatbed frame.
Page 530 7462 Remove the two screws (D) securing the ground straps to the either side of the scanner frame. Note: Remove the ground strap to prevent damage to the surface which the scanner is placed on. Push the ﬂatbed toward the rear of the cover. Lift and remove the scanner support platform.
Page 531: Scanner Unit Assembly Removal (Models X651, X652, X654, And X656)
7462 Scanner unit assembly removal (models X651, X652, X654, and X656) Warning—Potential Damage: When replacing the system card assembly and the operator panel assembly, make sure to: • Replace only one component at a time. • Perform a POR every after each component is replaced. If this procedure is not followed, then the printer will be rendered inoperable.
Page 532 7462 Remove the screw (D) securing the ground strap to the frame of the scanner unit assembly. Carefully slide the scanner unit assembly to the front, and lift up. Repair information...
Page 533: Scanner Unit Assembly Removal (Model X658)
7462 Scanner unit assembly removal (model X658) Warning—Potential Damage: When replacing the system card assembly and the operator panel assembly, make sure to: • Replace only one component at a time. • Perform a POR every after each component is replaced. If this procedure is not followed, then the printer will be rendered inoperable.
Page 534: Adf Removals
7462 Remove the three screws (D) securing the operator panel assembly. Remove the three screws (E) securing the operator panel assembly bottom to the scanner frame. Slide the ﬂatbed scanner to the rear, and remove. ADF removals ADF feed/pick roll assembly removal Lift the ADF top door assembly.
Page 535: Adf Separator Roll Removal
7462 Lift the rear of the ADF pick roll assembly. Remove the ADF pick roll assembly. ADF separator roll removal Lift the ADF top door assembly. Remove the ADF feed/pick roll assembly. Go to “ADF feed/pick roll assembly removal” on page 534.
Page 536: Adf Separator Torque Limiter Assembly Removal
7462 Press tab (A), and then slide the separator roll off the shaft. ADF separator torque limiter assembly removal Lift the ADF top door assembly. Remove the ADF feed/pick roll assembly. Go to “ADF feed/pick roll assembly removal” on page 534.
Page 537: Adf Front Cover Removal
7462 Press tab (A), and then slide the separator roll off the shaft. Slide the ADF separator torque limiter assembly to the front, and then remove. ADF front cover removal Lift the ADF top door assembly. Remove the two screws (A) from the top of the front cover assembly. Remove the one screw (B) from the bottom of the ADF front cover.
Page 538: Adf Rear Cover Removal
7462 Release the bottom tabs (C) on the ADF front cover. Remove the ADF front cover. ADF rear cover removal Lift the ADF left door cover. Remove the two metal screws (A). Remove the plastic screw (B) from the right side of the ADF rear cover. Remove the ADF rear cover.
Page 539: Adf Document Tray Assembly Removal
7462 ADF document tray assembly removal Remove the ADF front cover. Go to “ADF front cover removal” on page 537. Remove the ADF rear cover. Go to “ADF rear cover removal” on page 538. Remove the two metal screws (A) from the top of the ADF document tray assembly. Slide the ADF document tray assembly to the right.
Page 540 7462 Unscrew the two hinge pins (C) on the left and right sides. Pry out the front tabs (D). Remove the ADF top door assembly. Repair information...
Page 541: Adf Controller Card Removal
7462 ADF controller card removal Remove the ADF rear cover. Go to “ADF rear cover removal” on page 538. Disconnect all cables attached to the controller card. Remove the four screws (A) securing the ADF controller card. Remove the ADF controller card. ADF platen cushion removal Lift the ADF unit assembly.
Page 542: Adf Duplex Ccd Scan Glass Assembly Removal (Models X654, X656, And X658)
7462 Remove the two screws (C) securing the bottom door hinge plate. Remove the hinge plate and pull the ADF lower door assembly, and then remove. ADF duplex CCD scan glass assembly removal (models X654, X656, and X658) Remove the ADF platen cushion. Go to “ADF platen cushion removal”...
Page 543: Adf Duplex Ccd Assembly Removal (Models X654, X656, And X658)
7462 Pull up and release the two snaps (B) securing the ADF duplex CCD scan glass assembly. Remove the ADF duplex CCD scan glass assembly. ADF duplex CCD assembly removal (models X654, X656, and X658) CAUTION—POTENTIAL INJURY: When you see this symbol, there is a danger from hazardous voltage in the area of the product where you are working.
Page 544 7462 Remove the three screws (D) from the underside of the ADF unit assembly securing the ADF duplex CCD assembly to the ADF. Carefully remove the ADF duplex CCD assembly from the underside of the ADF unit assembly. Installation note: When reinstalling the ADF duplex CCD assembly, make sure to adjust the skew. Go to “Adjusting skew”...
Page 545: Adf Pinch Roll Assembly Removal
7462 ADF pinch roll assembly removal Remove the ADF top door assembly. Go to “ADF top door assembly removal” on page 539. Remove the two screws (A) on either side of the ADF pinch roll assembly. Remove the ADF pinch roll assembly. ADF turn guide removal Remove the ADF pinch roll assembly.
Page 546 7462 Using a ﬂat‑blade screwdriver, unfasten the hook securing the separator guide to the turn guide. Note: Upon reassembly, reattach the hook by pressing with your ﬁngers until it snaps into place. Repair information...
Page 547: Adf Media Pinch Pad Assembly Removal
7462 Pivot the turn guide out from the front side, giving room to dislodge the locating pins (B) from the rear. Remove the ADF turn guide. ADF media pinch pad assembly removal Remove the ADF duplex CCD assembly. Go to “ADF duplex CCD assembly removal (models X654, X656, and X658)”...
Page 548: Sensor (Adf Media Exit) Fan Bracket Assembly Removal (Models X654, X656, And X658)
7462 Remove the four screws (A) securing the ADF media pinch pad assembly. Remove the ADF media pinch pad assembly. Sensor (ADF media exit) fan bracket assembly removal (models X654, X656, and X658) Remove the ADF front cover. Go to “ADF front cover removal”...
Page 549: Sensor (Adf Media Exit) Bracket Assembly Removal (Model X651)
7462 Remove the screw (B) from the ground strap. Remove the sensor (ADF media exit) fan bracket assembly. Sensor (ADF media exit) bracket assembly removal (model X651) Remove the ADF front cover. Go to “ADF front cover removal” on page 537.
Page 550: Adf Transport Drive Motor Bracket Assembly With Cable Removal
7462 Remove the screw (B) from the ground strap. Remove the sensor (ADF media exit) fan bracket assembly. ADF transport drive motor bracket assembly with cable removal Remove the ADF rear cover. Go to “ADF rear cover removal” on page 538.
Page 551: Adf Feed Drive Motor Assembly Removal
7462 Remove the two screws (C) securing the ADF transport drive motor bracket assembly with cable to the ADF feed motor bracket. Slide the ADF transport drive motor bracket to the right, loosening the transport belt. Remove the ADF transport drive motor bracket assembly with cable. ADF feed drive motor assembly removal Remove the ADF transport drive motor bracket assembly with cable.
Page 552: Adf Pick Roll Position Cam Assembly Removal
7462 Remove the bushing from the pick roll feed shaft. Remove the six screws (B) securing the ADF feed drive motor assembly to the ADF unit assembly. Remove the ADF feed drive motor assembly to include the two belts and cable. ADF pick roll position cam assembly removal Remove the ADF front cover.
Page 553 7462 Disengage the clip (A) on the shaft arm (B), securing it to the shaft. Remove the two springs attached to the shaft arm (B). Remove the three screws (C) securing the ADF pick roll position cam assembly bracket. Remove the ADF pick roll position cam assembly bracket. Remove it from the shaft.
Page 554: Adf Solenoid Assembly Removal
7462 ADF solenoid assembly removal Remove the ADF front cover. Go to “ADF front cover removal” on page 537. Remove the ADF pick roll position cam assembly spring from the cam shaft lever. Disconnect the solenoid wire harness. Remove the two screws securing the solenoid bracket assembly to the frame of the ADF unit assembly. Remove the ADF solenoid assembly.
Page 555: Sensor (Adf 2Nd Scan) Removal
7462 Open the bottom door assembly. Remove the sensor by squeezing the tabs (A) and removing it from the front of the ADF frame. Disconnect the lower sensor (ADF lower door interlock) harness. Remove the sensor (ADF lower door interlock). Sensor (ADF 2nd scan) removal Remove the ADF media pinch pad assembly.
Page 556: Sensor (Adf 1St Scan) Removal
7462 Remove the sensor from the pinch pad mounting bracket assembly by squeezing the tabs (A) on the sensor. Remove the sensor (ADF 2nd scan). Sensor (ADF 1st scan) removal Remove the ADF turn guide. Go to “ADF turn guide removal” on page 545.
Page 557: Sensor (Adf Sheet Through) Removal
7462 Remove the sensor (ADF 1st scan). Remove the sensor (ADF 1st scan) harness. Sensor (ADF sheet through) removal Remove the ADF turn guide. Go to “ADF turn guide removal” on page 545. Remove the screw (A) securing the sensor (ADF sheet through) to its bracket. Remove the sensor (ADF sheet through).
Page 558: Sensor (Adf Document Set) Removal
7462 Sensor (ADF document set) removal Remove the ADF document tray assembly. Go to “ADF document tray assembly removal” on page 539. Remove the three screws (A) securing the separator guide to the ADF frame. Remove the sensor (ADF document set) harness. Remove the two screws (B) securing the sensor (ADF document set) bracket to the ADF frame.
Page 559: Switch (Adf Closed Interlock) Removal
7462 Remove the screw (C) securing the sensor (ADF document set) to the bracket. Switch (ADF closed interlock) removal Remove the ADF rear cover assembly. Go to “ADF rear cover removal” on page 538. Open the ADF unit assembly. Remove the ADF closed interlock harness from the switch. Using a prying tool, press the tabs (A) on either side of the switch, and pull it down through the bottom of the ADF unit assembly.
Page 560: Adf Unit Assembly Removal (Models X651, X652, X654, And X656)
7462 ADF unit assembly removal (models X651, X652, X654, and X656) Notes: • Use part number 40X2738 for the X651 and X652 models. • Use part number 40X6395 for the X654 and X656 models. Remove the scanner rear cover. Go to “Scanner rear cover removal”...
Page 561: Adf Unit Assembly Removal (Model X658)
7462 ADF unit assembly removal (model X658) Remove the scanner rear cover. Go to “Scanner rear cover removal” on page 522. Remove the scanner left support cover. Go to “Scanner support left cover removal (model X658)” on page 514. Disconnect the CCD harness and ground strap from behind the scanner left support cover. Disconnect the CCD harness and ground strap from behind the scanner rear cover.
Page 562: Adf Right Hinge Removal
7462 Remove the screw (A). Remove the ADF left hinge. ADF right hinge removal Remove the ADF unit assembly. Go to “ADF unit assembly removal (models X651, X652, X654, and X656)” on page 560 “ADF unit assembly removal (model X658)” on page 561..
Page 563 7462 Remove the four screws (A) securing the ADF right hinge to the ADF unit assembly. Remove the ADF left hinge. Repair information...
Page 564 7462...
Page 565: Component Locations
7462 Component locations Printer conﬁgurations Note: Printer conﬁguration may vary depending on your printer model. Basic models Automatic Document Feeder (ADF) Printer control panel Standard exit bin Multipurpose feeder 550-sheet tray (Tray 1) 550-sheet tray (Tray 2) Optional output bin Connectors Controller board Go to the Wiring diagram section at the last part of this manual.
Page 566 7462...
Page 567: Maintenance
Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover • Possible safety exposure from any non-Lexmark attachments Lubrication guide Lubricate only when parts are replaced or as needed, not on a scheduled basis. Use of lubricants other than those speciﬁed can cause premature failure.
Page 568: Scheduled Maintenance
7462 Scheduled maintenance The control panel displays an 80.xy error when it reaches 200K page counts. It is necessary to install the appropriate maintenance kit to maintain the print quality and reliability of the printer. Reset the maintenance counter after replacing the maintenance kit. Maintenance kits Description Part...
Page 569: Cleaning The Printer Parts
7462 Cleaning the printer parts Cleaning the exterior of the printer Make sure that the printer is turned off and unplugged from the wall outlet. CAUTION—SHOCK HAZARD: To avoid the risk of electric shock when cleaning the exterior of the printer, unplug the power cord from the wall outlet and disconnect all cables to the printer before proceeding.
Page 570 7462 Open the bottom ADF door. Wipe the ADF scanner glass under the ADF door. Close the bottom ADF door. Wipe the scanner glass (ﬂatbed) and backing material by moving the cloth or paper towel from side to side. Close the scanner cover. Maintenance...
Page 571 7462...
Page 572: Parts Catalog
7462 Parts catalog Legend The following column headings are used in the parts catalog: • Asm‑index—Identiﬁes the item in the illustration • P/N—Identiﬁes the part number of a FRU • Units/mach—Refers to the number of units in a printer • Units/opt—Refers to the number of units in an option •...
Page 573: Assembly 1: Covers (X651, X652, X654, And X656)
7462 Assembly 1: Covers (X651, X652, X654, and X656) Parts catalog...
Page 574 7462 Assembly 1: Covers (X651, X652, X654, and X656) Asm-index Units/mach Units/FRU Description Removal procedure 40X2169 Scanner cover plug, rear (X651) 40X4506 Scanner cover, rear 40X4508 Scanner cover, right (X651, X652, X654, and X656) 40X4509 Scanner support platform (X651, X652, X654, and X656) 40X1919 Output cover assembly (X651, X652, X654,...
Page 575 7462 Asm-index Units/mach Units/FRU Description Removal procedure 40X4123 X651de touch screen bezel 40X5757 X652de touch screen bezel 40X1971 Inner cover, left (X651, X652, X654, and X656) 40X1916 Side cover, left (X651, X652, X654, and X656) 40X4481 Access door (X651, X652, X654, and X656) -- 40X1973 Media support (X651, X652, X654, and X656)
Page 576 7462 Parts catalog...
Page 577: Assembly 2: Covers 1 (X658)
7462 Assembly 2: Covers 1 (X658) Parts catalog...
Page 578 7462 Assembly 2: Covers 1 (X658) Asm-index Units/mach Units/FRU Description Removal procedure 40X1970 Laser cover assembly, 550 sheet (X658) -- 40X4480 Output cover assembly (X658) 40X4331 Door assembly, rear 40X4470 Output bail 40X4335 Cover assembly, rear lower 40X4477 Corner cover, left rear (X658) 40X4479 Corner cover, right rear (X658) 40X4478...
Page 579: Assembly 3: Covers 2 (X658)
7462 Assembly 3: Covers 2 (X658) Parts catalog...
Page 580 7462 Assembly 3: Covers 2 (X658) Asm-index Units/mach Units/FRU Description Removal procedure 40X4510 Scanner cover, rear (X658) 40X4511 Scanner cover, right (X658) 40X4513 Scanner cover, front (X658) 40X4516 Scanner support cover, left rear (X658) 40X4520 Scanner support inner cover, right (X658) 40X4517 Scanner support cover, right (X658) 40X4518...
Page 581: Assembly 4: Media Path And Ducts
7462 Assembly 4: Media path and ducts Parts catalog...
Page 582 7462 Assembly 4: Media path and ducts Asm-index Units/mach Units/FRU Description Removal procedure 40X4384 EP cooling fan duct 40X1868 Print cartridge clamp assembly 40X4390 Machine pad 40X1869 Transfer deﬂector with static brush 40X1900 Media turn guide with actuator 40X4388 Inner deﬂector 40X4406 Print cartridge support roller 40X4395...
Page 583: Assembly 5: Pick Arm And Media Tray Assemblies
7462 Assembly 5: Pick arm and media tray assemblies Parts catalog...
Page 584 7462 Assembly 5: Pick arm and media tray assemblies Asm-index Units/mach Units/FRU Description Removal procedure 40X4459 MPF lift plate assembly (X651, X652, X654, and X656) 40X4425 MPF lift plate assembly with spring (X658) -- 40X6994 MPF pick solenoid assembly 40X1883 MPF pick roll assembly with ﬂange and clip -- 40X4457 MPF cam gear...
Page 585: Assembly 6: Drive Motor Assembly, Redrive, And Duplex
7462 Assembly 6: Drive motor assembly, redrive, and duplex Parts catalog...
Page 586 7462 Assembly 6: Drive motor assembly, redrive, and duplex Asm-index Units/mach Units/FRU Description Removal procedure 40X4467 Redrive assembly 40X5851 Duplex drive motor assembly 40X4346 Duplex assembly with 2 belts and 2 pulleys -- 40X4351 Duplex guide handle 40X4352 Duplex guide, rear 40X4353 Duplex guide spring, rear 40X4349...
Page 587: Assembly 7: Printhead, Charge, And Transfer Assembly
7462 Assembly 7: Printhead, charge, and transfer assembly Parts catalog...
Page 588 7462 Assembly 7: Printhead, charge, and transfer assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X4464 Printhead with cable assembly 40X1865 Printhead cable assembly 40X4317 Charge roll link spring, right 40X1893 Charge roll arm assembly with cable, right -- 40X1888 Transfer roll bracket assembly, right 40X1886 Transfer roll assembly with tool 40X1887...
Page 589: Assembly 8: System Card, Hvps And Scanner Controller Card Assemblies
7462 Assembly 8: System card, HVPS and scanner controller card assemblies X658 only Parts catalog...
Page 590 7462 Assembly 8: System card, HVPS and scanner controller card assemblies Asm-index Units/mach Units/FRU Description Removal procedure 40X4383 Cleaning blade contact 40X4381 Drum grounding contact 40X4382 Print cartridge HV contact 40X4370 Sensor (toner empty) 40X4362 HVPS card assembly 40X4361 HVPS / sensor cable assembly 40X8673 Sensor (input) 40X5848...
Page 591: Assembly 9: Fuser And Lvps Card Assemblies
7462 Assembly 9: Fuser and LVPS card assemblies Parts catalog...
Page 592 7462 Assembly 9: Fuser and LVPS card assemblies Asm-index Units/mach Units/FRU Description Removal procedure 40X1870 Fuser assembly 100V, type 1 40X4418 Fuser assembly 110V, type 1 40X1871 Fuser assembly 220V, type 1 40X5853 Fuser assembly 100V, type 2 40X5854 Fuser assembly 110V, type 2 40X5855 Fuser assembly 220V, type 2 40X4419...
Page 593: Assembly 10: Flatbed Scanner
7462 Assembly 10: Flatbed scanner flatbed scanner ref LED Parts catalog...
Page 594 7462 Assembly 10: Flatbed scanner Asm-index Units/mach Units/FRU Description Removal procedure 40X6393 Scanner LED assembly (X651, X652, X654, and X656) 40X6394 Scanner LED assembly (X658) 40X2642 Scanner platen glass cover assembly 40X4530 Scanner FB length sensor cable assembly -- 40X6396 Scanner LED module 40X4534 Sensor (platen glass length) assembly...
Page 595: Assembly 11: Adf Unit Assembly
7462 Assembly 11: ADF unit assembly Parts catalog...
Page 596 7462 Assembly 11: ADF unit assembly Asm-index Units/mach Units/FRU Description Removal procedure 40X6481 ADF unit assembly (X651 and X652) 40X6395 ADF unit assembly (X658) 40X7005 ADF unit assembly (X654 and X656) Parts catalog...
Page 597: Assembly 12: Adf Covers
7462 Assembly 12: ADF covers Parts catalog...
Page 598 7462 Assembly 12: ADF covers Asm-index Units/mach Units/FRU Description Removal procedure 40X4537 ADF top door assembly 40X3439 Left hinge assembly 40X2746 ADF cover cap, rear left (X651 and X652) 40X4563 Right hinge assembly 40X4539 ADF cover, rear 40X4564 Document tray extension 40X3444 ADF platen cushion 40X3392...
Page 599: Assembly 13: Adf Feed And Drive
7462 Assembly 13: ADF feed and drive Parts catalog...
Page 600 7462 Assembly 13: ADF feed and drive Asm-index Units/mach Units/FRU Description Removal procedure 40X4540 ADF feed / pick roll assembly 40X4545 Spring 40X7213 Feed motor assembly with belt and cable 40X4544 Transport motor bracket assembly with cable 40X2759 Transport drive gear and pulley kit, rear 40X2749 Feed one-way bearing and gear kit 40X4542...
Page 601 7462 Parts catalog...
Page 602: Assembly 14: Adf Electronics
7462 Assembly 14: ADF electronics Parts catalog...
Page 603 7462 Assembly 14: ADF electronics Asm-index Units/mach Units/FRU Description Removal procedure 40X6398 Spacer 40X4561 ADF document tray assembly 40X4559 ADF tray length cable assembly 40X4558 ADF sensor cable assembly 1 40X4606 Sensor (ADF media exit) bracket assembly (X651 and X652) 40X4607 Sensor (ADF media exit) bracket assembly with fan (X654, X656, and X658)
Page 604 7462 Parts catalog...
Page 605: Assembly 15: 250‑Sheet Option Tray Assembly (X651, X652, X654, And X656)
7462 Assembly 15: 250‑Sheet option tray assembly (X651, X652, X654, and X656) Parts catalog...
Page 606 7462 Assembly 15: 250‑Sheet option tray assembly (X651, X652, X654, and X656) Asm-index Units/mach Units/FRU Description Removal procedure 40X4569 Complete 250 sheet option tray assembly -- 40X3447 250 Sheet pick arm bracket assembly 40X3448 250 Sheet bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low)
Page 607 7462 Parts catalog...
Page 608: Assembly 16: 550 Sheet Option Tray Assembly (X651, X652, X654, And X656)
7462 Assembly 16: 550 Sheet option tray assembly (X651, X652, X654, and X656) Parts catalog...
Page 609 7462 Assembly 16: 550 Sheet option tray assembly (X651, X652, X654, and X656) Asm-index Units/mach Units/FRU Description Removal procedure 40X4576 Complete 550 sheet option tray assembly -- 40X3454 550 Sheet pick arm bracket assembly 40X4307 550 Sheet bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369...
Page 610 7462 Parts catalog...
Page 611: Assembly 17: 550‑Sheet Option Tray Assembly (X658)
7462 Assembly 17: 550‑Sheet option tray assembly (X658) Parts catalog...
Page 612 7462 Assembly 17: 550‑Sheet option tray assembly (X658) Asm-index Units/mach Units/FRU Description Removal procedure 40X3967 Complete 550 sheet option tray assembly (X658) 40X3454 550 Sheet pick arm bracket assembly 40X4307 550 Sheet bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low) 40X4369...
Page 613 7462 Parts catalog...
Page 614: Assembly 18: Hcit Assembly (X651, X652, X654, And X656)
7462 Assembly 18: HCIT assembly (X651, X652, X654, and X656) Parts catalog...
Page 615 7462 Assembly 18: HCIT assembly (X651, X652, X654, and X656) Asm-index Units/mach Units/FRU Description Removal procedure 40X4579 Complete HCIT option tray assembly 40X4590 HCIT pick arm bracket assembly 40X4595 Pick arm sensor cable assembly 40X4591 HCIT bellcrank recoil spring 40X4308 Pick roll assembly (2) 40X4369 Sensor (media low)
Page 616 7462 Parts catalog...
Page 617: Assembly 19: Mfp Stapler Assembly #1
7462 Assembly 19: MFP stapler assembly #1 Parts catalog...
Page 618 7462 Assembly 19: MFP stapler assembly #1 Asm-index Units/mach Units/FRU Description Removal procedure 40X7026 MFP stapler assembly (comes completely assembled) Parts catalog...
Page 619: Assembly 20: Mfp Stapler Assembly #2
7462 Assembly 20: MFP stapler assembly #2 Parts catalog...
Page 620 7462 Assembly 20: MFP stapler assembly #2 Asm-index Units/mach Units/FRU Description Removal procedure 40X4612 Handle cover 40X4613 Rear door assembly 40X4730 Stapler cover 40X4764 Hollow cover 40X7466 Staple cartridge holder 40X4610 Right cover 40X5544 Sensor (bin full receive) 40X4617 Finisher bin spring 40X5545 Standard output bin LED 40X5727...
Page 621: Assembly 21: Mfp Stapler Assembly #3
7462 Assembly 21: MFP stapler assembly #3 Parts catalog...
Page 622 7462 Assembly 21: MFP stapler assembly #3 Asm-index Units/mach Units/FRU Description Removal procedure 40X4645 Media stack ﬂap actuator 40X4646 Media stack ﬂap 40X4369 Sensor (media stack) 40X4621 Left tamper motor assembly 40X4622 Right tamper motor assembly 40X4624 Tamper recoil spring 40X4369 Sensor (tamper HP right) 40X4369...
Page 623: Assembly 22: Mfp Stapler Assembly #4
7462 Assembly 22: MFP stapler assembly #4 Parts catalog...
Page 624 7462 Assembly 22: MFP stapler assembly #4 Asm-index Units/mach Units/FRU Description Removal procedure 40X4641 Stapler assembly 40X5909 Sensor (media in stapler) Parts catalog...
Page 625: Assembly 23: Mfp Offset Stacker Assembly #1
7462 Assembly 23: MFP offset stacker assembly #1 Parts catalog...
Page 626 7462 Assembly 23: MFP offset stacker assembly #1 Asm-index Units/mach Units/FRU Description Removal procedure 40X7025 MFP offset stacker assembly (comes completely assembled) Parts catalog...
Page 627: Assembly 24: Mfp Offset Stacker #2
7462 Assembly 24: MFP Offset stacker #2 Parts catalog...
Page 628 7462 Assembly 24: MFP Offset stacker #2 Asm-index Units/mach Units/FRU Description Removal procedure 40X4612 Handle cover 40X4613 Rear door assembly 40X4730 Stapler cover 40X4610 Right cover 40X5544 Sensor (bin full receive) 40X4617 Finisher bin spring 40X5545 Standard output bin LED 40X5727 LED clear lens 40X5720...
Page 629: Assembly 25: Mfp Offset Stacker #3
7462 Assembly 25: MFP offset stacker #3 Parts catalog...
Page 630 7462 Assembly 25: MFP offset stacker #3 Asm-index Units/mach Units/FRU Description Removal procedure 40X4645 Media stack ﬂap actuator 40X4646 Media stack ﬂap 40X4369 Sensor (media stack) 40X4621 Left tamper motor assembly 40X4622 Right tamper motor assembly 40X4624 Tamper recoil spring 40X4369 Sensor (tamper HP right) 40X4369...
Page 631: Assembly 26: Mfp 4-Bin Mailbox Assembly #1
7462 Assembly 26: MFP 4-bin mailbox assembly #1 Parts catalog...
Page 632 7462 Assembly 26: MFP 4-bin mailbox assembly #1 Asm-index Units/mach Units/FRU Description Removal procedure 40X7024 MFP 4 bin mailbox assembly (comes completely assembled) Parts catalog...
Page 633: Assembly 27: Mfp 4-Bin Mailbox Assembly #2
7462 Assembly 27: MFP 4-bin mailbox assembly #2 Parts catalog...
Page 634 7462 Assembly 27: MFP 4-bin mailbox assembly #2 Asm-index Units/mach Units/FRU Description Removal procedure 40X4644 Top media bin bail 40X4642 Top cover 40X4135 1st - 3rd media bail 40X4640 Left cover 40X4638 Left rear inner cover 40X4369 Sensor (deﬂector gate HP) 40X4632 Rear door assembly 40X4637...
Page 635: Assembly 28: Mfp 4-Bin Mailbox Assembly #3
7462 Assembly 28: MFP 4-bin mailbox assembly #3 Parts catalog...
Page 636 7462 Assembly 28: MFP 4-bin mailbox assembly #3 Asm-index Units/mach Units/FRU Description Removal procedure 40X5750 Spring 40X5728 Sensor (pass through) 40X4635 Deﬂector gate solenoid 40X5751 Attach roller 40X5545 Standard output bin LED 40X5727 LED clear lens 40X4647 Output bin LED bracket 40X4136 Media bin full actuator 40X4633...
Page 637: Assembly 29: Envelope Feeder
7462 Assembly 29: Envelope feeder Parts catalog...
Page 638 7462 Assembly 29: Envelope feeder Asm-index Units/mach Units/FRU Description Removal procedure 40X5739 Envelope feeder (X658 only) Parts catalog...
Page 639: Assembly 30: Miscellaneous
MarkNet N8130 ﬁber ethernet print server -- 40X5038 MarkNet N8150 802.11n wireless print server (US/Americas) 40X5039 MarkNet N8150 802.11n wireless print server (WW, except US/Americas) 56P2129 Lexmark N4000e print server 56P2744 Lexmark N4050e (1 port USB) wireless 802.11g (US/Americas) Parts catalog...
Page 640 7462 Asm-index Units/mach Units/FRU Description Removal procedure 40X1593 Lexmark MarkNet N7002e (1 port parallel) ethernet 10baseT/100BaseTX 40X1594 Lexmark MarkNet N7002e (1 port parallel) ethernet 10base T/100Base TX 40X1592 Lexmark MarkNet N7020e (4 port USB) ethernet 10base T/100Base TX/1000BaseT 40X4819 RS-232C serial interface card...
Page 641: Assembly 31: Power Cords
7462 Assembly 31: Power cords Asm-index Units/mach Units/FRU Description Removal procedure 40X0269 Power cord LV, USA and Canada, Latin America 40X0288 Power cord HV, Argentina 40X0273 Power cord HV, Chile, Uruguay 40X3141 Power cord HV, Albania, Austria, Belgium, Bosnia, Brazil, Bulgaria, Catalan, Czech Republic, Croatia, Egypt, Finland, France, Germany,Greece, Hungary, Iceland, Indonesia, Iran, Italy, Jordan, Lebanon,...
Page 642 7462 Parts catalog...
Page 643: Assembly 32: Universal Trays And Accessories
7462 Assembly 32: Universal trays and accessories Asm-index Units/mach Units/FRU Description Removal procedure 40X5857 Universal media drawer with tray, 200 sheet (X651, X652, X654, and X656) 40X5858 Universal media tray, 200 sheet (X651, X652, X654, and X656) 40X5859 Universal media drawer with tray, 400 sheet (X651, X652, X654, and X656) 40X5860 Universal media tray, 400 sheet (X651,...
Page 644 7462...
Page 645: Appendix A: Printer Speciﬁcations
The power consumption levels listed in the previous table represent time‑averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values. Power Saver This product is designed with an energy-saving mode called Power Saver. The Power Saver Mode is equivalent to the EPA Sleep Mode.
Page 646: Off Mode
56 dBA Scanning 52 dBA Copying 56 dBA Ready 30 dBA Values are subject to change. See www.lexmark.com for current values. Temperature information Ambient operating temperature 15.6C° – 32.2C° ‑40.0C° – 60.0C° Shipping and storage temperature Appendix A: Printer speciﬁcations...
Page 647: Appendix B: Options And Features
– IPDS and SCS/TNe – PrintCryption – PRESCRIBE • Printer hard disk • Lexmark Internal Solutions Ports (ISP) – RS‑232‑C serial interface ISP – Parallel 1284‑B interface ISP – MarkNet N8150 802.11 b/g/n Wireless ISP – MarkNet N8130 10/100 Fiber ISP –...
Page 648 7462 Vertical kiosk presenter Horizontal kiosk presenter RFID UHF Appendix B: Options and features...
Page 649: Appendix C: Theory Of Operation
7462 Appendix C: Theory of operation POR sequence As the printer turns on, the engine code goes through a series of tests to verify hardware integrity. If a hardware failure is detected, then it is reported to the printer. If the POR sequence cannot be completed successfully, then the printer may post an error message.
Page 650: Printer Theory
7462 Printer theory Models X651, X652, X654, and X656 paper path rolls and sensors PC drum Sensor (input) Standard bin full actuator and sensor (standard bin full) Diverter PC cartridge Sensor (fuser output) Sensor (narrow media) Sensor (option pass through) Sensor (duplex input) Pick arm...
Page 651: Model X658 Paper Path Rolls And Sensors
7462 Model X658 paper path rolls and sensors PC drum Sensor (input) Standard bin full actuator and sensor (standard bin full) Diverter PC cartridge Sensor (fuser output) Sensor (narrow media) Sensor (option pass through) Sensor (duplex input) Pick arm assembly Functions of main components •...
Page 652 7462 Media tray assembly It is necessary to adjust the media tray rear guide and media tray side guide of the media tray assembly to match the media size. Rear media guide The rear media tray guide assembly can be adjusted to different media sizes by moving it to the front or rear. The rear guide should come into contact with the media and hold it in position.
Page 653: Media Tray Assembly
7462 Media tray assembly Wear strips Side guides End guides Detection of media size The media size set for the media tray assembly is transmitted to the switch (media size) by moving these guides. The media size is detected by the on/off information of these switches. Appendix C: Theory of operation...
Page 654 7462 Pick arm assembly Sensor (media empty) Media out actuator Sensor (media low) Pick roll assemblies Since all media trays are functionally equivalent in terms of the switch (media size), sensor (media empty), sensor (media low), only the components of one tray are described here. The pick arm assembly is a mechanical unit supplying media from the media tray assembly to the printer.
Page 655 7462 Sensor (media low) This sensor detects by the actuator position whether media in the media tray assembly is low. When the ﬂag of the actuator blocks, then unblocks the sensing area of the sensor (media low), the media level is determined to be low.
Page 656: Registration
7462 Registration Part Aligner assembly Sensor (input) Sensor (input) The sensor (input) is located just before the print cartridge and can detect whether media exists in the input path. Aligner assembly The aligner assembly is used to feed the media through the input path and to ensure that media is fed through the machine in a perfectly straight manner and not in a skewed manner.
Page 657: Transfer
7462 Transfer Transfer roll Transfer roll assembly The transfer roll assembly applies charge to the rear surface of the media when the media passes between the transfer roll assembly and photo conductor (drum). Thus, the toner image is transferred from the photo conductor (drum) surface to the media surface.
Page 658 7462 Polygon printhead Part Polygon printhead LD card assembly — This generates the laser beam. The beam is turned on or off according to a print data signal coming from the system card. Printhead motor/polygon mirror — The polygon mirror is mounted to the shaft of the printhead motor, and is rotated at a high speed by the printhead motor.
Page 659: Fuser
7462 When a laser beam is scanned across the photoconductor (drum) surface from one end to the other while turning on and off the beam, one line of latent image is created. If the scanning by the laser beam is repeated while rotating the drum, a two-dimensional image is created.
Page 660: Fuser Components
7462 Part Fuser unit assembly Fuser components The printhead scans the photo conductor drum surface with a laser beam. It consists of four components: laser diode (LD) card assembly, printhead motor, polygon mirror, and the start of scan card assembly. Appendix C: Theory of operation...
Page 661 7462 Hot roll Fuser lamp Sensor(Fuser output) Sensor(Narrow media) Fuser solenoid Pressure roll Part Fuser unit assembly Sensor (fuser output) Sensor (narrow media) Fuser solenoid Pressure roll Fuser lamp Heat roll The heat roll is a hollow metal tube with a coated surface. This tube is heated by the inner heater lamp. The heat is applied to the media passing between the heat roll and pressure roll, fusing the toner on the media.
Page 662 7462 Thermistor The thermistor monitors the surface temperature of the media-feed portion of the heat roll to control on/off of the main heater lamp and sub heater lamp. Sensor (fuser output) The sensor (fuser output) detects the arrival of media at the detection point in the exit area of the fuser, and also detects the ejection of media from this point.
Page 663: Exit
7462 Hot roll Fuser lamp Full contact detac Pressure roll Full contact detac Hot roll Pressure roll Part Hot roll Full detac Full detac Pressure roll Hot roll Pressure roll Fuser lamp Exit Appendix C: Theory of operation...
Page 664: Drive
7462 Part Sensor (standard bin exit) Sensor (standard bin full) The sensor (standard bin full) detects whether the standard bin is full by moving the actuator up and down. Drive Main drive motor assembly The main drive motor is a DC motor that drives the print cartridge, aligner, MFP, and fuser. Redrive motor assembly The redrive motor assembly is a DC motor that drives the redrive assembly that transports the media into the standard bin or output option.
Page 665: Electrical Components And Controller
7462 Electrical components and controller Part LVPS card assembly Duplex cooling fan Print cartridge cooling fan HVPS card assembly System card assembly Main cooling fan Switch (printer front door interlock) The switch is a safety switch to cut off a 24 VDC power supply from the LVPS card assembly to the high volt power supply (HVPS) card assembly, printer system card assembly and to the main drive motor assembly, while the printer front door assembly is open.
Page 666: Printhead Control
7462 LVPS card assembly The LVPS card assembly generates low voltages 5V for logic circuits, 5V for laser diodes, and 24V for cooling fans. The LVPS is switchable and can be switched to work with 100V, 110V, and 220V machines. LVPS cooling fan The LVPS cooling fan discharges air from the LVPS to prevent excessive temperature increases.
Page 667: Fuser Control
7462 Fuser control Fuser control method The on/off control of the main/sub heater lamps is performed based on the fuser control temperature. The fuser transmits between the ﬁve states (warm up, ready, standby, print, and low power) depending on the heat roll surface temperature or printer conditions.
Page 668 7462 Part Waste toner collection Drum Developer roll Charge The charge roll places a uniform negative electrostatic charge on the surface of the drum. The drum surface is made of a photoconductive material that holds an electrical charge as long as the drum remains in darkness. Light striking the drum discharges the surface charge.
Page 669 7462 This discharge/no discharge process creates an invisible, electrostatic image on the surface of the drum. This image is called a latent image. Modulated Laser Beam Printhead DRUM Drum Surface Drum Surface Image Voltage Laser Beam Laser Beam Discharge Level Invisible Latent Image Development The toner contained within the PC cartridge has an electrical property that causes it to adhere to the...
Page 670 7462 The toner adhering to the development roll is always in contact with the drum surface. When a less negative point on the drum (a discharged area) comes in contact with the more negative charged toner on the magnet roll, toner transfers from the magnet roll to that point on the drum. There is now a visible toner image on the drum surface.
Page 671 7462 Transfer As the paper travels between the transfer roll and the photoconductor (drum), the transfer roll applies a charge to the back of the printing paper. This positive charge transfers the negative charged toner image from the photoconductor (drum) to the top surface of the paper. The toner image is now on the paper and the paper is now stuck to the photoconductor (drum) due to the relative electrical differences between the negative electrical charge of the inner conductive layer of the drum and the positive electrical charge of the paper.
Page 672: Document Scanning At Adf
7462 Auto density sensing The cleaning blade removes any toner that remains on the drum after the transfer process. The toner that the cleaning blade removes is collected inside the sealed PC cartridge. Part Sensor shield assembly Sensor (toner density) The image density sensor assembly uses a reﬂection type sensor that detects a pre-placed toner patch and image on the photoconductor (drum) and outputs pulses when the central line of the patch image aligns with the central line of the detector.
Page 673: High Capacity Input Tray (Hcit) Tray Assembly
7462 The image data is read with the scanner LED image sensor assembly. This ADF employs a constant velocity transport system that scans images by feeding the document at a constant speed over the speciﬁed position (scan position) where the carriage of the scanner unit assembly is ﬁxed. ADF Scan position Platen registration point Carriage...
Page 674: Sheet/550-Sheet Tray Assembly
7462 Pick arm assembly Media size actuator Sensor (media empty) Sensor (media low) Sensor Sensor (pass through) (tray raised HP) HCF drawer assembly Tray lift drive motor Part Pick arm assembly Sensor (media empty) Sensor (media low) Sensor (tray raised HP) Tray lift drive motor HCF drawer assembly Sensor (pass through)
Page 675 7462 Part Lockable back restraint Media end guide Auto size ﬁnger actuator Rear media tray guide Media size sensing The media size set for the media tray assembly is set by positioning the right media guide, unlocking the slider lock, and sliding the rear paper guide. The rear paper guide triggers the movement of the auto size sensing ﬁnger, which then sets the switches of the controller card board.
Page 676 7462 Media level sensing The media level for the media tray assembly is triggered by the actuator ﬂag positioned in the two photointerrupter sensors in the pick arm bracket assembly. The actuator ﬂag blocks and unblocks the two sensors in different sequence; it determines whether the paper tray is empty, low, or full. 250-sheet tray Sensor A Sensor B...
Page 677: Paper Path, Rolls, And Sensors
7462 Pick arm assembly Sensor (media empty) Sensor (media low) Sensor (pass through) 550-sheet drawer assembly Paper path, rolls, and sensors Media transport path The following is a cross section of the printer and the tandem tray module, showing the main components directly associated with the media path and transport.
Page 678 7462 Models X651, X652, X654, and X656 paper path, rolls, and sensors PC drum Sensor (input) Standard bin full actuator and sensor (standard bin full) Diverter PC cartridge Sensor (fuser output) Sensor (narrow media) Sensor (option pass through) Sensor (duplex input) Pick arm assembly Part...
Page 679 7462 Part Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Model X658 paper path, rolls, and sensors PC drum Sensor (input) Standard bin full actuator and sensor (standard bin full) Diverter PC cartridge Sensor (fuser output) Sensor (narrow media) Sensor (option pass through)
Page 680: Media Tray Assembly
7462 Part Sensor (duplex input) Pick arm assembly Sensor (option pass through) PC cartridge Sensor (input) PC drum Functions of main components When the 250 or 550 sheet input trays are installed under the printer, additional trays are available. Media tray assembly It is necessary to adjust the media tray rear guide and media tray side guide of the media tray assembly to match the media size.
Page 681 7462 Part Rear media tray guide Bottom plate End guide Detection of media size The media size set for the media tray assembly is transmitted to the switch (media size) by moving these guides. The media size is detected by the on/off information of these switches. Pick arm assembly Since all media trays are functionally equivalent in terms of the switch (media size), sensor (media empty), sensor (media low), only the components of one tray are described here.
Page 682: Duplex
7462 Tray 2 media tray assembly Rear media guide Bottom plate End guide Media Size Analog switch S/W1 Analog switch S/W3 No Tray B5L/7.25” x 10.5”L 8.5” x 11”L Duplex Functions of main components When the duplex is installed, duplex (double-sided) printing is available with the printer. The following outlines the functions of the main components of the duplex.
Page 683 7462 Duplex drive motor assembly The duplex drive motor assembly transmits driving force to the two duplex media transport roll assemblies and the duplex media center transport roll assembly middle that feeds media. Duplex drive motor assembly Sensor (duplex input) Part Duplex drive motor assembly Sensor (duplex input)
Page 684 7462...
Page 685: Appendix D: Acronyms
7462 Appendix D: Acronyms Acronyms BLDC Brushless DC Motor Customer Replaceable Unit Customer Setup DIMM Dual Inline Memory Module DRAM Dynamic Random Access Memory Digital multimeter Enhanced Data Out EEPROM Electrically Erasable Programmable Read-Only Memory Electrophotographic Process EPROM Erasable Programmable Read-Only Memory Electrostatic Discharge Field Replaceable Unit Gigabyte...
Page 686 7462 Raster Imaging Processor Read Only Memory SDRAM Synchronous Dual Random Access Memory SIMM Single Inline Memory Module SRAM Static Random Access Memory Universally Adjustable Tray Used Parts Return V ac Volts alternating current V dc Volts direct current Volt Ohmmeter Appendix D: Acronyms...
Page 687: Index
7462 Index 59 Incompatible tray <x> 199 Numerics 61 Remove defective disk 199 1565 Emulation error, load emulation option 202 62 Disk full 199 200–282.yy paper jam 200 63 Unformatted disk 200 250-sheet/550-sheet tray assembly, theory 674 80 Routine maintenance needed 200 283 Staple jam 200 81 Routine Maintenance 200 290‑294.yy scanner jam 201...
Page 688 7462 Close ﬁnisher side door 185 quick disk test 272 Conﬁguration menu diagnostics USB Scan to Local 279 registration 263 conﬁguration menu Diagnostics menu entering 263 action for prompts 285 ADF edge erase 283 diagnostics menu clearing custom status 287 ASIC Test 278 conserve energy 282 automatic darkness adjustment 275...
Page 689 7462 Disk Full ‑ Scan Job Canceled 185 923.xx—924.xx error messages 225 display, printer control panel 256 925.xx error messages 227 document scanning (platen and ADF), theory 672 927.xx–935.xx error messages 227 DRAM test 266 936.xx–945.xx error messages 228 950.xx–990.xx error messages 229 drive, theory 664 ESD-sensitive parts duplex tests...
Page 690 7462 input tray tests feed tests 270 Network 189 sensor tests 270 Network <x> 189 Insert staple cartridge 187 No analog phone line connected to modem, fax is Insert Tray <x> 187 disabled. 189 inspection guide 567 No answer 189 Install bin <x>...
Page 691 7462 parts catalog legend 572 37 Insufficient memory for Flash Memory polygon printhead assembly, theory 657 Defragment operation 194 polygon printhead mechanical registration 37 Insufficient memory to collate job 194 adjustment 304 37 Insufficient memory, some Held Jobs were deleted 195 POR sequence 40 37 Insufficient memory, some held jobs will not be power‑on reset sequence 40...
Page 692 7462 Connect <x>bps 185 Set clock 193 Dialing 185 SMTP server not set up. Contact system Disk corrupted 185 administrator. 193 Disk Full ‑ Scan Job Canceled 185 Some held jobs were not restored 193 System busy, preparing resources for job. 193 Fax failed 186 System busy, preparing resources for job.
Page 693 7462 4-bin mailbox assembly deﬂector gate (bin 4) 396 ADF unit assembly (models X651, X652, X654, 4-bin mailbox assembly deﬂector gate and X656) 560 solenoid 393 alignment assembly 309 4-bin mailbox assembly LED card assembly 391 anti-tip latch assembly 415 charge roll assembly 335 4-bin mailbox assembly LED clear lens 402 duplex assembly 355...
Page 694 7462 high capacity stacker sensor (media bin full) offset stacker left cover 449 bracket assembly 439 offset stacker media stack ﬂap and media stack high capacity stacker switch (media bin HP) 438 ﬂap actuator 456 high capacity stacker upper deﬂector gate 443 offset stacker paddle drive motor assembly 457 offset stacker rear door assembly 447 HVPS card assembly 324...
Page 695 7462 right side cover (model X658) 331 sensor (high capacity stacker deﬂector gate right side cover (models X651, X652, X654, and HP) 446 X656) 332 sensor (high capacity stacker pass through) 444 right transfer roll bracket assembly 353 Sensor (input) 334 Sensor (media level) 363 scanner CCD assembly 504, 507 Sensor (media out) 363...
Page 696 7462 Remove paper from <linked bin set name> 191 squareness check, media 297 Remove paper from all bins 191 storing Remove paper from bin <x> 191 paper 33 Remove paper from standard output bin 191 System busy, preparing resources for job. 193 System busy, preparing resources for job.
Page 697 7462 repeating defects 44 skewed print 56 solid black pages 46 spots appear on prints 53 vertical lines and bands (process direction) appear on prints 48 vertical stripes (process direction) appear on prints 50 troubleshooting, service checks network service check 208 Unsupported disk 193 Unsupported USB device, please remove 193 Unsupported USB hub, please remove 193...
Page 698 7462 Index...
Page 699: Part Number Index
Locking universal media drawer with tray, 400 sheet (excluding X658) ........640 40X1556 Parts pack, ISP thumbscrew and standoff .....................639 40X1592 Lexmark MarkNet N7020e (4 port USB) ethernet 10base T/100Base TX/1000BaseT ....640 40X1593 Lexmark MarkNet N7002e (1 port parallel) ethernet 10baseT/100BaseTX ........640 40X1594 Lexmark MarkNet N7002e (1 port parallel) ethernet 10base T/100Base TX ........640...
Page 700 7462 Part name Page 40X1876 MPF gear shield ............................582 40X1883 MPF pick roll assembly with ﬂange and clip ..................584 40X1886 Transfer roll assembly with tool ....................... 588 40X1887 Transfer roll bracket with cable assembly, left ..................588 40X1888 Transfer roll bracket assembly, right .......................588 40X1892 Charge roll arm assembly, left ........................
Page 701 7462 Part name Page 40X2164 Media tray assembly (X658) ........................584 40X2164 Media tray assembly, 550 sheet .......................612 40X2164 Media tray assembly, 550 sheet .......................612 40X2169 Scanner cover plug, rear (X651) ....................... 574 40X2171 Scanner interface card assembly ......................594 40X2172 Scanner CCD ribbon cable (X651, X652, X654, and X656) .............594 40X2638...
Page 702 7462 Part name Page 40X3448 250 Sheet bellcrank recoil spring......................606 40X3453 250 Sheet option drawer assembly......................606 40X3454 550 Sheet pick arm bracket assembly ..................609, 612 40X3454 550 Sheet pick arm bracket assembly....................612 40X3609 Power cord 100 V, Japan ..........................641 40X3822 Media tray catch spring........................
Page 703 7462 Part name Page 40X4345 Duplex input sensor assembly ......................... 586 40X4346 Duplex assembly with 2 belts and 2 pulleys ..................586 40X4348 Duplex guide assembly, front ........................586 40X4349 Duplex guide spring, right ......................... 586 40X4350 Duplex drive belt, lower ..........................586 40X4351 Duplex guide handle ...........................586 40X4352...
Page 704 7462 Part name Page 40X4385 Envelope feeder interface cover (X658 only) ..................582 40X4386 Fuser drive release linkage ........................586 40X4388 Inner deﬂector .............................. 582 40X4389 LVPS cooling duct ............................582 40X4390 Machine pad ..............................582 40X4392 Main cooling duct (X651, X652, X654, and X656) ................582 40X4394 Tray catch spring ............................582 40X4395...
Page 705 7462 Part name Page 40X4491 Operator panel bezel (X658) ........................580 40X4492 Operator panel cable assembly (X658) ....................580 40X4493 Scanner controller card interface cable assembly ................590 40X4496 Scanner controller card power cable assembly .................. 590 40X4498 LVPS cooling fan cable assembly ......................590 40X4499 Standard output bin LED cable assembly (X656) ................
Page 706 7462 Part name Page 40X4534 Sensor (platen glass length) assembly ....................594 40X4535 Scanner cooling fan ............................ 594 40X4536 Scanner cooling fan ﬁlter ........................... 594 40X4537 ADF top door assembly ..........................598 40X4538 ADF cover, front ............................598 40X4539 ADF cover, rear .............................598 40X4540 ADF feed / pick roll assembly ........................
Page 707 7462 Part name Page 40X4574 250‑sheet tray controller card assembly....................606 40X4575 Sensor (pass through) with cable......................606 40X4575 Sensor (pass through) with cable ......................609 40X4575 Sensor (pass through) with cable......................612 40X4576 Complete 550 sheet option tray assembly ..................609 40X4578 550 Sheet controller card assembly ......................
Page 708 7462 Part name Page 40X4606 Sensor (ADF media exit) bracket assembly (X651 and X652) ............603 40X4607 Sensor (ADF media exit) bracket assembly with fan (X654, X656, and X658) ......603 40X4608 ADF ﬁlter and cover (X654, X656, and X658) ..................603 40X4609 Left cover ...............................
Page 709 7462 Part name Page 40X4646 Media stack ﬂap ............................622 40X4647 Output bin LED bracket ..........................636 40X4723 Printer maintenance kit (100 V type 1 fuser) ..................639 40X4724 Printer maintenance kit (110 V type 1 fuser) ...................639 40X4730 Stapler cover ..............................620 40X4764 Hollow cover ..............................
Page 710 40X5860 Universal media tray, 400 sheet (X651, X652, X654, and X656) ........... 643 40X590 Sensor (stapler/stacker pass through) ....................620 40X590 Sensor (media in stapler) ........................... 624 40X5952 Lexmark PrintCryption card ........................639 40X5953 Bar code/forms card ............................639 40X5958 IPDS card (available w/EMEA, AP, LAD ....................639 40X5969 Korean font card ............................639...
Page 711 Sensor (input)..............................590 41X4417 Fuser wiper cover ............................574 56P2129 Lexmark N4000e print server ........................639 56P2744 Lexmark N4050e (1 port USB) wireless 802.11g (US/Americas) ............639 7372935 Relocation kit (X651, X652, and X654) ....................639 7377730 Relocation kit (X658) ...........................639 99A0272 250 option drive shaft with spring......................
Page 712 7462 Part name Page 99A0275 Spring..............................606, 612 99A0275 Spring ..............................609, 612 99A0447 550 Option drive shaft ........................609, 612 99A0447 550 Option drive shaft..........................612 99A0954 Bevel gear with grease packet and washer • Bevel gear (1) • Instruction sheet (1) • Grease packet (1) ............................586 99A1206 Wear strips, 3 row dimpled 250 sheet ....................
Page 713: Part Name Index
7462 Part name index Part name Page 40X1367 10-Foot parallel printer cable ........................640 40X5303 1GB (1024MB) SO-DIMM ..........................639 40X4135 1st - 3rd media bail ............................634 40X1368 2-Meter USB printer cable .........................640 99A0272 250 option drive shaft with spring......................606 40X3448 250 Sheet bellcrank recoil spring......................
Page 714 7462 Part name Page 40X4557 ADF closed interlock switch cable assembly ..................603 40X3142 ADF controller card assembly ........................603 40X2746 ADF cover cap, rear left (X651 and X652) .....................598 40X4538 ADF cover, front ............................598 40X4539 ADF cover, rear .............................598 40X4561 ADF document tray assembly ........................
Page 715 7462 Part name Page 99A0954 Bevel gear with grease packet and washer • Bevel gear (1) • Instruction sheet (1) • Grease packet (1) ............................586 40X2750 Bushing 6 mm ...............................600 40X4602 Card reader assembly (3121 contact) ...................... 575 40X4603 Card reader assembly (5121 contact/RFID) ....................575 40X4604 Card reader assembly (5125 contact/HID) .....................575 40X4601...
Page 716 7462 Part name Page 40X4357 Duplex cooling fan cable assembly ......................592 40X4350 Duplex drive belt, lower ..........................586 40X4354 Duplex drive belt, upper ..........................586 40X5851 Duplex drive motor assembly ........................586 40X4348 Duplex guide assembly, front ........................586 40X4351 Duplex guide handle ...........................586 40X5551 Duplex guide spring, left ..........................586...
Page 717 7462 Part name Page 40X2665 Fuser oil wiper (black housing) .........................640 40X2666 Fuser wax wiper (gray housing) ....................... 640 41X4417 Fuser wiper cover ............................574 40X4612 Handle cover ..............................620 40X4822 Hard drive assembly with board ......................590 40X7035 Hard drive cooling fan ..........................590 40X4591 HCIT bellcrank recoil spring ........................615 40X4592...
Page 718 Lexmark MarkNet N7002e (1 port parallel) ethernet 10base T/100Base TX ........640 40X1593 Lexmark MarkNet N7002e (1 port parallel) ethernet 10baseT/100BaseTX ........640 40X1592 Lexmark MarkNet N7020e (4 port USB) ethernet 10base T/100Base TX/1000BaseT ....640 56P2129 Lexmark N4000e print server ........................639 56P2744 Lexmark N4050e (1 port USB) wireless 802.11g (US/Americas) ............639...
Page 719 7462 Part name Page 40X4138 Media bin deﬂector ............................. 636 40X4136 Media bin full actuator ..........................636 40X5541 Media output bin ............................620 40X4619 Media output bin extension ........................620 40X4139 Media output bin light pipe ........................634 40X3445 Media pinch pad assembly ........................598 40X3854 Media size actuator..........................
Page 720 7462 Part name Page 40X2089 MPF tray door assembly (X651, X652, X654, and X656) ..............574 40X7044 Operator panel assembly (X658) ......................580 40X4491 Operator panel bezel (X658) ........................580 40X2045 Operator panel cable assembly (X651, X652, X654, and X656) ............ 574 40X4492 Operator panel cable assembly (X658) ....................580 40X4599...
Page 721 7462 Part name Page 40X0273 Power cord HV, Chile, Uruguay .........................641 40X1774 Power cord HV, Denmark, Finland, Norway, Sweden ................. 641 40X1773 Power cord HV, South Africa, Namibia, Lesotho, Botswana, and Pakistan ........641 40X1772 Power cord HV, Switzerland ........................641 40X0271 Power cord HV, United Kingdom, Asian, Brunei, Cambodia, Indonesia,Laos, Malaysia, Myanmar, Philippines, Singapore, Thailand, Vietnam, Afghanistan, Bangladesh,...
Page 722 7462 Part name Page 40X4610 Right cover ..............................620 40X4563 Right hinge assembly ..........................598 40X4637 Right rear inner cover ..........................634 40X4622 Right tamper motor assembly ........................622 40X4819 RS-232C serial interface card ........................640 40X2172 Scanner CCD ribbon cable (X651, X652, X654, and X656) .............594 40X4531 Scanner CCD ribbon cable (X658) ......................594 40X2074...
Page 723 7462 Part name Page 40X4516 Scanner support cover, left rear (X658) ....................580 40X4517 Scanner support cover, right (X658) .......................580 40X4518 Scanner support cover, right rear (X658) ....................580 40X4519 Scanner support inner cover, left (X658) ....................580 40X4520 Scanner support inner cover, right (X658) .................... 580 40X4509 Scanner support platform (X651, X652, X654, and X656) ..............574 40X4550...
Page 724 7462 Part name Page 40X4575 Sensor (pass through) with cable ....................609, 612 40X4534 Sensor (platen glass length) assembly ....................594 40X4524 Sensor (scanner HP) with bracket ......................594 40X4369 Sensor (standard bin exit) .......................... 588 40X4372 Sensor (standard bin exit) actuator assembly ..................588 40X590 Sensor (stapler/stacker pass through) ....................
Page 725 7462 Part name Page 40X4472 Switch (media size assembly) ........................584 40X6392 System card assembly ..........................590 40X4623 Tamper drive belt ............................622 40X4624 Tamper recoil spring ........................... 622 40X4379 Toner density sensor cable assembly ....................592 40X4611 Top cover ............................... 620 40X4644 Top media bin bail ............................634 40X7214...
Page 726 7462 Part name Page 40X2786 Wear strips, 4 row dimpled 250 sheet ....................643 40X2788 Wear strips, 4 row dimpled 550 sheet ....................643 40X7002 Wear strips, dimpled 250 sheet ....................... 643 40X7004 Wear strips, dinky 550 sheet ........................643 40X7001 Wear strips, smooth 250 sheet ........................
Page 727 Print defects guide Page 1 of 1 Print defects guide Match a set of repeating defects on a print job to the marks on one of the vertical lines. The line that best matches the defects on the print job indicates which particular part may be causing the defect. For example, the distance between these two marks represents a repeating defect that occurs every 28.3 mm (1.11 in.), which means the charge rollers may need to be replaced.
Page 728 7462 MFP Printhead Assembly LVPS Redrive Motor Sensor Cooling Assembly Print Cartridge Hard Drive (STD Bin Full) Cooling Fan Cooling Fan Power OP Panel USB Switch Fuser Port Power 250V CR08 250V Switch LVPS (Top Cover Interlock) AIO POWER Fax Card Assembly Card Assembly S COV CLOSE Print Cartridge...
Page 729 7462 MFP SCANNER/ADF SCANNER CCD ASSEMBLY INVERTER +18 CDU LAMP ON ADF Controller +24VDC MOTOR Card SENSOR (ADF PAPER (ADF TRANSPORT) WIDTH) +24VDC DIDTH1 WIDTH2 LENGTH +24VDC +5VDC SENSOR +5VDC MOTOR (ADF PAPER LENGTH) LED_ON (ADF FEED) +24VDC (PAPER PRESENT) CLOSING SENSOR nUICC M RESET...

Lexmark 7462 series Service Manual

Product Information

Edition Notice

Notices and Safety Information

Preface

General Information

Diagnostic Information

Service Menus

Repair Information

Quick Links

Service Manual

Related Manuals for Lexmark 7462 series

Summary of Contents for Lexmark 7462 series
