Advanced Navigation Spatial Dual Reference Manual page 99

Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Table 39: System status
Spatial Dual Reference Manual
Description
System Failure
Accelerometer Sensor Failure
Gyroscope Sensor Failure
Magnetometer Sensor Failure
Pressure Sensor Failure
GNSS Failure
Accelerometer Over Range
Gyroscope Over Range
Magnetometer Over Range
Pressure Over Range
Minimum Temperature Alarm
Maximum Temperature Alarm
Low Voltage Alarm
High Voltage Alarm
GNSS Antenna Disconnected
Data Output Overflow Alarm
Page 98 of 137
Version 2.3
12/04/2016
