11.7.8

3D Model

This dialogue shows a real-time 3D model of Spatial Dual's orientation.
Illustration 38: Screenshot of Spatial Dual Manager 3D
model dialogue
11.7.9

Communications

This dialogue shows statistics on the data packets received from Spatial Dual and can
be useful in diagnosing signal integrity problems.
Illustration 39: Screenshot of
Spatial Dual Manager
communications statistics dialogue
