8.2

Navigation Specifications

Parameter
Horizontal Position Accuracy
Vertical Position Accuracy
Horizontal Position Accuracy (SBAS)
Vertical Position Accuracy (SBAS)
Horizontal Position Accuracy (Omnistar)
Vertical Position Accuracy (Omnistar)
Horizontal Position Accuracy (RTK)
Vertical Position Accuracy (RTK)
Velocity Accuracy
Roll & Pitch Accuracy (Static)
Heading Accuracy (Static)
Roll & Pitch Accuracy (Dynamic)
Heading Accuracy (Dynamic)
Slip Accuracy
Heave Accuracy
Orientation Range
Hot Start Time
Internal Filter Rate
Output Data Rate
Table 8: Navigation specifications
8.3

Heading Accuracy

Antenna Separation
Table 9: Heading accuracy
0.5 m
1 m
2 m
5 m
10 m
Spatial Dual Reference Manual
Page 26 of 137
Version 2.3
12/04/2016
Value
1.2 m
2.0 m
0.5 m
0.8 m
0.1 m
0.2 m
0.008 m
0.015 m
0.007 m/s
0.1 °
0.1 °
0.15 °
0.1 °
0.1 °
5 % or 0.05 m
Unlimited
500 ms
1000 Hz
Up to 1000 Hz
Accuracy
0.16 °
0.1 °
0.07 °
0.05 °
0.02 °
