centre of the antenna in the body co-ordinate frame (X positive forward, Z positive
down).
11.8.5.3

Odometer Offset

The odometer offset is measured from the centre of the Spatial Dual unit to the point
at which the vehicle's tyre makes contact with the road in the body co-ordinate frame
(X positive forward, Z positive down).
11.8.5.4

External Data Offset

These values are only required for speciality applications operating with external
sources of data. Please contact
with these values.
11.8.6

Baud Rates

When changing baud rates, some Microsoft Windows machines are unable to function
at the higher baud rates. It is recommended to test the baud rate first with the
permanent box unticked. This way, if it is not possible to communicate at the higher
baud rate, a power cycle can be used to revert to the previous baud rate.
support@advancednavigation.com.au
Illustration 47: Screenshot of
Spatial Dual Manager baud rates
dialogue
Spatial Dual Reference Manual
Page 71 of 137
Version 2.3
12/04/2016
for assistance
