Encom iPULSE R User Manual page 94

The following table describes the settings associated with the P-MP Remote mode.
Field Name
Remote IP address
Remote port
Multicast IP address
Multicast port
For ENCOM PULSE Link Version 2.2.6
Description
Enter the IP address of the P-MP Master radio to which the P-MP Remote
reports. The P-MP Remote radio will automatically send data received
from its associated PULSE radio network to the P-MP Master.
The is an Internet Protocol version 4 (IPv4) address, specified in dotted
notation, as shown in the following example:
Enter the UDP port to which data received from the P-MP Remote radio's
associated PULSE radio network will be sent.
Set this value to the Listening port setting of the P-MP Master radio.
The default listening port is 20011.
Enter the multicast address that the P-MP Remote radio listens to. This is
an Internet Protocol version 4 (IPv4) address, specified in dotted notation,
as shown in the following example:
Set this value to the Multicast IP address setting of the P-MP Master
radio.
Valid multicast addresses are in the range of 224.0.0.0 to
239.255.255.255.
The default address is 224.1.1.3.
Enter the UDP port on which the P-MP Remote listens for multicast
packets.
Set this value to the Multicast port setting of the P-MP Master radio.
The default multicast port is 20001.
Page 94
ENCOM PULSE Link
USER MANUAL
© 2012-2015 Encom Wireless Data Solutions Inc.
