Encom iPULSE R User Manual page 88

IP address
Network mask
Gateway address
Serial Port Mode
Field Name
Serial Mode
For ENCOM PULSE Link Version 2.2.6
IP address. Network performance can suffer greatly if two or more radios
are assigned the same IP address.
Enter the IP address of the radio. This is an Internet Protocol version 4
(IPv4) address, specified in dotted notation, as shown in the following
example:
Enter the network mask. This is an Internet Protocol version 4 (IPv4)
address, specified in dotted notation, as shown in the following example:
Enter the IP address of the radio or router that allows the radio to connect
with devices that are outside of their local LAN or VLAN. This is an Internet
Protocol version 4 (IPv4) address, specified in dotted notation, as shown
in the following example:
Note that the default gateway's IP address must be in the same subnet as
the radio's IP address.
Description
This option sets the protocol used by the iPULSE radio to communicate
with other devices (computer, iPULSE radio, TS1 terminal server, etc.)
via the Ethernet port. One of the following options can be selected:
Option
P-MP Master
Mode
Page 88
Description
Allows the iPULSE radio to communicate
with an unlimited number of iPULSE radios
configured in P-MP Remote mode. The UDP
protocol is used for low latency serial data
transfer. This mode is extremely useful for
typical "polling" type protocols.
See the P-MP Master Mode
information.
© 2012-2015 Encom Wireless Data Solutions Inc.
ENCOM PULSE Link
USER MANUAL
topic for more
