Advanced Tab - Encom iPULSE R User Manual

Advanced Tab

The Advanced tab allows you to modify the more advanced aspects of the radio's operation.
The following tables describe the settings found in each group in the Advanced tab.
Protocol Settings
Field Name
Wireless link rate
Hopping interval
Packet size
For ENCOM PULSE Link Version 2.2.6
Description
The rate at which data is transmitted over the radio's wireless link.
ENCOM serial radios support a wireless link rate of 76.8 kbps (kilobits per
second).
This option specifies the rate at which the radio hops from one frequency
to another (within the configured
This option is only shown when the radio is operating as a master.
Remotes will automatically follow the master radio's hopping interval.
The optimum packet size calculated by the radio.
If the Buffer mode setting in the
throughput, the radio will attempt to collect the specified number of
characters before transmitting the data over the wireless link.
Page 113
ENCOM PULSE Link
hop pattern).
Serial Port tab is set to High
