Encom iPULSE R User Manual page 92

The following table describes the settings associated with the P-MP Master mode.
Field Name
Multicast IP address
Multicast port
Listening port
For ENCOM PULSE Link Version 2.2.6
Description
Enter a multicast address to which UDP packets will be sent. This is an
Internet Protocol version 4 (IPv4) address, specified in dotted notation, as
shown in the following example:
Set the Multicast IP address setting of the P-MP remote radios to this
value.
Valid multicast addresses are in the range of 224.0.0.0 to
239.255.255.255.
The default address is 224.1.1.3.
Enter the port to which the multicast UDP packets will be sent.
Set the Multicast port setting of the P-MP remote radios to this value.
The default multicast port is 20001.
Enter the port on which to listen for UDP packets coming from the remote
radios.
Set the Remote port setting of the P-MP remote radios to this value.
The default listening port is 20011.
Page 92
ENCOM PULSE Link
USER MANUAL
© 2012-2015 Encom Wireless Data Solutions Inc.
