PULSE Master (0) Configuration

The following table shows the configuration settings required for the PULSE Master radio. The other
settings do not affect the wireless network operation, and are not discussed in this example.
Settings Tab Name
Wireless
Wireless
Wireless
Wireless
Wireless
Wireless
Wireless
For ENCOM PULSE Link Version 2.2.6
Setting Name
Repeater in system
Operating Mode
Primary hop pattern
Repeater hop pattern
Network address
Unit address
Security key
Page 147
ENCOM PULSE Link
Value (for this example)
Yes
Master
1
(Not used - can be set to any value)
0
0
0
