FSK Radio Serial Port Settings

The following screen shot shows the contents of the Serial Port tab for a radio with an FSK
interface.
The following tables describe the settings found in each group in the Serial Port tab.
Communication Settings
Field Name
Mode
For ENCOM PULSE Link Version 2.2.6
Description
The mode in which the physical port operates. One of the following
options can be used:
Mode
FSK (2 wire)
FSK (4 wire)
Page 103
ENCOM PULSE Link
Description
A single pair of wires is used for both
transmitting and receiving characters.
Supports half-duplex operation.
One pair of wires is used to transmit, and
another pair of wires is used to receive.
