Spectrum Scan Toolbar

The Spectrum Scan toolbar allows you to manage a spectrum scan session.
The following table describes the items found in the Spectrum Scan toolbar:
Item Name
Start
Stop
Copy
Show Peak
Reset Peak
For ENCOM PULSE Link Version 2.2.6
Description
Click the Start button to start a spectrum scan session.
Click the Stop button to stop an active spectrum scan session.
Click the Copy button to take a snapshot of the current spectrum
scan graph. The snapshot is placed in the Windows clipboard in
graphical format, and can be pasted in any application that accepts
bitmaps (such as Microsoft Paint, Microsoft Word, etc.).
Click the Show Peak button to display the aggregate of all spectrum
readings obtained from the radio. This is shown in light blue in the
Spectrum Scan graph.
Click the Show Peak button again to hide the aggregate spectrum
reading.
Click the Reset Peak button to clear the aggregate spectrum
reading.
