Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
The Carrier Ethernet infrastructure supports the following types of Ethernet flow points (EFPs): • Static EFPs that are user-configurable. • Dynamic EFPs that are created and maintained during a Cisco Intelligent Services Gateway ( ISG) session. With this feature, a new EFP type has been added that is intended for use on a trunk port.
TEFP is supported on a PC interface and on a Gigabit interface. The procedure listed below is for TEFP Note configuration on a PC interface. Similar procedure is used for TEFP configuration on a gigabit interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 22
Step 5 encapsulation dot1q vlan-id [, vlan-id [- vlan-d]] Defines the matching criteria to map 802.1Q frames ingress on an interface to the appropriate service instance. Example: Device(config-if-srv)# encapsulation dot1q 1-5, 7, 9-12 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Use one or more of the commands listed below to verify the Trunk EFP Support feature configuration. SUMMARY STEPS 1. enable 2. show ethernet service instance 3. show ethernet service instance interface port-channel [number] 4. show bridge-domain 5. exit DETAILED STEPS Step 1 enable Example: Device> enable Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Use these resources to install and configure the software and to troubleshoot and resolve technical issues with Cisco products and technologies. Access to most tools on the Cisco Support and Documentation website requires a Cisco.com user ID and password.
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
VLAN translation model. Effective Cisco IOS-XE Release 3.15.0S, QoS policies on EFPs are now supported with ingress rewrite type as push. In the ingress direction with one VLAN tag is pushed and in the egress direction one VLAN tag is popped.
◦Ingress push—The rewrite ingress tag push dot1q vlan-id symmetric command adds a tag to an ingress packet ◦ QinQ with rewrite Starting with Cisco IOS XE Release 3.15, rewrite ingress tag push is supported on QoS with CoS Marking for EVCs on RSP2 module. Note Ingress push on Qos on for EVC is not supported on RSP1 module.
Effective Cisco IOS-XE Release 3.14.0S, dot1ad encapsulation is also supported on the Note trunk EFPs. • • Effective Cisco IOS-XE Release 3.15.0S, ingress mapping of Differentiated Services Code Point (DSCP) or Class of Service (CoS) to the C-CoS or S-CoS is mandatory. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• default—Sets a command to its defaults • description—Adds a service instance specific description • encapsulation—Configures Ethernet frame match criteria • ethernet—Configures Ethernet-lmi parameters • exit— Exits from service instance configuration mode • ip—Interface Internet Protocol config commands Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
VLANs, or lists of VLANs or VLAN ranges. VLAN IDs are 1 to 4094. • Enter a single VLAN ID for an exact match of the outermost tag. • Enter a VLAN range for a ranged outermost match. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
255 characters. encapsulation dot1ad encapsulation dot1ad add inner vlan range encapsulation dot1q Removes one or more VLAN tag values for matching criteria. remove encapsulation dot1ad remove Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The router uses the default ether types 0x8100 and 0x88a8 for dot1q and Q-in-Q encapsulations. Starting with Cisco IOS XE Release 3.15, the ethertypes 0x9100 and 0x9200 are supported using the custom ethertype feature by configuring the dot1q tunneling ethertype command on a physical port.
Service instances do not have to be in a split-horizon group. If a service instance does not belong to a group, it can send and receive from all ports within the bridge domain. A service instance cannot join more than one split-horizon group. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The router supports multicast static MAC addresses, which allow you to enable multicast at the layer 2 level. You can use multicast static MAC addresses to forward multicast packets to specific EFPs on a network. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
1, you cannot configure any other encapsulations that also match previous encapsulations in the same interface and bridge domain. • QinQ is not supported on Trunk EFP interfaces. • Trunk EFPs should be configured with the rewrite ingress tag pop 1 symmetric command. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
{1 | 2} (Optional) Specify that encapsulation modification to occur on packets at ingress. symmetric • pop 1—Pop (remove) the outermost tag. • pop 2—Pop (remove) the two outermost tags. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Note Ciso IOS XE Release 3.8 introduces support for Trunk EFPs on port-channel interfaces. Traffic may not flow to the TEFP when the port-channel or its member links are in down state. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• priority-tagged —Specify priority-tagged frames, VLAN-ID 0 and CoS value of 0 to 7. • untagged —Map to untagged VLANs. Only one EFP per port can have untagged encapsulation. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(Optional) Save your entries in the configuration file. Configuring Asymmetric EFPs Effective Cisco IOS-XE Release 3.18S, this feature introduces new rewrite rules for the egress direction in the EFP. You can configure asymmetric rewrite rules in both ingress and egress directions of the EFP.
However, when encapsulations do not match in the same bridge domain, traffic cannot be forwarded. In this example, the service instances on Gigabit Ethernet 0/0/1 and 0/0/2 can not forward between each other, since Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The switch supports hairpinning, which refers to traffic ingressing and egressing same interface. To achieve haripinning, configure two EFPs in the same bridge domain on the same physical interface, as in this example. Router (config)# interface gigabitethernet0/2 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
1 but not to service instance 2. Configuring Examples for Asymmetric EFPs Configuring Asymmetric EFP with POP enable configure terminal interface TenGigabitEthernet0/0/26 no ip address service instance 1 ethernet encapsulation untagged rewrite egress tag pop 1 bridge-domain 30 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Using the EVCs, service providers can encapsulate packets that enter the service-provider network with multiple customer VLAN IDs (C-VLANs) and a single 0x8100 Ethertype VLAN tag with a service provider VLAN (S-VLAN). Within the service provider network, packets are switched based on the S-VLAN. When Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
For information about the effect on cost of service (CoS) for different EFT tagging operations, see the Cisco ASR 920 Router Chassis Software Configuration Guide. Example for VLAN Translation Configurations • For 1-to-1 VLAN translation configuration: Router (config)# interface gigabitethernet0/1 Router (config-if)# service instance 965 ethernet Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Users on each of a customer's sites can properly run STP, and every VLAN can build a correct spanning tree based on parameters from all sites and not just from the local site. • CDP discovers and shows information about the other Cisco devices connected through the service-provider network.
If the network does not tunnel PDUs, switches on the far ends of the network cannot properly run STP, CDP, and other Layer 2 protocols. For example, STP for a VLAN on a switch in Customer Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
When you enable protocol tunneling (PAgP or LACP) on the service-provider switch, remote customer switches receive the PDUs and can negotiate the automatic creation of EtherChannels. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
2020#sh run int gi0/0/9 Building configuration... Current configuration : 228 bytes interface GigabitEthernet0/0/9 no ip address media-type auto-select negotiation auto no keepalive service instance 200 ethernet encapsulation untagged l2protocol tunnel xconnect 2.2.2.2 1 encapsulation mpls Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
BDI model. There are the limitations: • You must configure BDIs for bridge-domain routing. • The bridge domain must be in the range of 1 to 4094 to match the supported VLAN range. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
STP with bridge domains. • EVC supports only MSTP. • All incoming VLANs (outer-most or single) mapped to a bridge domain must belong to the same MST instance or loops could occur. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Cross-connect bridge-domain entries are provided, and encapsulation matching is achieved by matching bridge-domain entries for the EFPs on which cross-connect is configured. The following types of encapsulation tags are supported: • untagged • rewrite tags with pop1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
VLAN ranges. Step 5 xconnect peer-router-id vcid Bind the attachment circuit to a pseudowire virtual circuit (VC) and enter pw-class pw-class name xconnect configuration mode. Step 6 Return to privileged EXEC mode. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The detection of MAC address movement is disabled for static MAC addresses where the forwarding behavior is configured by the user. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The group-id range is from 0 to 2. Example: Router(config-if-srv)# bridge-domain 100 Step 8 mac static address address Specifies the multicast MAC address. Example: Router(config-if-srv)# mac static address 0000.bbbb.cccc Step 9 Return to privileged EXEC mode. Example: Router(config-if-srv)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
1 this keyword. • priority-tagged—Specify priority-tagged frames, VLAN-ID 0 and CoS value of 0 to 7. • untagged—Map to untagged VLANs. Only one EFP per port can have untagged encapsulation. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Displays information about all EVCs, or a specific EVC when you | interface interface-id] [detail] enter an EVC ID, or all EVCs on an interface when you enter an interface ID. The detail option provides additional information about the EVC. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
This command displays the number of addresses present for the bridge-domain bridge-domain id specified bridge domain. show mac address-table learning This command displays the learning status for the specified bridge domain. bridge-domain bridge-domain id Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
This is an example of output from the show mac-address table count command: Router# show mac address-table count bridge-domain 10 Mac Entries for BD --------------------------- Dynamic Address Count : 20 Static Address Count Total Mac Addresses : 20 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
— features in this document. MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Technical Assistance Description Link The Cisco Support website provides extensive online http://www.cisco.com/cisco/web/support/index.html...
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
◦ After configuring 2048 EOMPLS successfully, if you configure a local connect session, an error is displayed in syslog as resources are exhausted. All the 2048 EOMPLS and the local connect session are in UP state. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
EVC local connect using internetworking VLAN. Before You Begin Ensure that service instances are configured with proper encapsulations and rewrites as needed. Procedure enable configure terminal l2vpn xconnect context connect1 member GigbitEthernet0/3/4 service-instance 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
GigabitEthernet0/1/7 no ip address negotiation auto no keepalive service instance 1 ethernet encapsulation dot1q 10 show run | sec localconnect1 l2vpn xconnect context localconnect1 member GigabitEthernet0/1/6 service-instance 1 member GigabitEthernet0/1/7 service-instance 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
A notification is displayed when you have not configured interworking VLAN. The following configuration describes the scenario: enable configure terminal interface GigabitEthernet0/1/6 service instance 1 ethernet encapsulation dot1q 2,4,5-8,10 enable configure terminal interface GigabitEthernet0/1/7 service instance 2 ethernet encapsulation dot1q 5 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
For example, in the case of Layer 2 interfaces, the MAC table would be cleared and MSTP would reconverge. For Layer 3 interfaces, the ARP cache would be cleared and potentially the IGP would reconverge. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(EFP), EFD events such as CCM interval mismatch, MD level mismatch bring down all the interfaces containing MEPs created for this CFM service. • EFD action is not applicable to Trunk EFPs. • EFD actions are not successful with a forwarding-loop. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The following example shows a sample output of a service instance that is brought down by an EFD action. Device#show ethernet ser ins int g0/0/6 Identifier Type Interface State CE-Vlans 2 Static GigabitEthernet0/0/6 ErrorDis Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Using Ethernet Fault Detection Configuration Example for EFD The following example is a sample of configuration of EFD. Device#show ethernet ser ins int g0/0/6 Identifier Type Interface State CE-Vlans 2 Static GigabitEthernet0/0/6 ErrorDis Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
C- VLAN component are lower than those of the S-VLAN component. The Ethernet encapsulation should be used in combination with the CFM maintenance level to determine which maintenance domain a particular traffic flow belongs to. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• The CFM 802.1ag module must be present in the software image. Restrictions for Transparent CFM • Untagged encapsulation is not supported for transparent CFM. • Transparent CFM is not supported on Smart SFP. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The following example shows the sample configuration of Transparent CFM on EFP. interface GigabitEthernet0/0/1 no ip address negotiation auto service instance 1 ethernet EVC encapsulation dot1q 10 transparent-cfm bridge-domain 4000 cfm mep domain MD5 mpid 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
This problem is solved with the VLAN Translation feature. The current implementation of the feature allows one or more 802.1Q tags to be replaced with other 802.1Q tags and thus the desired tag manipulation can be Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Rewrite operation to achieve the correct tagging behavior (VLAN 50 on outgoing tag) for CPE3. As there is no inner tag here, the outer CoS is propagated in the newly added tag to both CPE2 and CPE3 ACs. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Tag to both CPE2 and CPE3 ACs. Limitations for VLAN Translation with QoS • Only 1:1 and 2:1 translate rewrites are supported in Cisco IOS XE 3.17 release. 1:2 and 2:2 translations are not supported. • Translate operation can only be applied to a unique tag matching service instance.
Specifies the encapsulation adjustment that is to be performed on the frame dot1q vlan-id symmetric ingress to the service instance. Step 7 bridge-domain domain-number Binds a service instance to a bridge domain instance. Step 8 Returns to privileged EXEC mode. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
VLAN tags to be terminated on the subinterface. Step 6 rewrite ingress tag translate 2-to-1 Specifies the encapsulation adjustment that is to be performed on the dot1q vlan-id symmetric frame ingress to the service instance. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Enter your password if prompted. Step 2 Enters global configuration mode. configure terminal Step 3 class-map match-all cos value Determine how packets are evaluated when the packets meet all of the match criteria. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configuration Example for 1:1 VLAN Translation The following example shows the sample configuration for 1:1 VLAN Translation. service instance 50 ethernet encapsulation dot1q 50 rewrite ingress tag translate 1-to-1 dot1q 500 symmetric bridge-domain 50 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
1-to-1 dot1q 2 symmetric bridge-domain 1 Verifying policy-map on ingress QoS The show policy-map interface command verifies the policy-map on ingress QoS. show policy-map interface gig0/0/3 service instance 1 GigabitEthernet0/0/3: EFP 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Verifying TCAM Index Details The show platform hardware pp active feature qos tree service-instance <num> port-number <num> input tcam-info command displays the TCAM index details pertaining to the specified interface. Tcam-handle=2253 First-Index=184 Last-Index=249 Total-Count=66 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the feature information table. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Prerequisites for MAC Address Limiting on Service Instances Bridge Domains and EVC Port Channels Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
• If the acceptance of this address would increase the secure address count on the service instance beyond the maximum number allowed, an attempt is made to make room by removing an existing address from Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Before an unknown MAC address is learned, a series of checks are run against a set of configured and operational constraints. If any of these checks fails, the address is not learned, and a configured violation response is triggered. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
However, there are no restrictions on the count that is configured on the service instance. The table below shows an example of an initial configuration where three service instances are configured on a bridge domain: Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Type 1 Violation --The address of the ingress frame cannot be dynamically learned due to a deny list, or because doing so would cause the maximum number of secure addresses to be exceeded (see the MAC Address Limiting and Learning, on page 84). Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
That is, the age of the MAC address is measured from the instant that it was first encountered on the service instance. This interpretation can be modified by using the mac security aging time aging-time Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
When MAC security is enabled on a service instance, all existing MAC table entries for the service instance are purged. Then, permitted MAC address entries and sticky addresses are added to the MAC table, subject to the prevailing MAC address limiting constraints on the bridge domain. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The MAC table is scanned for addresses that are attributable to this service instance, and dynamically learned MAC addresses are removed when the new MAC address limit is less than the old MAC address limit. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if-srv)# bridge-domain 200 Step 7 mac security Enables MAC security on the service instance. Example: Device(config-if-srv)# mac security Step 8 Returns to user EXEC mode. Example: Device(config-if-srv)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device# configure terminal Step 3 interface port-channel channel-group Specifies the port channel group number and enters interface configuration mode. Example: • Acceptable values are integers from 1 to 64. Device(config)# interface port-channel 2 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Returns to user EXEC mode. Example: Device(config-if-srv)# end Configuring a MAC Address Permit List Perform this task to configure permitted MAC addresses on a service instance that is a member of a bridge domain. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if)# service instance 100 ethernet Step 5 encapsulation dot1q vlan-id Defines the matching criteria to be used for mapping ingress dot1q frames on an interface to the appropriate service instance. Example: Device(config-if-srv)# encapsulation dot1q 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if-srv)# mac security address permit a2aa.aaaa.aaae Step 12 mac security Enables MAC security on the service instance. Example: Device(config-if-srv)# mac security Step 13 Returns to user EXEC mode. Example: Device(config-if-srv)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Step 2 configure terminal Enters global configuration mode. Example: Device# configure terminal Step 3 interface type number Specifies the interface type and number, and enters interface configuration mode. Example: Device(config)# interface gigabitethernet2/0/1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if-srv)# mac security address deny a2aa.aaaa.aaad Step 11 mac security address deny mac-address Adds the specified MAC address as a denied MAC address for the service instance. Example: Device(config-if-srv)# mac security address deny a2aa.aaaa.aaae Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets the maximum number of secure addresses permitted on the service instance. Example: Device(config-if-srv)# mac security maximum addresses 500 Step 8 mac security Enables MAC security on the service instance. Example: Device(config-if-srv)# mac security Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if-srv)# mac security violation protect Step 8 mac security Enables MAC security on the service instance. Example: Device(config-if-srv)# mac security Step 9 Returns to user EXEC mode. Example: Device(config-if-srv)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Step 2 configure terminal Enters global configuration mode. Example: Device# configure terminal Step 3 interface type number Specifies the interface type and number, and enters interface configuration mode. Example: Device(config)# interface gigabitethernet2/0/1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
If sticky MAC addressing is configured on a secured service instance, MAC addresses that are learned dynamically on the service instance are retained during a link-down condition. Perform this task to configure sticky MAC addresses on a service instance. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if)# service instance 100 ethernet Step 5 encapsulation dot1q vlan-id Defines the matching criteria to be used to map ingress dot1q frames on an interface to the appropriate service instance. Example: Device(config-if-srv)# encapsulation dot1q 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
2. show ethernet service instance id id interface type number mac security 3. end DETAILED STEPS Command or Action Purpose Step 1 enable Enables privileged EXEC mode. • Enter your password if prompted. Example: Device> enable Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Displays all the service instances with MAC security show ethernet service instance mac security enabled. Example: Device# show ethernet service instance mac security Step 3 Returns to user EXEC mode. Example: Device# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Step 3 Returns to user EXEC mode. Example: Device# end Showing the MAC Addresses of All Secured Service Instances SUMMARY STEPS 1. enable 2. show ethernet service instance mac security address 3. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Displays the addresses of a specific service instance. number mac security address Example: Device# show ethernet service instance id 200 interface GigabitEthernet 1/0 mac security address Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Returns to user EXEC mode. Example: Device# end Showing the MAC Security Statistics of a Specific Service Instance This section describes how to display the MAC security statistics of a specific service instance. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to display the MAC security statistics of all the service instances on a specific bridge domain. SUMMARY STEPS 1. enable 2. show bridge-domain bridge-id mac security statistics 3. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
2. show bridge-domain bridge-id mac security last violation 3. end DETAILED STEPS Command or Action Purpose Step 1 enable Enables privileged EXEC mode. • Enter your password if prompted. Example: Device> enable Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Clears all the dynamically learned MAC addresses on number mac table the specified service instance. Example: Device# clear ethernet service instance id 100 interface gigabitethernet0/0/1 mac table Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Clears all dynamically learned MAC addresses on the specified bridge domain. Example: Device# clear bridge-domain 100 mac table Step 3 Returns to user EXEC mode. Example: Device# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Total violation count: 321 Example Displaying the MAC Security Status of a Specific Service Instance Device# show ethernet service instance id 100 interface te0/0/3 mac security Bridge-domain 100 MAC Security enabled: yes Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Gi0/0/3 ServInst 10 0000.00ac.ef0a dynamic Gi0/0/3 ServInst 10 0000.00ac.ef0b dynamic Example Displaying the Secured Service Instances for a Specific Bridge Domain Router# show bridge-domain 10 mac security Gi0/0/3 ServInst 10 MAC Security enabled: yes Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Guide Ethernet Local Management Interface on a provider "Configuring Ethernet Local Management Interface edge device on a Provider Edge Device” module in the Cisco IOS Carrier Ethernet Configuration Guide IP SLAs for Metro Ethernet "IP SLAs for Metro Ethernet" NSF/SSO and MPLS "NSF/SSO - MPLS LDP and LDP Graceful Restart"...
Use these resources to install and configure the software and to troubleshoot and resolve technical issues with Cisco products and technologies. Access to most tools on the Cisco Support and Documentation website requires a Cisco.com user ID and password.
Feature Information for MAC Address Limiting on Service Instances Bridge Domains and EVC Port Channels Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Configuring MAC Address Limiting on Service Instances Bridge Domains and EVC Port Channels Feature Information for MAC Address Limiting on Service Instances Bridge Domains and EVC Port Channels Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configuration Examples for Configuring Ethernet CFM in a Service Provider Network, page 205 • Additional References, page 210 • Feature Information for Configuring Ethernet CFM in a Service Provider Network, page 211 • Glossary, page 211 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Ethernet island, and is identified by a globally unique service ID. A customer service instance can be point-to-point or multipoint-to-multipoint. The figure below shows two customer service instances. Service Instance Green is point to point; Service Instance Blue is multipoint to multipoint. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
A unique maintenance level in the range of 0 to 7 is assigned to each domain by a network administrator. Levels and domain names are useful for defining the hierarchical relationship that exists among domains. The hierarchical relationship of domains parallels the structure of customer, service provider, and operator. The Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Maintenance Associations and Maintenance Points A maintenance association (MA) identifies a service that can be uniquely identified within the maintenance domain. The CFM protocol runs within a maintenance association. A maintenance point is a demarcation Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
If port on which the MEP is configured is blocked by Spanning-Tree Protocol (STP), the MIP can receive and might respond to CFM messages from both the wire and relay side, but cannot forward any CFM messages. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Maintenance points on device ports act as filters that confine CFM frames within the bounds of a domain by dropping frames that do not belong to the correct level. Maintenance points must be explicitly configured on Cisco devices. Two classes of maintenance points exist, MEPs and MIPs. Maintenance Endpoints Maintenance endpoints (MEPs) have the following characteristics: •...
A MIP has only one level associated with it and the command-line interface (CLI) does not allow you to configure a MIP for a domain that does not exist. The figure below illustrates MEPs and MIPs at the operator, service provider, and customer levels. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Catalogued by MIPs at the same maintenance level. • Terminated by remote MEPs at the same maintenance level. • Unidirectional and do not solicit a response. • Carry the status of the port on which the MEP is configured. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
SNMP Traps The support provided by the Cisco software implementation of CFM traps is Cisco proprietary information. MEPs generate two types of Simple Network Management Protocol (SNMP) traps, continuity check (CC) traps and cross-check traps.
The distinction between a VLAN port and the EFP is the encapsulation. VLAN ports use a default dot1q encapsulation. For EFPs, untagged, single tagged, and double tagged encapsulation exists with dot1q and IEEE dot1ad EtherTypes. Different EFPs belonging to the same bridge domain can use different encapsulations. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Determine customer MIPs. Customer MIPs are allowed only on the UNIs at the uPEs if the service provider allows the customer to run CFM. Otherwise, the service provider can configure Cisco devices to block CFM frames. • Configure a MIP on every uPE, at the UNI port, in the customer maintenance domain.
Ethernet transport end to end. CFM, however, can be used with other transports. What to Do Next After you have defined the Ethernet CFM domains, configure Ethernet CFM functionality by first provisioning the network and then provisioning service. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Enables CFM processing globally on the device. Example: Device(config)# ethernet cfm global Step 11 interface type number Specifies an interface and enters interface configuration mode. Example: Device(config)# interface gigabitethernet0/0/2 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to set up service for Ethernet CFM. Optionally, when this task is completed, you may configure and enable the cross-check function. To perform this optional task, see “Configuring and Enabling Cross-Checking for an Inward Facing MEP on the U PE-A”. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures a maintenance association within a maintenance domain and enters Ethernet connectivity fault management direction down (CFM) service configuration mode. Example: Device(config-ecfm)# service s41 evc 41 vlan 41 direction down Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets the encapsulation method used by the interface. Example: Device(config-if-srv)# encapsulation dot1q 5 Step 14 bridge-domain bridge-id Binds a service instance to a bridge domain instance. Example: Device(config-if-srv)# bridge-domain 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures a maintenance association within a maintenance domain and enters Ethernet connectivity fault management direction down (CFM) service configuration mode. Example: Device(config-ecfm)# service s41 evc 41 vlan 41 direction down Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets the encapsulation method used by the interface. Example: Device(config-if-srv)# encapsulation dot1q 5 Step 14 bridge-domain bridge-id Binds a service instance to a bridge domain instance. Example: Device(config-if-srv)# bridge-domain 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configuring and Enabling Cross-Checking for an Inward Facing MEP on the U PE-A Perform this task to configure and enable cross-checking for an inward facing MEP. This task requires you to configure and enable cross-checking on two devices. This task is optional. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures the maximum amount of time that the device waits for remote MEPs to come up before the cross-check operation is started Example: Device(config)# ethernet cfm mep crosscheck start-delay 60 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if)# no ip address Step 16 service instance id ethernet evc-id Specifies an Ethernet service instance on an interface and enters service instance configuration mode. Example: Device(config-if)# service instance 100 ethernet evc_100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if)# no ip address Step 24 ethernet cfm mip level level-id Provisions a MIP at a specified maintenance level on an interface. Example: Device(config-if)# ethernet cfm mip level 7 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
UNI service types are matched with EVC configurations and Ethernet service instances are matched with CE-VLAN configurations. Configurations are rejected if the pairings do not match. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Defines a universally unique customer service instance (CSI) and VLAN ID within the maintenance domain. Example: Device(config-ether-cfm)# service csi2 vlan 10 Step 5 Returns to global configuration mode. exit Example: Device(config-ether-cfm)# exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to enable Ethernet OAM on a device or on an interface. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. ethernet oam [max-rate oampdus | min-rate num-seconds| mode {active | passive} | timeout seconds] 5. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
VLANs on the device are not shown. However, it should be noted that CFM traffic will not flow into or out of the device if the VLANs are not properly configured. CE-A ethernet cfm domain Customer level 7 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
VLANs on the device are not shown. However, it should be noted that CFM traffic will not flow into or out of the device if the VLANs are not properly configured. CE-A ethernet cfm domain Customer level 7 service Customer1 evc evc1 vlan 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
A UNI often includes a C-VLAN-aware bridge component. The term UNI is used broadly in the IEEE P802.1ag standard when the purpose for various features of CFM are explained. UNI has no normative meaning. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
To find information about the features documented in this module, and to see a list of the releases in which each feature is supported, see the feature information table. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Restrictions for CFM Configuration over EFP Interface with Cross Connect Feature Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Configures the encapsulation. Defines the matching criteria second-dot1q {any | vlan-id [vlan-id [-vlan-id]]} that maps the ingress dot1q, QinQ, or untagged frames on an interface for the appropriate service instance. Example: Router(config-if-srv)# encapsulation dot1q 100 second dot1q 200 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
{any | vlan-id [vlan-id[-vlan-id]]} Configures the encapsulation. Defines the matching criteria that maps the ingress dot1q, QinQ, or untagged frames on an interface for the appropriate Example: service instance. Router(config-if-srv)# encapsulation dot1q 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
{any | vlan-id[vlan-id[-vlan-id]]} Configures the encapsulation. Defines the matching criteria that maps the ingress dot1q, QinQ, or second-dot1q {any | vlan-id[vlan-id[-vlan-id]]} untagged frames on an interface for the appropriate service instance. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures the encapsulation. Defines the matching criteria that maps the ingress dot1q, QinQ, or untagged second-dot1q {any |vlan-id [vlan-id [-vlan-id]]} frames on an interface for the appropriate service instance. Example: Router(config-if-srv)# encapsulation default Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures the encapsulation. Defines the matching second-dot1q {any |vlan-id[vlan-id[-vlan-id]]} criteria that maps the ingress dot1q, QinQ, or untagged frames on an interface for the appropriate service instance. Example: Router(config-if-srv)# encapsulation dot1q 10-20, 30, 50-60 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
PE3(config-if-srv)# xconnect 1.1.1.1 1 encapsulation mpls PE3(cfg-if-ether-vc-xconn)# cfm mep domain L6 mpid 256 PE3(config-if-srv-ecfm-mep)# end PE3# Configuring CFM over EFP Interface with xconnect—Port Channel-Based xconnect Tunnel Use the following commands at the customer facing port: Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Router(config)# interface Port-channel 1 Specifies the Gigabit Ethernet interface to configure, where: slot/subslot/port—Specifies the location of the interface. Step 4 service instance id Ethernet [service-name] Example: Router(config-if)# service instance 101 ethernet Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example for Configuring CFM over EFP Interface with xconnect—Port Channel-Based xconnect Tunnel PE3(config)# ethernet cfm domain L2 level 2 PE3(config-ecfm)# service s256 evc 256 direction down PE3(config-ecfm-srv)# continuity-check PE3(config-ecfm-srv)# end PE3# PE3(config)# int port-20 PE3(config-if)# no ip address Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Te2/0/0:(2.2.2.2, 1) XCON N/A Total Remote MEPs: 2 • Use the show ethernet cfm mpdb command to verify the catalouge of CC with MIP in intermediate routers. PE2# show ethernet cfm mpdb Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
4181 Te8/0/1 point2point • Use show ethernet cfm error command to view the error report: PE2# show ethernet cfm error -------------------------------------------------------------------------------- MPID Domain Id Mac Address Type MAName Reason -------------------------------------------------------------------------------- 001d.45fe.ca81 BD-V Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
CFM Configuration over EFP Interface with Cross Connect Feature Feature Information for CFM Configuration over EFP Interface with Cross Connect Feature Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Traditional microwave radios use fixed modulation schemes whereby any degradation in the wave propagation conditions (for example, due to adverse weather conditions such as heavy fog or rain) led to complete loss of Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The command support registrations on one or more individual links identified by either link ID or source MAC address. With multi-hop topology, all individual links identified by the interface. If the interface is degraded, the links too get degraded. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
IDs but not a mixture of both. • When registering an EEM script and specifying multiple links it is recommended that the threshold is equal to or lower than the minimum nominal bandwidth across all those links. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(SD) Device(config-if)# ethernet event microwave hold-off 30 occurrences. Step 5 ethernet event microwave loss-threshold Specifies the number of bandwidth Vendor-Specific Messages number-of-messages (VSM) sent from the microwave transceiver to the Cisco device. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if)# ethernet event microwave loss-threshold 3 This configuration specifies the continuous bandwidth VSM messages the Cisco device misses before declaring a signal recovery event. The signal degradation event is generated if any of these Note becomes degraded: •...
The following is sample output from the show ethernet event microwave statistics command where GigabitEthernet interface 0/0/2 has been specified: Device#show ethernet event microwave statistics GigabitEthernet 0/0/2 Microwave Bandwidth Status for GigabitEthernet0/0/2 State: SIGNAL_OK Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The MEP is configured outside EFP. The corresponding domain/service configuration would look like: ethernet cfm ieee ethernet cfm global ethernet cfm domain md1 level 1 service ma1 evc evc1 vlan 100 direction down continuity-check Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Ethernet metropolitan-area networks (MANs) and WANs. This document describes the implementation of IEEE 802.1ag Standard-Compliant CFM (IEEE CFM) in Cisco IOS XE software. IEEE CFM together will be called “Ethernet CFM” throughout this document. •...
MAs within a domain. The MA direction is specified when the MA is configured. The short MA name must be configured on a domain before MEPs can be configured. The CFM protocol runs for a specific MA. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
CFM at the operator level does not allow discovery of the network by the higher provider and customer levels. Network designers determine domain configurations. The following characteristics of domains are supported: • Name is a maximum of 63 characters in length. • Direction is specified when the MA is configured. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
At the request of an administrator, linktrace and loopback messages can also be transmitted. MEPs are either “Up” (toward the bridge) or “Down” (toward the wire). Support for Up MEPs varies by Cisco release. When the continuity-check static rmep command is configured on a port MEP and continuity checking does not detect a removed MEP, the port is set to MAC operation down and the interface protocol is set to down.
An Ethernet CFM LBM can be generated on demand using the CLI. The source of a loopback message must be a MEP. Both Ethernet CFM LBMs and LBRs are unicast, and LBMs specify the destination MAC address or MEP identifier (MPID), VLAN, and maintenance domain. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
SNMP Traps The support provided by the Cisco IOS XE software implementation of Ethernet CFM traps is Cisco proprietary information. MEPs generate two types of Simple Network Management Protocol (SNMP) traps, continuity check (CC) traps and cross-check traps.
• Assign a MEP at the network to network interface (NNI) between operators, if there is more than one operator. • Proceed to next higher operator level and assign MEPs. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Determine customer MIPs. Customer MIPs are allowed only on the UNIs at the uPEs if the service provider allows the customer to run CFM. Otherwise, the service provider can configure Cisco devices to block CFM frames. • Configure a MIP on every uPE, at the UNI port, in the customer maintenance domain.
Perform this task to set up service for Ethernet CFM. Optionally, when this task is completed, you may configure and enable the cross-check function. To perform this optional task, see Configuring and Enabling the Cross-Check Function (CE-A), on page 267. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets the amount of time that data from a missing MEP is kept in the continuity check database or that entries are held in the error database before they are purged. Example: Router(config-ecfm)# mep archive-hold-time 60 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets a port as internal to a maintenance domain and defines mpid {port | vlan vlan-id} it as a MEP. Example: Router(config-if)# ethernet cfm mep domain Customer mpid 701 vlan 100 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Enables the transmission of CCMs. | static rmep] Example: Device(config-ecfm-srv)# continuity-check Step 7 continuity-check [interval time | loss-threshold threshold Configures the time period between CCM transmissions. | static rmep] • The values supported are platform dependent. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configuring and Enabling the Cross-Check Function (CE-A) Perform this task to configure and enable cross-checking for a down MEP. This task requires you to configure and enable cross-checking on two devices. This task is optional. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(CFM) service configuration mode. Example: Device(config-ecfm)# service s41 evc 41 vlan 41 direction down Step 5 mep mpid mpid Statically defines the MEPs within a maintenance association. Example: Device(config-ecfm)# mep mpid 702 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MEPs to come up before the cross-check operation is started. Example: Device(config)# ethernet cfm mep crosscheck start-delay 60 Step 8 Returns the device to privileged EXEC mode. exit Example: Device(config)# exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configuring Multi-UNI CFM MEPs in the Same VPN Effective with Cisco IOS-XE Release 3.14S, services can be configured, such that two or more bridge domains (BDs) are used to achieve UNI isolation and backhauling towards provider edge (PE) device. Local MEPs (with up direction) should be configured on the UNIs (with the associated BDs) to monitor the service backhaul connection.
A system reboot is required for the functionality to take Example: effect. Router(config)# platform cfm Step 3 ethernet cfm global Globally enable Ethernet CFM on the router. Example: Router(config)# ethernet cfm global Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Define a customer alias maintenance association (MA) name or number or meg-id | number ma-number | vlan vlan-id VPN ID to be associated with the domain, a VLAN ID or port MEP, and enter ethernet-cfm-service configuration mode. | vpn vpn-id} Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MA name with alias not configured and services with matching configured MA alias. Router# show ethernet cfm maintenance-point remote -------------------------------------------------------------------------------- MPID Domain Name MacAddress IfSt PtSt Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
"IP SLAs for Metro Ethernet" ISSU feature and functions "Cisco IOS Broadband High Availability In Service Software Upgrade" Performing an ISSU "Cisco IOS In Service Software Upgrade Process and Enhanced Fast Software Upgrade Process" Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Networks MIBs MIBs Link CISCO-ETHER-CFM-MIB To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs RFCs Title No new or modified RFCs are supported by this feature, and support for existing RFCs has not been modified.
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
A UNI often includes a C-VLAN-aware bridge component. The term UNI is used broadly in the IEEE P802.1ag standard when the purpose for various features of CFM are explained. UNI has no normative meaning. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Connectivity Fault Management (CFM) and Ethernet Local Management Interface (LMI). • All VLANs used on a PE device to connect to a customer edge (CE) device must also be created on that CE device. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Ethernet LMI can also be enabled or disabled at the interface to override the global configuration. The last Ethernet LMI command issued is the command that has precedence. No EVCs, Ethernet service instances, or UNIs are defined, and the UNI bundling service is bundling with multiplexing. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Communication of end-to-end status of the Ethernet virtual circuit (EVC) to the customer edge (CE) device • Communication of EVC and user network interface (UNI) attributes to a CE device • Competitive advantage for service providers Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(UNI service type with EVC or Ethernet service instance and CE-VLAN configuration). The configuration is rejected if the configurations do not match. Perform this task to configure the OAM manager on a provider edge (PE) device. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if)# service instance 22 ethernet Step 23 encapsulation untagged Defines the matching criteria to map untagged ingress Ethernet frames on an interface to the appropriate service instance. Example: Device(config-if-srv)# encapsulation untagged Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to enable Ethernet Local Management Interface (LMI) on a device or on an interface. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. ethernet lmi interface 5. ethernet lmi {n393 value | t392 value} 6. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to display Ethernet Local Management Interface (LMI) or Operation, Administration, and Management (OAM) manager information. After step 1, all the steps are optional and can be performed in any order. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
[type number] [detail] Displays interface-only information about Ethernet customer service instances for all interfaces or for a specified interface. Example: Device# show ethernet service interface ethernet 1/3 detail Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Ethernet LMI on a CE Device Configuration This example shows how to configure Ethernet Local Management Interface (LMI) globally on a customer edge (CE) device: Device# configure terminal Device(config)# ethernet lmi global Device(config)# ethernet lmi ce Device(config)# exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Ethernet metropolitan-area networks (MANs) and Ethernet WANs. It relies on a new, optional sublayer in the data link layer of the Open Systems Interconnection (OSI) model. The OAM features covered by this protocol are Discovery, Link Monitoring, Remote Fault Detection, Remote Loopback, and Cisco Proprietary Extensions.
The p-parser classifies frames as OAM PDUs, MAC client frames, or loopback frames and then dispatches each class to the appropriate entity. OAM PDUs are sent to the control block. MAC client frames are passed to the superior sublayer. Loopback frames are dispatched to the multiplexer. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Standardized mechanism to monitor the health of a link and perform diagnostics Cisco Implementation of Ethernet OAM The Cisco implementation of Ethernet OAM consists of the Ethernet OAM shim and the Ethernet OAM module. The Ethernet OAM shim is a thin layer that connects the Ethernet OAM module and the platform code. It is implemented in the platform code (driver).
OAM PDUs are sent to the CPU for software processing. The non-OAM PDU frames are either looped back at the MAC level or discarded at the MAC level. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Before the release of the IEEE 802.3ah Link Fault RFI Support feature, when an OAM PDU control request packet was received with the Link Fault Status flag set, one of three actions was taken: • A warning message was displayed or logged, and the port remained operational. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to reenable a link monitoring session after it was previously disabled. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. ethernet oam link-monitor supported 5. exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
OAM PDUs. The tasks in this section describe how to stop and start link monitoring operations. Stopping Link Monitoring Operations Perform this task to stop link monitoring operations. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config-if)# ethernet oam Step 5 no ethernet oam link-monitor on Stops link monitoring operations. Example: Device(config-if)# no ethernet oam link-monitor on Step 6 exit Returns to global configuration mode. Example: Device(config-if)# exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to create a template to use for configuring a common set of options on multiple Ethernet OAM interfaces. Steps 4 through 10 are optional and can be performed in any sequence. These steps may also be repeated to configure different options. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures a period of time in which error frames {none | high-frames} | low low-frames} | window milliseconds} are counted. Example: Device(config-template)# ethernet oam link-monitor frame-seconds window 699 Step 10 exit Returns to global configuration mode. Example: Device(config-template)# exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to put a port into a blocking state when an OAM PDU control request packet is received with the Link Fault Status flag set. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. ethernet oam remote-failure {critical-event | dying-gasp | link-fault} action {} 5. exit Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The following example shows that the local OAM client, Gigabit Ethernet interface Gi0/0/1, is in session with a remote client with MAC address 0012.7fa6.a700 and OUI 00000C, which is the OUI for Cisco. The remote client is in active mode and has established capabilities for link monitoring and remote loopback for the OAM session.
0 Errored Frame Period records 0 Errored Frame Second records Remote event logs: ------------------ 0 Errored Symbol Period records 0 Errored Frame records 0 Errored Frame Period records 0 Errored Frame Second records Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Feature Name Releases Feature Information Using Ethernet Operations, Cisco IOS XE Release 3.13.0S This feature was introduced on the Administration, and Maintenance Cisco ASR 920 Series Aggregation Services Router (ASR-920-12CZ-A, ASR-920-12CZ-D, ASR-920-4SZ-A, ASR-920-4SZ-D). Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Restrictions for ITU-T Y.1731 Performance Monitoring in a Service Provider Network • A frame-delay measurement message (DMM) with CFMoXconnect on a Cisco ASR 920 router works only if the control-word command is enabled. If the remote end of the pseudowire does not enable the...
Information About ITU-T Y.1731 Performance Monitoring in a Service Provider Network control-word command by default, enable the command to get the DMM time stamp working. Cisco ASR 9000 Series Routers and ALU 7450 are examples of peer platforms where the control-word command needs to be enabled.
An MIP is transparent to the frames with ETH-DM information; therefore, an MIP does not require information to support the ETH-DM function. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
For more information about CFM and Y.1731 performance monitoring commands, see the Cisco IOS Carrier Ethernet Command Reference. For more information about debug commands, see the Cisco IOS Debug Command Reference.
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
ITU-T Y.1731 Performance Monitoring in a Service Provider Network Feature Information for ITU-T Y.1731 Performance Monitoring in a Service Provider Network Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Media Endpoint Discovery (MED) is an LLDP enhancement that was formalized by the Telecommunications Industry Association (TIA) for voice over IP (VoIP) applications. The Cisco implementation of LLDP is based on the IEEE 802.1ab standard. This document describes LLDP and LLDP-MED and how they are supported in Cisco software.
Advertisements are sent out and received on every active and enabled interface, allowing any device in a network to learn about all devices to which it is connected. Applications that use this information Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The figure below shows a high-level view of LLDP operating in a network node. When you configure LLDP or Cisco Discovery Protocol location information on a per-port basis, remote devices can send Cisco medianet location information to the switch. For more information, see the Using Cisco Discovery Protocol module.
• Power —Network connectivity devices and endpoints exchange power information. LLDP-MED provides information about how much power a device needs and how a device is powered. LLDP-MED also determines the priority of the device for receiving power. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
If LLDP-MED is disabled or if the endpoint does not support the LLDP-MED power TLV, the initial allocation value is used throughout the duration of the connection. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Enabling and Disabling LLDP Globally LLDP is disabled globally by default. This section describes the tasks for enabling and disabling LLDP globally. Enabling LLDP Globally Perform this task to enable LLDP globally. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to disable LLDP on a supported interface. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. no lldp {med-tlv-select tlv | receive | transmit} 5. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
LLDP information can be transmitted and received only on an interface where LLDP is configured and enabled. Perform this task to enable LLDP. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. lldp {med-tlv-select tlv | receive | transmit} 5. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Hold time is the duration that a receiving device should maintain LLDP neighbor information before aging it. Perform this task to define a hold time for an LLDP-enabled device. SUMMARY STEPS 1. enable 2. configure terminal 3. lldp holdtime seconds 4. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Step 4 Returns to privileged EXEC mode. Example: Device(config)# end Setting LLDP Packet Frequency Perform this task to specify an interval at which the Cisco software sends LLDP updates to neighboring devices. SUMMARY STEPS 1. enable 2. configure terminal 3. lldp timer rate 4.
Perform this task to enable an LLDP TLV on a supported interface. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. lldp tlv-select tlv 5. end DETAILED STEPS Command or Action Purpose Step 1 enable Enables privileged EXEC mode. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Disabling LLDP TLVs Perform this task to disable an LLDP TLV on a supported interface. SUMMARY STEPS 1. enable 2. configure terminal 3. interface type number 4. no lldp tlv-select tlv 5. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
LLDP-MED TLV support is enabled by default if LLDP is enabled globally and locally on a supported interface. Specific TLVs, however, can be enabled and suppressed. Enabling LLDP-MED TLVs Perform this task to enable a specific LLDP-MED TLV on a supported interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Device(config-if)# lldp med-tlv-select inventory-management Step 5 Returns to privileged EXEC mode. Example: Device(config-if)# end Disabling LLDP-MED TLVs Perform this task to disable a specific LLDP-MED TLV from a supported interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device(config)# interface ethernet 0/1 Step 4 no lldp med-tlv-select tlv Disables a specific LLDP-MED TLV from a supported interface. Example: Device(config-if)# no lldp med-tlv-select inventory-management Step 5 Returns to privileged EXEC mode. Example: Device(config-if)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
(R) Router, (B) Bridge, (T) Telephone, (C) DOCSIS Cable Device (W) WLAN Access Point, (P) Repeater, (S) Station, (O) Other Device ID Local Intf Hold-time Capability Port ID Device1 Et0/0 Et0/0 Total entries displayed: 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Physical Topology MIB MIBs MIBs Link PTOPO MIB To locate and download MIBs for selected platforms, Cisco software releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Using Link Layer Discovery Protocol in Multivendor Networks Feature Information for Link Layer Discovery Protocol in Multivendor Networks Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
This document describes how the IEEE 802.3ad Link Bundling feature leverages the EtherChannel infrastructure within Cisco IOS XE software to manage the bundling of Ethernet links. The supported Ethernet link types for link bundling are Gigabit Ethernet and Ten Gigabit Ethernet.
Each EtherChannel has a numbered port-channel interface that must be manually created before interfaces can be added to the channel group. The configuration of a port-channel interface affects all LAN ports assigned to that port-channel interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
IEEE 802.3ad Link Bundling provides a capability to dynamically provision, manage, and monitor various aggregated links and enables interoperability between various Cisco devices and devices of third-party vendors. LACP supports the automatic creation of EtherChannels by exchanging LACP packets between LAN ports.
The following LACP enhancements are supported: • Four member links per LACP bundle. • Cisco nonstop forwarding (NSF), and nonstop routing (NSR) on Gigabit EtherChannel bundles. • Link failover time of 250 milliseconds or less and a maximum link failover time of 2 seconds; port channels remain in the LINK_UP state to eliminate reconvergence by the Spanning-Tree Protocol.
Supported Version 3 (L2TPv3), IPinIP, Any Transport Over Multiprotocol Label Switching (MPLS) (AToM) tunnels Layer 2 Tunneling Protocol Not Supported Version 2 (L2TPv2) MPLS (6PE) Supported Multicast VPN Not Supported VLANs Supported Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• Cisco Discovery Protocol enable is not supported on the port channel interface. • All LAN ports in a port channel should be enabled. If you shut down a LAN port in a port channel, the shutdown is treated as a link failure and the traffic is transferred to one of the remaining ports in the port channel.
In active mode, the port will initiate negotiations with Example: other ports by sending LACP packets. Device(config-if)# channel-group 25 mode active Step 9 Returns to privileged EXEC mode. Example: Device(config-if)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Step 5 ip address ip-address mask Assigns an IP address and subnet mask to the EtherChannel. Example: Device(config-if)# ip address 172.31.52.10 255.255.255.0 Step 6 Returns to privileged EXEC mode. Example: Device(config-if)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Although the EtherChannel Min-Links feature works correctly when configured only on one end of an Note EtherChannel, for best results, configure the same number of minimum links on both ends of the EtherChannel. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Returns to global configuration mode. exit Example: Device(config-if)# exit Step 10 interface type slot/subslot/ port Specifies the next port to bundle and places the CLI in interface configuration mode. Example: Device(config)# interface gigabitethernet 0/0/4 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The LACP max-bundle must be set to 1. To configure the LACP 1:1 redundancy feature, perform this task in interface configuration mode: Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Sets the maximum number of active member ports to 1. Example: The minimum number of active member Note ports should be 1. Device(config-if)# lacp max-bundle 1 Step 6 Exits configuration mode. Example: Device(config-if)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Perform this task to set the LACP system priority and port priority. The system ID is the combination of the LACP system priority and the MAC address of a device. The port identifier is the combination of the port priority and port number. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Returns to privileged EXEC mode. Example: Device(config-if)# end Step 7 Displays the system ID (a combination of the system priority show lacp sys-id and the MAC address of the device). Example: Device# show lacp sys-id Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Device# configure terminal Step 3 no interface port-channel number Removes the specified port channel group from a physical port. Example: • number—Valid range is from 1 to 64. Device(config)# no interface port-channel 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
To verify and isolate a fault, start at the highest level maintenance domain and do the following: 1 Check the device error status. 2 When a error exists, perform a loopback test to confirm the error. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Hardware is Hardware type (Gigabit EtherChannel). address is Address being used by the interface. Maximum transmission unit of the interface. Bandwidth of the interface, in kilobits per second. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
When the number of hours in any of the “last” fields exceeds 24 hours, the number of days and hours is printed. If that field overflows, asterisks are printed. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Number of packets that are discarded because they are smaller than the minimum packet size for the medium. giants Number of packets that are discarded because they exceed the maximum packet size for the medium. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Total number of bytes, including data and MAC encapsulation, transmitted by the system. underruns Number of times that the far-end transmitter has been running faster than the near-end Device’s receiver can handle. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Number of times the carrier was not present during the transmission. PAUSE output Not supported. output buffer failures Number of times that a packet was not output from the output hold queue because of a shortage of shared memory. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Down *Aug 20 17:07:45.093: %C10K_ALARM-6-INFO: CLEAR CRITICAL GigE 0/0/2 Physical Port Link Down *Aug 20 17:07:47.093: %LINK-3-UPDOWN: Interface GigabitEthernet0/0/2, changed state to up *Aug 20 17:07:48.093: %LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet0/0/2, Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
A - Device is in Active mode P - Device is in Passive mode Channel group 5 LACP port Admin Oper Port Port Port Flags State Priority Number State Gi0/0/5 bndl 32768 0x42 0x3D Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Feature Name Releases Feature Information Configuring IEEE 802.3ad Link Cisco IOS XE Release 3.13.0S This feature was introduced on the Bundling Cisco ASR 920 Series Aggregation Services Router (ASR-920-12CZ-A, ASR-920-12CZ-D, ASR-920-4SZ-A, ASR-920-4SZ-D). Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
• Only one local SPAN destination interface is supported. You cannot configure a local SPAN destination interface to receive ingress traffic. • Outgoing Cisco Discovery Protocol (CDP) and Bridge Protocol Data Unit (BPDU) packets are not replicated. • When enabled, local SPAN uses any previously entered configuration.
The following configuration guidelines apply when configuring local SPAN on the router: • When enabled, local SPAN uses any previously entered configuration. • Use the no monitor session session number command with no other parameters to clear the local SPAN session number. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The traffic from the source ports or Vlans are mirrored into the RSPAN Vlan and forwarded over Trunk or the EVC bridge domain (BD) ports carrying the RSPAN Vlan to a destination session monitoring the RSPAN Vlan. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
SPAN or RSPAN destination interface stops trunking on the interface. Source Interface A source interface is an interface monitored for network traffic analysis. An interface configured as a destination interface cannot be configured as a source interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
RSPAN BD tag + packet RSPAN BD tag + packet pop1 tag pop2 tag push1 tag (Single traffic)-Source port RSPAN Vlan (BD) rewrite pop1 RSPAN Vlan (BD) rewrite pop1 rewrite tag symmetric tag symmetric Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Removing Sources or Destinations from a Local SPAN Session To remove sources or destinations from a local SPAN session, use the following commands beginning in EXEC mode: SUMMARY STEPS 1. enable 2. configure terminal 3. no monitor session session-number Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Router(config-mon-rspan-src)# destination remote vlan2 under the EFP or port which carries the RSPANd traffic. Step 6 no shutdown Restarts the interface. Example: Router(config-mon-rspan-src)# no shutdown Step 7 Exists the configuration. Example: Router(config-mon-rspan-src)# end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Associates the RSPAN destination session number with the destination port. Example: • single_interface —Specifies the Gigabit Ethernet or Ten Gigabit Ethernet interface. Router(config-mon-rspan-dst)# destination interface gigabitethernet 0/0/1 ◦slot/subslot/port—The location of the interface. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures an RSPAN source session number and enters RSPAN source session configuration mode for the session. Example: • session_number—The valid sessions are 1 through 14. Router(config)# monitor session 1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Router(config)# source interface gigabitethernet 0/2/1 Configuration Example: Removing Sources or Destinations from a Local SPAN Session This following example shows how to remove a local SPAN session: Router(config)# no monitor session 8 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
• The following example shows the RSPAN source session with Vlan 20 as source: Router# show monitor session 3 Session 3 --------- Type : Remote Source Session Status : Admin Enabled Source VLANs RX Only : 20 : 1464 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Page 417
Configuring Switched Port Analyzer Feature Information for Local SPAN and RSPAN Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 418
Configuring Switched Port Analyzer Feature Information for Local SPAN and RSPAN Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Bridge allows the service provider switches to transparently carry customer Layer 2 control frames, such as spanning tree Bridge Protocol Data Units (BPDUs) or Cisco proprietary protocol frames such as Cisco Discovery Protocol (CDP) without mixing the service provider's own traffic and with other customer traffic in the service provider's network.
Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
• C-UNI—an be either an access port or an 802.1Q trunk port. The port uses the customer bridge addresses. To configure a C-UNI port, enter the ethernet dot1ad uni c-port interface configuration command. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The S-bridge component is capable of inserting or removing a service provider VLAN (S-VLAN) for all traffic on a particular port. IEEE 802.1ad adds a new tag called a Service tag (S-tag) to all ingress frames traveling from the customer to the service provider. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
The table below shows Layer 2 MAC addresses that are reserved for the C-VLAN component. Table 27: Reserved Layer 2 MAC Addresses for the C-VLAN Component Assignment Value Bridge Group Address 01-80-C2-00-00-00 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 424
Table 28: Reserved Layer 2 MAC Addresses for the S-VLAN Component Assignment Value IEEE 802.3 Full Duplex PAUSE Operation 01-80-C2-00-00-01 IEEE 802.3 Slow_Protocols_Multicast_Address 01-80-C2-00-00-02 IEEE 802.1X PAE Address 01-80-C2-00-00-03 Provider Bridge Group Address 01-80-C2-00-00-08 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Reserved for future Drop Drop Drop media access method 01-80-C2-00-00-06 Reserved for future Drop Drop Drop bridge use 01-80-C2-00-00-07 Reserved for future Drop Drop Drop bridge use 01-80-C2-00-00-08 Provider STP Drop Drop Peer (BPDU) Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 426
All bridge domains Not supported Not supported Not supported 01-80-C2-00-00-20 GARP Multicast Data Data Data Registration Protocol (GMRP) 01-80-C2-00-00-21 Generic VLAN Data Data Data Registration Protocol (GVRP) 01-80-C2-00-00-22-2F Other GARP Data Data Data addresses Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
6. encapsulation {default | dot1q | priority-tagged | untagged} 7. bridge-domain bridge-id [split-horizon group group-id] 8. rewrite ingress tag { pop {1 | 2} symmetric | push dot1ad vlan-id [dot1q vlan-id] symmetric} 9. end Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 428
Configure the bridge domain ID. The range is from 1 to 4000. group-id] You can use the split-horizon keyword to configure the port as a member of a split horizon group. The group-id range is from 0 to 2. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 429
20 ethernet encapsulation default rewrite ingress tag push dot1ad 30 symmetric bridge-domain 20 The example shows the NNI port. interface GigabitEthernet0/5/2 ethernet dot1ad nni service instance 20 ethernet encapsulation dot1ad 30 bridge-domain 20 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Configures Trunk EFP on dot1ad NNI and C-UNI ports on the interface. Example: Note Trunk EFP is not supported on the S-UNI port. Router(config-if)# ethernet dot1ad nni Router(config-if)# ethernet dot1ad uni c-port Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 431
20 ethernet encapsulation dot1q 20-30 rewrite ingress tag pop1 symmetric bridge-domain from-encapsulation The example shows the Trunk EFP configuration on the NNI port. interface GigabitEthernet0/5/2 ethernet dot1ad nni service instance trunk 20 ethernet Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Example: Router> enable Step 2 configure terminal Enter global configuration mode. Example: Router# configure terminal Step 3 interface interface-id Enter interface configuration mode. Valid interfaces are physical ports. Example: Router(config)# interface gigabitethernet0/0/1 Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Page 433
• dot1ad vlan-id—Specifies the 802.1 do1ad tag. Valid Vlan ID range is from 1 to 4094. • dot1q vlan-id—Specifies the 802.1 do1q tag. Valid Vlan ID range is from 1 to 4094. Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
This command displays 802.1ad configuration globally on the router. The following is a sample output from the command: Router# show ethernet dot1ad Interface: GigabitEthernet0/2/1 DOT1AD NNI Port L2protocol pass Interface: GigabitEthernet0/2/7 DOT1AD C-Bridge Port Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
MIBs MIBs Link — To locate and download MIBs for selected platforms, Cisco IOS releases, and feature sets, use Cisco MIB Locator found at the following URL: http://www.cisco.com/go/mibs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
Unless noted otherwise, subsequent releases of that software release train also support that feature. Use Cisco Feature Navigator to find information about platform support and Cisco software image support. To access Cisco Feature Navigator, go to www.cisco.com/go/cfn. An account on Cisco.com is not required.
Page 437
Configuring MAC Address Limiting on a Bridge Domain configuration guidelines default configuration Example supported features Configuring MAC Address Limiting on a Service Instance EVC, Service Instances and Bridge Domains default configuration EVCs Carrier Ethernet Configuration Guide (Cisco ASR 920 Series) IN-1...
Page 438
Sticky MAC Address Configurations Prerequisites for MAC Address Limiting on Service Instances and Bridge Domains Prerequisites for MAC Address Limiting on Service Instances and Bridge-Domains Transitions Violation Response Configuration Carrier Ethernet Configuration Guide (Cisco ASR 920 Series) IN-2...
