Table 33. System Info
Area or Button
Upper left
Upper right
Lower area
Notices
Table 34. RS20i Circuit Boards
Board Function
H531 Inputs and Output Channels 1-8
H532 Output Channels 9-16
H617 Output Channels 17-24 (if installed, this is an option).
H335 DSP board
H336 Front Panel
H337 Serial I/O and Automation
H555 Audio Decoder and triggers
HDMI HDMI interface card. Supports 4K video formats.
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Description
Version – Identifies the current software version installed on the RS20i.
BuildDate – The build date associated with the current software version.
SerialNumber – The unique unit serial number.
MACAddress – The network MAC address for the unit.
Auro Engine – The Auro Engine Version number and build date.
Temperatures – The current temperatures in Celsius are displayed for the H531,
H532 and H335 boards.
Fan – The current fan speed as a percentage. The fan speed may increase to
keep the internal temperatures down. The minimum speed is 8%.
ModelCode – The RS20i ModelCode (for use by Datasat Digital Entertainment).
The lower portion of the screen displays the hardware and firmware version
information for the circuit boards (listed in Table 34, below).
Tap on the lower portion of the screen to switch to a display of voltages
measured from the board. Tap again to return to the firmware version.
The information under Board, BoardId, Addr, and HwVer are related to the
physical hardware installed in the system, and will not change.
LdrVer and LdrCs refers to the boot loader on each board, which was
programmed during the manufacturing.
fwVer and fwCs are firmware versions that are loaded by the system software.
The Voltage information screen shows expected and measured voltages from
select boards. An error in the measured voltage is indicated by
will trigger an alert on the home screen.
Select Notices to view Software License information for Open Source Software.
Page 93
RED text, and
Document # 9301H52900 Ver. 1.02
