Setting / Control
Output Mapping
LCD Brightness
LCD Contrast
Update System
Software
USB Save/Restore
Access Control
System Info
More
4.8.1

Update System Software

There are two ways you can update your software. The first way is to connect to the servers at Datasat
Digital Entertainment to select and install the update. This requires that the RS20i is connected to the
Internet. The second way is to install the update from a USB Device. Both methods are described in
more detail below.
Setup > Update
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Description
Standard 16 Ch Out – Standard output channel assignments.
Copy Ch 1-8 to Ch 9-16 – The output of channels 1 through 8 will be copied
to output channels 9 through 16 for both the Analog output connector and
Digital output connector. Output channels 9-16 are not assignable if this
option is used.
Select the Brightness button and use the Volume Control knob to adjust the
brightness of your touch screen, 0.5 to 10.0.
Select the Contrast button and use the Volume Control knob to adjust the
contrast of your touch screen, 0.5 to 2.5.
Update the processor software via the internet. See 4.8.1 Update System
Software, page 87.
Save and restore configurations through the USB interface. See 4.8.2 USB
Save/Restore, page 89.
Assign password protections. See Access Control, page 91.
View system information and a log file of system messages. See 4.8.4 System
Info, page 92.
Touch the More button to view the second System Setup screen. See 4.9
System Setup (2), page 94.
Figure 55. System Update Screen
Page 87
Document # 9301H52900 Ver. 1.02
