Table 25. Speaker Filter
Control
Chan nn
-
+
Pink Noise On/Off
Filters
Enabled/Disabled
Constant Q/BW
Filter 1-9
Freq (Hz)
Q
Gain

4.6 Bass Management Setup

This section describes how to configure the bass management on the RS20i using the Setup screens.
This assumes that you are familiar with the RS20i bass management features and concepts. If not, you
are encouraged to review topic 4.7.3, Bass Management Theory (page 83) before proceeding with the
setup.
The Bass Management configuration, including the Speaker Configuration, is contained within an Output
Preset configuration of the RS20i. The configuration changes made in this screen are applied to the
currently selected Output Preset. Separate Output Presets can be made with different Bass Management
and Speaker Configuration settings.
Bass management balances the bass portion of the audio system based on the speaker configuration.
Sub-bass configurations vary from none up to 4 subwoofers.
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Description
Channel selection
- previous channel
+ next channel
Channel pink noise.
Enable or Disable all PEQ filters for all channels.
Constant Q or constant bandwidth.
Select filter 1 to 9 to set the filter parameters.
Filter Frequency: 20Hz to 20kHz.
Filter Q: 0.1 to 10.0.
Filter Gain: -60dB to 12.0dB.
Page 73
Document # 9301H52900 Ver. 1.02
