3.1 Example: Creating an Input Preset

Once the RS20i is installed, you need to make sure that Input Presets have been assigned for each of the
input sources required by your system. The RS20i ships with a set of pre-built Input Presets that are
ready to use. To create user-defined Input Presets for other input sources required by your system, use
the RS20i setup menus. This section gives a brief introductory example of how to create an Input Preset.
Detailed explanation of the Input Preset as well as all RS20i configuration items is given in the next
section, about Setup Menus.
Prior to creating an input, it is necessary to identify the following:
•
Input source
•
Input options
•
EQ set up - Name
•
Output preset - Name
The following example describes how to create "stereo 2" input, with stereo input, stereo level gain of 1.0
dB, global delay of 0 ms, assignment of EQ and output preset.
1. Open the Input Setup screen by selecting "Inputs".
Setup > Inputs
2. Next select Edit Input Presets. The Edit Input Presets screen displays.
3. On the left side choose the Copy Input Preset radio button.
4. Under Copy, select Stereo1.
5. Touch the blank box under to. A keyboard will appear.
Type in Stereo2, then select OK. The Edit Input Presets screen will return.
6. Touch the Copy button.
The screen will now change to Input Setup.
7. Select Assign Buttons and the Input Button Assignments screen will display. Select an unused
button number from the Buttons drop down menu. In this example select button 3.
8. Next from the Assign drop down list, select Stereo 2. Then touch the Assign button on the right
side of the screen. In the Current Assignments listing on the screen, Button 3 will now be
assigned to Stereo 2.
9. At the bottom of the screen, touch the Back button to return to the Input Preset screen.
10. Select the Input Source button. This will open the Input Select screen.
The right side of the screen should display "Current Input: Stereo2".
If it is not displayed, return to the Input Setup screen by selecting the Input button and selecting
Stereo 2 in the Current Input drop down menu. Return to the Input Select screen by touching
the Input Source button.
11. In the Analog input section, touch the Stereo1 L/R option to change it to Stereo2 L/R. Then
touch the Back button to return to the Input Preset screen.
12. In the Input Setup screen, select the Input Options button to go to the Input Options screen.
13. In the Input Options screen, you can (if necessary) set the Global Delay for the selected input.
Select the Global Delay and Surround Offset button. Select the Global audio delay button
and turn the knob to increase or decrease the delay. Then touch the Back button to return to the
Input Preset screen.
14. Select the Stereo Level button to change input gain on Left and Right to 1.0 dB. Select the L or
R button and turn the knob to increase or decrease the gain.
Touch the Back button to return to the Input Preset Setup screen.
