Installation and Set Up

This part of the manual contains information the installer needs to set up and configure the
RS20i Audio Processor. Refer to the Important Safety Instructions, page 20.

2.1 Unpacking System Components

The packaging is designed to handle normal shipping and handling. Upon receipt of shipment,
check for signs of damage before opening and report all damage to the carrier. All shipments
made from Datasat Digital Entertainment are the customer's responsibility once they leave our
premises.
Before installation begins, we suggest that a complete inventory be taken to minimize problems
or questions during installation.
Important: Save all packing material. A unit that is returned to the factory must be in its
original packing to provide effective protection to the unit. Failure to do so may void
your warranty.
Note: Refer to the actual packing slip from your order to verify the contents of your
shipment. Contact Datasat Digital Entertainment immediately if items listed on your
packing slip are missing.
The following is a standard packing list for the RS20i Audio Processor. The exact contents may vary,
depending on the options you have ordered.
Table 2. RS20i Standard Packing Kit
Item Key Item Description
2501000100 Power cord, North American/Taiwan (Note: International power cords
may also be included, as needed)
9003E11901 Rack screw kit, Truss head screw & washer
9003H56400 Fuse kit, RS20i 115V
9003H56401 Fuse kit, RS20i 230V
9120H56000 Rack ear, RS20i
9022H51901 Cable assembly, DB25 to XLR Analog Audio Output
9303H561M0 Tech note, RS20i Input voltage setting and fuse replacement
9331H71600 RS20i Document disc (includes Installation/Operation manual and other
documents)
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Page 19
Document # 9301H52900 Ver. 1.02
Qty
1
1
1
1
2
2
1
1
