Speaker Options Configuration Screen - Datasat RS20i Installation And Operating Manual

Subwoofer Configuration
The subwoofer configuration option configures the bass management with the number of sub-woofer
channels between 0 and 4.
Table 27. Subwoofer Configuration Options
Subwoofer Configuration Options
No Subs
Mono
LFront/RFront
Front/Back
LFront/RFront/Back
LFront/RFront
LBack/RBack
4.6.1

Speaker Options Configuration Screen

Each speaker or speaker pair can be individually configured in Bass Management by selecting the
speaker icon on the Bass Management screen.
Any Left/Right paired speakers share the same settings, so the configuration needs to be set only on one
of the two. For example, when the Left Front speaker is configured, the Right Front speaker will use that
configuration. Speaker pairs that share configurations are L/R, Ls/Rs, Lb/Rb, HL/HR, HLs/HRs, Lb/Rb,
and Lw/Rw.
Each speaker or speaker pair may display a different set of options. Figure 51 shows Bass Management
Center Speaker Options for a configuration with Subwoofers. Touch the icon of the Center Speaker, in
the Bass Management Setup screen, to access this screen.
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Number of
Subwoofers
0
1 to 4
2
2
3
4
Subwoofer Channel Assignments
None
Ch4, Ch13, Ch14, Ch15
Ch4 - Left Front
Ch13 - Right Front
Ch4 - Front
Ch13 - Back
Ch4 - Left Front
Ch13 - Right Front
Ch14 - Back
Ch4 - Left Front
Ch13 - Right Front
Ch14 - Left Back
Ch15 - Right Back
Note: This option is not available for
speaker configurations with HC (Auro11.1
or Auro13.1).
